Maintronic XRD600 REG User manual

XRD600 REG
DMX-Retrot-Dimmer
Item.No. 10.252 - XRD600 REG
Valid from Version: Hardware: H2 Firmware: F2.2.0
Document Date: 07.04.2020
Document: 10252_MA_en_A4_XRD600REG
Manual

Manual XRD600 REG English
2
Table of contents
1. Safety instrucons 3
2. Introducon 4
2.1 Thanks a lot 4
2.2 About this Document 4
2.3 Contact 4
2.4 Legals 4
2.5 Disclaimer 4
2.6 Return consignment 4
3. Device properes 5
3.1 Intended use 5
3.2 Funcons and features 5
4. Models 6
4.1 XRD600 REG (top-hat rail) 6
5. Comissioning 8
5.1 Measuring procedure (AdapvDIM) 8
5.2 Power rang of retrot dimmers 8
6. Operaon via buons 9
6.1 Device buon 9
6.2 Push buon input - Universal voltage input 9
6.3 Funcons push buon operaon: 9
6.4 Set Min-level push buon 10
6.5 Commissioning and diagnosis 11
7. Start new measument with the device buon 12
8. Operaon via DMX 13
8.1 Preparaon 13
8.2 Assign DMX start address 14
8.3 DMX parameters 15
8.4 Operang notes 16
8.5 Excerpt from technical data 16
8.6 LED indicator 17
8.7 Appendix - Symbols 17

www.maintronic.de [e-mail] 3
1. Safety instrucons
Aenon
For your own safety, read all instrucons and infor-
maon in this manual carefully before inial ope-
raon. Keep this manual for future reference.
The instrucons are an integral part of the product
and must be handed to the end customer.
All informaon and instrucons in this manual
must be observed completely and in detail. The
manufactuer is not responsible for any direct or
consequenal damage that results from disregar-
ding any informaon in this manual.
Waste disposal
In accordance with European Direcve 2002/96/
EC (it`s) not longer usable electronic devices and
defecve or used baeries (European Direcve
2006/66EG)
must collected separately and disposed by an envi-
ronmentally sound recycling.
This symbol indicates that electrical and electronic
equipment must be disposed of separately from
normal waste at the end of its operaonal lifeme.
Should these product are no longer be useable,
the user is required by law to dispose of old ap-
pliances separately from their household waste e.
g. at a local authority collecon point or recycling
center.
CE-marking
At the me of placing the devices on the market,
they comply with the EU direcves in the version
valid for the respecve device. Declaraons of
conformity are available for all products.
The CE marking is marked on the devices and is
shown in the applicable documents.
Danger
The interior and the connectors of the amplier
holds hazardous voltages.
The unit must only be installed and serviced by a
proven electrican specialist, in accordance of all
relevant regulaons, safety and accident preven-
on direcves of the country.
Be sure that the exisng mains voltage corres-
ponds with the specied operang voltage before
operang the device.
Risk of electric shock. Do not operate the device
without a cover. Even when switched o, voltage
may be present at the outputs. When working on
the device or connected loads, always disconnect
the upstream fuse from the power supply.
Only install the device in places with a good ven-
laon and without humidity or high temperatu-
res. Do not expose the unit to rain or snow. Do not
operate the unit near heat sources, e.g. radiators.
Do not open the device. Otherwise you will risk a
damage and void the warranty.
The unit should be serviced by qualied personnel
when the unit:
• objects have fallen or liquid has been spilled
into the unit
• does not appear to operate normally
• has been dropped or has a broken housing
For cleaning only use a dry, so cloth, by no means
liquids.

Manual XRD600 REG English
4
2. Introducon
2.5 Disclaimer
The contents of this document are for product in-
formaon purposes only. Features of the products
may be diering during the connuous product
development and may be changed by maintronic
at any me without noce.
maintronic does not assume any liability or war-
ranty concerning this manual or the described pro-
ducts.
2.6 Return consignment
You can nd a return form on our homepage in
the service secon. Please ll out the return form
with a detailed error descripon and aach the
purchase receipt. Our product must be returned
well packed in a package.
2.1 Thanks a lot
Congratulaons and thank you for choosing this
maintronic product and the trust you have placed
in us. We, the team of maintronic, wish you a lot of
fun with this product.
2.2 About this Document
Due to connuous product development, some of
the informaon may not be complete and up-to-
date.
The informaon in this document is subject to
change without prior noce. Please check our
website www.maintronic.de, if there is a newer
version.
2.3 Contact
You can nd downloads, manuals, onlinehelp as
well as frequently asked quesons (FAQ) on our
Website www.maintronic.de. Please contact us,
should any problems regarding your product arise.
2.4 Legals
The division building automaon and all associ-
ated products are products of MTC maintronic®
GmbH (hereaer maintronic). All rights reserved,
as well as mistakes and typing errors.
The trademarks and trade names menoned in
this document are the property of their respecve
owners.

www.maintronic.de [e-mail] 5
3. Device properes
3.1 Intended use
One-channel phase dimmer for brightness control
of R,L,C including LED retrot loads. Operates as
a digital leading and trailing edge phase dimmer
with automac load detecon.
Please use this product only for its intended pur-
pose:
• As a dimmer for switching and dimming lumi-
naires
• Solid in dry and clean environment
• Only approved for indoor use
• Installaon in switch cabinets top-hat rail, in a
juncon box with insulated enclosure
• Access is only possible with tools
• Only operate on 1 phase with 230V AC
• With a back-up fuse of max. 16A
3.2 Funcons and features
• DMX retrot-universal-dimmer
• Control via DMX / RDM or push buon input
• Load types: LED retrot, NV halogen lamps
with coiled or electronic transformers and
incandescent lamps
• Adapve dimming
• Manual min-level
• Load number display
• Zero load dimming
• So-O
• Fademe

Manual XRD600 REG English
6
4. Models
4.1 XRD600 REG (top-hat rail)
Module Item.No. Power Construcon
XRD600 REG 10.252 600W DIN rail housing (REG)
4.1.1. Housing dimensions
Rail-mounted device according to DIN 43 880 for
mounng on a top-hat rail in a switch cabinet (2TE
= 36mm), in a juncon box or small distributor (in-
sulated enclosure).
Top connecons (-X1)
L‘ 1Load output N 4 Neutral conductor
L 2 Input Voltage 230V AC T (-) 5Push buon input GND / N
N3Neutral conductor T (+) 6Push buon input 12...230V
Boom connecons (-X2)
+24V 7+24V DC DMX (+) 9DMX / DMX RDM Signal +
DMX (-) 8DMX/DMX RDM Signal - GND 10 -24V / DMX Shield
Operang elements and indicators
1Device buon Commissioning; Programming
2Status LED Display Status of the device
Fig. 1 - Housing dimensions and connecons
4.1.2. Connecons

www.maintronic.de [e-mail] 7
Fig. 3 - Connecon diagram with push buon 24 VDC
Fig. 2 - Connecon diagram with push buon 230 VAC
4.1.3. Connecon diagram

Manual XRD600 REG English
8
5. Comissioning
5.1 Measuring procedure
(AdapvDIM)
NOTE - During calibraon, the connected
lights may icker. This is system-condi-
oned and not a defect of the device. The
calibraon must be completed and can not
be interrupted by switching o the device.
The maximum load is possible up to an ambient
temperature of 50 ° C. Between 50 ° C and 70 ° C,
the power is reduced by 15 was / ° C, please con-
sider this during installaon.
5.2 Power rang of retrot dimmers
Load type cung method Power output in percent Calculated power load
Ohmic trailing edge approx. 100% of the rated power 600 VA
LED trailing edge approx. 70% of the rated power 420 VA
LED leading edge approx. 20% of the rated power 120 VA
As a rule:
Example 28x 4W (rated power LED) + 20% power factor = 135 VA power to be processed. Speci-
caons depend on the light source used and may vary upwards and downwards.
When starng up for the rst me (voltage is ap-
plied to the device for the rst me aer installa-
on), the dimmer will start a measuring procedure
and calibrate accordingly to the connected load.
For minor calibraon, the dimmer decides which
cung method ( leading or trailing edge) is used
and adjusts itself to load type 3 or 4.
Should a new calibraon be required by changing
the light source or to set a dierent load type, the
device must be recalibrated, for a new calibraon
see 7.

www.maintronic.de [e-mail] 9
6. Operaon via buons
6.1 Device buon 1
6.3 Funcons push buon operaon:
Max-Level 100% - When doub-
le-clicking 100%, the brightness
jumps to maximum 100%. The
previous dimming level will not
be overwrien and will be reac-
vated the next me it is switched
on. If the brightness is subse-
quently „lowered“ again with a
single keystroke, the previous
output brightness is restored.
So you can quickly switch from
a low level to full brightness and
back.
Last Memory Level - The last set
brightness level is saved and will
be recalled at next power up.
6.2 Push buon input
Universal voltage input
It is possible to operate and program the device via
the device buon.
NOTE - Operaon with the device buon
is only possible within the rst 60 minutes
aer Power-On and will be deacvated
aer 60 minutes.
The device is equipped with a push buon input
(T), on which standard 230V AC buons can be
connected. Both DC voltage (from 12V DC) or AC
voltage can be used on the push buon input.
The mains voltage will be used as alternang volta-
ge. No polarity has to be observed.
For DC voltage, the supply voltage of the DMX sig-
nal side (-X2) can be used. It is absolutely necessary
to pay aenon to the correct polarity. DC(+) must
be connected to terminal 6, DC(-) to terminal 5.

Manual XRD600 REG English
10
6.4 Set min-level with push buon
(Alternavely the min level can be congured via
DMX - see 9.3)
In case of a ickering load or if the load remains
too bright, the in-level (the lowest dimming value)
can be adjusted via a push buon connected to
the push buon input.
Perform the conguraon with the following
steps:

www.maintronic.de [e-mail] 11
6.5 Commissioning and diagnosis
Press device buon
twice briey
A single digit is dis-
played for the load type.
The number of lumi-
naires is displayed as a
two-digit number with
half brightness. For each
digit, the LED ashes/
blinks as many mes as
the value of the digit. For
the number 0, the LED
ashes/blinks longer.
6.5.1. Display load type
(currently used dimming mode)
Display load type Blinking paern
Status-LED 100%
Ohmic load (trailing edge)
Inducve load halo. (leading edge)
LED / CFL load (trailing edge)
LED / CFL load (leading edge)
Inducve load (leading edge)
Non-dimmable load
No load connected quick ashing
If the load used is not compable with the select-
ed dimming mode, the system switches to a com-
pable mode.
6.5.2. Determine load no. (max. number
of lamps of the same type)
In order to opmally use the dimmer and to see
how many luminaires of the same type can be
used, it is possible to determine the load number
of the luminaire. To do this, measure with a single
luminaire. Aer the measurement, the load type is
displayed and aerwards the load number is indi-
cated by the LED ashing.
Display Load No.
value as
number
Flashing paern with half brightness - Load No.
10 ---------
1x short; pause; 1x long for 0
35 ----------- - - - -
3x short; pause; and 5x short
NOTE - A load number is only available for
load type LED.
The integrated load number display is a
recommendaon and helps to determine
the maximum number of lamps.
The device buon can be used to display the
current dimming mode (load type) and the load
number (max. Luminaires of the same type).

Manual XRD600 REG English
12
7. Start new measument with the device buon
To acvate, release the buon within these 2 sec-
onds, a ashing paern follows and the parameter
will be processed. If the buon is released outside
this 2 sec. window, the programming will be ter-
minated.
Parameter Load / Funcon Features
1any load
Automac calibraon - the load type is determined automacally, dimming
parameters are set automacally and the dimming curve is adjusted to achie-
ve the best possible dimming result
Dimmmode
2
; Dimming curve (linear characterisc)
3 * ; Dimming curve (xed LED curve) * Factory seng
4
; Dimming curve (automac)
5
; Dimming curve (xed)
6corridor mode
7Reset reset to factory default sengs
Select a parameter from below table.
To leave a set corridor mode, it is necessary to perform
a factory reset.
Programming must be done within the
rst 60min aer power-on.
The key must be released within the acve
phase for each parameter (as long as the
LED is on).
Some situaons may require a re-measuring of
the dimmer, e.g. if the load is changed or the load
type is modied. To start programming, press and
hold the device buon or push buon .
Aer 20 sec. the programming mode starts (LED
and load turns o), each parameter is indicated
by a ashing of the LED and load for 2 seconds.

www.maintronic.de [e-mail] 13
8. Operaon via DMX
8.1 Preparaon
According to the DMX standard, no more than 32
DMX devices (with separate power supply) should
be connected to a DMX signal. Then the DMX sig-
nal must be amplied with a repeater. To supply
the bus, a supply voltage of 12 - 24V DC must be
present (current consumpon per module <7mA).
If your controller has a masterfader or overall vo-
lume control, make sure that the DMX value 255
(Max. Level) is adjustable, otherwise no program-
ming can be performed.
A value from 1 to 512 can be assigned as start
address. In the delivery state, the start address (of
the device) is preset to 1. The module uses one
DMX channel.
For example, perform a factory reset:
Press one of the two buons (device buon
or push buon , aer 20 seconds the LED il-
luminates for 2 seconds, which shows phase 1.
Hold the buon pressed in, phase 6 is followed by
a slightly longer pause unl phase 7 is acvated.
During these 2 seconds of the acvated phase the
push buon must be released.
The dimmer is now reset to the factory sengs.
To operate a device with DMX, a DMX512 control-
ler is required. A gateway can also be used to crea-
te an interface to other protocols such as KNX...
A supply voltage of 24V DC must be available (cur-
rent consumpon per module <7mA). Within the
DMX protocol, a correct clamping of the signal line
with + 24V and -GND must be ensured.
NOTE - Before operang the dimmer, it is
necessary to send a DMX signal once. As
long as the DMX input is used (DMX signal
is transmied), the device buon and
push buon inputs are not acve. One se-
cond aer the last DMX signal has been
received, the buon inputs are reacvated
again.

Manual XRD600 REG English
14
8.2 Assign DMX start address
NOTE - Programming must be done within
the rst 60min aer power-on.
• Press the device buon> 2 seconds ... (load
jumps to 0 and 100% for half a second each),
then the LED ashes consistently.
• At the desired start address (1-512) briey set
or fade the value to 251-255 (full on) and set
to 0 (full o) again.
• The dimmer accepts this channel as a new
DMX start address. This is indicated by two
long ashes of the LED and possibly connected
lights go to 100% brightness for about one
second. Aerwards, the programming mode is
exited.
NOTE - If the programming does not take
place aer 10 minutes, the programming
mode will be exited and the device is back
in normal operaon.
The module can display the currently con-
gured DMX address via the LED To do
this, press the device buon 3 mes in
succession. The address is displayed as a
digit, for each digit the LED ashes as oen
as the value of the digit is. For the digit 0
the LED ashes long.

www.maintronic.de [e-mail] 15
8.3 DMX parameters
Some system parameters can be programmed
via DMX telegrams. In this case, a separate DMX
address is used for each parameter. The addresses
have the same values as the parameter IDs (1 - 7).
The appropriate parameter selecon during pro-
gramming determines which parameter should be
programmed.
NOTE - Programming must be done within
the rst 60min aer power-on.
1. Press the device buon > 2 seconds ... (load
jumps to 0 and 100% for half a second each),
then the LED ashes consistently.
2. Select the desired parameter by pressing the
buon again. Again a parameter change is in-
dicated by the output level 0 and 100% (as at
start). The ashing paern is then indicated by
a long light followed by a brief ash of the LED.
3. Set the fader of the desired parameter:
4. To save, press the device buon > 1 second ...
(load jumps to 100%, 7%, 100% for half a sec-
ond each), then the LED ashes consistently.
NOTE - If the programming does not take
place aer 10 minutes, the programming
mode will be exited and the device is back
in normal operaon.

Manual XRD600 REG English
16
8.5 Excerpt from technical data
Rated Voltage
Connected Load
Power loss Standby - 0,75W; Operaon at full load - 1,8W
DMX512 / DMX RDM 1 DMX channel; power supply via external power supply unit
12 - 24V DC is required
parallel connecon of modules possible
Alternave Ansteuerung Push buon input
(Universal voltage)
12...230V AC oder DC
Detailed technical data can be found in the data sheet of the product.
8.4 Operang notes
8.4.3. Noise emission
It may occur that the dimmers cause acousc noi-
se when they are not used under unfavourable
condions or with certain consumers.
Make sure the phases are evenly balanced.
8.4.4. Flickering
The dimmer requires a faultless mains, ickering
may occur in case of mains supply uctuaons or
ripple control signals as well as during calibraon.
This circumstance is system related and not a de-
fect of the device.
8.4.1. Derang
In the event of over temperature, an automac
derang occurs (status derang is indicated by the
LED), which means that the dimmer‘s power is re-
duced and the load dimmed down.
8.4.2. Short circuit
Automac shutdown in the event of a short circuit.
Every 30 sec. it is tested whether the short circuit
is sll present. As soon as the short circuit is eli-
minated, an automac restart takes place. If the
error is sll present aer 5 min, the device is swit-
ched o completely.
Turn o the power and remove the error.

www.maintronic.de [e-mail] 17
8.7 Appendix - Symbols
Symbols / legend
Connected load
ON = full brightness
Connected load
dimmed
Connected load
OFF = O
Device LED
ON = full brightness
Device LED
LED - dimmed
Device LED
OFF = O
Load type with leading edge
Load type with trailing edge
Device buon
External push buon input
Time for a key press
in this case, press the buon for more than 2 sec.
8.6 LED indicator
Operang states are indicated over the LED.
Status LED indicators Blinking paern approx. 3 sec.
0s 1,5s 3s
Modulstart INIT OOOOOOOOOO----------
Once when applying the operang voltage
Standby O-------------------
During operaon with switched o channel
Output Switched On OOOOOOOOOOOOOOOOOOOO
Switched on, the brightness of the LED depends on the output level
Receive bus event O-O-----------------
DMX-telegram received
Operaon via push buon input OOOO-OO-------------
DMX input buon is pressed, mains voltage is present
Programming mode OOOOO-----OOOOO-----
DMX idencaon display; ready for load calibraon
Error 1 O-O-O-O-O-O---O-----
Switching o outputs due to overload.
Error 2 O-O-O-O-O-O---O-O---
Reducon of output level due to overload.
Fatal Error O-O-O-O-O-O-O-O-O-O-
Shutdown due to overload or overtemperature
Measuring procedure O--O--O--O--O--O--O-
Performing calibraon with dimming mode
Corridor funcon acvated OOOOOOOO--OOOOOOOO--
If the corridor mode is acvated

Carl-Zeiss-Str. 10-14
97424 Schweinfurt / Germany
Tel. [phone]
Fax. [phone]
www.maintronic.de
inf[email protected]
