Manfrotto MVR911ECCN Use and care manual

Firmware Update procedure
Manfrotto MVR911ECCN
Requirements
In order to update the firmware, you will need:
1. a PC running the “Manfrotto Firmware Update GUI” software, and having a USB port available
2. a standard mini USB cable (not supplied) to connect the remote control and computer.
The cable must be mini-B male to A male.
FIX VAR
FOCUS
PEED

- 2 -
Description
This document describes the firmware update procedure for the Manfrotto MVR911ECCN remote control.
Download
Visit www.manfrotto.com and find the relevant update file (*.upg) for your device. Download the file to your
PC, ready for step 4.
Update Procedure
1. Turn the Remote Control on in Update Mode, as follows:
• confirmtheremoteisswitchedoff(A)
• pressandholdbuttons(B)&(C)
• turnontheproductandwaituntilLEDs(D),(E)&(F)startblinking
• releasethebuttons
2. connect the remote to the PC using the USB cable, as follows:
• unplugthecameraUSBcable(G)fromtheremote’scentralconnector
• plugthestandardminiUSBcableintotheremote(OUTminiUSBslot)
• finally,connectthestandardminiUSBcabletoafreeUSBportonthePC
B
F
E
C
G
D
A
FOCUS SPEED
LIMIT
FIX VAR
FOCUS
FOCUS SPEED
LIMIT
FIX VAR
FOCUS
1
2
3

- 3 -
The first time you connect the remote to your PC, the operating system will notify you that a new device has
beenfound:thePCshouldproceedtofindandinstalltheremotecontrol’sdriversautomatically,without
requiring specific actions on your part. Wait until the PC has identified the device correctly and confirmed that
it is ready for use.
3. run the Manfrotto Firmware Update GUI software on the PC
4. clickthe“…”button(highlightedinredbelow)tonavigatetotheupdatefile(*.upg)yousavedonyourPC.
5. clickthe“Update”buttontostarttheprocedure(thisbuttonisenabledonlyafterthe*.upgupdatefilehas
been loaded, and only if a compatible remote control unit is properly connected to the PC)
6. disconnect the remote control from the PC, then turn it off.
Please note:
Afterperformingfirmwareupdates,itisadvisabletocheckproperfunctioningoftheremote.Intheeventof
any malfunction or irregularity, try repeating the update procedure.
When the update file has been successfully applied and the
procedure has finished, a confirmation dialog box will appear.

- 4 -
MVR911ECCN update_rev 1.2 Copyright © 2012 Manfrotto Bassano Italy
Troubleshooting
The interface may display informational messages, warnings or error dialog boxes (see example below):
A list of possible messages and their explanation follows.
Message Description Possible solutions
Firmware updated successfully Normal and correct confirmation
message at the end of the update
procedure
Warning: device not found
Please verify that the device is
in update mode and properly
connected, then try again
After loading the update file, the
programcouldn’tfindacompatible
remote control unit connected to the
PC
Checkthefollowingpoints,thentryagain:
• Is the USB connection cable
properly inserted? If not, remove
andreinsertit,ensuringit’sfully
inserted
• Is the remote in “update mode”?
Ifnot,orifyou’reunsure,turn
the device off, disconnect it
from the computer, then turn
it on in “update mode” before
reconnecting it to the PC
• Is the update file the right one for
the remote? If not, download the
correct file from the Manfrotto
web site
Warning: Firmware update failed
Please try again
Acommunicationerrortookplace
during the update sequence
Restart the update procedure from
thebeginning,aftercheckingthat:
• the connection cable is properly
inserted
• the batteries are well-charged
Error: UPG file corrupted
Get a new UPG file and try again
Theupdatefiledidn’tpassthe
verification test
Try downloading a new update file
from the web site
Error: UPG file not supported
Please update the GUI program to the
latest version and try again
The UPG file seems to have an
unrecognized version
Try downloading and installing the
latest version of the "Manfrotto
Firmware Update GUI" from the web
site
Error: missing library
Try re-installing the update GUI
program on your computer
Some required libraries or
components of the “Manfrotto
Firmware Update GUI” software seem
to be missing
First uninstall the program, then try
installing it again
Error: unexpected exception while
programming
Please try again
Oneormoreunexpectederrorshave
happened while downloading the
firmware to the remote
Try repeating the update procedure
from the start
