Makita BHP460 User manual

Cordless Percussion-DriverDrill
Equippedwith Electric Brake
INSTRUCTION MANUAL

SPECIFICATIONS
Model BHP460
Wood screw
Concrete Steel Wood
16
mm 1518”) 13 mm (112”) 38 mm (1-1/2”1 ll~l~m~~~/~~
Machine screw
6 mm (1/4”1
2
No load speed (RPM) Blows per minute Overall length
High Low High Low
0 - 1,50O/min. 0 460/mtn. 0 - 22,500 0 - 6,900 267 mm (10-1/2”)
Net weight
2.7 kg
(5.9 Ibs)
Battery Cartridge 62417
Voltage
24 V
Battery Cartridge 82430
Voltage
24 V
Model DC24SA Battery charger
Input output Charging time
A.C.
only 50 Hz ~ 60 Hz D.C. 7.2 V ~~ 12 V 30 min.
Model DC24SA Battery charger
Input output Charging time
A.C. only 50 Hz - 60 Hz D.C. 7.2 V
- 12 V
60 min.

GENERAL SAFETY RULES USA0031
(For All Battery Operated Tools)
WARNING! Read and understand all instructions. Failure
tofollow all instructions listed below, may result inelectric
shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area
1. Keepyour work area clean and well lit. Cluttered benches and dark areas invite
accidents.
2. Do notoperate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases, or dust. Power tools create sparks which may
ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control.
Electrical Safety
4. A battery operated tool with integral batteries or a separate battery pack
mustbe recharged only
with the specified charger for the battery. A charger
that may be suitable for one type of battery may create
a risk of fire when
used with another battery.
5. Use battery operated tool only with specifically designated battery pack.
Use of any other batteries may create a risk of fire.
Personal Safetv
6.
7.
8.
9.
10.
11.
Stay alert, watch what you aredoing, and use common sensewhen operating
a power tool. Do not use tool while tired or under the influence of drugs,
alcohol, or medication.
A moment of inattention while operating power tools
may result
in serious personal injury.
Dress properly.
Do notwear loose clothing orjewelry. Containlonghair. Keep
your hair, clothing, and glovesaway from movingparts. Loose clothes, jewelry,
or long hair can be caught in moving parts.
Avoid accidental starting. Be sure switch is
in the locked or off position before
inserting battery pack. Carrying tools with your finger on the switch or
inserting the battery pack into a tool
with the switch on invites accidents.
Remove adjusting keys or wrenches before turning the tool on.
A wrench
or a key that is left attached to a rotating part of the tool mayresult in personal
injury.
Do notoverreach. Keep proper footing and balance atall times. Proper footing
and balance enable better control
of the tool in unexpected situations.
Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
3

Tool Use and Care
12. Use clamps or other practical way to secure and support the workpiece to
a stable platform. Holding the work by hand or against your body is unstable
and may lead to
loss of control.
13. Do notforce tool. Use the correct toolfor your application. The correct tool
will do the job better and safer at
the rate for which it is designed.
14. Do not use tool if switch does not turn it on or off. A tool that cannot be
controlled with the switch is dangerous and must be repaired.
15. Disconnect battery pack from tool or place the switch in the locked or off
position before making any adjustments, changing accessories, or storing
the tool. Such preventive safety measures reduce the risk of starting the tool
accidentally.
16. Store idle tools out of reach of children and other untrained persons. Tools
are dangerous in the hands of untrained users.
17. When battery pack is not in use, keep it away from other metal objects like:
paper clips, coins, keys, nails, screws, or other small metal objects that can
make a connection from one terminal to another. Shorting the battery
terminals together may cause sparks, burns, or a fire.
18. Maintain tools with care. Keep cutting tools sharp and clean. Properly
maintained tools with sharp cutting edge are less likely
to bindand are easier
to control.
19. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool's operation. If damaged, have
the tool serviced before using. Many accidents are caused by poorly
maintained tools.
20. Use only accessories that are recommended by the manufacturer for your
model. Accessories
that may be suitable for one tool may create a risk of injury
when used on another tool.
Service
21. Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnelmay result ina risk of injury.
22. When servicing a tool, use only identical replacement parts. Follow
instructions in the Maintenance section of this manual. Use of unauthorized
parts or failure to follow Maintenance Instructions may create a risk of shock
or injury.
4

Specific Safety Rules
USB023 1
1. Hold tool by insulated gripping surfaces when performing an operation where
the cutting tool may contact hidden wiring.
Contact with a "live" wire will
make exposed metal parts of the tool "live" and shock The operator.
2. Be aware that this tool is always in an operating condition, because it does
not have to be plugged into an electrical outlet.
3. Always be sure you have a firm footing.
Be sure no one is below when using the tool in high locations.
4. Hold the tool firmly.
5. Keep hands away from rotating parts.
6. Do not leave the tool running. Operate the tool only when hand-held.
8. Do not touchthe bit or the workpiece immediately after operation; they may
be extremely hot and could burn your skin.
SYMBOLS
The followings show the symbols used for tool.
v .................................... volts
- ____ .................................... direct current
k .................................... no load speed
.../ min ................................... revolutions or reciprocation per minute
b .................................... number of blow
5

uscoo2 1
IMPORTANT SAFETY INSTRUCTIONS
FOR CHARGER
&
BATTERY CARTRIDGE
I. SAVE THESE INSTRUCTIONS - This manual
contains important safety and operating instructions for battery charger.
2. Before usingbattery charger, read all instructions and cautionary markings
on (1) battery charger, (21 battery, and (3) product using battery.
3. CAUTION - To reduce risk of injury, charge only MAKITA rechargeable
batteries marked on the charger label. Other types of batteries may burst
causing personal injury and damage.
4. Do not expose charger to rain or snow.
5. Use of an attachment not recommended or sold by the battery charger
manufacturer may result
in a risk of fire, electric shock, or injurytopersons.
6. To reduce risk of damage toelectric plug and cord, pullby plug rather than
cord when disconnecting charger.
7. Make sure cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
8. An extension cord should not be used unless absolutely necessary. Use of
improper extension cord could result
in a risk of fire and electric shock. If
extension cord must be used, make sure:
a. That pinsonplug
of extensioncordare the same number, size, andshape
b. That extensioncordisproperly wired and
in good electrical condition; and
c. That wire size is at least as large as the one specified
in the table below.
TABLE 1
RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR BATTERY CHARGERS
as those of plug on charger;
I Length of Cord (Feet) I 25
I 50 I 100 I 150 I
I
AWG Size of Cord I 18 I 18 I 18 I 16 I
9. Do not operate charger with damaged cord or plug - replace them im-
mediately.
IO. Do notoperate charger if it has receiveda sharp blow, beendropped, or other-
wise damaged
in any way; take it to a qualified serviceman.
11. Do not disassemble charger or battery cartridge; take it to a qualified
serviceman when service or repair is required. Incorrect reassembly may
result
in a risk of electric shock or fire.
12. To reducerisk of electric shock, unplug charger fromoutlet beforeattempt-
ing any maintenance or cleaning. Turningoff controls will notreduce thisrisk.
6

usc002
ADDITIONAL SAFETY RULES
FOR CHARGER & BATTERY CARTRIDGE
1. Do not charge Battery Cartridge when temperature is BELOW 10°C (5OoF
2. Do notattempt to use a step-uptransformer, anengine generator or DC power
3. Do not allow anything to cover or clog the charger vents.
4. A battery short can cause a large current flow, overheating, possible burns
or ABOVE 4OoC (104OF).
receptacle.
and even a breakdown.
(1 ) Do not touch the terminals with any conductive material.
(2) Avoid storing battery cartridge in a container with other metalobjectssuch
(3) Do not expose battery cartridge to water or rain.
ture may reach or exceed 5OoC (122OF).
completely worn out. The battery cartridge can explode in a fire.
as nails, coins, etc.
5. Do not store the tool and Battery Cartridge
in locations where the tempera-
6. Do not incinerate the Battery Cartridge even if it is severely damaged or is
SAVE THESE INSTRUCTIONS.
Symbols
The followingshow the symbols usedfor the charger. Be sure that you understandtheir meaning before use.
@ +
0 Ready to charge
0 Charging
0 Chargingcomplete
*s 8 Delay charge (Cooling)
Mx 0 Defective battery
Conditioning
x 0 Coolingabnormality
7

FUNCTIONAL DESCRIPTION
Installingor removing battery cartridge
Always switch off the tool before insertion or removalof the battery cartridge.
To remove the battery cartridge, with-
draw
it from the tool while sliding the
buttonon the side of the cartridge.
To insert the battery cartridge, align the
tongue on the battery cartridge with the
groove in the housing and slip it into
place. Always insert it all the way until it
locks in place with
a little click. If you can
see the red part on the upper side of the
button, it is not locked completely. Insert
it fully until the red part cannot be seen. If
not,
it may accidentally fall out of the tool,
causing injury to you or someone around
you.
Do not use force when inserting the battery cartridge. If the cartridge does not slide in
easily, it is not being inserted correctly.
Charging
1. Plug the battery charger into your power
source. Two charging lights will flash in
green color repeatedly.
2. Insert the battery cartridge into charger
until it stops adjusting to the guide of
charger. Terminal cover of charger can
be opened with inserting and closed
with pullingout the battery cartridge.
3. When the battery cartridge is inserted,
the charging light color will change from
greento red and charging will begin.The
charging light will keep lighting up lit
steadily duringcharging.
One red charging light indicatescharged
condition in
0-- GO% and two redon& indicates 80 - 100Y0.
ones.
The chargingtime is as follows:
Battery 8241
7: approx. 30 minutes.
Battery 82430: approx.
60 minutes.
5. Ifyou leave the battery cartridge inthe charger after the chargingcycle is complete, the
charger will switch into its "trickle charge (maintenancecharge)" mode which will last
approximately 24 hours.
4. With finish of charge, the charging lights will change from two red ones to two green
6. After charging, unplugthe charger from the power source.
8

Coolingsystem
*This charger is equippedwith cooling fan for heatedbattery in order to enable the battery
to prove its own performance. Sound of cooling air comes out during cooling, which
means not trouble on the charger.
-Trouble on cooling fan
-Incomplete cool downof battery, such as, being cloggedwith dust
The battery can be charged in spite of the yellow warning light. But the chargingtime will
be longer than usualin this case.
Check the sound
of cooingfan, vent on the charger and battery, which can be sometime
cloggedwith dust.
The cooling system is in order although no sound of coolingfan comes out, if the yellow
warning lightwill not flash.
Always keep cleanthe vent on chargerand battery for cooling.
The products should be sent to repair or maintenance, if the yellow warning lightwill fre-
*Yellow light will flash for warning inthe followingcases.
quently flash.
Conditioningcharge
Conditioningcharge can extend the life of battew by automatically searchingthe optimum
charging condition for the batteries in every situation.
The battery employed inthe followingconditions repeatedly,will be worn out shortly, and
yellow warning light may flash.
1. Rechargeof battery with its high temperature
2. Rechargeof battery with its low temperature
3. Recharge of full chargedbattery
4. Over-dischargeof battery (continueto discharge battery in spite of down of power.)
5. Rechargeunder broken cooling system
The charging time of such battery is longer than usual.
Tricklecharge (Maintenancechargel
If you leave the battery cartridge in the charger to prevent spontaneous discharging after
full charge, the chargerwill switch into its "trickle charge (maintenancecharge)" modeand
keep the battery cartridge fresh and fully charged.
Tips for maintainingmaximum battery life
1. Chargethe battery cartridge before completely discharged.
Always stop tool operation and charge the battery cartridge when you notice less tool
power.
2. Never recharge a fully chargedbattery cartridge.
Overchargingshortens the battery service life.
3. Chargethe battery cartridge with room temperature at 10°C - 40°C (50°F - 104°F).
Let a hot battery cartridgecool down before charging it.
4. Chargethe Nickel Metal Hydride battery cartridge when you do not use it for more than
six months.
9

CAUTION:
*The battery charger is for charging Makita-battery cartridge Never use
it for other pur-
posesor for other manufacturer's batteries.
When you charge a new battery cartridge or a battery cartridge which has not been used
for
a long period of time, it may not accept a full charge. This is a normal condition and
does not indicate
a problem. You can recharge the battery cartridge fully after discharg-
ing it completely and recharging
a couple of times.
If you charge a battery cartridge from a just-operatedtool or battery cartridge which has
been left in
a location exposed to direct sunlight for a long time, the charging light may
flash in redcolor. If this occurs, wait for awhile. Chargingwill beginafter the battery car-
tridge is cooledby the cooling fan installedin the charger.When the temperature on bat-
tery is more than approx. 70°C, two charging lights may flash in red color, and when
approx.
50°C - 70°C, one charging light in redcolor.
If the charging light flashes alternately in green and red color, charging is not possible.
The terminals on the charger or battery cartridge are clogged with dust or the battery
cartridge isworn out or damaged.
Any of the following conditions indicatesdamage to the charger and/or battery cartridge.
Ask your MakitaAuthorizedor FactoryService Center to check them.
1) The charging light does not flash (green)when the battery charger is plugged into a
2) The charging light does not light up or flash (red)when the battery is inserted in the
3) Charging is not completed at even more than two hours after red light comes ON at
power source.
charger port.
start of charging.
Switch action
CAUTION:
Before insertincl the batten/ cartridae into the tool, always check to see that the switch
10

Reversing switch action
CAUTION:
Always check thedirection of rotation before operation.
Use the reversing switch only after the tool comes to a complete stop. Changing the
When not operating the tool, always set the reversing switch lever to the neutral posi-
direction of rotation beforethe tool stops may damage the tool.
tion.
This tool has
a reversing switch to change
the direction
of rotation. Depress the re-
versing switch lever from the A side for
clockwise rotation or from the B side
for
counterclockwiserotation.When the switch
lever is in the neutral position, the switch
trigger cannot bepulled.
Speed change
To change the speed, first switch off the
tool and then slide the speed change lever
to the
"11" side for high speed or "I" side
for
low speed. Be sure that the speed
change lever is set
to the correct position
before operation. Use the right speed for
your job.
Reversingswitch lever
I
Clockwise Counterclockwise
t Lowspeed
Highspeed
Speed change lever
CAUTION:
*Always set the speed change lever fully to the correct position. If you operate the
tool
with the speed change lever positionedhalf-way between the "I" side and "11" side, the
tool may bedamaged.
Do not usethe speed change lever while the tool is running.The tool may bedamaged.
11

Selectingthe action mode
This tool employs an action mode changing
ring. Select one
of the three modes suit-
able for your work needs by usingthis ring.
For rotation only, turn the ring
so that the
arrow on the tool body points toward the
CM mark on the ring. For rotation with
hammering, turn the ring
so that the arrow
pointstoward the
b on the ring. For rota-
tion with clutch, turn the ring
so that the
arrow points toward the
ciS mark on the
ring.
CAUTIO
N :
Always set the ring correctly to your desired mode mark. If you operate the tool with the
ring positioned half-way betweenthe mode marks, the tool may be damage.
Adjustingthefastening torque
The fastening torque can be adjusted in 16
steps by turning the adjusting ring so that
its graduations are aligned with the arrow
on the tool body. The fastening torque
is
minimum when the number 1 is aligned
with the arrow, and maximum when the
number
16 isaligned withthe arrow.
Before actual operation, drive a trial screw
into your material or a piece
of duplicate
material to determine which torque level is
requiredfor
a particular application.
Graduations
Arrow
Adjustingring
I
ASSEMBLY
Installing or removingdriver bit or drill bit
CAUTION:
Alwavs be sure that the tool is switched off and the battew cartridge is removed before
instaliingor removing the bit.
Turn the sleeve counterclockwise to open
the chuck jaws. Place the bit in the chuck
as far as it will go. Turn the sleeve clock-
wise to tighten the chuck. To remove the
bit,turn the sleeve counterclockwise.
12

When not using the driver bit, keep it in the
bit holders.
Bits
45 mm (1-3/4") longcan be kept there.
Side grip (auxiliary handle)
Always use the side grip to ensure operat-
ing safety. Install the side grip so that the
teeth on the grip fit in between the protru-
sions on the tool barrel. Then tighten the
grip by turning clockwise
at the desired
position.
It may be swung 360" so as to be
secured
at any position.
Bit Bit holder
Adjustable depth rod
The adjustable depth rod is used to drill
holes
of uniform depth. Loosen the thumb
screw, set to desired position, then tighten
the thumb screw.
Thumb screw
13

OPERATION
CAUTION:
*Always insert the battery cartridge all the way until it locks in place.
If you can see the
red part on the upper side of the button, it is not locked completely. Insert
it fully until
the red part cannot be seen.
If not, it may accidentally fall out of the tool, causing injury
toyou or someonearoundyou.
When operating overhead, make sure the battery cartridge is locked securely so that it
will not be fallen out of the tool. If not, it may accidentally fall out of the tool, causing
injuryto
you or someone aroundyou.
- . , . -. . ,
5 5 (7/32"1
5 8 (7/32"1
6.1 115/64"1
Screwdrivingoperation
First,turn the action mode changing ring so
that the arrow on the tool body points to
the m9 marking. Adjust the adjusting ring
to the proper torque lever for your work.
Then proceedas follows.
Place the point
of the driver bit in the
screw headand apply pressure to the tool.
Start the tool slowly and then increase the
speed gradually. Release the trigger as
soon as the clutch cuts in.
.. ~. ,
3.6 - 3.919/4" - 5/32")
4.0 - 4 2 15/32'' - 11/64")
4.2-4.4111/64"- 11/64")
NOTE:
Make sure that the driver bit is inserted straight in the screw head, or the screw andlor
bit may be damaged.
When driving wood screws, predrill pilot
holes to make driving easier and to pre-
vent splitting of the workpiece. See the
chart.
2.5 - 2.8 13/32" - 7/64"l
A R 13/lfi"l I 3 1 - 3 4 11/8" - 9/64")
51I13/fi4"1 I 33-3611/8"-9/64")
If the tool is operated continuously until the battery cartridge has discharged, allow the
tool to rest for
15 minutes before proceedingwith a fresh battery.
Drillingoperation
First, turn the action mode changing ring so that the arrow on the tool body points to the
~nv marking. The adjusting ring can be aligned win any torque levels for this operation.
Then proceedas follows.
Drillinginwood
When drilling in wood, best results are obtained with wood drills equippedwith
a guide
screw. The guide screw makesdrillingeasier by pullingthe bit into the workpiece.
14

Drillingin metal
To preventthe bit from slipping when starting
a hole, makean indentationwith a center-
punchand hammer at the point to bedrilled.Placethe point of the bit in the indentation
and start drilling.
Use
a cutting lubricant when drilling metals. The exceptions are iron and brass which
should be drilleddry.
CAUTION:
@Pressingexcessively on the tool will not speed up the drilling. In fact, this excessive
pressurewill only serve to damage the tip
of your bit, decreasethe tool performance and
shortenthe service
life of the tool.
*There is
a tremendous force exerted on the tool/bit at the time of hole breakthrough.
Holdthe tool firmly and exert care when the bit beginsto break through the workpiece.
A stuck bit can be removed simply by setting the reversingswitch to reverse rotation in
order to back out. However, the tool may back out abruptly if you do not hold
it firmly.
Always secure small workpieces in a vise or similar hold-downdevice
9 If the tool is operated continuously until the battery cartridge has discharged, allow the
Hammer drilling operation
First, turn the action mode changing ring so that the arrow on the tool body points to the
c==1 marking. The adjusting ring can be aligned in any torque levels for this operation.
Position the bit at the desired location for the hole, then pullthe trigger.
Do not force the
tool. Light pressuregives best results. Keep the tool in position and prevent it from slip-
ping away from the hole.
Do not apply more pressure when the hole becomes clogged
with chips or particles. Instead, run the tool
at an idle, then remove the bit partially from
the hole.
By repeatingthis several times, the hole will be cleaned out and normal drilling
CAUTION:
There is
a tremendous and sudden twisting force exerted on the tool bit at the time of
hole breakthrough, when the hole becomes clogged with chips and particles,
or when
striking reinforcing rods embedded in the concrete. Always use the side grip (auxiliary
handle) and firmly hold the tool by both side grip and switch handle during operations.
Failureto do
so may result in the loss of control of the tool and potentially severe injury.
tool to rest for
15 minutes before proceedingwith a fresh battery.
may be resumed.
9
Blow-outbulb
Usethe blow-out bulb to clean out the hole.
15

MAINTENANCE
CAUTION:
Always be sure that the tool is switched off and the battery cartridge is removed before
attempting to perform inspection or maintenance.
Replacingcarbon brushes
Remove and check the carbon brushes
regularly. Replacewhen they wear down to
the limit mark. Keep the carbon brushes
clean and free to slip in the holders. Both
carbon brushes should be replaced
at
the same time. Use only identical carbon
brushes.
Use
a screwdriver to remove the brush
holder caps. Take out the worn carbon
brushes, insert the new ones and secure
the brush holder caps.
I Limitmark
Brush holder cap
To maintainproduct SAFETY and RELIABILITY, repairs, maintenanceor adjustment should
be performed by Makita Authorized or Factory Service Centers, always using Makita
replacementparts.
16

ACCESSORIES
CAUTION
These accessories or attachments are recommended for use with your Makita tool specified In this
manual The use of any other accessories or attachments might present a risk of injury to persons
The accessories or attachments should be used only in the proper and intended manner
Phillips #2 784214-0A
- I #3 I 784215-0A
711120-1
711121-A
711122-A
711123-A
711124-A
711125-A
71
1 126-A
711127-A
711128-A
711129-A
711130-A
3/16" 3/16" 4
114' 114" 4
114" 1/4"
6
511 6" 114" 6
318' 114'' 6
112" 318'' 6
518" 318" 6
314" 318" 6
114" 1/4" 13
318" 114" 13
112" 3/8" 13
Slotted
- Phillipsbit
#5F I 784010-0A
Part
No. I Size I L (mm)
784201-5 I No.1 I 65 (2-5/8")
Square drill bit
-
7846064A
- Heavy dutymasonry drillbit
for percussion drill
704202-3
Bit Shank Overall
Part No' I diameter 1 dia. 1 length
45 (1-314")
784207-3
1 I 150(4-718")
Drillbits Grip assembly
Tested best in Makitadriver-drillsfor smooth fast
drillingand more holes per batten/ change.
High speedsteel. For drilling in metal, wood and
plastic.Jobbers length. Special surface treatment
for lubricitygives smoother drilling.
Part
No. 122575-0
-
Part No.
711011 -A
711012-A
711013-A
711014-A
711015-A
711016-A
71
1 017-A
711018-A
71
1 019-A
711020-A
Drill
dia.
111
6"
3/32"
118"
5/32"
311
6"
7/32"
114"
9/32"
5/16"
11/32"
Shank
dia.
1/16"
1 3/32"
118"
5/32"
3/16"
7/32"
114"
9/32"
5/16"
11/32"
5/16". 3/8" Best a
convenient case.
Flute Overall
length length
' Depth rod
Part No 122576-8
c 718" 1-718"
3-518"
", 3/16". 1/4".
ling bits in
17

Highcapacit batterycharger
Model
DC248A
. Battery82417
- Battery82430
Plasticcarryingcase
18

19

1 NAME PLATE BHP4EO
2 HOUSING BUMPER SET
3 HOUSINGSET
4
5 SPEED CHANGE LEVER ASS’Y
E F/R CHANGE LEVER
7 SWITCH
8 BITHOLDER
9 SUPPORT PLATE
10 TERMINAL
11
12 KEYLESS DRILL CHUCK 13
13 GEARASS’Y
14 TAPPING SCREW 4x25
15 TAPPING SCREW ST 4x8
16 DCMOTOR
17 PAN HEAD SCREW M3X8
18 CARBON BRUSH CB-430
19 HOLDERCAP
20 HOUSING SET
21 HOUSING BUMPER SET
22 MAKITA LABEL
TAPPING SCREW
BIND PT 3x1 6
- FLAT HEAD SCREW MBX32
1
1
1
8
1
1
I
2
1
1
1
1
1
4
3
1
I
1
2
1
1
1
MAKITALIMITED ONE YEAR WARRANTY
Warranty Policy
Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to
be free of defects from workmanship and materials for the peripd
of ONE YEAR from the date of
original purchase. Should any trouble develop during this one-year period, return the COMPLETE
tool, freight prepaid, to one of Makita’s Factory or Authorized Service Centers. If inspection shows
the trouble is caused by defective workmanship or material, Makita
will repair (or at our option,
replace) without charge.
This Warranty does not apply where:
repairs have been made or attempted by others:
repairs are required because of normal wear and tear:
The tool has been abused, misused or improperly maintained;
alterations have been made to the tool.
IN NO EVENT SHALL MAKITA BE LIABLE bOR ANY INDIRECT, INCIDENTAL OR CON-
SEQUENTIAL DAMAGES FROM THE SALE OR USE OFTHE PRODUCT. THISDISCLAIMER
APPLIES BOTH DURING AND AFTER THE TERM
01 THISWARRANTY.
MAKITA DISCLAIMS LIABILITY FOR ANY IMPLIED WARRANTIES, INCLUDING IMPLIED
WARRANTIES OF “MERCHANTABILITY” AND “FITNESS FOR A SPECIFIC PURPOSE,”
AFTER THE ONE-YEAR TERM OFTHIS WARRANTY.
This Warranty gives you specific legal rights, and you may also have other nghts which vary from
state to state. Some states do not allow the exclusion or limitation of incidental or consequential
damages,
so the above limitation or exclusion may not apply to you. Some states do not allow
limitation on how long an implied warranty lasts,
so the above limitation may not apply to you.
-
Makita Corporation
3-11 -8, Sumiyoshi-cho,
Anjo, Aichi 446-8502Japan
884324-062
PRINTED IN JAPAN
2MWl-5N
