Mairdi M800BTD User manual

Wireless Communication Headset
USER GUIDE

Specifications
Pairing Name: M800BTD
Bluetooth Specification:CSR8635. V4.1,dual mode, downward compatible.
Frequency Range: 2402-2480MHz
Modulation: GFSK,π/4 DQPSK, 8DPSK
Two Bluetooth devices can be connected at the same time.
Transmission Distance: up to 20 meters (Transmission distance varies depending on the
environment and Bluetooth device)
Maximum Talk Time: 12 hours
Standby Time: 250 hours
Speaker:
Resistance: 32 ohms
Frequency: 20Hz-20KHz, Hi-fi
Sensitivity: 115dB±3dB
Distortion:≦1%
Microphone:
Microphone: Noise Canceling
Sensitivity: -38dB±3dB
Crystal clear sound and voice (DSP)
Headset Battery:
Type: Lithium-ion polymer
Capacity:145mA per hour stand
Battery Capacity: 150mAh
Charging Voltage: 5V DC
Life Time: Minimum recharging 1000 times
Operating Temperature: -10℃ to +60℃
Charging Time: 2 hours
Charging interface: Micro USB
Charging Base
Size:74.7*74.7*52mm Net Weight:105g
Net Weight:
M800BT Mono 46.5g M800BT Duo 58.2g
LED Indicator
（Battery, Pairing,Call status）
Multi-function button
( Answer, Hang up, Pause
and Play)
Plus button
(Volume up,Next song,
Mic mute)
Minus button
(Volume down,Last song)
Noise canceling Microphone On/Off button
(Power on,Power off)

Pairing with Bluetooth Device
1. Be sure that your smart phone, laptop or desk phone with Bluetooth function.
2. Activate the Bluetooth function on your smart phone, laptop or desk phone.
3. Turn on your headset (slide switch to icon “ ”), you can hear prompt tone” power on”.
The Led indicator will flash red and blue alternately, which indicates the headset is in
pairing mode.
4. (If pairing fails, the headset will power off automatically after indicator flashes 5mins, with
prompt tone “power off” heard.)
5. Pair headset to your smart phone, laptop or desk phone.
1) Search Bluetooth device on your smart phone, laptop or desk phone.
2) Open “Bluetooth” menu and press “discover” or “add” to search M800BTon your
smart phone, laptop or desk phone.
3) When M800BT shows on your Bluetooth devices list, please click it to start pairing.
Prompt tone “connect” will be heard when pairing is successful, and the LED indicator will
repeatedly flash blue every 5 seconds.
4) The second time to use this headset on your Bluetooth device, it will pair with your
Bluetooth device automatically when turn on the headset and Bluetooth device.
Button Function:
Button Function Action
On/Off Button
Headset on Slide switch to icon “ ”
Headset off Slide switch to icon “off”
Plus Button
Volume up Tap the Plus button to increase
the speaker volume
Next song Long press the Plus button to
switch to next song when
playing music
Mic mute Long press the Plus button for 2
seconds to activate mic mute
during a call, repress the Plus
button for 2 seconds to cancel
mic mute.
Minus Button
Volume down Tap the Minus button to
decrease the speaker volume
Last song Long press the Minus button to
switch to last song when playing
music
Multi-function Button
Pause Tap the Multi-function button
when playing music
Answer /end call Tap the Multi-function button
Reject call Long press the Multi-function
button for 2 seconds.

Headset LED Indicators
Headset Status LED Status
Pairing Mode Light flashes blue and red alternately
Pairing Successfully Light flashes blue repeatedly every 5 seconds
Battery Low Light flashes red continuously
Charging Mode Red light continuously on
Fully Charged Blue light continuously on
Prompt Tone Introduction
Headset Status Tone
Power on Power on
Power off Power off
Pairing Successfully Connect
Volume up/down “toot”
Battery Low “toot” every 5 minutes
Mic Mute “toot” every 3 seconds
Function Introduction:
1. Pair with 2 devices simultaneously
M800BTD can pair with 2 devices simultaneously.
1) Connect the first device with M800BTD
2) Turn off the Bluetooth function of the first device
3) Connect the second device with M800BTD
4) Turn on the first device’s Bluetooth function, then M800BT is paired with both devices.
2. Redial function
Quick press the multi-function button twice to redial the last call.
3. One-touch play function
Press the multi-function button once, the default music player of the mobile phone will
play automatically (some mobile phones cannot implement this function).
4. Automatic re-connection function
Bluetooth connection can be automatically re-connected even if disconnected within 5
minutes in the effective distance. If reconnect fails, please turn off the headset and turn it
on again to reconnect.
5. Mic mute function
Long press the plus button for 2 seconds to activate mic mute during a call, repress the
plus button for 2 seconds to cancel mic mute. The tone “toot” will be heard every 3 seconds
during mic mute status.

Cautions:
1. Most mobile phones have headset power on screen display. When headset battery low,
the headset will beep and the indicator will turn red. Please charge it in time.
2. Do not connect the charged headset to the charging circuit for a long time. Overcharging
will shorten battery life.
3. Please keep the headset battery safely. Do not put the battery or the headset into fire or
water to avoid explosion.
4. Do not use headset with high volume for extra long time, which may cause hearing loss.
Always listen at a moderate level.
5. Do not connect the high voltage device to charge, which may cause damage to the
headset.
6. Make sure that the headset is fully charged before using it if long time no use.
7. Lifetime of the battery will be significantly reduced if your device is left
uncharged for a long time. We therefore recommend that you recharge your device at least
once a year.
Product Warranty Card
Customer Name Product Model No.
Date of Purchase Tel No./E-mail:
Problem Description:
Microphone Speaker Battery Buttons
Warranty:
Failure of headset buttons, speaker or microphone; charge unavailable.
Out of Warranty:
1. Ear cushions broken.
2. Fail to follow the user manual or disassemble the headset.
3. Incorrect connect with high voltage device for charging which causes earphone damage.
4. Artificial damage caused by impact, falling, water, pulling.
OQC
CHECKING
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Warning
Any Changes expressly or modifications not approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired
operation.
