Congratulations on the purchase of your new Barryvox®.
This user manual explains the functionality and use of the
Barryvox®. The Barryvox®is a revolutionary, sensor-controlled
avalanche transceiver, which is very easy to use. Additional
detailed information and advanced instruction may be found in
the Barryvox®Extended Reference Guide.
Register your Barryvox®and get a 3 year warranty
extension!
Register your Barryvox®today at www.Barryvox.com, to get
important information such as announcements about the avail-
ability of software updates.
After a successful registration your device is covered for 5 years
by warranty.
Barryvox®Transceivers – Made in Switzerland
Our heritage is compelling. Mammut and Barryvox®follow the
time-honored tradition of world-class precision products made
in Switzerland. From its design to its engineering and production,
this device is completely made in Switzerland.
This device is compatible with all avalanche transceivers that
comply with the EN 300718 standard and operate on a frequen-
cy of 457 kHz.
North America:
Mammut Sports Group Inc.
458 Hurricane Lane
Williston, US-VT05495
Phone [phone]
[email protected]
Europe:
Mammut Sports Group GmbH
Mammut Basecamp 1
DE-87787 Wolfertschwenden
Phone [phone]
[email protected]
Switzerland (Head Oce):
Mammut Sports Group AG
Birren 5, CH-5703 Seon,
Phone [phone]
[email protected]
mammut.com

USER MANUAL
BARRYVOX®
25
EN
HANDLING THE BARRYVOX®.............26
INITIAL SETUP .......................27
COCKPIT – OVERVIEW OF FUNCTIONS .....32
GROUP CHECK .......................34
SEND ..............................36
SEARCH ............................37
EXCAVATING THE BURIED SUBJECT .......40
ADDITIONAL INFORMATION .............41
DECLARATIONS OF CONFORMITY ........238
The following documents for the Barryvox®transceivers
are available at www.mammut.ch/BarryvoxManual:
Barryvox®User Manual
This user manual describes the SEND and group check
functions as well as the standard search mode.
In addition, you will find all information regarding
basic maintenance, warranty and repair as well as the
technical specifications.
Barryvox®Extended Reference Guide
The Extended Reference Guide is a comprehensive
resource of information for your Barryvox®. It includes
additional information that augments the user manual
concerning rescue techniques, and in particular the
alternate search mode. It is an important and valuable
resource for all educators.
Approval / Conformity
All information concerning approval and conformity is
available at the very end of this booklet.
USER MANUAL
BARRYVOX®

USER MANUAL
BARRYVOX®
26
EN
Like all transceivers, the Barryvox®contains shock sensitive
ferrite antennas. Therefore, you should handle it with utmost
care!
Store the device and the carrying system in a dry spot that is
protected from extreme cold or heat and direct sunshine.
Always check the result of the self- and battery test, pay atten-
tion to alert messages and carry out the group check.
It is your responsibility to frequently check your Barryvox® for
mechanical damage of the casing, proper function of the main
switch, battery compartment cover as well as cleanliness and
mechanical integrity of the battery contacts.
To ensure the proper performance of the transceiver, it is
highly recommended that you send your device to an official
Barryvox®service center once every three years for a func-
tional test. The recommended date of the next check can be
viewed under «Maintenance» in the shut down sequence of
the device. (see chapter «Periodic Checks» of the Barryvox®
Extended Reference Manual).
Interferences
Always avoid having other electronic devices (e.g. mobile
phones, radios, headlamps, cameras), metal objects (pocket
knives, magnetic buttons), or other transceivers close to (20
cm in SEND; 50 cm in SEARCH) your running avalanche
transceiver.
You should not wear clothing with magnetic buttons! Users of
pacemakers are advised to carry the device in a secure pants
pocket. Consult the manufacturer’s instructions with regard to
the impact on pacemakers.
When searching, hold the device at a minimum of 50cm
away from these objects and turn off any electronic
devices, if possible. It is highly recommended to turn OFF
mobile phones!
HANDLING THE BARRYVOX®

USER MANUAL
BARRYVOX®27
EN
Batteries
Only use alkaline (LR03/AAA) batteries of the same type.
Always insert 3 new batteries of the same type. In case these
batteries need to be removed, the same 3 batteries or 3 new
batteries must be reinserted. Never use rechargeable batteries
and always replace all the batteries at the same time.
Make sure the lid is properly closed and that the device and the
batteries stay dry
Use a fingernail or the leash clip to slide battery door to the left,
and it will swing open.
2
1
2
1
Periodically inspect the battery compartment. Clean or dry it, if
needed, since moisture can cause corrosion.
Avoid touching the contacts with your hands, use a clean cloth.
A reliable power supply is crucial for safe operation.
When storing or not using the transceiver for an extended
period of time (summer, travelling,
shipping), remove alkaline batteries and leave the battery
compartment
open. The warranty becomes void if batteries have leaked!
INITIAL SETUP

USER MANUAL
BARRYVOX®
28
EN
Main Switch OFF / SEND / SEARCH
The main switch is located on the top side of the device. In the
left position OFF, the device is turned off, in the center position
SEND the device is in SEND mode and in the right position
SEARCH, the device is in SEARCH mode. For safety reasons, it
is required to press the hinged unlock button to leave the SEND
mode. To return from SEARCH to SEND, simply push the main
switch sideways.
SEARCH –>SEND SEND –>OFF
OFF –>SEND SEND –>SEARCH
Always make sure that the switch locks into position mechani-
cally to avoid an undesired change of mode.

USER MANUAL
BARRYVOX®
29
EN
User Interface and Use of Buttons
The use of the Barryvox®is easy and straightforward. All user
interaction is done with the button on the front side. To
confirm your selection, use the orange button. The action
triggered by pressing the button is shown at the bottom
left of the screen.
Samples:
Press the button to…
…activate group check.

USER MANUAL
BARRYVOX®
30
EN
BarryLeash
Attach the BarryLeash to the bottom of the device.
Start-Up / Self- and Battery Test
While starting, the device conducts a self test. The result of
the self-test is shown the first time the device enters a SEND
mode.
If the battery power falls below 20% or the battery icon is
displayed , the batteries must be replaced as soon as possible!
The meanings of the different alert messages are described in
detail in the Barryvox®Extended Reference Guide.
1. 2. 3.
Carrying Positions
Adjust the BarryMount to fit your body. Regardless of the carry-
ing position, the display should always face your body!

USER MANUAL
BARRYVOX®31
EN
Carrying the Transceiver in a Pocket
If you carry the Barryvox®in a pants pocket, the zipper must
remain closed for the duration of the
trip. Always use a secured pocket (see illustration). The wrist
loop should be secured to your pants or around your belt.
BarryMount (Recommended Carrying Position)
The BarryMount should be put on over your innermost layer of
clothing prior to beginning the trip (see illustration) and must be
worn on your body for the duration of the trip. The transceiver
must always remain covered by one layer of clothing. The
device itself is inserted into the BarryMount according to the
illustration. It should always remain attached to the holster
using the clip of the BarryLeash.

USER MANUAL
BARRYVOX®
32
EN
Turning the Device ON and OFF
Firmware Version (Barry Brain)
Group Check: enter group
check by pressing the key
The device shuts down 3
seconds after the main switch
has been moved to the OFF
position.
Press the key to access
device and maintenance info.
COCKPIT – OVERVIEW OF FUNCTIONS
W-Link Region (see chapter
«Additional Information»)
Year of the next periodic check
(see chapter «Handling the
Barryvox»)

USER MANUAL
BARRYVOX®
33
EN
Group Check
Leader
Participant
Status information or
instructions for the leader.
Exit Group Check and enter
SEND mode by pressing the
key
SEND
Remaining battery
percentage
The device is currently
in SEND mode
SEND mode status
Self test status information.
Alert messages.
(Status information disappears
after 10sec in SEND mode)
SEND mode functions
properly.
Alert:
the SEND function
is compromised and
transmits with reduced
power.

USER MANUAL
BARRYVOX®
34
EN
1 m
3 m
Simple Group Check
Before a party takes off, the transceivers of all party members
must be checked. The participants switch their device to SEND
mode.
The group leader activates the group check by switching their
device from OFF to SEND and presses the button within
the first seconds.
GROUP CHECK
Participants –>SEND
Leader –>Group Check

USER MANUAL
BARRYVOX®
35
EN
The test is successful if you can clearly hear beep sounds from each participant‘s transceiver
within the range indicated on the display.
The members of the party must be spread out appropriately to avoid mutual interference.
The indicated test distance must not be shortened, or the group check becomes very unreliable.
Once all the participant‘s devices are tested, the group check is concluded. The group leader’s
transceiver must be switched to the SEND mode.
If no tone is heard within the indicated range, the device must not be used.
Further procedure: 1. Check if the device is switched to SEND.
2. Replace the batteries.
3. Have the device checked by the manufacturer.
Chapter «Maintenance and Repair» in the Barryvox®Extended Reference Guide).
If your Barryvox®detects that the transmit frequency of the tested device is out of tolerance, a
warning message will be shown. In this case, repeat the test with 5m distance between the par-
ticipants to identify the defective transmitter. Such devices must be checked by the manufacturer.

USER MANUAL
BARRYVOX®
36
EN
The SEND mode is the normal operating mode outdoors or in
all other situations in which there is a risk of avalanches.
Each time the SEND mode is activated, this is
confirmed by an ascending triple beep sound.
Each individual signal pulse is tested. If the
test is successful, this is confirmed by a blink
of the red SEND-Control LED.
If the device detects that the SEND function
is compromised, the red SEND-Control LED
stops flashing and screen shows an alert
message.
To save battery power, the LCD screen is automatically deac-
tivated in the SEND mode, but can be activated any time by
pressing any button.
SEND

USER MANUAL
BARRYVOX®
37
EN
Signal Search
BarryTip: Move swiftly.
Emergency plan, search strategies and
search strip widths: please see back
side of device.
Search avalanche surface systemati-
cally.
During signal search, the rescuer has
their visual focus on the surface of the
debris in order to look for visual clues
on the snow surface. The first signal
is indicated by a distinct double beep
sound.
Coarse Search
BarryTip: Move swiftly, move in the
direction of the arrow.
Hold the transceiver with the extended
arm horizontally in front of you.
If the distance increases, then you are
moving away from the victim. Continue
the search in the opposite direction.
Distance below 10
BarryTip: Reduce search speed,
precisely follow the arrow.
1
2
Be aware that electronic devices including mobile phones used
by other rescuers may disturb the search. Therefore it is highly
recommended to switch off phones which are not absolutely
required!
SEARCH

USER MANUAL
BARRYVOX®
38
EN
1 2 3 4
SIGNAL SEARCH COARSE SEARCH >10 FINE SEARCH PINPOINTING

USER MANUAL
BARRYVOX®
39
EN
Fine Search
BarryTip: Follow the arrow! Step
slowly forward and backwards until
you have found the point of lowest
distance indication. Hold the device
at knee height.
Pinpointing
BarryTip: Place a visual indicator at
the point where you have found the
lowest distance indication. The visu-
al reference is important to probe in
a systematic pattern.
If the buried subject is hit with the
probe, leave the probe in the snow.
Mark the buried subject as «found» by pushing the
button after you have successfully located it witha probe
strike!
Multiple Burials
The marking feature allows to continue
the search for further buried subjects
by marking the previously located ones
as found. Excavate the buried subjects
already found while the search continues,
unless the burial depth is particularly deep. (See chapter «Mul-
tiple Burials» in the Barryvox®Extended Reference Guide).
Automatic Revert to SEND
For the safety of the rescuers, the device automatically switch-
es into SEND mode after 4 minutes without user interaction or
motion.
Leaving SEARCH Mode
After 4 seconds the device automatically
switches into SEND mode.
3
4

USER MANUAL
BARRYVOX®
40
EN
max. 1.5 – 2 m
2- 4 min.
max. 1.5 – 2 m
2- 4 min.
max. 1.5 – 2 m
2- 4 min.
The first rescuer positions him/herself directly at the probe. All
additional rescuers position themselves one shovel length from
each other in the direction of snow removal, thus typically in
the fall line.
The rescuer at the tip of the conveyor belt digs directly follow-
ing the probe to the buried subject, thus avoiding any chance
to miss it
BarryTip: in hard snow, cut blocks with the shovel. In case
of multiple burials, switch off the transceiver of the buried
subject as soon as possible.
EXCAVATING THE BURIED SUBJECT
1x SL
1x SL
SL = max. Shovel Length
Rotate!
