Parts Breakdown 9227C
Page 1 of 3 2/8/2008

Parts Breakdown 9227C
Fig # Part ID Part Name Quantity
1 539168-0 SUPPORT ASS'Y, 9227C 1
1 539186-8 N/A 1
1 632679-5 SUPPORT COMPLETE, 9227C 1
2 634291-7 FIELD 115V, 9227C 1
3 416253-5 BAFFLE PLATE, 9227C 1
4 211031-6 BALL BEARING 608LLB, HR2400 1
5 681644-1 INSULATED WASHER, 9227C 1
6 516306-1 ARMATURE ASS'Y 115V, 9227C 1
7 240002-6 FAN 70, 9227C 1
8 285687-1 BEARING RETAINER 48, 9227C 1
9 211106-1 B. BEARING 6201LLB, 5007NB 1
10 961052-5 RETAINING RING S-12, 9218PBL 1
11 266012-5 TAPPING SCREW 5X35, HR160DH 4
12 266171-5 HEX. SOCKET HEAD BOLT M8X25,9227C 2
13 152490-4 GRIP 36, 9227C 1
13 153489-2 GRIP 36, 9557NB 1
13 416256-9 LOOP HANDLE, 9227C 1
14 415491-6 PIN CAP, 9523NB 1
15 233072-2 COMPRESSION SPRING 8, 9523NB 1
16 911221-8 P.H. SCREW M5X16, JR3000V 1
17 911211-1 P.H. SCREW M5X12, HM1500B 1
18 159951-5 GEAR HOUSING COMPLETE, 9227C 1
19 256446-0 PIN 6, 9015A 1
19 256504-2 SHOULDER PIN 9, 9227C 1
20 632783-0 LEAD UNIT, 9227C 1
21 652014-1 P.H. SCREW M4X8, 2708 1
22 816330-7 INDICATION LABEL 1
23 266038-7 TAPPING SCREW 5X70, HP2030 2
24 688110-9 MAGNET SLEEVE, 9227C 1
25 961012-7 STOP RING E-6, 2030S 1
26 255058-6 RIVET 2, 9227C 1
27 233002-3 COMPRESSION SPRING 3,9227C 1
29 182917-0 HANDLE SET, 9227C 1
30 664630-7 CORD 3X18X8 SJ, 9820-2 1
31 682502-4 CORD GUARD 8-85, HP1621F 1
31 682503-2 CORD GUARD 8-90, 9005B 1
31 682503-2 CORD GUARD 8-90, 9005B 1
32 687063-9 STRAIN RELIEF, 4323K 1
33 265995-6 TAPPING SCREW 4X18, 4323K 2
34 654571-5 TERMINAL BLOCK, 9227C 1
35 265995-6 TAPPING SCREW 4X18, 4323K 1
36 652014-1 P.H. SCREW M4X8, 2708 2
37 651282-3 SWITCH, 9227C 1
38 631226-9 CONTROLLER 100-130V, 9227C 1
38 631801-1 N/A 1
39 271417-6 DIAL 28, 9227C 1
40 182918-8 MOTOR HOUSING SET, 9227C 1
41 858695-1 NAME PLATE 1
42 191963-2 CARBON BRUSH CB-303 SET, 9227C 1
43 643750-0 BRUSH HOLDER CAP, HM1100C 2
44 819001-5 MAKITA LABEL, 9015A 2
45 226744-6 SPIRAL BEVEL GEAR 52, 9227C 1
45 227512-0 SPIRAL BEVEL GEAR 52, 9227C 1
46 962151-6 RETAINING RING R-32, 9005B 1
47 211106-1 B. BEARING 6201LLB, 5007NB 1
48 316896-2 HOUSING W/O BEARING, 9227C 1
49 266034-5 TAPPING SCREW 4X16, 9524NB 4
50 152552-8 SPINDLE COMPLETE, 9227C 1
51 743012-7 7 RUBBER PAD, 9217SPC 1
51 743052-5 PAD 165, 9227C 1
Page 2 of 3 2/8/2008

Parts Breakdown 9227C
51 743052-5 PAD 165, 9227C 1
52 182917-0 HANDLE SET, 9227C 1
53 265995-6 TAPPING SCREW 4X18, 4323K 4
1,001 783204-6 HEX WRENCH, 3705, HR5000 1
1,002 262542-4 SLEEVE 18, 9227C 1
1,003 794094-2 N/A 1
1,004 153489-2 GRIP 36, 9557NB 1
1,004 152490-4 GRIP 36, 9227C 1
5,008 782412-6 LOCK NUT WRENCH 28, GA7911 1
5,011 224517-1 LOCK NUT, 9227CY, 5,7 1
5,012 810134-9 N/A 1
