Makita maktec MT814 Manual

P 1/ 8
Specification
Standard equipment
Optional accessories
110
120
230
240
6.8 50/60
50/60
50/60
50/60
6.2
3.3
3.1
710
---
710
710
420
420
420
420
630
630
630
220 50/603.4 710 420 630
630
Continuous Rating (W)
Voltage (V) Cycle (Hz) Input Output Max. Output (W)Current (A)
Note: The standard equipment for the tool shown above may vary by country.
Models MT814 and MT815 have been developed as the aesthetic
change models of maktec hammer drill MT813, featuring:
Industrial performance and durability at less expense
Tool body ergonomically designed to;
provide comfortable grip and more control.
give maximum power thrust.
The specification difference between MT814 and MT815 is;
MT814: Keyed chuck model
MT815: Keyless chuck model
Chuck key S-13 ................................................ 1 pc (MT814 only)
Key holder 10 ................................................... 1 pc (MT814 only)
Side grip ........................................................... 1 pc
Depth gauge ..................................................... 1 pc
Plastic carrying case ........................................ 1 pc ("K models" only)
Tool box ........................................................... 1 pc ("KSP models" only)
Chuck capacity: mm (")
Chuck type
Reverse switch
No load speed: min -1 = rpm
Impacts per min.: min -1= ipm
Capacities: mm (") Steel
Concrete
Wood
Protection against electric shock
Power supply cord: m (ft)
Weight according to
EPTA-Procedure 01/2003*: kg (lbs)
0 - 3,200
Model No. MT814
0 - 48,000
Keyed
1.5 - 13 (1/16 - 1/2)
16 (5/8)
13 (1/2)
30 (1-3/16)
Yes
Double insulation
2.1 (4.6)
2.0 (6.6)
MT815
Keyless
2.0 (4.4)
Variable speed control by trigger Yes
TCT drill bits, etc.
Dimensions: mm ( " )
Width (W)
Height (H)
Length (L)
Model No.
(The image above is
MT815.)
MT814 MT815
296 (11-5/8) 295 (11-5/8)
202 (8)
77 (3)
*including Side grip
PRODUCT
Model No.
Description
MT814, MT815
Hammer Drills 16mm (5/8")
CONCEPT AND MAIN APPLICATIONS
TECHNICAL INFORMATION
H
L
W
These models will be also available with:
Plastic carrying case as "K models" (MT814K, MT815K)
Tool box as "KSP models" (MT814KSP, MT815KSP)
All manuals and user guides at all-guides.com
all-guides.com

P 2/ 8
Repair
CAUTION: Repair the machine in accordance with “Instruction manual” or “Safety instructions”.
[1] NECESSARY REPAIRING TOOLS
[2] LUBRICATIONS
Fig. 1
Code No. Description Use for
1R005 Description Removing / Fitting Retaining ring R-35
1R026 Bearing setting pipe 16-8.2 Removing Helical gear 37
1R028 Bearing setting pipe 20-12.2 Assembling Helical gear 37 to Spindle
1R035 Bearing setting plate 15.2 Holding Spindle when assembling Helical gear 37
1R037 Bearing setting plate 15.2 Holding Gear housing when removing Spindle
1R045 Gear extractor Removing Armature from Gear housing
1R139 Drill chuck extractor Locking Spindle when removing Drill chuck
1R269 Bearing extractor Removing Ball bearings from Armature
1R283 Round Bar for Arbor 9-50 Removing Spindle from Helical gear 37
1R298 Hex bar 10 with Square socket Removing Drill chuck
781024-2 Wrench 43 Removing / Assembling Keyed drill chuck
781007-2 Wrench 14 Removing / Assembling Keyless drill chuck
1R223 Torque wrench shaft 20-90 N.m Removing / Assembling Drill chuck
1R224 Ratchet Head 12.7 for 1R223
Item No.
Apply the following lubricants to the specific portions to protect the parts and product from unusual abrasion.
Description
7
7Gear housing
8
14
14
Steel ball 3.5
17
Lubricant AmountPortion to lubricate
Ring 12
Ball bearing 6202DDW
Makita grease N No.1
Molybdenum disulfied
lubricant
8
17
Helical gear 37
Spindle
Pin 4
Gear room where Armature engages with 14
Cam portion
a. The portion where Ball bearing 6202DDW contacts
b. The portion which is inserted into Plane bearing 8
of Gear housing complete
Whole portion
a
3g
a little
b
Gear housing
cover complete
All manuals and user guides at all-guides.com

P 3/ 8
Repair
[3] DISASSEMBLY/ASSEMBLY
[3]-1. Drill chuck
DISASSEMBLING
1R223
Drill chuck can be removed as illustrated in Fig. 2 when Drill chuck is not out of order.
ASSEMBLING
Take the disassembling step in reverse.
Note: The fastening torque of 1R223 has to be 34.3N.m. up to 44.1N.m.
Fig. 2
1R223
1R224
1R298 1R298
1R224
MT814
1R139
1. Fit the flats of Spindle to the notch of 1R139 and then hold 1R139 in vise.
2. Attach 1R224 and 1R298 to 1R223 and then secure 1R298 with Drill chuck.
3. Turn 1R223 counterclockwise.
1. Fit the flats of Spindle to the notch of 1R139
and then hold 1R139 in vise.
2. Insert the pin of 781024-2 into the hole of Drill
chuck, and then turn 781024-2 counterclockwise.
1R139
When removing a Drill bit is impossible, 1R298 can not be secured with the drill chuck.
Therefore, remove the drill chuck from Spindle as illustrated in Fig. 2A or 2B.
MT815
MT814
MT815
Fig. 2A
781024-2
Fig. 2B
Vise
781007-2
Flats of the hexagonal
ring of Keyless drill
chuck 1. Hold two flats of Keyless drill chuck in vise.
2. Fit the flats of 781007-2 to those of Spindle.
3. Turn Wrench 14 clockwise.
All manuals and user guides at all-guides.com

P 4/ 8
Repair
[3] DISASSEMBLY/ASSEMBLY
[3]-2. Armature
DISASSEMBLING
1. Remove Handle cover complete
and four 4x18 Tapping screws.
Remove Carbon brushes together
with Brush holders from Motor
housing.
2. Separate Gear housing and Gear
housing cover complete from
Motor housing by removing three
4x30 Tapping screws.
Brush holder (2pcs.)
(1) Remove Armature from the machine as illustrated in Fig. 3.
(2) Disassemble the Armature as illustrated in Fig. 4.
Handle cover complete
Carbon
brush (2pcs.)
Remove Armature ass’y from Gear
housing cover complete with 1R045.
Disassemble Armature ass’y as illustrated below.
Gear housing
cover complete
Gear housing
Motor housing
Spindle
Gear housing
Gear housing
cover complete
Rubber ring 19
1R269
Ball bearing
608LLB
Ball bearing 607ZZ
Insulation washer
3. Armature ass’y can be removed
together with Gear housing cover
complete. Do not lose Pin 4 and Steel
ball 3.5 mounted in the Spindle hole.
Fig. 3
Fig. 4
Gear housing cover complete
1R045
Armature ass’y
4x18 Tapping
screw (4pcs,)
4x30 Tapping screw (3pcs.)
All manuals and user guides at all-guides.com

P 5/ 8
Repair
[3] DISASSEMBLY/ASSEMBLY
[3]-3. Helical gear 37, Ball bearing 6202DDW
DISASSEMBLING
1. Remove Gear housing and
three 4x30 Tapping screws.
2. Remove Pin 4 and Steel ball 3.5
from Spindle hole.
Be careful not to lose them.
(3) Disassemble Spindle and Helical gear 37 as illustrated in Fig. 6.
1. Inserting 1R026 over Spindle,
Press down 1R026 using arbor
press to slightly push Spindle.
2. Set 1R283 between Arbor press
and Spindle, and push down
Spindle with Compression
spring 16 from Helical gear 37
in Gear housing.
3. Remove Retaining ring R-35 using 1R005,
Separate Ring 12 and Ring 19 from Gear
housing.
Spindle
Ring spring 12
Steel ball 3.5
Pin 4
3. Remove Ring spring 12
from Spindle with Awl.
Fig. 5
Fig. 6
1R037
Spindle (in 1R026)
1R026
Gear housing
Spindle with
Compression
spring 16
Ring 12
(1) Remove Drill chuck as illustrated in Fig. 2.
(2) Separating Gear housing, remove Pin 4, Steel ball 3.5 and Rind spring 12 from Spindle as illustrated in Fig. 5.
Gear housing
Gear housing
cover complete
1R283
Retaining
ring R-35
1R005
Helical
gear 37
Ring 19
Awl
All manuals and user guides at all-guides.com

P 6/ 8
Repair
[3] DISASSEMBLY/ASSEMBLY
[3]-3. Helical gear 37, Ball bearing 6202DDW (cont.)
Assemble Ball bearing 6202DDW, Spindle and Helical gear 37 to Gear housing as illustrated in Fig. 8.
Fig. 8
Ring 12
1. Assemble Ball bearing
6202DDW, Ring 19 and
Ring 12.
2. Assemble Retaining
ring R-35 to secure
Ball bearing 6202DDW
in place.
3. Insert Spindle into Ball
bearing 6202DDW.
4. Putting Spindle thread into
the hole of 1R035,
set Gear housing on 1R035.
Ring 19
Ball bearing
6202DDW
ASSEMBLING
ASSEMBLING
Retaining
ring R-35
Spindle
Helical gear 37
Helical gear 37
Ring spring 12
1R028
5. Assemble Helical gear 37 to Spindle
in Gear housing using Arbor press,
1R028 and 1R035.
Compression
spring 16
Spindle thread
6. Secure Helical gear 37 in place
with Ring spring 12.
7. Insert Steel ball 3.5 and
Pin 4 into Spindle hole.
1R035
1R035
Pin 4
Steel ball 3.5
1. Insert Spindle into Gear housing. 2. Strike Spindle with Plastic hammer, and Ball bearing 6202DDW
can be removed together with Spindle.
Fig. 7
(4) Remove Ball bearing 6202DDW as illustrated in Fig. 7. Use the removed Spindle as a jig.
Ball bearing
6202DDW
Spindle
Spindle
as a jig
Gear housing
Note: Ball bearing 6202DDW is highly loaded when Spindle is removed from Helical gear 37.
Therefore, be sure to replace the ball bearing 6202DDW with the new one.
All manuals and user guides at all-guides.com
all-guides.com

Circuit diagram
P 7/ 8
Orange
Blue
Brown Purple
Color index of lead wires' sheath
Black
Red
Field
viewed from
Commutator
side
Brush holder on the opposite
of Switch
Switch
Noise suppressor
(if used)
Power supply cord
White Lead wire is used
for some countries.
Black Lead wire is used
for some countries.
Brush holder near Switch
Fig. D-1
All manuals and user guides at all-guides.com

Wiring diagram
P 8/ 8
Rib A
Rib B
Rib C
Brush holder
Noise Suppressor
Switch
When the sags of Lead wires are
left around here, fix them with
Lead wire holder A.
Connect Insulated connecting
terminal to Brush holder as
illustrated.
Put Noise suppressor in this
place if it is used.
Connect Insulated connecting
terminal to Brush holder so that
the purple lead wire is along the
upper space as illustrated.
Route Field lead wires (black,
white) of Left coil between
Rib A and Rib B of Motor
housing.
Route Field lead wires (black, red)
of Right coil between Rib B and
Rib C of Motor housing.
Fig. D-2
Fig. D-3
Wiring of Field lead wires
Wiring in Handle section
Lead wire holder A
Lead Wire holder B
Fix Field lead wires (black)
with Lead wire holder B.
Right coil
(Handle cover side)
Left coil
