Parts Breakdown DA3000R
Page 1 of 2 2/8/2008

Parts Breakdown DA3000R
Fig # Part ID Part Name Quantity
1 911161-0 P.H. SCREW M4X35, 9218SB 4
2 159272-5 GEAR HOUSING, DA3000R (T2) 1
3 256745-0 PIN 4 DA3000R 2
4 221342-1 SPIRAL B. GEAR 10, DA3000R,T1 1
4 226751-9 SPIRAL BEVEL GEAR 7, DA3000R,T2 1
5 256014-9 PIN 3, DA3000(R) 1
6 211051-0 BALL BEARING 609LLB HR2400 1
7 221682-7 H. GEAR 32, DA3000R 1
8 211014-6 B. BEARING 606, 6826 1
9 156951-6 GEAR HOUSING COVER 1
10 211033-2 B. BEARING 608LB, 5091D 1
11 241822-1 FAN 58, DA3000R 1
12 511821-0 ARMATURE, DA3000R 1
13 681614-0 INS. WASHER, 9031 1
14 211028-5 B. BEARING 627LB, 6510LVR 1
15 521476-3 FIELD, DA3000R 1
16 265891-8 TAPPING SCREW M4X55, DA3000R 2
16 266147-2 TAPPING SCREW 4X55, 6824 2
18 211051-0 BALL BEARING 609LLB HR2400 1
19 221343-9 SPIRAL B. GEAR 36, DA3000R,T1 1
19 226752-7 SPIRAL BEVEL GEAR 24, DA3000R, T2 1
20 256023-8 PIN 5, DA3000R,T1 1
21 193443-4 DRILL CHUCK, DA3000R 1
21 763068-490A N/A 1
22 443049-1 FELT RING 38, DA3000R 1
23 286216-3 CAP 46, DA3000(R) 1
26 911168-6 P.H. SCREW M4X40, 6905B 2
27 155502-2 SWITCH COVER, DA3000R 1
28 911133-5 P.H. SCREW M4X18, N9501B 2
29 687001-1 STRAIN RELIEF, 6013BR 1
30 651982-5 SWITCH,DA3000R 1
30 650527-6 SWITCH, DA3000R 1
31 643550-8 BRUSH CAP , 9031 2
32 191947-0 CARBON BRUSH 76, 6905B 1
33 651936-2 SWITCH ASS'Y SGEB108CV-1P,T2 1
34 854740-0 NAME PLATE, DA3000R 1
35 157722-4 MOTOR HOUSING, DA3000R (T2) 1
37 682500-8 CORD GUARD, DA3000R 1
38 664002-6 CORD 1
39 961017-7 STOP RING E-3, 4304 1
40 158011-0 SWITCH LEVER, DA3000R 1
41 256626-8 PIN 4, LS1221 1
42 251304-5 C.H. SCREW M4X12, DA3000R 1
43 253969-9 WASHER 4, DA3000R 1
44 953106-2 RIVET 0-5, HM1500 2
46 263002-9 RUBBER PIN 4, HR2400 1
47 263002-9 RUBBER PIN 4, HR2400 1
48 263002-9 RUBBER PIN 4, HR2400 1
49 263002-9 RUBBER PIN 4, HR2400 1
400 763414-1 CHUCK KEY, DA3000, DA3000R, 1
401 411780-7 KEY HOLDER,6402 1
Page 2 of 2 2/8/2008
