Parts Breakdown TW1000
Page 1 of 2 2/8/2008

Parts Breakdown TW1000
Fig # Part ID Part Name Quantity
1 421895-2 FRONT BUMPER, TW1000 1
2 154555-8 HAMMER CASE CPL., TW1000 1
3 256253-1 PIN 5, 6908DWA 2
4 253909-7 F. WASHER 35, 6910 1
5 231921-7 RING SPRING 22, TW1000 1
6 325587-4 ANVIL,TW1000 1
7 325415-3 HAMMER, TW1000 1
8 216002-8 STEEL BALL 4.8, NHP1310 32
9 253712-6 F. WASHER 36, 6910 1
10 233428-9 COMP.SPRING 45,TW1000 1
11 333112-7 RING, 6910 1
12 216010-9 STEEL BALL 10.3, 6910 2
13 324501-7 SPINDLE, TW1000 1
14 227149-3 GEAR 37, TW1000 2
15 256051-3 PIN 10, 6910 2
16 221815-4 S. GEAR, 6910 1
17 267170-0 FLAT WASHER 34, 2702 1
18 310154-8 BEARING BOX, TW1000 1
19 213459-4 O RING 32, HK1810 1
20 213855-6 O RING 95, TW1000 1
21 317841-0 HAMMER CASE COVER, TW1000 1
22 211137-0 BALL BEARING 6201LLU,4140 1
23 240003-4 FAN 80, 2012NB 1
24 516916-4 ARMATURE ASS'Y 115V, TW1000 1
25 681665-3 INSULATION WASHER, TW1000 1
26 211066-7 B. BEARING 6200LLB, BO4552 1
27 265345-5 HEX. BOLT M5X60, HM0810B 2
28 418814-7 BAFFLE PLATE, TW1000 1
29 526146-9 FIELD ASS'Y 115V, TW1000 1
30 154556-6 MOTOR HOUSING CPL.,TW1000 1
31 263005-3 RUBBER PIN 6,LS1013 1
32 345517-9 PLATE, TW1000 1
33 266157-9 H.S.H.BOLT M6X12, TW1000 2
34 282018-5 D-RING, TW1000 1
35 941151-9 F. WASHER 6, 5007NB 4
36 265538-4 H.S.H. BOLT M6X60, TW1000 4
36 265538-4 H.S.H. BOLT M6X60, TW1000 4
37 421896-0 REAR BUMPER, TW1000 1
38 183935-1 HANDLE SET, TW1000 1
39 911233-1 P.H. SCREW M5X20, 2030S 4
40 265995-6 TAPPING SCREW 4X18, 4323K 4
41 421897-8 BUMPER, TW1000 1
42 265995-6 TAPPING SCREW 4X18, 4323K 2
43 687063-9 STRAIN RELIEF, 4323K 1
44 654531-7 TERMINAL BLOCK 2P, N900 1
45 682564-2 CORD GUARD, 5007NLK 1
46 664251-5 N/A 1
47 183935-1 HANDLE SET, TW1000 1
48 263005-3 RUBBER PIN 6,LS1013 1
52 685725-3 N/A 1
53 861265-7 NAME PLATE, TW1000 1
54 181047-4 CARBON BRUSH SET 154,5402A 1
55 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
56 651572-4 SWITCH SL220SD-19 1
1,001 122727-3 N/A 1
1,002 824737-3 PLASTIC TOOL CASE, TW1000 1
5,001 810134-9 N/A 1
Page 2 of 2 2/8/2008
