INSTRUCTION MANUAL
No load speed
(RPMI
6,000
DOUBLE
INSULATION
Overall length Net weight Spindle thread
458 mm (1 8")
4.2 kg (9.3 Ibsl 5/8"- 11 UNC

GENERAL SAFETY RULES
(For All Tools)
WARNING! Read and understand all instructions. Failure
tofollow all instructions listed below, may result
in electric
shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS.
1. Keepyour work area cleanand well lit. Cluttered benches and dark areas invite
accidents.
2. Donotoperate power tools in explosive atmospheres, suchas in thepresence
of flammable liquids, gases, or dust. Power tools create sparks which may
ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to loose control.
4. Double Insulatedtools are equipped with a polarized plug (onebladeiswider
than the other.) This plug
will fit in a polarized outlet only one way. If the
plug does not fit fully
in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install a polarized outlet.
Do not change
the plug
in any way. Double insulation eliminates the need for the three
wire grounded power cord and grounded power supply system.
Avoid body contact
with grounded surfaces suchas pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is
grounded.
Don't expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk
of electric shock.
Donot abuse the cord. Never use the cord tocarry the tools or
pull the plug
from an outlet. Keep cord away from heat, oil, sharp edges
or movingparts.
Replace damaged cords immediately. Damaged cords increase the risk
of
electric shock.
8. When operating a powertooloutside, use anoutdoor extensioncordmarked
"W-A" or "W." These cords are rated for outdoor use and reduce
the risk
of electric shock.
9. Stay alert, watchwhat you are doinganduse commonsensewhenoperating
a power tool. Do not use tool while tired or under the influence of drugs,
alcohol, or medication.
A moment of inattention while operating power tools
may result in serious personal injury.
IO. Dress properly. Donotwear looseclothingorjewelry. Containlonghair. Keep
your hair, clothing, andgloves awayfrom movingparts. Looseclothes, jewelry
or long hair can be caught
in moving parts.
2

11. Avoid accidental starting. Be sure switch is off before plugging in. Carrying
tools
with your finger on the switch or plugging in toolsthat havethe switch
on invites accidents.
12. Remove adjusting keys or switches before turning the tool on. A wrench or
a key that is left attached to a rotating part
of the tool may result in personal
injury.
13. Do notoverreach. Keepproper footing andbalanceat all times. Proper footing
and balance enables better control of the tool in unexpected situations.
14. Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
15. Use clamps or other practical way to secure and support the workpiece to
a stable platform. Holding the work by handor against your body is unstable
and may lead to
loss of control.
16. Do not force tool. Use the correct toolfor your application. The correct tool
will do the job better and safer at the rate for which
it is designed.
17. Do not use tool if switch does not turn it on or off. Any tool that cannot
be controlled
with the switch is dangerous and must be repaired.
18. Disconnect the plugfrom the power source before makingany adjustments,
changing accessories, or storing the tool. Such preventive safety measures
reduce the risk of starting the tool accidentally.
19. Store idle tools out of reach of children and other untrained persons.
Tools
are dangerous in the hands of untrained users.
20. Maintain tools with care, Keep cutting tools sharp and clean. Properly
maintainedtools, with sharp cutting edges are less likely to bindand are easier
to control.
21. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tools operation. If damaged, have
the tool serviced before using. Many accidents are caused
by poorly main-
tained tools.
22. Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one tool, may become hazardous
when used on another tool.
23.
Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of
injury.
24. When servicing a tool, use only identicalreplacement parts. Follow instruc-
tions
in the Maintenance section of this manual. Use of unauthorized parts
or failure tofollow Maintenance Instructionsmaycreate a risk of electric shock
or injury.
3

Specific Safety Rules
1. Always use proper guardwith grinding wheel. A guard protects operator from
broken wheel fragments.
2. Accessories must be rated for at last the speed recommended on the tool
warning label. Wheels and other accessories running over rated speed can
fly apart and cause injury.
3. Holdtool by insulated gripping surfaces when performinganoperationwhere
the cutting tool may contact hidden wiring or its own cord. Contact with
a "live" wire will make exposed metal parts of the tool "live" and shock the
operator.
4. Keep guards in place.
5. Use only wheels having a maximum operatingspeed at least as highas "No
Load RPM" marked onthe tool's nameplate. When using depressed center
wheels, be sure to use only fiberglass-reinforced wheels.
6. Check the wheel carefully for cracks or damage before operation. Replace
cracked or damaged wheel immediately.
7. Use only flanges specified for this tool.
8. Be careful not to damage the spindle, the flange (especially the installing
surface) or the lock
nut. Damage to these parts could result in wheel
breakage.
9. Hold the tool firmly.
IO. Keep hands away from rotating parts.
11. Make sure the wheel is not contacting the workpiece before the switch is
turned on.
12. Before using the tool on an actual workpiece, let it run for a while. Watch
for vibration or wobbling that could indicate poor installation
or a poorly
balanced wheel.
13. Use the specified surface of the wheel to perform the grinding.
14. Watch out for flying sparks. Holdthe tool so that sparks fly away from you
15. Do not leave the tool running. Operate the tool only when hand-held.
16. Do not touch the workpiece immediately after operation; it may beextremely
hot and could burn your skin.
17. Check the backing pad carefully for cracks, damage or deformity before
operation. Replace cracked, damaged or deformed pad immediately.
18. Hold the tool firmly.
19. Keep hands away from rotating parts.
20. Make sure abrasive disc is not contacting the workpiece before the switch
21. Do not leave the tool running. Operate the tool only when hand-held.
22. Do not touch the workpiece immediately after operation; it may beextremely
and other persons or flammable materials.
is turned on.
hot and could burn your skin.
SAVE THESE INSTRUCTIONS.
4

The foilowings show the symbols used for tool.
v ................................. volts
A ................................. amperes
Hz ................................. herts
kg
................................. kilograms
h ................................. hours
min
................................. minutes
S ................................. seconds
'TJ ................................. alternating current
- direct current
____
.................................
n, ................................. no load speed
................................. alternating or direct current
-
..............
................... Class II Construction
A ................................. splash-proof construction
AA ................................. watertight construction
... /min
@ ................................. number of blow
................................ revolutions or reciprocation per minute
5

Installing side grip (auxiliary handle)
CAUTION:
Always be sure that the tool is switched off and unplugged before installing or removing
Pressthe shaft lock to prevent spindle rota-
tion when installingor removing accessories.
CAUTION:
Never actuate the shaft lock when the
spindle is moving. The tool may bedamaged.
the side grip.
Always install
the side grip on the tool
securely before operation. The side grip can
be installed in any of three positions on the
sides of the tool, whichever is convenient
and keeps the guard properly positioned.
Always holdthetool's switch handleandthe
side grip firmly with both hands during
operation.
Shaft lock
6

Installing or removing abrasive disc
CAUTION:
Always be sure that the tool is switchedoff and unplugged before installing or removing
the disc.
NOTE:
Use sander accessories specified in this manual. These must be purchased by separate.
Mount the rubber pad onto
the spindle. Fit
the disc
on over the rubber pad and screw
the lock nut onto the spindle.
To tighten the lock nut, pressthe shaft lock
firmly
so that the spindle cannot revolve,
then use the lock nut wrench and securely
tighten clockwise.
Lock nut
. ._
Abrasive disc
Rubber
pad
I
r- --
Lock nut wrench
I
\
Shaft lock
To remove the disc, follow the installation procedure in reverse.
7

IF USED AS A GRINDER
NOTE:
Use grinder accessories specified
in this manual. These must be purchased by separate.
WARNIN
G :
Always use guard assembly or accessory kit, noted below, for type 27 depressed center
wheel.
Guard assembly Guard accessory kit
Part
No. 192578-8 ... For 180mm (7")
Part No. 192588-5
... For 230 mm (9")
Part No. 192606-9 ... For 180 mm (7")
Part No. 192607-7
... For 230 mm (9")
Installing wheel guard
CAUTION:
Always be sure that the tool is switchedoff and unplugged before installing or removing
the wheel guard.
When using adepressed center wheel or an
abrasive cut-off wheel, always use a wheel
guard. Mount the wheel guard withthe tab
on the wheel guard band aligned with the
notch on the bearing box. Then rotate the
wheel guard
160 degrees counterclockwise.
Be sure to tighten the screw securely.
wheel guard
Installing or removing depressed center wheel
CAUTION:
Always be sure that the tool is switched off and unplugged before installing or removing
the wheel.
Mount the inner flange onto the spindle.
Fit
the wheel on over the inner flange and screw
the lock nut onto the spindle.
Lock nut
Depressed
center wheel
Inner flange
8

To tighten the lock nut, press the shaft lock
firmly
so that the spindle cannot revolve,
then use the lock
nut wrench and securely
tighten clockwise.
To removethe wheel, follow the installation
procedure in reverse.
Switch action
To start the tool, simply pull the trigger.
Release the trigger to stop. For continuous
operation, pullthe trigger and then push in
the lock lever.
To stop the tool from the
locked position, pull the trigger fully, then
release it.
Lock nut wrench
Lock lever
CAUTION:
Before plugging in the tool, always check to see that the switchtrigger actuates properly
and returns to the
“OFF” position when released.
Operation
CAUTION :
After use, always switch off and wait for the wheel to come to a complete stop before
placing the tool down.
Holdthe tool firmly.Turn the tool
on andthen
apply the wheel or disc to the workpiece.
In general,keeptheedge of thewheel or disc
at an angle
of about 15O to the workpiece
surface.
During
the break-inperiodwithanew wheel,
do not work
the grinder in the 6 direction or
it will cut intothe workpiece. Once the edge
of the wheel has been rounded off by use,
the wheel may be worked in both A and
B
directions.
9

WARN I NG :
It should never be necessary to force the tool. The weight of the tool applies adequate
pressure. Forcing and excessive pressure could cause dangerous wheel breakage.
Continued use of a worn-out wheel may result in wheel explosion and serious personal
injury. Depressed center wheel should not be used after
it has been worn down to
115 mm (4-1/2") in diameter. Use of the wheel after this point is unsafe and it should
be removed from service and rendered unusable by intentional destruction.
10

MAINTENANCE
CAUTION:
Always be sure that the tool
is switched off and unplugged before attempting to perform
inspection or maintenance.
Replacing carbon brushes
When the resin insulating tip inside the
carbon brush is exposed to contact the
commutator, itwill automatically shut off the
motor. When this occurs, both carbon
brushesshould be replacedat thesametime.
Use
only identical carbon brushes.
Useascrewdriverto removethe brush holder
caps. Take out the worn carbon brushes,
insert the new ones and secure the brush
holder cam
Insulating tip
\I-
Commutato
-Carbon brush
J
Brush holder cap
To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjust-
ment should be performed by MakitaAuthorized or Factory Service Centers, always using
Makita replacement parts.
11

ACCESSORIES
CAUTION:
These accessories or attachments are recommended for use with your Makita tool specified in this
manual. The
use of any other accessories or attachments might present a risk of injury to persons.
The accessories or attachments should be used only
in the proper and intended manner.
0
@Wheel guard @Depressed center wheel (1 per pkgl
Part No. Size 1") Size 1")
180 x 6 x 22
17" x 114" x 718")
230 x 6 x 22
19" x 1/4" x 7/8"1
741425-6
741421-4
165191-5 180 17")
164879-4 230
19")
@Inner flange 89
(For depressed center wheel)
Part
No. 224317-9
@Lock
nut 518"-40
(For depressed center wheel)
Part No. 224509-0
12

@Rubber pad
Part
No. 743012-7
Part
No.
742067-A-5
742069-A-5
@Abrasive disc (5 per pkgl
Grit Diameter (mm)
16
24
@Sanding lock
nut 48
(For abrasive disc)
Part No. 224517-1
@Wire cup brush
7420894-5
1 ;: 1 180 (7")
742070-A-5
742071-A-5
1 ,:: I
742091-A-5
@Flexible grinding wheel
110 per pkg)
Part
No. Diameter (mm) Size
lmml
150 16")
18Ox 3 x 22
(7" x 118" x 718")
(includesone
back up pad, @
Part No. 743027-4)
741442-6
@Urethane washer
14
Part No. 261039-0
@Plastic pad
Part
No. 743027-4
When usingwire brush, mount urethanewasher
14to the spindle. It will make it easier to remove
wire brush.
@Hubbed grinding wheel Lock
nut wrench 28
Part No. 782412-6
-
Grip 36
Part No. 152539-0
Part No. Grit Size
741415-A
9" x 114" x 518"
13

Sep-10-'98 us
ANGLE SANDER
Model 9060L
27
Note: The switch and other part configurations
may differ from country to country.
14

MODEL 9060L
$;M &, DESCRIPTION
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
ITEM NO.
NO. USED
1
2
2
1
I
2
1
1
1
I
4
1
1
I
1
1
1
1
1
I
MACHINE
~
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
-
1
I
1
4
1
1
I
1
1
1
1
1
1
1
4
I
2
1
1
-
Hex Socket Head Boll M5x10
comprerston
Spring 12
PO" cap
Tapping screw 5x35
Retaining Ring S-9
Spiral Bevel Gear 12
Ball Bearing 6301DDW
Bearing Retainer 57
Fan 80
ARMATURE ASSEMBLY
IWith Item 9. 11 & 121
ln~ulsmn Washer
Ball Bearing
6200DDW
Baffle Plats
FIELD ASSEMBLY
Tapping Screw 4x25
Handle Set IWith llem
291
Tapping Screw 5x60
Makita
Label
Molar Housing Complete
Sep.-10-'96 us
DESCRIPTION
Makita Label
Brush
Holder Cap
A.C. Carbon Brush
Name Plate
Switch
Tapping Screw 4x18
Slrain Reliel
Cord
Cord Guard
Handle SeI IWilh Item 161
Tapping Screw CT 5x16
Spindle Complete
Bearing Box
Ball Bearing 6203DOW
Ralsining Ring R-40
Spiral Bevel Gear 50
Hex.
Socket Head Boll M5x10
Grip 36 Complele
Gear Housing Complete
P," 8
NowThe
switch and other part specifications may ddfer from couni~y to country.
15

MAKITALIMITEDONE YEAR WARRANTY
Warranty Policy
I:very Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to
be Free of defects from workmanship and materials for the period of ONE YEAR from the date
of
original purchase. Should any trouble develop during this one-year period. return the COMPLETE
tool. freight prepaid,
lo oneof Makita’s Factory or Authorized Service Centers. If inspection show
the trouble is caused by defective workmanship or material. Makita will repair (or at our option.
replace) without charge.
ThisWarranty doesnot apply where:
8 repairs have been made or attempted by others:
8 repairs are required because of nomial wear and tear:
8 The tool has been abused. misused or improperly maintained;
8 alterations have been made to the tool.
IN NO EVI;NT SHALL MAKITA BE LIABLE FOR ANY INDIRIKT, INCIDI<NTAL OR CON-
SEQUENTIAL DAMAGES FROM THE SALEOR USE
OF THE PRODUCT. THIS DISCLAIMI:R
APPLIES BOTH DURING AND AFTER THETERM
01: THIS WARRANTY.
MAKITA DISCLAIMS LIABILITY
I:OR ANY IMPLIED WARRANTIES. INCLUDING IMPLII..D
WARRANTIES
OF “MERCHANTABILITY” AND “FITNESS FOR A SPI:CII’IC PURPOSI.,”
AFTER THEONE-YIAR TERM
01: THISWARRANTY.
This Warranty gives you specific legal rights. and you may also have other rights which vary lrom
state lo slate. Some states do not allow the exclusion or limitation of incidental or consequential
damages,
so the above limitation or exclusion may not apply lo you. Some states do not allow
limitation on how long an implied warranty lasts,
so the above limitation niay not apply to you.
--I____ ____)_*----__-P-**f.~-~~------~
Makita Corporation
3-11 -8, Sumiyoshi-cho,
Anjo, Aichi
446-8502 Japan
884184 - 985 PRINTED
IN JAPAN
1998
- 9 - N
