Malvern Instruments Zetasizer uV User manual

Zetasizer μV
Essentials
MAN0429 Issue 1.0 December 2008
English
Man0429-1.0 (Zetasizer uV Essentials).book Page i Friday, December 19, 2008 9:32 AM

© Malvern Instruments Ltd. 2008
Malvern Instruments makes every effort to ensure that this document is correct. However, due to
Malvern Instruments’ policy of continual product development we are unable to guarantee the
accuracy of this, or any other document after the date of publication. We therefore disclaim all
liability for any changes, errors or omissions after the date of publication. No reproduction or
transmission of any part of this publication is allowed without the express written permission of
Malvern Instruments Ltd.
Head office:
Malvern Instruments Ltd.
Enigma Business Park,
Grovewood Road,
Malvern,
Worcestershire WR14 1XZ
United Kingdom.
Tel + [44] (0)1684-892456
Fax + [44] (0)1684-892789
Windows XP is a registered trademark of the Microsoft Corporation.
Zetasizer, NIBS and M3-PALS are registered trademarks of Malvern Instruments.
Tygon is a registered trademark of Cole Palmer Instruments Company Limited.
Printed in England
Man0429-1.0 (Zetasizer uV Essentials).book Page ii Friday, December 19, 2008 9:32 AM

Addendum 0078-1.0 Page 1
Addendum to manual
Addendum number ADD0078-1.0
Date 18/09/2009
Manual number MAN0426-1.0 / MAN0429-1.0
Manual name Zetasizer APS Essentials manual / Zetasizer uV Essentials
manual
This Addendum presents new information for operating the Zetasizer APS and μV
instruments. The content should be read in-place of, or in conjunction with, the
sections indicated in the respective manuals. The information detailed will be
incorporated into the next manual release for the instrument.
Space required (Zetasizer μV)
Provide enough space to allow easy access to all components and connections. This
diagram shows the recommended space for a system.
ill 8309
Space required - Read in place of relevant section on page 2-3 of the Zetasizer
μV and Zetasizer APS Essentials Manual.
200mm
800mm
500mm
200mm 200mm

Page 2 Addendum 0078-1.0
Allow at least 800mm above the bench surface for access to the cell area. The sys-
tem dimensions are given below:
Space required (Zetasizer APS)
Provide enough space to allow easy access to all components and connections. This
diagram shows the recommended space for a system. Always place the (optional)
PTC-1 to the left of the instrument as the heat output is from the left side of the
PTC-1 and this will prevent hot air being directed towards the APS.
ill 8330
Allow at least 800mm above the bench surface for access to the plate holder area.
The system dimensions are given below:
Component Width Depth Height
Zetasizer μV 350mm 410mm 170mm
Computer and printer S e e m a n u f a c t u r e r ’ s d o c u m e n t a t i o n
Component Width Depth Height
Zetasizer APS 500mm 390mm 320mm
PTC-1 200mm 385mm 310mm
Computer Refer to manufacturer’s literature.
800mm
500mm
100mm
150mm
200mm
200mm

Addendum 0078-1.0 Page 3
Positioning the Instrument
Warning!
Do not position the instrument such that the power cord, where it exits the
product, is unreachable for disconnection.
Warning!
Do not obstruct the ventilation slots underneath the instrument, nor the
fans on the rear panel. Restricting airflow can damage the instrument or
cause overheating.
Replacing the system fuse
Warning!
Fuses must not be replaced by the operator. Only the supervisor or a
Malvern representative should attempt to change the fuse.
If the instrument does not power up, check the system fuses. These are located in
the mains power switch on the rear panel.
Before changing a fuse, disconnect the instrument from the mains power.
Pull the fuse holders out and replace any faulty fuses with ones of the following
specification:
Positioning the Instrument - Read in place of relevant section on page 3-1 of
the Zetasizer μV and Zetasizer APS Essentials Manual.
Replacing the system fuse - Read in place of relevant section on page 4-3 of
the Zetasizer μV and on page 4-2 of the Zetasizer APS Essentials Manual.
Rating:
Size:
T 2A HRC 250v (T = Time delay)
5mm x 20mm

Page 4 Addendum 0078-1.0

Zetasizer μV Essentials Page i
Introduction to this manual
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Using this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Access to the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Where to get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Site requirements
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Space required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Power requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Computer specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Additional services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Health and safety
General warnings and Safety regulations . . . . . . . . . . . . . . . . . . . . 3-1
Electrical warnings and Safety regulations . . . . . . . . . . . . . . . . . . . 3-1
PAT testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Power cords and Power safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Laser safety regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Temperature warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Sample handling warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Moving the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Disposal of the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Maintenance
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Cleaning the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Cleaning the Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Replacing the system fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Table of contents
Man0429-1.0 (Zetasizer uV Essentials).book Page i Friday, December 19, 2008 9:32 AM

Table of Contents Zetasizer μV Essentials
Page ii MAN 0429
Man0429-1.0 (Zetasizer uV Essentials).book Page ii Friday, December 19, 2008 9:32 AM

Zetasizer μV Essentials Page 1-1
1
Introduction
to this manual
Introduction
This manual covers the operation and maintenance of the Zetasizer μV particle
analyser.
Note
For the Zetasizer model, serial number, software and firmware version,
left-click the μV icon in the right corner of the status bar.
Using this manual
Read the Health and Safety information in Chapter 3 before using the instrument.
For more detail on the Zetasizer software, use its online Help. Each dialogue has a
Help button giving information about it. Advice buttons present more sample-
related content.
Menu commands
Software menu commands are referred to in the form main menu-menu item.
As an example, the command Configure-New SOP refers to selecting the New
SOP item in the Configure menu. Menu commands are shown in bold text.
Man0429-1.0 (Zetasizer uV Essentials).book Page 1 Friday, December 19, 2008 9:32 AM

Chapter 1 Introduction to this manual
Page 1-2 MAN 0429
1
Access to the instrument
Malvern personnel
Malvern personnel (service engineers, representatives, etc.) have full access to the
instrument and are the only people authorised to perform all service procedures
that may require the removal of the covers.
Warning!
Removal of the main covers by unauthorised personnel, even a supervisor,
will invalidate the warranty of the instrument.
Supervisor
The supervisor is responsible for the management and safety of the instrument and
its operation. The supervisor also trains the operators. They can perform all user
maintenance routines identified in Chapter 4.
The supervisor has access to a more detailed manual in English.
Operator
An operator is a person trained in the use of the system. The operator can perform
all user maintenance routines identified in Chapter 4, except changing the fuse.
Warning!
Failure to follow these guidelines could result in exposure to hazardous
voltages and laser radiation.
Where to get help
Help desk
Direct all queries regarding the system to the local Malvern representative initially.
Please quote the following information:
Model and serial number of the instrument (located on the rear panel).
The Zetasizer software version (select Help-About within the software).
Contact the United Kingdom help desk if the local Malvern representative is not
available. The direct line to the United Kingdom Helpdesk is [phone].
This help line is primarily English speaking.
Man0429-1.0 (Zetasizer uV Essentials).book Page 2 Friday, December 19, 2008 9:32 AM

Introduction to this manual Chapter 1
Zetasizer μV Essentials Page 1-3
Remote support
Malvern Instruments offers a remote support service over the Internet. (A direct
Internet connection must be available.)
Benefits include fast and efficient fault diagnosis, reducing downtime and costs.
Online user training is also available, plus software updates.
Malvern Website - www.Malvern.com
The Malvern website offers a comprehensive range of particle characterisation
resources for use by customers 24 hours a day, seven days a week.
Resources include software downloads, frequently asked questions, a knowledge
base and Application Notes, plus information on other particle characterisation
solutions that Malvern can provide.
Man0429-1.0 (Zetasizer uV Essentials).book Page 3 Friday, December 19, 2008 9:32 AM

Chapter 1 Introduction to this manual
Page 1-4 MAN 0429
Man0429-1.0 (Zetasizer uV Essentials).book Page 4 Friday, December 19, 2008 9:32 AM

Zetasizer μV Essentials Page 2-1
2
Site requirements
This is a copy of Chapter 2 of the manual MAN0429 issue 1.0.
Man0429-1.0 (Zetasizer uV Essentials).book Page 1 Friday, December 19, 2008 9:32 AM

Chapter 2 Site requirements
Page 2-2 MAN 0429
2
© Malvern Instruments Ltd. 2008
Malvern Instruments makes every effort to ensure that this document is correct. However, due to Malvern
Instruments’ policy of continual product development we are unable to guarantee the accuracy of this, or
any other document after the date of publication. We therefore disclaim all liability for any changes, errors or
omissions after the date of publication. No reproduction or transmission of any part of this publication is
allowed without the express written permission of Malvern Instruments Ltd.
Head office:
Malvern Instruments Ltd.
Enigma Business Park,
Grovewood Road,
Malvern,
Worcestershire WR14 1XZ
United Kingdom.
Tel + [44] (0)1684-892456
Fax + [44] (0)1684-892789
Windows 2000 and XP are registered trademarks of the Microsoft Corporation.
Zetasizer, NIBS and M3-PALS are registered trademarks of Malvern Instruments.
Tygon is a registered trademark of Cole Palmer Instruments Company Limited.
Printed in England
Man0429-1.0 (Zetasizer uV Essentials).book Page 2 Friday, December 19, 2008 9:32 AM

Site requirements Chapter 2
Zetasizer μV Essentials Page 2-3
Introduction
This document outlines site requirements for a Zetasizer μV. Ensure all these are
met before the instrument is delivered.
Environmental conditions
The site must be:
Indoors and away from strong light (windows).
Away from heat sources like radiators.
Well ventilated (for noxious materials).
On a horizontal vibration-free bench.
We recommend that the computer is positioned to the right of the instrument.
Space required
Provide enough space to allow easy access to all components. This diagram shows
the recommended space for a system.
ill 8309
200mm
800mm
500mm
200mm 200mm
Man0429-1.0 (Zetasizer uV Essentials).book Page 3 Friday, December 19, 2008 9:32 AM

Chapter 2 Site requirements
Page 2-4 MAN 0429
Allow at least 800mm above the bench surface for access to the cell area. The sys-
tem dimensions are given below:
Power requirements
The mains power supply must be clean and filtered. If necessary, fit an Un-inter-
ruptible Power Supply (UPS) to remove any spikes or noise. The power require-
ments are:
Power cords and Power safety
The notes in this section indicate best practice. Adhere to these when connecting
the instrument to the power supply.
Warning!
Do not operate this product with a damaged power cord set. If the power
cord set is damaged in any way, replace it immediately.
Warning!
Do not use the power cord supplied with this product on any other
products.
Power cord set requirements
Power cord sets must meet the requirements of the country where the product is
used. For more information, contact a Malvern representative.
Component Width Depth Height
Zetasizer μV 350mm 410mm 170mm
Computer and printer S e e m a n u f a c t u r e r ’ s d o c u m e n t a t i o n
Component Power requirement Power sockets required
Zetasizer μV ~ 90V-260V AC, 50/
60Hz, 100W
1
Computer See manufacturer’s documentation
Computer monitor See manufacturer’s documentation
Printer See manufacturer’s documentation
Man0429-1.0 (Zetasizer uV Essentials).book Page 4 Friday, December 19, 2008 9:32 AM

Site requirements Chapter 2
Zetasizer μV Essentials Page 2-5
General requirements
The following requirements apply to all countries:
The power cord must be approved by an acceptable accredited agency respon-
sible for evaluation in the country where the power cord set will be installed.
The power cord set must have a minimum current capacity of 10A (7A in Japan
only) and a nominal voltage rating of 125 or 250 volts AC, as required by each
country's power system.
The area of the wire must be a minimum of 0.75mm2or 18AWG, and the
length of the cord must be less than 3m.
The power cord must be routed so it will not be walked on, pinched by items
placed on or against it, or become wet. Pay particular attention to the plug, the
electrical outlet and the point where the cord exits the product.
Computer specification
As with any software, running other software at the same time may affect the speed
of the Zetasizer software.
Minimum recommended specification
Pentium P4 PC 2.8GHz, 512MByte RAM, 160GByte hard disk drive, 1024 x 768
screen resolution, CD-ROM drive, USB port, Windows XP Pro (SP2) operating
system.
Note:
A laptop computer must have a free USB port to operate with the system.
Networks
The PC running the Zetasizer software can be connected to a network, but the
Zetasizer software must be run locally.
Man0429-1.0 (Zetasizer uV Essentials).book Page 5 Friday, December 19, 2008 9:32 AM

Chapter 2 Site requirements
Page 2-6 MAN 0429
Additional services
Purge specification
If measuring samples at low temperatures there is a risk of condensation occurring
on the cell; this occurs when the measurement temperature is less than the ‘dew
point’ of the ambient air surrounding the cell being measured. This is particularly
likely in humid climates.
If this may be a problem the purge inlet port can be used to connect a dry air supply
i.e. a supply with a dew point below the target temperature. This removes any
moisture in the air immediately surrounding the cell and prevents condensation. If
using the purge inlet connector, the air or Nitrogen supply must conform to this
specification:
Compressed air to DIN 8573-1
Oil = Class 1
Water = Class 3
Particulate = Class 3
Pressure = 100 kPa g
Caution!
The purge air line supply must conform to the above specification. Failure
to meet this specification may result in permanent damage to the instru-
ment and invalidate the warranty.
Telephone socket specification
The telephone socket for remote support needs a direct Internet connection.
Laser safety
Zetasizer μV instruments are Class 1 laser products and as such, require no special
laser safety considerations during normal operation. However, during servicing
(which must be performed by a qualified Malvern representative), the servicing
engineer may be exposed to class 3b or above laser radiation. We therefore recom-
mend that the administrative controls recommendations of the Laser Safety Regu-
lations (IEC 60825-1(1993) +A1(1997)+A2(2001) are implemented.
Man0429-1.0 (Zetasizer uV Essentials).book Page 6 Friday, December 19, 2008 9:32 AM

Zetasizer μV Essentials Page 3-1
3
Health and safety
General warnings and Safety regulations
Warning!
The instrument or samples to be measured may be hazardous if misused.
Read and fully understand this section before operating the system.
Warning!
Use of the system in a manner not specified by Malvern Instruments Ltd
may impair the protection provided by the system.
The instrument must only be stored or operated in environmental conditions con-
forming to Chapter 2.
Electrical warnings and Safety
regulations
Warning!
The Zetasizer μV contains high voltage components. Only Malvern
trained personnel are permitted to remove its main cover.
The instrument is mains powered and all power cables and electrical sockets should
be treated accordingly. Do not place cables where they may become wet.
Should the instrument become wet (e.g. sample or dispersant is spilt), switch it off
and disconnect it from the mains power supply immediately. Scrupulously clean
and dry the instrument before re-applying power.
Man0429-1.0 (Zetasizer uV Essentials).book Page 1 Friday, December 19, 2008 9:32 AM

Chapter 3 Health and safety
Page 3-2 MAN 0429
3
Warning!
This product must be connected to a protective earth.
The metal parts of the optical unit and the accessories are earthed via a
protective earth connection.
PAT testing
If PAT testing is required, connect the earth lead to the earth stud underneath the
rear right-hand corner of the instrument. We recommend that the product is PAT
tested annually, or if it is suspected that its electrical safety has been compromised.
Power cords and Power safety
The notes in this section indicate best practice. Follow these when connecting the
instrument to the power supply.
Warning!
Do not operate this product with a damaged power cord set. Replace a
damaged power cord set immediately.
Warning!
Do not use the supplied power cord on any other products.
Power cord set requirements
Power cord sets must meet the requirements of the country where the product is
used. For further information on the requirements, contact a Malvern
representative.
General requirements
These requirements apply to all countries:
The power cord must be approved by an acceptable accredited agency respon-
sible for evaluation in the country where the power cord set will be installed.
The power cord set must have a minimum current capacity of 10A (7A in Japan
only) and a nominal voltage rating of 125 or 250 volts AC, as required by each
country's power system.
Man0429-1.0 (Zetasizer uV Essentials).book Page 2 Friday, December 19, 2008 9:32 AM
