Clevertronics ECFLED-LI Installation and operating instructions

Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24 hours. Conduct
the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 hours after disconnection from the mains
supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are required to be
recorded in a service logbook, which is to be kept on-site at all times. If the unit fails to remain illuminated for the
requisite time, remedial action must be taken to repair the situation and once completed, the unit must pass a
subsequent test. For more specific information, please refer to the current edition of the AS 2293.3 Standard.
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Fault: Green LED flashes once every 5 seconds-Battery is disconnected
Check: Battery is connected.
Fault: Green LED blinks off once every 5 seconds- Charging very flat battery
Allow 20min to recover battery then recheck
Fault: Green LED flashes at 2Hz (Fast flash)- Faulty battery
Replace battery
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during construction. As a
result, any Exit & Emergency Units, on these circuits, will have their batteries discharged or “cycled”. The Lithium battery
in this fitting has been selected to give excellent long life performance in a controlled AS2293 testing environment.
Excessive battery cycling will reduce through-life performance and may lead to premature battery failure. Battery warranty
claims, as a result of such abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Victoria (Head Office & Manufacturing)
195 Chesterville Rd
Moorabbin VIC 3189
Phone: [phone]
Fax: [phone]
News South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
ECFLED-LI
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the requirements
of the AS/NZS2293.3:2005
Models:
ECFLED-LI Economy Lithium Cleverfit LED Exit
Spare Parts:
1550195 –EcoLi,3.2V 600mAh 210mm lead,noBRKT
8002900 –PCA: LED Strip ECFLED-LI CT10242-D1
8002880 –PCA: Driver ECOLITH Cleverfit CT10240-L4
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before
installation, ensure that the electricity supply has been switched off and isolated. Installation must be
carried out in accordance with the relevant Australian and International Standards.
1942250 V1.1 March 2019

Images and Dimensions
Installation:
The Economy Lithium Cleverfit LED Exit (ECFLED-LI) can be installed either Ceiling or Wall Mounted and
can be mounted perpendicular to a wall using the (optional) Cleverfit Cantilever Bracket. The ECFLED uses
a “slide connect bracket base” that is mounted and wired into position first. The main body can be installed
once the base is wired or later to avoid damage during the construction phase. Please follow the steps
below to install the Cleverfit Exit:
•Disengage the slide connect bracket from the exit body. Position the base in the mounting position.
•Using the bracket as a guide, mark 2 holes for mounting and one for mains access. Then install the
bracket using appropriate fixings (not supplied).
•Connect the 240VAC supply to the mounting bracket.
•Configure allthe mounting parts and cable entry points as below (if required) and engage the body into
the slide connect bracket. Apply mains power and check that the Cleverfit Exit is operational.
Cleverfit Maintenance:
Lamp Replacement:
•Use only the lamp(s) recommended on the label inside the Cleverfit.
•To replace the lamp bar, remove the self-tapping screws, disconnect the signal cable and install
the new lamp bar.
•
*Please note that the 50,000 hour LED Lamp Bar used in the Cleverfit Exit does not suffer from burn
out. Lamp replacement can be done as scheduled maintenance, at >5 year intervals. Please make a
note, in the site logbook, as to when lamps should be changed.
Battery Replacement:
•Use only the battery recommended on the label inside the Cleverfit and on this instruction.
•Remove the screw securing the fitting to the mounting bracket.
•Remove the fitting from the bracket by sliding it forward.
•The battery is located in the top of the fitting. See images.
•Remove the clip holding the battery.
•Unplug the battery from the PCA and remove it.
•Insert the new battery into the holder, route the DC cable to the PCA and plug the new battery
into the connector.
•Secure the battery using clip.
Changing Exit Legend Inserts:
The Cleverfit Exit uses Clevertronics patented “Tamper proof” Exit legend cover and comes
complete with spare legend inserts to enable straight on, left or right arrow as well as SS/DS
combinations.
To change an Exit legend insert first remove the diffuser. The clear tamper proof cover is held in
place by 3 locking tabs in the top inside area of the diffuser. Use a tool to disengage and push
the locking tabs through to release the cover and remove the insert, replacing it with the desired
one. When double sided is required remove the cardboard insert from the second side when
adding decal.
To re-install the clear cover, first engage the 3 small lugs on the bottom of the cover into their
respective recesses in the diffuser. Once sure the lugs are located, and then the 2 side lugs,
carefully push the 3 locking tabs back in, to complete the process.
Cable Entry Point –Top of
bracket for ceiling mount,
20mm diameter, located in
centre of bracket.
Mounting Bracket - front view
Wall Mount screw
fixing point
Wall Mount screw
fixing point
Cable Entry Point –Rear of bracket for wall mount, 20mm
diameter, located in centre of bracket. Note: Bracket shown
from front with the terminal block cover removed.
Mounting Bracket –top view
Cable Entry Point –Rear of bracket for wall mount, 20mm
diameter, located in centre of bracket Note: Bracket only
shown from front with the terminal block cover removed.
Ceiling mount -
screw fixing points.
(Same other side)
250
Battery PCA
Fitting Top View
