Directed Mit4 Use and care manual

Directed Digital System

MIT4

Firmware Specific Guide

This product is intended for installation by a professional

installer only! Attempts to install this product by a person

other than a trained professional may result in severe

damage to a vehicle’s electrical system and components.

Directed Digital System 2015-08

Contents

Warning! Safety first ....................................................................................................................... 3

Introduction .................................................................................................................................... 4

Vehicle application guide ........................................................................................................... 4

Wiring connections ......................................................................................................................... 5

Main power harness (H1), 12-pin thick gauge connector ............................................................... 5

Auxiliary output harness (H2), 16-pin black connector .................................................................. 5

Analog harness (H3), 18-pin white connector .............................................................................. 6

MC501 harness (H4), 8 thick-gauge wires (optional)..................................................................... 6

Installation...................................................................................................................................... 7

Type 1 ..................................................................................................................................... 7

Type 2 ..................................................................................................................................... 8

Type 3 ..................................................................................................................................... 9

Type 4 ................................................................................................................................... 10

Installation type 1.................................................................................................................... 11

Installation type 2.................................................................................................................... 13

Installation type 3.................................................................................................................... 15

Installation type 4.................................................................................................................... 17

Connecting the module .................................................................................................................. 20

Important! .............................................................................................................................. 20

Manual or automatic transmission selection ................................................................................ 20

Optional sensors ..................................................................................................................... 21

RF kits.................................................................................................................................... 21

When used in conjunction with SmartStart.................................................................................. 21

Module programming.............................................................................................................. 22

LED diagnostics and troubleshooting.......................................................................................... 23

Hard reset .............................................................................................................................. 24

Learning the Tach (not needed with Virtual Tach) ............................................................................... 25

Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 25

Limited lifetime consumer warranty .................................................................................................. 26

Quick Reference Guide – Viper, Clifford, Python, Avital & Automate (Regular Key)................................ 27

Quick Reference Guide – Autostart (Regular Key).............................................................................. 29

3Directed Digital System MIT4

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

• Due to the complexity of this system, installation of this product must only be performed by an authorized

Directed dealer.

• When properly installed, this system can start the vehicle via a command signal from the remote control.

Therefore, never operate the system in an area that does not have adequate ventilation.

The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:

• Never use a test light or logic probe when installing this unit. Always use a multimeter.

• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).

• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the

remote start system must be disabled using the installed toggle switch. It is the user’s sole responsibility to

properly handle and keep out of reach from children all remote controls to assure that the system does not

unintentionally remote start the vehicle.

• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT

TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR

PARTIALLY ENCLOSED VEHICLE STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.

Use of this product in a manner contrary to its intended mode of operation may result in property damage,

personal injury, or death. Except when performing the Safety Check outlined in this installation guide, (1) Never

remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the

ignition. The user is responsible for having the neutral safety feature of the vehicle periodically checked, wherein

the vehicle must not remotely start while the car is in gear. This testing should be performed by an authorized

Directed dealer in accordance with the Safety Check outlined in this product installation guide. If the vehicle

starts in gear, cease remote start operation immediately and consult with the user to ﬁx the problem immediately.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS

INTENDED MODE OF OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS

MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT

AND REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DIRECTED WILL NOT BE HELD

RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.

Remote starters for manual transmission pose signiﬁcant risks if not properly installed and operated. When testing

to ensure the installation is working properly, only remote start the vehicle in neutral gear, on a ﬂat surface and

with a functional, fully engaged parking brake. Do not allow anyone to stand in front of or behind the vehicle.

This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission.

Installation in such vehicles may pose certain risk.

4Directed Digital System MIT4

Introduction

The MIT4 ﬁrmware for Directed Digital Systems is a complete solution for remote start, security

(if applicable), bypass interface, and convenience needs compatible with speciﬁc MITSUBISHI

vehicles.

Warning! This module can only be programmed via the web tool, which can be found on

www.directechs.com or using the Directechs Mobile application for smartphones. Features

and functions will become accessible when you connect the module using the XKLoader.

Vehicle application guide

The following table lists the vehicles and features which are compatible with this product. The number assigned

to each year allows you to determine which installation type should be used for your vehicle.

Vehicles

2015

2014

2012

2011

2010

2009

2008

2007

2006

PK-Immobilizer Bypass-Data No Key Req'd

RS-RAP Shut Down (Retained ACC Power)

RS-SmartStart 3.0 Compatible

RS-Tach / RPM Output

SS-Entry Monitoring ALL Door Pins

SS-Entry Monitoring Driver Door Pin

SS-Entry Monitoring Trunk/Hatch Pin

ST-Brake Status (foot brake)

ST-E-Brake Status

ST-Ignition Status

Mitsubishi

Eclipse 3* or 4* 3* or 4* 3* or 4* 3* or 4* 3 3 3 ••••••••••

Eclipse (Without OEM Alarm) 2 2 2 2 2 2 2 • • • • • • • • •

Eclipse Spyder 3* or 4* 3* or 4* 3* or 4* 3* or 4* 3 3 3 ••••••••••

Eclipse Spyder (Without OEM Alarm) 2 2 2 2 2 2 2 • • • • • • • • •

Endeavor 3* or 4* 3* or 4* 3* or 4* 3* or 4* 3* 3* •••••••• •

Endeavor (Without OEM Alarm) 2 2 2 2 2 2 • • • • • • • • •

Galant 3* or 4* 3* or 4* 3* or 4* 3* or 4* 3* or 4* 3 3 •••••••• •

Galant (Without OEM Alarm) 2 2 2 2 2 2 2 • • • • • • • • •

Mirage 1 1 ••••••••••

Legend:

DL: OE Door Lock & Alarm Controls

PK: Transponder & Immobilizer Override

RS: Remote Start & Engine Controls

SS: Integrated Security & Monitoring

ST: Function/Feature Status

* Install Type 3 and 4: the Lock and Unlock wires must be pinned into the connector.

5Directed Digital System MIT4

Wiring connections

The wiring connections listed below are speciﬁc to this ﬁrmware.

Main power harness (H1), 12-pin thick gauge connector

Conn./Pin Color Description

H1/1 White Relay 3 COM – Parking Light Output 1

H1/2 White/Brown Relay 3 N.O.– Parking Light Input 1

H1/3 Brown/Red Relay 2 N.O. – No Connection1

H1/4 Yellow/Red Relay 2 COM – Keysense BCM Side

H1/5 Orange/Red Relay 2 N.C. – Keysense Key Side

H1/6 Yellow Relay 1 COM – No Connection1

H1/7 White Relay 3 COM – Parking Light Output 1

H1/8 White/Brown Relay 3 N.O.– Parking Light Input 1

H1/9 Black (-) Ground

H1/10 Red (+) 12 Volt (Battery)

H1/11 Orange/Yellow Relay 1 N.C. – No Connection 1

H1/12 Brown Relay 1 N.O.– No Connection

Auxiliary output harness (H2), 16-pin black connector

Conn./Pin Color Description

H2/1 Violet/Brown No Connection

H2/2 Yellow/Black No Connection

H2/3 Orange/Black No Connection

H2/4 Tan HS CAN Low

H2/5 Tan/Black HS CAN High

H2/6 Light Green No Connection

H2/7 Orange/Green No Connection

H2/8 Orange/Brown No Connection

H2/9 Violet/Green No Connection

H2/10 Green/Black (-) FACTORY ALARM ARM 2

H2/11 White/Violet No Connection

H2/12 White/Red No Connection

H2/13 Lt. Blue/Black No Connection

H2/14 Green/Red No Connection 2

H2/15 N/A No Connection

H2/16 Violet/Yellow No Connection

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed.

2. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are

low current and a relay may be necessary.

6Directed Digital System MIT4

Analog harness (H3), 18-pin white connector

Conn./Pin Color Description

H3/1 Lt. Blue/Red No Connection

H3/2 Black/White (-) Parking Brake Input (Manual Transmission) 2

H3/3 Gray (-) Hood Input 2

H3/4 N/A No Connection

H3/5 Gray/Black (+) Glow Plug Input 2

H3/6 Violet/White (AC) Tach Input 2

H3/7 Dark Blue (-) UNLOCK OUTPUT

H3/8 Brown/Black No Connection 1

H3/9 Red/White (-) Trunk Release Output 1

H3/10 White/Green (-) Door Input 2

H3/11 Yellow/Green (+) Door Input 2

H3/12 Blue/Red No Connection

H3/13 Light Blue (-) Trunk Trigger Input 2

H3/14 Pink/Yellow (-) Start Trigger Input 2

H3/15 Dark Green (-) LOCK OUTPUT

H3/16 Brown/White (+) Brake Input 2

H3/17 Brown (+) Siren Output 1

H3/18 Blue/White (-) Ground When Running (Status) Output 1

MC501 harness (H4), 8 thick-gauge wires (optional)

Conn./Pin Color Description

H4/1 Pink/White (+) Ignition 2/Flex Relay Output 3

H4/2 Red/White (+) Fused (30A) Ignition 2/Flex Relay Input

H4/3 Pink (+) Ignition Output (Also Input to Yellow in Ribbon Cable)

H4/4 Red (+) 12 Volt (Battery) Input

H4/5 Orange (+) Accessory Output

H4/6 Red (+) 12 Volt (Battery) Input

H4/7 Green Starter Input (From Key Switch) 4

H4/8 Violet (+) Starter Output (To Starter)

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are

low current and a relay may be necessary.

2. These connections are only required if the corresponding statuses are not supported by the ﬁrmware. See "Vehicle application guide"

on page 4 for a list of compatible features.

3. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed.

4. The Green wire is only required for starter kill and antigrind applications.

7Directed Digital System MIT4

Installation

Type 1

Refer to "Vehicle wiring reference charts" on page 11 for more information on vehicle-speciﬁc connections.

2 & 8: White/Brown: (+) 12V

16 Black 3 Wh

4 White 12 White4 Red

7 White 2 Wh

2 Bk6 Green

18 White

Manual/Auto. Transmission Type Prog.

Button

Manual/Auto. Transmission Type

Prog.

Button

9: Black: (-) Ground

10: Red: (+) 12V

1 & 7: White: (+) Parking Lights

HS CAN Low: Tan: 4

HS CAN High: Tan/Black: 5

(-) Hood Input: Gray: 3

(-) Unlock Output: Dk. Blue: 7

(-) Lock Output: Dk. Green: 15

The Remote Start

Safety Override

Switch MUST be in

the ON position.

Remote Start Safety

Override Switch

[1] (+) Siren Output: Brown: 17

Siren

[1] The siren is only compatible with hybrid systems.

[2] The green wire is only required for starter kill and antigrind connections.

All adapters are displayed from the wire side (unless specified otherwise).

31 2

4 5 6

7 White4 White

8 thick-gauge wires

MC501

1 2

2 3 4 5

11 12 138 96 7 10

34567891011

12 13 14 15 16 17 18 19 20 21 22

(+) Accessory Output: Orange: 5

(+) Ignition Input/Output: Pink: 3

(+) 12V Input: Red: 4

(+) 12V Input: Red: 6

[2] Starter Input (Key Side): Green: 7

(+) Starter Output (Car Side): Violet: 8

(+) Ignition:

Green, pin 2

(+) 12V:

White, pin 1

(+) Parking Lights:

Green, pin 1

(+) Starter:

Pink, pin 5

(+) Accessory:

Yellow, pin 4

(-) Lock:

Green, pin 22

(-) Unlock: Lt. Blue, pin 11

Ignition Switch Connector

(left side of steering column) C-22 Door Locks Connector

White 22-pin conn.

(attached to the side of fuse box)

C-405 White Connector

Hood Pin

HS CAN High: Brown, pin 6

HS CAN Low: Black, pin 14

OBDII Diagnostic Connector

under Driver Dash

(connector side view)

Clutch: Green, pin 1

For Manual

Transmission

ONLY

For Automatic

Transmission ONLY

Clutch

Pedal

8Directed Digital System MIT4

Type 2

Refer to "Vehicle wiring reference charts" on page 11 for more information on vehicle-speciﬁc connections.

2 & 8: White/Brown: (+) 12V

16 Black 3 Wh

4 White 12 White4 Red

7 White 2 Wh

2 Bk6 Green

18 White

Manual/Auto. Transmission Type Prog.

Button

Manual/Auto. Transmission Type

Prog.

Button

9: Black: (-) Ground

10: Red: (+) 12V

1 & 7: White: (+) Parking Lights

HS CAN Low: Tan : 4

(-) Auto Headlamp Shutoff: Green/Black: 10

HS CAN High: Tan/Black: 5

(-) Hood Input: Gray: 3

(-) Unlock Output: Dk. Blue: 7

(-) Lock Output: Dk. Green: 15

The Remote Start

Safety Override

Switch MUST be in

the ON position.

Remote Start Safety

Override Switch

[1] (+) Siren Output: Brown: 17

(-) GWR Output: Blue/White: 18

Siren

[1] The siren is only compatible with hybrid systems.

All adapters are displayed from the wire side (unless specified otherwise).

31 2

4 5 6

7 White4 White

8 thick-gauge wires

MC501

(+) Accessory 1 Output: Orange: 5

(+) Accessory 2 Output: Orange: 5

(+) Ignition Input/Output: Pink: 3

(+) 12V Input: Red: 4

(+) 12V Input: Red: 6

[2] Starter Input (Key Side): Green: 7

(+) Starter Output (Car Side): Violet: 8

(+) Ignition: Red or

Black/White, pin 2

(+) 12V:

White, pin 1

(-) Driver Door Trigger:

Lt. Green, pin 6

Clutch:

Brown/Black,

pin 2

(+) Parking Lights:

Green/White, pin 2

(+) Starter:

Black/Yellow,

pin 5

(+) Accessory 1:

Blue/Red, pin 4

(+) Accessory 2:

Blue/Black, pin 6

(-) Lock:

Violet/White

or Violet, pin 13

(-) Unlock:

Lt. Green/Red,

pin 14

Ignition Switch Connector

(left side of steering column)

C-208 White Connector

(Junction Block at Driver Kick Panel)

C-204 White Connector

(Front of Junction Block

at Driver Kick Panel)

Junction Block

front view

For Manual Transmission ONLY

Clutch

Pedal

Junction Block

rear view

(Driver Kick Panel)

Hood Pin

HS CAN High: Red, pin 6

HS CAN Low: Black, pin 14

OBDII Diagnostic Connector

under Driver Dash

(connector side view)

765

131415 12

4 3 2 1

891011

Relay pin 30 Relay pin 87a

87a

Cut

C-204

[2] The green wire is only required for starter kill and antigrind connections.

3 4

8 9 10 11

12 13

C-219 White 24-pin Connector

(Rear of Junction Block.

at Driver Kick Panel)

4321

10 11 12 15

13 16 17 18

22 23 2419 20 21

68 9

9Directed Digital System MIT4

Type 3

Refer to "Vehicle wiring reference charts" on page 11 for more information on vehicle-speciﬁc connections.

2 & 8: White/Brown: (+) 12V

16 Black 3 Wh

4 White 12 White4 Red

7 White 2 Wh

2 Bk6 Green

18 White

Manual/Auto. Transmission Type Prog.

Button

Manual/Auto. Transmission Type

Prog.

Button

9: Black: (-) Ground

10: Red: (+) 12V

1 & 7: White: (+) Parking Lights

HS CAN Low: Tan : 4

HS CAN High: Tan/Black: 5

[1] (-) Hood Input: Gray: 3

(-) Unlock/Disarm Output: Dk. Blue: 7

(-) Lock/Arm Output: Dk. Green: 15

The Remote Start

Safety Override

Switch MUST be in

the ON position.

Remote Start Safety

Override Switch

[2] (+) Siren Output: Brown: 17

All adapters are displayed from the wire side (unless specified otherwise).

31 2

4 5 6

7 White4 White

8 thick-gauge wires

MC501

(+) Accessory 1 Output: Orange: 5

(+) Accessory 2 Output: Orange: 5

(+) Ignition Input/Output: Pink: 3

(+) 12V Input: Red: 4

(+) 12V Input: Red: 6

[3] Starter Input (Key Side): Green: 7

(+) Starter Output (Car Side): Violet: 8

(+) Ignition: Red or

Black/White, pin 2

(+) 12V: Blue/Yellow, pin 1

(-) Driver Door Trigger:

Lt. Green, pin 6

(+) Starter:

Black/Yellow, pin 5

(+) Accessory 1:

Blue/Red, pin 4

(+) Accessory 2:

Blue/Black, pin 6

C-204 White Connector

(Front of Junction Block.

at Driver Kick Panel)

Junction Block

front view

Junction Block

rear view

(Driver Kick Panel)

Hood Pin

HS CAN High: Red, pin 6

HS CAN Low: Black, pin 14

OBDII Diagnostic Connector

under Driver Dash

(connector side view)

765

131415 12

4 3 2 1

891011

C-204

(-) GWR Output: Blue/White: 18

Clutch:

Brown/Black,

pin 2

For Manual Transmission ONLY

Clutch

Pedal

Relay pin 30 Relay pin 87a

87a

Cut

(-) Auto Headlamp Shutoff: Green/Black: 10

[2] The siren is only compatible with hybrid systems.

[1] The installation of an aftermarket hood pin is only required on vehicles

that are not equipped with a factory hood pin.

[3] The green wire is only required for starter kill and antigrind connections.

Ignition Switch Connector

(left side of steering column)

(+) Parking Lights:

Green/White, pin 2

C-208 White Connector

(Junction Block at Driver Kick Panel)

3 4

8 9 10 11

12 13

(-) Lock/Arm:

Lt. Green/Black, pin 22

(-) Unlock/Disarm:

Red/Green, pin 5

C-217 White 24-pin Connector

(Rear of Junction Block,

at Driver Kick Panel)

321

10 11 12 151413 16 17 18

22 23 2419 20 21

76 8 9

Solder onto a diode, cut away the unneeded

Empty pin

Diode

Solder the wire to secure it on the metal pin.

This part can be removed

because only the metal pin is

Unlock* wire from Remote Starter

*Lock: Same procedure have to be done for missing Lock wire.

If there’s no Lock/Unlock wires, you can either insert

Lock/Unlock wires directly as shown below or use

Installation Type 4 on page 10.

Siren

10 Directed Digital System MIT4

Type 4

Refer to "Vehicle wiring reference charts" on page 11 for more information on vehicle-speciﬁc connections.

2 & 8: White/Brown: (+) 12V

4: Yellow/Red: Keysense Cut

5: Orange/Red: Keysense Cut

16 Black 3 Wh

4 White 12 White4 Red

7 White 2 Wh

2 Bk6 Green

18 White

Manual/Auto. Transmission Type Prog.

Button

Manual/Auto. Transmission Type

Prog.

Button

9: Black: (-) Ground

10: Red: (+) 12V

1 & 7: White: (+) Parking Lights

HS CAN Low: Tan : 4

HS CAN High: Tan/Black: 5

[1] (-) Hood Input: Gray: 3

(-) Unlock Output: Dk. Blue: 7

(-) Lock Output: Dk. Green: 15

The Remote Start

Safety Override

Switch MUST be in

the ON position.

Remote Start Safety

Override Switch

[2] (+) Siren Output: Brown: 17

Siren

[2] The siren is only compatible with hybrid systems.

All adapters are displayed from the wire side (unless specified otherwise).

[1] The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin.

31 2

4 5 6

Keysense:

Blue/Red, pin 6

7 White4 White

8 thick-gauge wires

MC501

(+) Accessory 1 Output: Orange: 5

(+) Accessory 2 Output: Orange: 5

(+) Ignition Input/Output: Pink: 3

(+) 12V Input: Red: 4

(+) 12V Input: Red: 6

[3] Starter Input (Key Side): Green: 7

(+) Starter Output (Car Side): Violet: 8

(+) Ignition: Red or

Black/White, pin 2

(+) 12V:

Blue/Yellow, pin 1

(-) Driver Door Trigger:

Lt. Green, pin 6

(+) Starter:

Black/Yellow,

pin 5

(+) Accessory 1:

Blue/Red, pin 4

(+) Accessory 2:

Blue/Black, pin 6

Ignition Switch

Connector

(left side of

steering column)

C-217 White 24-pin Connector

(Rear of Junction Block.

at Driver Kick Panel)

C-204 White Connector

(Front of Junction Block.

at Driver Kick Panel)

Junction Block

front view

Junction Block

rear view

(Driver Kick Panel)

Hood Pin

HS CAN High: Red, pin 6

HS CAN Low: Black, pin 14

OBDII Diagnostic Connector

under Driver Dash

(connector side view)

765

131415 12

4 3 2 1

891011

C-204

43 5 67

1 2

(-) GWR Output: Blue/White: 18

Clutch:

Brown/Black,

pin 2

For Manual Transmission ONLY

Clutch

Pedal

Relay pin 30 Relay pin 87a

87a

Cut

(-) Auto Headlamp Shutoff: Green/Black: 10

(+) Parking Lights:

Green/White, pin 2

C-208 White Connector

(Junction Block at Driver Kick Panel)

3 4

8 9 10 11

12 13

CUT

4321

10 11 12 15

13 16 17 18

22 23 2419 20 21

68 9

11 Directed Digital System MIT4

Vehicle wiring reference charts

This section provides information on the following connections:

• "Installation type 1"

• "Installation type 2"

• "Installation type 3"

• "Installation type 4"

Refer to www.directechs.com for more information on any additional connections.

Installation type 1

Function Wire color Pin Polarity Connector Nb.

pins

Conn.

color Location on vehicle

Mirage 2014-2015

Accessory 1 Yellow 4 (+) Ignition Switch 6 White Left side of Steering column

Ignition Green 2 (+) Ignition Switch 6 White Left side of Steering column

Power 12V White 1 (+) Ignition Switch 6 White Left side of Steering column

Starter Pink 5 (+) Ignition Switch 6 White Left side of Steering column

Clutch Green 1 (+) Clutch Switch 2 Gray at Clutch pedal

Parking Lights Green 1 (+) C-405 13 White Junction Block

CAN2 High Brown 6 Data OBDII connector 16 Black Drivers under dash

CAN2 Low Black 14 Data OBDII connector 16 Black Drivers under dash

Lock Green 22 (-) C-22 22 White Right of Junction Block

Unlock Lt. Blue 11 (-) C-22 22 White Right of Junction Block

Ground Vehicle chassis

Locating components for type 1

CAN Low:

Black

CAN High:

Brown

OBDII Diagnostic Connector - 16-pin black

CAN Low: Black, pin 14

CAN High: Brown, pin 6

12 Directed Digital System MIT4

Unlock:

Lt.Blue, pin 11

Lock:

Green, pin 22

C-22 Door Locks Connector - 22-pin white (at Driver Kick Panel, besides fuse box)

Lock: Green, pin 22

Unlock: Lt. Blue, pin 11

Accessory:

Yellow, pin 4

12V:

White, pin 1

Ignition:

Green, pin 2

Starter:

Pink, pin 5

Ignition Switch Connector - 6-pin white (left side of steering column)

(+) 12V: White, pin 1

(+) Ignition: Green, pin 2

(+) Accessory: Yellow, pin 4

(+) Starter: Pink, pin 5

13 Directed Digital System MIT4

Installation type 2

Function Wire color Pin Polarity Connector Nb.

pins

Conn.

color Location on vehicle

Eclipse (without OEM alarm) 2006-12

Accessory 1 Blue/Red 4 (+) Ignition Switch 6 White Left side of Steering column

Accessory 2 Blue/Black 6 (+) Ignition Switch 6 White Left side of Steering column

Ignition Red 2 (+) Ignition Switch 6 White Left side of Steering column

Power 12V Blue/Yellow 1 (+) Ignition Switch 6 White Left side of Steering column

Starter Black/Yelllow 5 (+) Ignition Switch 6 White Left side of Steering column

CAN2 High Red 6 Data OBDII connector 16 Black Drivers Under Dash

CAN2 Low Black 14 Data OBDII connector 16 Black Drivers Under Dash

Clutch Brown/Black 1 Open Clutch Switch 2 White at Clutch pedal

Parking Lights Green/White 2 (+) C-208 15 White Junction Block

Lock Violet/White 13 (-) C-219 24 White Junction Block

Unlock Lt. Green/Red 14 (-) C-219 24 White Junction Block

Door Trigger Lt. Green 6 (-) C-204 15 White Junction Block

Ground Vehicle chassis

Eclipse Spyder (without OEM alarm) 2006-12
