Mando Footloose Operating instructions

Mando Footloose user manual 2
Welcome!
You are the owner of
‘Mando Footloose’,
the city’s latest
transport system that will
change your lifestyle.”
“
This manual is prepared for you to use Mando Footloose properly
and give helpful tips for adjusting and maintaining the product.
It is very important to read this manual before using
Mando Footloose, so you can fully understand the product.
Please notice the safety information and warnings shown
throughout the manual. This will prevent injury or problems during
the operation of Mando Footloose.
If you need more information or have any additional inquiry, please
contact the store.
If there is any discrepancy between this manual and “parts
information from the manufacturer”, it is recommended to follow
“parts information from the manufacturer”.
Thank you for purchasing Mando Footloose and congratulations on
your wise choice.
Advantages of Mando Footloose
• Compact and refined design
• New generation of transport
• Comfortable ride
Contents
A. Introduction
A-1 Mando Footloose parts identification ————— 03
A-2 Checking the components ——————————— 04
B. Items to be checked before riding —— 05
C. Adjustment of the product
C-1 Adjustment of seat height ———————————— 06
C-2 Adjustment of handlebar ———————————— 07
C-3 Adjustment of brake —————————————— 08
D. Folding instructions
How to fold / tips for folding —————————————— 09
E. Riding instructions
E-1 How to ride ———————————————————— 10
E-2 Description of HMI display ——————————— 10
E-3 Setting the HMI modes ————————————— 11
F. Battery and charging
F-1 About battery maintenance ——————————— 12
F-2 About replacing the battery ——————————— 12
F-3 Description of the battery ———————————— 13
F-4 Before charging the battery ——————————— 14
F-5 Appropriate places for charging ———————— 15
F-6 Charging instructions —————————————— 16
F-7 How to check the charging status ——————— 17
F-8 Duration of charging ——————————————— 17
G. How to use the product properly
For the proper use of the product —————————— 18
H. Accessories ———————————————————— 21
I. Guarantee of quality
I-1 Application and limitation of the warranty——— 24
I-2 Registration of a genuine product ——————— 25
J. Specification ———————————————————— 25

Mando Footloose user manual 02
English
A new way of moving 03
Mando Footloose parts identification
A-1
Seat
Seatpost
Seatpost clamp
Rear frame
Folding lever
Alternator
Motor
Pedal
Rear wheel
Front frame
Center frame
HMI (Information Display)
Throttle lever
Handle grip
Handlepost height clamp
Handlepost
Handlepost folding clamp
Fork
Front wheel
15
16
17
18
19
14
7
8
9
10
11
12
13
1
2
3
4
5
6
Symbol Description
Safety: It represents safety warnings that may affect safety.
Warning: It represents cases which may cause death or serious injury
/ injury due to inappropriate handling.
Caution: It represents cases which may cause damage to the product due
to inappropriate handling.
Point: It represents key points for proper operation and maintenance.
Don’t: It represents actions that should be avoided for safety.
18
17
19
15
16

Mando Footloose user manual 04
English
A new way of moving 05
1. Tire pressure
45~55psi (MAX 70psi) / Use a proper pump when pumping air into the tires.
(The number is based on the original tire installed to the product. Air pressure
may vary with the type of tire)
- Excessive air pressure -> Uncomfortable riding quality
- Insufficient air pressure -> May cause a flat tire or inflexible handling.
2. Battery energy check
- The remaining amount of energy in the battery can be checked on the HMI
screen.
(For more information about charging the battery, please refer to ‘F. Battery
and Charging’)
3. Brakes
- Check that front and rear brakes work properly.
(Front brake -> left lever, rear brake -> right lever)
It works the opposite way in the U.K., Singapore and several
other countries.
- Practice braking by gripping the brake levers gently.
(Abrupt use of the brakes may cause injuries)
4. Seat height and handle height / adjustment and locking
- Incorrect seat height and handle height may cause uncomfortable riding and
handling and reduce a rider’s coordination of the bike which may potentially
cause injuries.
(For more information about adjusting seat height and handle height, please
refer to ‘C. Adjustment of the Product’)
- When the handlepost clamp / handlepost folding lever is not fixed tightly the
steering might be affected.
(The rider may lose balance and get injured)
5. Changing operating modes
- Practice changing the operating modes before riding. (For more information
about HMI setting including switching operating modes, please refer to ‘E.
Riding Instructions’)
6. Other safety checklist
- During night riding, ensure that the front / rear reflectors are fixed, clean and
working properly for identification and safety. Additional lighting is essential
in most countries by law.
- Ensure that your shoe strings are tied. (Untied shoe strings may be caught
up by a pedal or crankshaft)
- Ensure that each part of the bike is fastened properly for operation.
(Check the tightness and operation of all parts including the brake cable and pedals)
Loosely fixed screws or bolts may cause injury and excessively tight screws
or bolts may affect operation and cause damage to the product.
- Ensure that the front / rear wheels are correctly aligned.
-> Bounce the front / rear wheels by lifting it up 2~3 inches off the ground.
-> Rock the front / rear wheels side to side. If any movements or wobbles
are detected, do not operate the product.
B
Items to be checked
before riding
Before every ride, it is important to carry out a safety check to avoid any
problems.
Manipulating the brake lever
HMI-battery
Handlepost folding lever
HMI-Operating mode
If any defect listed in the checklist is
found, please contact the store.
Mando Footloose body
HMI (Information display) Bell Light Rear reflector
General battery charger
High speed battery charger
(sold separately)
Introduction
Checking the components
Before riding, check the components included in the box.
* The components of this product may be changed, without prior notice, to improve the function of the product.
A-2
User manual Stand
18
17
15
16

Mando Footloose user manual 06
English
A new way of moving 07
Adjustment of the
product
Adjustment of the handlebar
Mando Footloose has a foldable handle system for which you can adjust
the angle of the handlebar and its height.
1.Setting the handle height
The height at which a rider feels comfortable when going up and down a
slope or cornering
- If the handle is too low you may experience backache, neck pain or wrist
pain during a ride.
- If the handle is too high you may find the handling is unsteady during a ride.
2. How to adjust the handle height
- Loosen the lever of the handlepost clamp located under the handlebar.
- Adjust the handle to the desired height.
- After ensuring the alignment of the handle, tighten the clamp lever.
- Note : The tightness of the lever may be adjusted with the adjustment of a
screw on the other side of the clamp to the lever.
3. Finding the right angle of the handlebar
While holding the handlebar with the clamp bolts, set the angle of the handle
at which you can perform throttling and braking comfortably. Then re-tighten
the clamp bolts.
- If the angle of handle is not properly set, it may cause finger or wrist pain.
- Place fingers on the brake levers and adjust the angles so they lie parallel to
the extension line of the arm.
- Setting the angle of brake lever: Adjust it with the brake lever clamp bolts.
- Setting the angle of the throttle lever: Adjust it with the throttle bolts.
4. Adjustment of the brake lever
If it is hard to grab the handle due to your hand size, it is encouraged to
contact the store or a specialist to adjust the lever reach.
C-2
1) Check whether the sit front is on
the straight line with the handle post.
2) If the sit moves or goes down with the
lever closed, turn the nut beside the
clamp to clockwise
Note
It is important to adjust the brake prop-
erly so you can easily reach the brake
lever. It is recommended to set the brake
at which produces the best braking
power within the adjustment range of
the brake lever reach.
• If the brake lever reach is too short:
you may find it too stiff or hand pain.
• If the brake lever reach is too long:
it may not produce the best braking power.
Minimum insertion line
Handlepost clamp
How to adjust the seat post
1) Open the seat clamp lever
completely.
2)Adjust the height of the seat
post that fits the user (Do not
pull out the seat post beyond
the minimum insertion depth).
3)Close the lever.
Adjustment of seat height
For riding Mando Footloose, it is important to place the seat properly and
adjust the height. When adjusting the seat, adjust (1) the height first and then
(2) the front and back part of the seat.
1. Adjusting the seat up and down
How to check the seat height
1) Sit on the seat.
2) Put one heel on the pedal.
3) Adjust the seat height so that your heel is parallel to the axis of pedal and
you can almost straighten your leg (However, it is not recommended to
straighten your leg completely).
4) Get into and off from the seat when the product is standing.
Enquire at the store to learn how to adjust the optimum seat height. If you
would like to adjust the seat height by yourself, you have to ensure the fol-
lowing.
5) Ensure that the seatpost clamp is tightened properly.
6) Ensure that the seat post is not above the ‘minimum insertion’ line.
7) Ensure that the seat is not twisted to one side.
8) Ensure that the seat is properly clamped to the seatpost.
2. Adjusting the seat forward and backward
As the seat is adjustable in forward and backward directions, it enables an
optimal seat position.
For proper operation and better charging efficiency when pedaling with
Mando Footloose, it is recommended to set the pedal position so it can rotate
continuously. Adjust the seat forward and backward by aligning the imaginary
line vertically drawn from knee cap with the axis of pedal. Within this range,
find the most comfortable position.
3. Adjusting the seat angle
Most riders prefer the seat parallel to the ground. However, some prefer to
raise or lower the front part of the seat. If you have pain while sitting on the
seat, lowering the front part of the seat may help reduce it (however, the
center of gravity may move to the front).
The seat fastening clamp of Mando Footloose is in the form of 2 bolts; 1
at the front and 1 at the back. Adjust the seat to ensure that the seat lies
horizontally or at a preferred angle by screwing the front and back bolts in
turns. A little difference gives a large effect on the performance and comfort of
Mando Footloose.
Although the seat height has been properly adjusted, you may feel uncom-
fortable while riding if the slope and front/back position of the seat are not
balanced. Also, the seat provided with the product may not fit to your body. In
this case, it is encouraged to ask assistance of a specialist at the store.
C-1
Adjustment of the
product
The first point to consider before a ride
is to adjust Mando Footloose to your
body. Proper adjustment allows comfort-
able riding and safety. Should you have
any difficulty with the adjustment, please
contact the store. Even though you
have completed the fitting (adjustment
of Mando Footloose to yourbody) with
proper skills and tools, it is encouraged to
confirm your adjustment with the store.
Adjustment of the seat
Minimum insertion line
If Mando Footloose is improperly fitted,
you may lose control or get injured such
as joint injury during a ride.
The seat is designed for general sizes;
therefore, it does not correspond to every
rider’s pelvic shape and sitting habits. If
you are unable to find a comfortable posi-
tion, and it causes consistent pain even
after seat adjustment, it is encouraged to
replace it with another type of seat.
After seat adjustment ensure that it is se-
cured properly before riding. before rid-
ing. Loosely placed seat clamp or seat-
post clamp may cause damage to the
seatpost. Due to this damage, you may
lose control and fall off the bike.
In some cases, riding with a improperly
positioned seat may cause minor or se-
vere injury (e.g. It may chafe skin and
cause prostate pain/numbness, knee
pain, etc) Should you feel uncomfortable
or have pain, stop riding and visit the
store for specialist assistance.
Tighten clamp bolts properly. Loosely
screwed bolts may cause wobbling and
fatigue during a ride, or may cause you to
fall off from the bike.

Mando Footloose user manual 08
English
A new way of moving 09
Adjustment of brake
How to use the
product properly
1. How to use the brake
3. How to replace the pad
A pad should be replaced when its total thickness is less than 3 mm.
① How to remove the old pad
Back the inner adjustment knob all the way out (counterclockwise). Pull the pad spreader clip from
between the pads, then pull the pads out of the caliper one at a time.
② Install a new pad and spring
Insert the new pads one at a time into the caliper.
C-3
1) Right lever = rear brake 2)
For stable use, it is recommended to use the
throttle with your thumb, grab the brake lever
with your forefinger and middle finger, and use
the rest of the fingers to grab the grip.
3) Left lever = front brake, use the same
method
2. How to adjust the brake reach
1) Use a 2mm hex wrench to adjust the
brake reach.
2) Initial position 3) The brake reach has been adjusted
(adjust the brake reach according to the
length of your fingers)
How to fold/ tips for folding
Mando Footloose is designed to be foldable so the volume of the product can
be reduced to allow easier storage and transport. Folding can be done by
operating the folding lever located in the center.
1. How to fold Mando Footloose
1) Ensure that the power is off. 2) It is recommended to stand on the left
side of Mando Footloose with the front
wheel heading forward.
Folding instructions
D
3) To fold the handlepost, loosen the
handlepost clamp folding lever and lift
the whole clamp upward.
4) When the handlepost clamp is lifted,
the whole handlepost can be folded
backward to its left side.
5) Check that the right pedal is forward the
cranks horizontal (incorrectly aligned
pedals may damage the frame).
7) Hold the position of rear wheel with
your right foot against the tire so Mando
Footloose does not move during folding,
and fold Mando Footloose by lifting the
seat or centre frame up.
8) Hold the seat or frame with your left
hand and push down the folding lever to
the ‘fixed position’ with your right hand.
9) Roll Mando Footloose by holding the seat.
OFF
6) Unlock the folding lever located in the
center frame by pulling it up (hold the
upper part of the front frame with your
left hand and lift the folding lever with
your right hand).
2. Unfolding Mando Footloose: Reverse the steps above.
Make sure to place the black pad on the inner side (towards the wheel), and blue pad on the
outer side (away from the wheel).
Once the pad is installed on the caliper, slide the pad spreader clip back to its initial position
(between the pads).
BB7 and BB5 Installation & Set-Up Guide English
13SRAM 5002 yluJnoitaroproC
PAD REPLACEMENT (BB5 ONLY)
A pad should be replaced when its total thickness (backing plate and friction material) is less than 3mm.
1. REMOVE THE OLD PADS
Back the inner adjustment knob all the way out (counterclockwise). Pull the pad spreader clip from between the pads, then pull
the pads out of the caliper one at a time.
2. INSTALL THE NEW PADS AND SPREADER
Insert the new pads one at a time into the caliper.
V
ERY IMPORTANT : M AKE SURE YOU PLACE THE BLACK PAD ON THE INNER SIDE ( TOWARDS THE WHEEL ) AND THE BLUE PAD ON THE OUTSIDE
( AWAY FROM THE WHEEL .) O NCE THE PADS ARE IN THE CALIPER YOU CAN SLIDE THE SPREADER CLIP BACK INTO POSITION – BETWEEN THE PADS .
Pad spreader
Pad
A detailed picture about the pad
spreader clip
Blue pad “Right”
Black pad “Left” Tips for folding / unfolding
①
Ensure that the power is off before folding / unfolding.
②
Do not turn the power on during folding.
③
After unfolding, lock the folding lever so it is closed properly. If the folding lever is not fixed completely, it may
cause a problem during a ride.

Mando Footloose user manual 10
English
A new way of moving 11
Alarm: Mando Footloose has an alarm function that shows a critical status of the product.
2.
When the product has a problem (may be self-detected) 1. Alarm for the remaining battery capacity
When the product has a problem, a red warning sign will
appear in the top right area as shown in the picture above.
If the warning sign does not disappear after turning the
HMI on / off (more than once), stop using the product and
contact the store.
Riding instructions
Setting the HMI Modes
E-3
- When the product is turned on, it is automatically set to ‘Auto’ for transmission setting, ‘Normal’ for riding settings and ‘Soft’ for pedaling settings.
- The ‘Auto’ mode of the transmission setting allows for automatic transmission, and it is automatically set to Auto 2 when turned on and as Auto 1 when going
down a slope.
if under the same rpm (number of pedal rotations)
Slow acceleration
/ low battery use
Fast acceleration
/ high battery use
Pedaling settings
if under the same rpm (number of pedal rotations)
Smooth pedaling
/ low power generation
Heavy pedaling
/ high power generation
Transmission setting 1
(Manual transmission
-> Automatic transmission)
Automatic transmission
‘Select’ button ‘Mode’ button
HMI
Charge the battery as soon as possible if the screen in the
picture above appears.
Low Battery
Please charge
the battery
Transmission setting 2
(Automatic transmission
-> Manual transmission)
Riding settings
(Riding by pedaling only)
Low speed / high torque
Manual transmission
High speed / low torque
How to ride
Mando Footloose allows two ways of riding.
1. Riding Mando Footloose by pedaling
Start Mando Footloose off by pedaling as if so for general bikes.
Mando Footloose accelerates proportionally to the number of pedal rotations.
2. Riding Mando Footloose by throttling
Start Mando Footloose off by pushing the throttle lever slowly with your
thumb. Mando Footloose accelerates proportionally to the degree of pushing
the throttle lever.
Riding instructions E-1
Ensure that the number of pedal rotations
does not exceed 90 rpm (rotations per min-
ute). Excessive number of rotations may re-
duce the lifetime and cause breakdown of
the product due to overload.
Check the degree of acceleration force by
operating the throttle lever. Injudicious oper-
ation of the throttle may cause an accident.
Do not operate the throttle in situations other
than riding (e.g.when rolling Mando Foot-
loose or standing).
The optimal range of the number of pedal
rotations is 30~60 rpm (charging information
appears on the screen when the number of
pedal rotations is greater than 30 rpm).
The maximum speed should not exceed
the maximum speed regulated in each
country, even when throttle lever is pushed
to its deepest point (when it is accelerating
to its maximum). The maximum speed may
vary with slope of the road, a head wind,
the body weight of a rider and/or charging
status.
E-2
Transmission settings
Auto: automatic transmission
Manual: manual transmission
Riding settings (applicable only when
pedaling)
Eco: slow acceleration / low battery use
Normal: average acceleration / average
battery use
Hard: fast acceleration / high battery use
Pedaling settings
Soft: smooth pedaling / low power generation
Medium: normal pedaling / normal power
generation
Hard: heavy pedaling / high power generation
Independent power generation
Power generated from the alternator by pedaling
Current speed
Current riding speed (km/h)
Trip distance Mileage (km)
*Initializing the mileage: Push the ‘Select’ but-
ton for more than 2 seconds.
Remaining amount of battery
Current remaining amount of battery
‘Mode’ button
Use to change between modes
‘Select’ button
Search the menu to select one of the following:
Automatic transmission set 1 -> auto trans-
mission set 2 -> setting Riding mode -> Ped-
aling mode (repeated)
‘Power On/Off’ button
Power On/Off (turning the bike on/off). Push the
button for more than a second to turn it on / off.
Total cumulative mileage
Total cumulative mileage
The function of the automatic transmission may be affected by the body weight of
a rider, road condition, slope of the road and / or wind.
Description of the HMI screen
HMI Main Screen
MODE SELECT
0
0368
1) Install the HMI to the
holder on the handlebar.
2) Fix the position by pushing
it completely until you hear
a Click
Click

Mando Footloose user manual 12
English
A new way of moving 13
F-1
F-2
Battery and charging
About maintaining the battery
The battery is located inside the rear frame.
① Do not leave the product in hot
areas such as inside a car or beside
a heater.
- If it is stored in hot areas,
the capacity of the battery may be
reduced which may shorten the
travelling range, and an internal safety
switch may be activated to disable the
battery for a time.
② Before storing the product for a long
period of time, ensure that the battery
is fully charged to ensure a longer
battery lifetime.
③ Do not operate the product at a
temperature below- 10°C.
- It may reduce the lifetime of the
battery.
④ Do not operate the product at a
temperature higher than 40°C.
- It may reduce the lifetime of the
battery.
About replacing the battery
If battery replacement is required, please contact the store or service center
(Battery replacement is a paid service).
The replacement schedule varies with the operating environment, temperature
or charging habits. However, the battery has to be replaced if the range per
battery charge becomes too short, the battery does not recover and the
performance of the product deteriorates.
(In the winter, the range per battery charge reduces due to low temperatures.
It recovers as the temperature goes up, so battery replacement is not
required).
① If you find any unusual circumstance
such as a smell or deformation of
the frame around the battery, stop
operating the product.
- If the product is operated under such
conditions, it may generate heat, or
cause a rupture or a fire. If you find
such problems, do not operate the
product and contact the store.
② Do not disassemble the product.
Do not deform or disassemble the
battery.
- It may generate heat, or cause a
rupture or a fire.
③ Do not store the product with a com-
pletely discharged battery for a long
period of time (over 3 months).
- This may be the cause deterioration
of the battery.
F-3
Battery and charging
Description of the battery
Even though the battery has a high qual-
ity its capacity decreases as it is charged
and discharged repeatedly; thus, a
replacement is necessary (as with any
other battery).
1. About the lithium-ion battery equipped in Mando Footloose
The battery equipped in Mando Footloose is a lithium-ion battery which pro-
duces a high output, leading to high capacity and performance. Compared
to the conventional nickel-cadmium cell or nickel-hydrogen cell, it can store a
high amount of electricity within a small-sized / light-weight battery.
2. Features of the battery
1) Batteries are susceptible to hot or cold temperatures. In a battery, charging
and discharging occurs by chemical reactions. The chemical reactions
are affected by the temperature and the performance of a battery is highly
influenced by hot climate in the summer and cold climate in the winter
(Avoid operating the product at a temperature below - 10°C or above 40°C.
It may reduce the lifetime of the battery).
2) A battery naturally discharges. The discharged amount is recovered after
charging before use.
3) A new battery may not show the best performance at first use. It will be
maximized after 2~3 times of use (if you don’t see any improvement,
contact the store).
3. Degradation during winters
The range may shorten or speed may decrease due to the low output in cold
temperature eg below - 10°C. However, it recovers as the temperature gets
warmer (when it is at the optimal temperature). Therefore, it is recommended
to keep the battery at room temperature before use.
4. How to maintain the battery when it is hot
Avoid charging the battery directly after a ride or charging in a hot place such
as near a heater. It may shorten the life or range. If the temperature of the
battery is too high, it may not function.
1) A lithium-ion battery discharges slowly compared to the conventional
batteries, but completely discharging it may reduce the lifetime of the bat-
tery. If you need to keep the battery for a long period of time (more than 1
month), keep it in a cool and dry place after fully charging it.
2) A lithium-ion battery is susceptible to high temperatures.
- Do not keep the battery in hot places such as inside a car under the sun
or beside a heater in winter time.
- Do not recharge a fully charged battery.
5. Factors that affect the lifetime of the battery
1) A lithium ion battery discharges slowly compared to the conventional
batteries, but completely discharging it may reduce the lifetime of the bat-
tery. If you need to keep the battery for a long period of time (more than 1
month), keep it in a dry place after fully charging it.
2) A lithium-ion battery is susceptible to high temperatures.
- Do not keep the battery in hot places such as inside a car under the sun
or beside a heater in winter time.
- Do not recharge a fully charged battery.
How to deactivate the Deep Sleep Mode
1) What is Deep Sleep Mode?
- It is an automatic protective function to use the battery for a long term. In
the case that the product is not in use for a long period of time, it is put in a
“Protection Mode” and the power cannot be turned on.
2) How to deactivate Deep Sleep Mode
 ① Connect the charger with the product
② Begin charging (for about 1 minute)
③ Disconnect the charger from the product
④ Deactivation of Deep Sleep Mode completed
- If the power is not turned on even after repeating the above steps
2-3 times, please contact the store or service center.

Mando Footloose user manual 14
English
A new way of moving 15
F-5
Battery and charging
Appropriate places for charging the battery
Despite the battery charging temperature
is between 0~30°C, when the battery is
stored at a place exposed to the direct
sunlight or directly after a ride, charging
cannot be initiated as the interior tem-
perature of the battery is out of the range
of possible charging temperature. It may
take up to 3 hours to reach the possible
charging temperature in a place with a
room temperature of 30°C.
Occasionally, charging the battery near
electric appliances like TV or radio may
cause noise in the radio or may distort
the image on TV. In this case, charge the
battery in a place away from the electric
appliances.
1. Appropriate places for charging the battery
Charge the battery at a place where the following conditions exist:
- A flat and stable place
- A place away from water or rain
- A place not exposed to direct sunlight
- A well ventilated dry place
- A place which children or pets cannot reach
- A place with a room temperature between 0~30°C.
However, during hot summer or cold winter time, charging may begin, but
may be discontinued. Try to charge the battery at a room temperature be-
tween 15~25°C, which is optimal for the battery.
1) Examples of appropriate places for charging the battery
- Summer: A shady and well-ventilated place (optimal temperature 15~25°C)
- W i n t e r : A warm place where the temperature is kept above 0°C at night
(optimal temperature 15~25°C) Charging is possible at a tempera-
ture between 0~30°C. However, if the interior temperature of the
battery is out of the range of possible charging temperature directly
after a ride, then it will enter a ‘standby state’ until the interior tem-
perature of the battery reaches the possible charging temperature.
2. Inappropriate places or ways for charging the battery
- Summer: Charging at a place exposed to the direct sunlight and charging
the battery directly after a ride. Even though charging may begin
normally, it may be discontinued when the temperature of the bat-
tery exceeds the possible charging temperature in order to protect
the battery. In this case, cool down the battery and charge the
battery again at a cooler place.
- W i n t e r : Charging outdoor, at a cold place such as a warehouse, or near
a heater. Even though charging may begin normally, it may be
discontinued when the temperature reaches below 0°C in order
to protect the battery. In this case, charge the battery at a warmer
place.
Before charging the battery
Cautions when charging the battery:
1) If a charging plug gets unplugged while charging, do not plug it back in
right away in order to prevent any possible false operation. Plug it back in
after 5~10 seconds.
2) Do not keep the Mando Footloose charger in a place where children or
pets can reach it.
- It may be dangerous or cause a fire due to their unexpected behavior.
3) Do not touch the power plug of the Mando Footloose charger or charging
socket with wet hands.
- The socket may be contaminated with foreign substances.
4) Always use the Mando Footloose (original) charger.
- If you use a charger other than Mando Footloose charger, it may generate
heat, cause a rupture or a fire. Do not use other types of chargers.
5) Do not use Mando Footloose charger for other electronic appliances.
- The Mando Footloose charger is designed only for Mando Footloose.
Even with the same type of socket, do not use the Mando Footloose
charger to charge other products. It may cause a fire or damage.
6) To maintain the Mando Footloose charger, keep the following in mind:
- Do not bind or roll the power cord when using it for charging. Do not
damage or make an alteration to the power cord. Do not bend or twist
the power cord by force.
- Do not put a heavy object on the power cord or do not fix the power cord
with a nail.
- Do not use a damaged power cord (a power cord with disconnected or
exposed wires).
It is very dangerous as it may cause a fire or electric shock. If you find any
defect, do not use it and contact the store.
7) Do not disassemble or rebuild the Mando Footloose charger.
- It may cause a fire or electric shock.
8) Do not place the Mando Footloose charger on a high surface such as a table.
- It may fall off the table and cause injury.
9) Do not leave the Mando Footloose charger connected to house hold
current.
- Dust accumulated on the electrical outlet may cause a fire. When the
Mando Footloose is not in use, keep the power cord unplugged from the
electrical outlet for safety.
10) Do not immerse the Mando Footloose charger in water or do not leave it
in rain.
- Using a charger that is wet is very dangerous as it may cause a fire. If
it is wet, unplug the power cord from the electrical outlet and have it
checked at the store.
11) Do not charge near inflammable vapours.
- It may cause a fire.
12) If Mando Footloose is not in use for more than 10 days, ‘Deep Sleep
Mode’ would be activated to protect the battery. It can be awaken by
charging the battery 1~2 times for 1 minute each.
F-4
Battery and charging
1) Ensure that the Mando Footloose
charger is placed on an even and
stable place.
- The power cord may be pulled by an
object, or it may fall off from a height,
and become malfunctioned.
2) Do not drop the Mando Footloose
charger from a height or hit it.
- It may not work properly or may get
damaged.
3) Do not put a cover or an object on
the Mando Footloose charger. Also,
do not use multiple Mando Footloose
chargers stacked or attached to
each other.
- The interior of the chargers may be-
come hot and may not work properly.
4) Do not step on the Mando Footloose
charger.
- It may cause a failure or damage.
5) Ensure that the sockets on the Mando
Footloose charger and the main body
are not wet or dusty.
- It may cause a failure in charging the
battery or damage. Always keep the
sockets clean.
6) Do not attach metal to the sockets.
- It may cause a failure.
7) Do not use the AC power of a car.
- Always use the household current to
charge the product.
8) Do not leave the Mando Footloose
charger connected to household
current after fully charged.
- It may cause a failure due to lightning
or other factors. When the Mando
Footloose charger is not in use, keep
the power cord unplugged from the
electrical outlet for safety.

Mando Footloose user manual 16
English
A new way of moving 17
F-7
Battery and charging
How to check the charging status
1. How to check the charging status
1) Indication by the charging lamp
2. Troubleshooting
1) Power LED is not ON
- Check if AC power is ON and if the power cord is plugged properly.
2) Red LED is not ON while charging the battery
- Check if the charger port is properly plugged.
3) Red LED does not change to green LED while charging the battery
- Check whether the room temperature is at the optimal temperature. If red
LED is still ON at the optimal temperature, it indicates that the battery has
a failure - contact the store.
4) Red LED changes to green instantly
- It indicates that the battery is fully charged. Otherwise, it indicates that the
battery has a failure - contact the store.
5) Green LED is ON even though the battery is not fully charged
- Repeat recharging the battery after completely discharging 2~3 times. If
you still have the same problem, contact the store.
Even though charging may begin normal-
ly, it may be discontinued when the bat-
tery temperature exceeds the possible
charging temperature in order to protect
the battery. In this case, cool down the
battery and charge the battery again at
a cooler place
Despite the battery is at between 0~
30°C, if the battery is charged at a place
exposed to direct sunlight or directly after
a ride, charging cannot be initiated
because the interior temperature of the
battery is out of the possible charging
temperature range.
2A General
Charger
4A High-speed charger
Left Lamp Right Lamp
Power Off Off Off Off
Standby Red Red Off
In Progress Red Red Red
Completed Green Red Green
F-8
Time to Charge
Using a general charger, it usually takes about 5.5 hours when the
battery icon on the HMI screen is completely empty (it takes about 3
hours when using a high-speed charger, sold separately).
* The time to fully charge a battery varies with the condition of the battery and the room temperature.
If you find any problem while charging a
battery, turn off the power of the charger
immediately, disconnect the charging
plug of the charger from the product, and
unplug the power cord from an electric
outlet.
* Charging a battery that has not been
used for a long period of time may
take longer and as long as the red
LED is ON, you may consider it as
working properly.
Charging Instructions
F-6
Battery and charging
Do not disconnect the charging plug from Mando Footloose while charging. It may
cause false operation or a failure.
If charging does not begin properly, turn off the power of the
charger and retry charging.
1) Ensure that the power of the charger is
‘OFF’. Plug the power cord into an
electric outlet.
4) Charge (the red lamp of the charger
is ON).
7) Disconnect the charging plug from
Mando Footloose.
2) Connect the charging plug to Mando
Footloose.
3) Turn on the power of the charger.
5) Charging completed (the green lamp of
the charger is ON).
6) Turn off the power of the charger.
8) Unplug the power cord from the electric
outlet.
2. 4A High-speed Charger
1) Plug the power cord into an electric
outlet.
2) Connect the charging plug to Mando
Footloose.
4) When charging is completed (the green
lamp of the charger means ON), disconnect
the charging plug from Mando Footloose.
3) Charge (the red lamp of the charger
means ON).
5) Unplug the power cord from the electric
outlet.
1. 2A General Charger

Mando Footloose user manual 18
English
A new way of moving 19
For the proper use of the product
How to use the
product properly
4. Safety Tips for Riding
1) Follow the road regulations and traffic rules in the local area.
2) Assume that others cannot see you during a ride.
3) Mind the cars that are moving slowly, turning and following, opening of
doors of parked cars, children and pets on the road.
4) Secure a clear view and mind obstacles on the road such as a construction
site, railroad or uneven road.
5) Before passing an intersection, stop temporarily at the intersection and look
at both directions.
6) Always follow the traffic regulations when turning or crossing a street.
7) Do not wear earphones during a ride.
8) Do not carry someone on your back during a ride. Do not link the product
with a towing device such as a trailer.
9) Do not install any equipment that may block the view or interrupt the
operation of Mando Footloose.
10) Do not obstruct pedestrians or cause fear by jumping out, driving danger-
ously or swerving intentionally.
11) Do not ride Mando Footloose after drinking alcohol.
12) Avoid riding Mando Footloose in bad weather.
13) Do not press the throttle lever while rolling Mando Footloose.
14) This product is designed to be operated on paved road. It is not
appropriate for riding on uneven roads, off road, racing, jumping or stunts.
Inappropriate use may damage the frame.
15) If too much pedaling speed is used (over 90 rpm) the internal circuit
protection may be over riden.
16) For braking, always use the right brake (rear brake) first and then the left
brake (front brake).
17) Depending on the repeated use of the brakes, the disk brakes may pro-
duce a noise. When it produces a noise, contact the store to adjust the
gap between the brakes.
18) Ensure that the folding lever is completely locked after unfolding Mando
Footloose. If the folding lever is not completely fixed, it may cause a
problem during the ride.
19) Do not operate the motor while braking.
20) Do not hit the HMI or detach it from the product while riding.
21) Do not turn the power off while riding.
22) Do not turn the power on while throttling.
23) If the distance going up a hill is too short, the gear may not shift to the
‘hill mode (the first gear)’ during a ride under the automatic transmission mode.
24) If the frame of Mando Footloose is deformed, the automatic transmission
mode may not operate properly.
25) If Mando Footloose is hit by something during a ride, the automatic trans-
mission mode may not operate properly.
26) After shifting to ‘hill mode’ (the first gear), the riding speed is limited
(low-speed and high-torque mode).
27) When riding up a hill at a low speed, the automatic transmission may not
operate properly.
28) Do not operate the product if it was disassembled and rebuilt by the user.
GG
How to use the
product properly
1. Safety tips: For safe riding, safety equipment required. Be
aware of the safety requirements (including the NATIONAL
TRAFFIC LAWS) and follow them.
1) Wear a helmet that meets the safety code. Follow the steps, instructions
and suggestions stated in the user manual.
2) Conduct a safety inspection with a specialist regularly.
3) Practice the operation of the product including pedaling, handling, braking
and throttling in advance.
4) Wear a pair of comfortable shoes. A lose cloth might get caught by the
product. Do not wear sandals or pedal with bare feet when riding the
product.
5) Use lights and wear bright colors so pedestrians or car drivers can notice
you when riding Mando Footloose at night.
6) Protect your eyes by wearing sunglasses when the sunlight is strong.
7) Wear safety equipment and use lights to meet local traffic laws.
8) Do not perform any stunts while riding. Stunts and dangerous actions can
bring instant excitement, but it may harm the product or cause injuries.
9) Operate the product at the appropriate speed depending on the circum-
stances. Higher speeds may increase danger.
10) The maximum weight of a rider for this product is 100 kg (including
personal belongings).
2. Motor and Alternator
1) Ensure that the number of pedal rotations do not exceed 90 times per
minute (Excessive rotations may cause a damage due to overheat).
2) Do not use high pressure washers to clean the product. Use a soft sponge.
3) The motor and alternator shouldn’t be submerged in water.
=> It is waterproof but only at the normal level for daily living.
4) Do not disassemble the motor or alternator.
If you disassemble the motor or alternator warranty will be void.
5) Do not operate the product in reverse direction at a speed higher than 5 km/h.
(Avoid reverse rotations. It may damage the product due to abnormal voltages)
3. Regular Maintenance
For safe use of Mando Footloose, have a maintenance service every 6
months at the store. Perform the first maintenance service within 2 months of
date of purchase.
Wear a helmet that meets the safety code
Safety equipment
For the proper use of the product
Do not disassemble
Avoid reverse rotations
Carrying lighting devices and reflective material on your Mando Footloose vehicle
is important for your safety. Seeing and to be seen while participating in traffic con-
ditions is key. All member states of the EU have their own dedicated local national
regulations with regards to lighting and reflection, the way how these should be
carried and the conditions and timing when these should be carried. Please make
sure you are fully aware of the national regulations which apply to your personal
situation and please make sure your vehicle is equipped with the proper lighting
and reflective material in conformity with these national regulations.

Mando Footloose user manual 20
English
A new way of moving 21
For the proper use of the product
How to use the
product properly
G
Securing a clear view
Cautions in rainy weather:
in rainy weather, it is hard for a tire to grip the road. Also, it is hard to secure the safety of the rider
and other car drivers due to low braking power and unclear visibility. Wet roads increase the risk of
accidents. Ensure the product is only used at low speeds and learn how to stop safely on a wet road,
by braking gently.
Suggestions for a night ride:
riding Mando Footloose at night is more dangerous than riding it during day time. Try to avoid riding at
night or in early mornings since a rider cannot be seen by other car drivers or pedestrians. For a ride at
night or in early mornings, use lights and wear safety accessories.
Use a light during a night ride.
Check regularly if the rear reflector is well attached to the product.
Do not remove the rear reflector. It is necessary for safety. Without the rear reflector, an accident may
be caused because a rider cannot be seen by car drivers or pedestrians. If you collide with a car, you
may be critically injured and even die. For a night ride, keep the following suggestions in mind:
- Wear a helmet that has reflective stripes on it. Attach a safety light to your body and Mando Footloose.
- Install a brightly colored light so you can easily be seen by car drivers or pedestrians.
- Ensure that the light and reflector is not blocked by any object.
- Ensure that the rear reflecting plate is installed properly.
- Ride at a slow speed for your safety.
- Avoid riding in a dark area or crowded place.
- Avoid riding off road or on uneven roads.
- Ride on familiar routes and protect yourself with defensive riding.
Replacement of parts, installation of accessories:
There are many kinds of parts and accessories that can improve the riding quality, performance and
design. However, you should be cautious when you replace parts or install accessories.
The safety is not ensured when parts are replaced and accessories are installed to Mando Footloose
because the manufacturer of Mando Footloose has not tested the compatibility between
Mando Footloose and these parts / accessories. Before installing any part, accessory or tire on
Mando Footloose, contact the store to check the compatibility. Read the manual of the part / accessory
to check the compatibility between Mando Footloose and the part / accessory.
If the parts / accessories are not compatible with Mando Footloose, do not install them. In appropriate
use of parts / accessories may cause a critical injury .
For replacement of parts, for safety and warranty service it is recommended to use the genuine parts.
Contact the store before replacing any parts / accessories.
It is important to tighten the nuts and bolts according to the accurate torque values. Always tighten
the nuts and bolts to the specified torque values. If a bolt is tightened too tight, it may be over-
stretched or deformed. Loosely screwed bolts may cause wobbling and fatigue during a ride. Thus,
tightening the bolts too tight or loose may damage the bolts. Make sure to use the accurately adjusted
torque wrench to tighten the bolts and nuts. If you don’t have a torque wrench, please contact the
store or the specialist.
Part Appropriate Torque Values
Handlebar clamp 8Nm
Handle grip 3Nm
Handle post 6Nm
Seat 6Nm
How to place a light
2) Open the cover of the light by pushing
the cover backward.
1) Check if all components are in the
package; a light, light holder, nut, and
batteries.
3) After placing batteries, close the cover.
4) Place the light holder on the desired
location of the handlebar.
7) Installation completed (Press the power
button for 2~3 seconds to turn the
power on and off).
6) Place the light on the light holder.
5) Put the tip of the band to the light
holder, and assemble the band and nut.
H
Accessories

Mando Footloose user manual 22
English
A new way of moving 23
1) Unscrew the bolt in the band part (use a
Phillips screwdriver).
3) Fasten the bolt after adjusting the
degree of fixation and angle (The angle
of the reflecting light should be perpen-
dicular to the ground).
2) Place the band part on the seatpost.
4) Installation completed.
2) Place the bell on the handlebar by pull-
ing the band part of the bell.
4) Installation completed.
3) Fasten the bolt with the nut by screwing
it clockwise.
1) Check if all components are in the pack-
age; a bell, Phillips bolt and a nut.
How to place a bell
How to place a rear reflecting plate
Be cautious, the nut easily falls off during installation.
How to use the stand
1) Place the pedal parallel with the ground. 2) Pull a rod with hand.
4) Move the rod until it is placed as shown
in the picture
.
3) Move the rod while pulling it.
5) Fix the rod to the ‘stop’ position of the
stand holder.
6) Repeat the same steps for the other rod.
7) Place the unfolded stand on the ground
so the rods stretch to the ground (When
folding the stand, follow the steps in
reverse order).
The maximum load capacity of the stand is 25 kg. If you ride on Mando Footloose or put
too much force on the product while it is on the stand, the stand may be damaged.
HH
Accessories Accessories

Mando Footloose user manual 24
English
A new way of moving 25
Guarantee of Quality I -1
I -2
J
6. How to repair the product during the warranty period
In order to repair the product during the warranty period, visit the store with
your Mando Footloose and its warranty certificate and apply for the warranty
repair. The certificate is required for the warranty repair.
7. The area covered by the warranty
This warranty applies only to the products purchased and used within the
country where Mando Footloose is bought. Therefore, the warranty expires
when it is transferred to another country.
8. Other
The warranty is a written guarantee, promising to repair or replace the product
if necessary within a specified period of time. Therefore, in principle, repair
for the damage occurred after the warranty period is chargeable. However,
for damages resulted from the manufacturer the manufacturer will repair the
product at a fair cost based on the conditions stated in the warranty and the
degree of the manufacturer’s responsibility. In such case, contact the store.
* Based on a ride by pedaling. Subject to change according to the conditions of operating environment
including the intensity of pedaling, the weight of the rider and the road condition.
How to register a genuine product
1) Enter the information in Certificate of Authenticity on the last page
2) Please hand in Certificate of Authenticity to a shop.
3) Registration of a genuine product is now completed.
Application and limitation of the warranty
Location of the serial number
Registration of a genuine product
Specification
To apply for the warranty, a genuine product must be registered.
Driving System Series Hybrid System Wheel Size 20”
Maximum
Speed 25 km/h Display Detachable HMI Display
(2.4” Color LCD)
Range Max. 35~45 km* Frame Aluminum
Motor Dual winding motor, 250W Fork Carbon fiber
Battery 36V 8.2Ah Weight 21.7 kg
Guarantee of Quality I -1
1. Warranty Promises
This warranty applies to the product that has defects in material or workman-
ship excluding consumable parts. The product will be repaired or
replaced free of charge according to the conditions specified below
(“warranty”):
2. Warranty period
Warranty period-2 years from the date of purchase
Parts applied for warranty-all parts of the product, excluding consumable parts
3. Items not covered by the warranty
1) The warranty does not cover the defect/damage specified below or
resulted from any of the the following circumstances:
① Small defects (sound, vibration etc) which do not affect the quality or function of the product
② A flat tire or cut made by nails or broken glass
③ When the user did not follow “the user’s responsibility” as stated below
④ Having inappropriate maintenance or service
⑤ Using a part that is not genuine or not approved by the manufacturer
⑥ Rebuilding the product or installation of parts that are not approved by the manufacturer and legislation
⑦ Accidents caused by collisions, falling off, rolling into a ditch or any other actions caused by the user’s
careless riding
⑧ Unintended use of the product such as racing, or off road use.
⑨ Operating the product in unusual circumstance such as on stairs where Mando Footloose cannot be
operated properly
⑩ Damage of parts due to prolonged use and ‘normal wear and tear’ (heating of the battery due to its
life time, natural discoloration of the painted or plated surface, heating of used parts)
⑪ External factors including vehicle exhaust, chemicals, bird droppings or damage from sea wind / water
⑫ Natural disasters such as an earthquake, typhoon, flooding or a fire
2) The manufacturer does not cover the following expenses or loss:
① Replacement, repair or additional cost of consumable parts (such as: tire, tube, wire, grip, brake shoe,
pedal, fuse, gasket, bolds and nuts, light bulbs, springs or similar parts)
② Expenses for maintenance, cleaning and repair
③ Repair costs at a store that is not approved by Mando Footloose
④ Expenses accompanied with the repair such as a telephone charge, shipping fee or car rental
⑤ Compensation for loss of business revenue or loss resulting from a malfunctioning product
4. Users Responsibility
In order to ensure proper functioning of Mando Footloose and operate it
safely, the user must meet the responsibilities stated below while bearing the
expenses associated with the responsibilities.
1) The proper operation of Mando Footloose
The proper operation based on the information about maintaining the
product and requirements (the maximum weight capacity(100kg) of a user)
stated in this manual.
2) Checking the product before a ride (refer to ‘B. Items to be checked before
riding’)
3) Receiving a regular maintenance service or additional repair service ap-
proved by the manufacturer
5. Start of Warranty
This warranty is started by the registration of a genuine product at a shop
where Mando Footloose is purchased.
Application and limitation of the warranty
Information about the transfer of ownership
In the case that a transfer of ownership is required, please contact the store
representative.
