Makita DVR350 User manual

GB Cordless Concrete Vibrator Instruction Manual
F Vibrateur à béton sans-fil Manuel d’instructions
D Akku-Betonverdichter Betriebsanleitung
I Vibratore del cemento a batteria Istruzioni per l’uso
NL Accu-trilnaald Gebruiksaanwijzing
E Vibrador de hormigón a batería Manual de instrucciones
P Vibrador para cimento a bateria Manual de instruções
DK Akku betonvibrator Brugsanvisning
GR Δονητής αναμχλευσης μπαταρίας Οδηγίες χρήσεως
DVR340
DVR350
DVR440
DVR450
DVR850

2
12
3
4
5
8
7
3
4
5
6
1
2

3
END003-2
Symbols
The followings show the symbols used for the equipment. Be sure that you understand their meaning before use.
Symboles
Nous donnons ci-dessous les symboles utilisés pour l’outil. Assurez-vous que vous en avez bien compris la significa-
tion avant d’utiliser l’outil.
Symbole
Die folgenden Symbole werden für die Maschine verwendet. Machen Sie sich vor der Benutzung unbedingt mit ihrer
Bedeutung vertraut.
Simboli
Per questo utensile vengono usati i simboli seguenti. Bisogna capire il loro significato prima di usare l’utensile.
Symbolen
Voor dit gereedschap worden de volgende symbolen gebruikt. Zorg ervoor dat u de betekenis van deze symbolen
begrijpt alvorens het gereedschap te gebruiken.
Símbolos
A continuación se muestran los símbolos utilizados con esta herramienta. Asegúrese de que entiende su significado
antes de usarla.
Símbolos
O seguinte mostra os símbolos utilizados para a ferramenta. Certifique-se de que compreende o seu significado antes
da utilização.
Symboler
Nedenstående symboler er anvendt i forbindelse med denne maskine. Vær sikker på, at De har forstået symbolernes
betydning, før maskinen anvendes.
Σύμβολα
Τα ακλουθα δείχνουν τα σύμβολα που χρησιμοποιούνται για το μηχάνημα. Βεβαιωθείτε τι καταλαβαίνετε
τη σημασία τους πριν απ τη χρήση.
• Do not use the tool in the rain. • No utilice la herramienta bajo la lluvia.
• N’utilisez pas l’outil sous la pluie. • Não utilize a ferramenta à chuva.
• Benutzen Sie das Werkzeug nicht bei Regen. • Anvend ikke maskinen i regn.
• Non usare l’utensile sotto la pioggia. • Μη χρησιμοποιείτε το εργαλείο στη
βροχή.
• Gebruik het gereedschap niet in de regen.
• Do not clean the tool with water. • No limpie la herramienta con agua.
• Ne nettoyez pas l’outil avec de l’eau. • Não limpe a ferramenta com água.
• Reinigen Sie das Werkzeug nicht mit Wasser. • Rengør ikke maskinen med vand.
• Non pulire l’utensile con acqua. • Μη καθαρίζετε το εργαλείο με νερ.
• Maak het gereedschap niet met water schoon.
• Only for EU countries
Do not dispose of electric equipment or battery pack together with household waste material!
In observance of European Directive 2002/96/EC on waste electric and electronic equipment,
2006/66/EC on batteries and accumulators and waste batteries and accumulators and their
implementation in accordance with national laws, electric equipment and battery pack that have
reached the end of their life must be collected separately and returned to an environmentally
compatible recycling facility.
• Uniquement pour les pays de l’UE
Ne pas jeter les appareils électriques et les batteries avec les ordures ménagères !
Conformément aux directives européennes 2002/96/CE (relative aux déchets d’équipements
électriques et électroniques) et 2006/66/CE (relative aux piles et accumulateurs ainsi qu’aux
déchets de piles et accumulateurs), ainsi qu’à leur application en conformité avec les lois nation-
ales, les appareils électriques et batteries qui ont atteint la fin de leur durée de service doivent
être collectés séparément et renvoyés à un établissement de recyclage respectueux de l’environ-
nement.
• Nur für EG-Länder
Werfen Sie Elektrogeräte oder Akkus nicht in den Hausmüll!
Gemäß der Europäischen Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte, 2006/66/
EG über Batterien, Akkus sowie verbrauchte Batterien und Akkus und ihre Umsetzung gemäß
den Landesgesetzen müssen Elektrogeräte und Akkus, die das Ende ihrer Lebensdauer erreicht
haben, getrennt gesammelt und einer umweltgerechten Recycling-Einrichtung zugeführt werden.
Cd
Ni-MH
Li-ion

4
• Soltanto per i Paesi dell’unione europea
Questo apparecchio elettrico o la batteria non devono essere gettati via con i rifiuti domestici.
In osservanza alla Direttiva Europea 2002/96/CE sugli apparecchi elettrici ed elettronici di scarto,
2006/66/CE sulle batterie e gli accumulatori, e sulle batterie e gli accumulatori esausti, e la sua
implementazione secondo le leggi locali, gli apparecchi elettrici e le batterie che hanno raggiunto
la fine della loro vita di servizio devono essere raccolti separatamente e portati in un centro di
smaltimento ecocompatibile.
• Alleen voor EU-landen
Geef elektrisch gereedschap of accu’s niet met het huisvuil mee!
Volgens de Europese richtlijn 2002/96/EC inzake oude elektrische en elektronische apparaten,
richtlijn 2006/66/EC inzake batterijen en accu’s en wegwerpbatterijen, en de toepassing daarvan
binnen de nationale wetgeving, dienen gebruikte elektrisch apparaten en accu’s die het einde van
hun levensduur hebben bereikt, gescheiden te worden ingezameld en te worden afgevoerd naar
een recyclebedrijf dat voldoet aan de geldende milieu-eisen.
• Sólo para países de la Unión Europea
¡No tire aparatos eléctricos ni baterías a la basura con los residuos domésticos!
En conformidad con la Directiva Europea 2002/96/EC sobre residuos de aparatos eléctricos y
electrónicos y la Directiva Europea 2006/66/EC sobre baterías y acumuladores y residuos de
baterías y de acumuladores y su aplicación de acuerdo con la legislación nacional, los aparatos
eléctricos y las baterías cuya vida útil haya llegado a su fin se deberán recoger por separado y
trasladar a una planta de reciclaje que cumpla con las exigencias ecológicas.
• Apenas para os países da União Européia
Não deite equipamentos eléctricos nem baterias no lixo doméstico!
De acordo com as directivas europeias 2002/96/CE sobre ferramentas eléctricas e electrónicas
usadas e 2006/66/CE sobre baterias e acumuladores e respectivos resíduos e a implementação
dessas directivas conforme a lei nacional, as ferramentas eléctricas e as baterias que atingem o
fim de sua vida útil devem ser recolhidas em separado e encaminhadas a uma instalação de
reciclagem compatível com os regulamentos sobre o meio ambiente.
• Gælder kun lande i EU
Undlad at bortskaffe elektrisk udstyr eller akkuer sammen med almindeligt husholdningsaffald.
I henhold til EU-direktiv 2002/96/EC angående brugt elektrisk og elektronisk udstyr, 2006/66/EC
angående batterier og akkumulatorer og brugte batterier og iværksættelse af bortskaffelse af bat-
terier og akkumulatorer i overensstemmelse med nationale love, skal elektrisk udstyr og akkuer,
der har nået slutningen af deres levetid, indsamles separat og afhændes til en genbrugsfacilitet,
som er miljømæssigt kompatibel.
•Μνο για χώρες ΕΕ
Μην απορρίπτετε ηλεκτρικ εξοπλισμ ή μπαταρίες μαζί με τα οικιακά απβλητα!
Σύμφωνα με την Ευρωπαϊκή Οδηγία 2002/96/ΕΚ περί αποβλήτων ειδών ηλεκτρικού και
ηλεκτρονικού εξοπλισμού και την Οδηγία 2006/66/EΚ περί μπαταριών και συσσωρευτών
και αποβλήτων μπαταριών και συσσωρευτών και την εφαρμογή τους σύμφωνα με την
εθνική νομοθεσία, απαιτείται συλλογή του ηλεκτρικού εξοπλισμού και των μπαταριών, το
ριο ζωής των οποίων έχει λήξει, ξεχωριστά και επιστροφή τους σε εγκατάσταση
ανακύκλωσης συμβατή με την προστασία του περιβάλλοντος.

5
ENGLISH (Original instructions)
Explanation of general view
1 Recessed part in the battery
cartridge cover
2 Battery cartridge cover
3 Red part
4 Button
5 Battery cartridge
6Cover
7 Switch lever
8 Slope
SPECIFICATIONS
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Specifications and battery cartridge may differ from
country to country.
• Weight, with battery cartridge, according to EPTA-Pro-
cedure 01/2003
ENE055-1
Intended use
The tool is intended for removing bubbles from concrete
when casting concrete.
GEA010-1
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future refer-
ence.
GEB082-1
CORDLESS CONCRETE VIBRATOR
SAFETY WARNINGS
1. Always keep your hands and face away from
vibrating head when operating.
2. Switch off the tool immediately if you notice
abnormal noise or something faulty during oper-
ation.
3. Inspect the tool carefully for breakage, cracks or
deformation if you accidentally drop it or strike it
against something.
4. Do not carry the tool with finger on switch.
5. Do not set the tool down and switch it on. The
vibrating head may whip around out of control
and cause an accident.
6. Be careful not to allow water, wet concrete or the
like to get into the tool. Do not let the tool fall
into wet concrete.
7. Insert the vibrating head carefully between iron/
steel frames or reinforcing rods not to come in
contact with them.
8. Do not crush or twist the flexible hose.
9. Do not overly bend the flexible hose.
10. Use a wet cloth or the like to carefully wipe off
any wet concrete left on the tool after use. Extra
care should be given to thorough cleaning of the
vents, switch area, cover openings, etc.
11. Do not use the tool in the rain. Do not clean the
tool in water.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this instruc-
tion manual may cause serious personal injury.
ENC007-6
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CARTRIDGE
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using bat-
tery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them out
with clear water and seek medical attention right
away. It may result in loss of your eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any conduc-
tive material.
(2) Avoid storing battery cartridge in a container
with other metal objects such as nails, coins,
etc.
(3) Do not expose battery cartridge to water or
rain.
Model DVR340 DVR440 DVR350 DVR450 DVR850
Vibrations per minute (min–1) 12,500 12,500 13,000 13,000 12,500
Vibration amplitude 1.0 mm
Vibration head (diameter x length) 25 mm x 221 mm
Flexible shaft assembly length 800 mm 1,200 mm 800 mm 1,200 mm 2,400 mm
Overall length 1,083 mm 1,483 mm 1,083 mm 1,483 mm 2,683 mm
Net weight 3.1 kg 3.6 kg 3.0 kg 3.5 kg 5.2 kg
Rated voltage D.C. 14.4 V D.C. 18 V
