Manhart ECM F Series User manual

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 1
Installation Manual MANHART ECM BMW F8x Mx Deleter

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 2
Package contents
Technical specifications
▪Automotive electronics
▪Operating temperature range -40 ° C to +85 ° C
▪Aluminum casing
▪Dimensions L 70mm x W 45mm x H 25mm
Scope of delivery
▪ECM Fxx / Gxx module
▪Cable set including connector
▪Installation and operating instructions

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 3
Required tools

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 4
Disconnect battery minus pole

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 5
Dismantle cover underneath glove box

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 6
Dismantle cover underneath glove box

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 7
Dismantle cover underneath glove box

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 8
Dismantle door sill cover and side cover

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page: 9
Dismantle side cover of co-driver‘s footwell

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
10
Uncover the plug of the FEM ECU

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
11
Disconnect CON 3 plug

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
12
FEM/BDC CON 3

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
13
Remove the cable from the chamber

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
14
Connect the cable to plug and combine plugs

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
15
FEM/BDC CON 8

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
16
Dismantle CON 8 plug

Article: MANHART BMW F8x Mx Deleter
Author: MANHART Performance
Subject: ECM Installation Manual
Date: 11.04.2020 Page:
17
