Makita DTD137 User manual

DTD137
DTD148
EN Cordless Impact Driver INSTRUCTION MANUAL 4
SL Akumulatorski udarni vijačnik NAVODILO ZA UPORABO 12
SQ Vidhosës me goditje me
bateri MANUALI I PËRDORIMIT 20
BG Акумулаторен ударен
винтоверт
РЪКОВОДСТВО ЗА
ЕКСПЛОАТАЦИЯ 28
HR Akumulatorski udarni zavrtač PRIRUČNIK S UPUTAMA 37
МК Безжичен ударен одвртувач УПАТСТВО ЗА УПОТРЕБА 45
RO Maşină de înşurubat cu
impact cu acumulator MANUAL DE INSTRUCŢIUNI 54
SR Бежични ударни одвртач УПУТСТВО ЗА УПОТРЕБУ 62
RU Аккумуляторный ударный
шуруповерт
РУКОВОДСТВО ПО
ЭКСПЛУАТАЦИИ 70
UK Акумуляторний ударний
шурупокрут
ІНСТРУКЦІЯ З
ЕКСПЛУАТАЦІЇ 79

1
2
3
1
1
2
1
1
1
11
AB
1
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
2

12
123
1
2
3
Fig.9
Fig.10
Fig.11
Fig.12
Fig.13
3

4ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model DTD137 DTD148
Capacities Machine screw 4 mm - 8 mm 4 mm - 8 mm
Standard bolt 5 mm - 16 mm 5 mm - 16 mm
High tensile bolt 5 mm - 14 mm 5 mm - 14 mm
No load speed Impact mode (Hard) 0 - 3,400 min-1 0 - 3,600 min-1
Impact mode (Medium) 0 - 2,100 min-1 0 - 2,100 min-1
Impact mode (Soft) 0 - 1,100 min-1 0 - 1,100 min-1
T mode 0 - 3,400 min-1 0 - 3,600 min-1
Impacts per minute Impact mode (Hard) 0 - 3,600 min-1 0 - 3,800 min-1
Impact mode (Medium) 0 - 2,600 min-1 0 - 2,600 min-1
Impact mode (Soft) 0 - 1,100 min-1 0 - 1,100 min-1
T mode 0 - 2,600 min-1 0 - 2,600 min-1
Rated voltage D.C. 14.4 V D.C. 18 V
Overall length 119 mm 119 mm
Net weight 1.2 - 1.4 kg 1.2 - 1.5 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Batterycartridge D.C.14.4 V Model BL1415N / BL1430 / BL1430B / BL1440 / BL1450 / BL1460B
D.C.18 V Model BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /
BL1840B / BL1850 / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionofresidence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
Intended use
The tool is intended for screw driving in wood, metal
and plastic.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ing to EN62841:
Model DTD137
Sound pressure level (LpA) : 95 dB (A)
Sound power level (LWA) : 106 dB (A)
Uncertainty(K):3dB(A)
Model DTD148
Sound pressure level (LpA) : 96 dB (A)
Sound power level (LWA) : 107 dB (A)
Uncertainty(K):3dB(A)
NOTE: The declared noise emission value(s) has
been measured in accordance with a standard test
methodandmaybeusedforcomparingonetoolwith
another.
NOTE: The declared noise emission value(s)
mayalsobeusedinapreliminaryassessmentof
exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).

5ENGLISH
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN62841:
Model DTD137
Work mode : impact tightening of fasteners of the
maximumcapacityofthetool
Vibration emission (ah) : 11.0 m/s2
Uncertainty(K):1.5m/s2
Model DTD148
Work mode : impact tightening of fasteners of the
maximumcapacityofthetool
Vibration emission (ah) : 12.5 m/s2
Uncertainty(K):1.5m/s2
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
andmaybeusedforcomparingonetoolwithanother.
NOTE:Thedeclaredvibrationtotalvalue(s)mayalso
beusedinapreliminaryassessmentofexposure.
WARNING: The vibration emission during
actual use of the power tool can differ from the
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
to this instruction manual.
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.
Cordless impact driver safety warnings
1. Hold the power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden wiring.
Fastenerscontactinga"live"wiremaymake
exposed metal parts of the power tool "live" and
could give the operator an electric shock.
2. Always be sure you have a rm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool rmly.
4. Wear ear protectors.
5. Do not touch the bit or the workpiece immedi-
ately after operation. They may be extremely
hot and could burn your skin.
6. Keep hands away from rotating parts.
7. Use auxiliary handle(s), if supplied with the
tool.Lossofcontrolcancausepersonalinjury.
8. Hold the power tool by insulated gripping
surfaces, when performing an operation where
the cutting accessory may contact hidden
wiring.Cuttingaccessorycontactinga"live"
wiremaymakeexposedmetalpartsofthepower
tool "live" and could give the operator an electric
shock.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product.
MISUSE or failure to follow the safety rules stated
in this instruction manual may cause serious
personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
