Parts Breakdown HP1620F
Page 1 of 2 2/8/2008

Parts Breakdown HP1620F
Fig # Part ID Part Name Quantity
1 265995-6 TAPPING SCREW 4X18, 4323K 7
2 850768-6 NAME PLATE, HP1620F 1
3 183712-1 HOUSING SET, HP1621F 1
4 921923-8 HEX. BOLT M8 X 120, HP2050F 1
5 345280-4 HEX. WASHER, HP2050F 1
6 417630-4 GRIP BASE, HP2070F 1
7 152489-9 GRIP 36, HR2410 1
8 192541-1 DRILL CHUCK S13, HP1620F 1
9 324397-6 SPINDLE, HP1621F 1
10 233389-3 COMPRESSION SPRING 15, HP1621F 1
11 211201-7 B. BEARING 6002LLB, 6510LVR 1
12 961055-9 RETAINING RING S-15, 5057KB 1
13 226579-5 HELICAL GEAR 45, HP1621F 1
14 216018-3 STEEL BALL 5.0,BFT122FZ 1
15 418319-7 CHANGE LEVER, HP1621F 1
16 345354-1 PLATE 19, HP1621F 1
17 153695-9 N/A 1
17 153831-7 CAM HOLDER CPL.,HP1621F 1
18 210023-2 BALL BEARING 627DDW, 9910 1
19 240067-8 FAN 55, HP1621F 1
20 517456-5 ARMATURE ASS'Y 115V, HP1621F 1
21 210023-2 BALL BEARING 627DDW, 9910 1
21 211028-5 B. BEARING 627LB, 6510LVR 1
22 633566-1 FIELD 115V, HP1621F 1
23 638237-5 BRUSH HOLDER UNIT, HP1621F 1
24 191927-6 CARBON BRUSH SET CB-407, 6821 1
25 686038-5 RECEPTACLE SLEEVE, HP2070F 2
26 418320-2 HANDLE COVER, HP1621F 1
27 265995-6 TAPPING SCREW 4X18, 4323K 1
28 687169-3 STRAIN RELIEF, HP1621F 1
29 682549-8 CORD GUARD 8, HP2030 1
30 660002-4 POWER SUPPLY CORD, JN1601 1
30 664881-2 CORD 1
31 650543-8 SWITCH, HP1621F 1
32 631570-4 LIGHT CIRCUIT, HR1830F 1
33 819063-3 MAKITA LABEL, 6992DWDE 1
34 183712-1 HOUSING SET, HP1621F 1
35 345400-0 N/A 1
1,001 763440-0 CHUCK KEY S13, HP2032 1
1,002 324219-0 DEPTH GAUGE,HP2050F 1
1,003 182992-6 PLASSTIC CARRYING CASE,HP1621FK 1
1,003 824724-2 PLASTIC TOOL CASE, HP1621FK 1
1,003 824795-9 N/A 1
5,001 810134-9 N/A 1
5,001 810277-7 N/A 1
