APS GR18HEC11A User manual

Grille Installation Instruction
Part# GR18HEC11A 2004-2006 Chrysler Pacifica Main Upper
Page 1of 2
Rev. 120801
Parts
List
Item Part Name QTY Description Item Part Name QTY Description
1 Billet Grille insert 1 23 bars 4 Truss head screw 2 8#X 3/4"
2 L shape bracket 4 / 5 Button Head Screw 4 10-24×1″
3 U-clip 2 8# 6 K-Nut 4 10-24
Install Notes: Overlay Replacement Drill Cut
Step Description illustration
1 Identify the grille & hardware with
parts list.
2 Hood up, and remove the OEM
grille from vehicle. N/A
3
Attach the 4 L shape brackets to
the vehicle. As shown on figure1 &
2.
4
For the upper L shape brackets: You will need to drill a small pilot hole into the radiator support to attach the
(2) upper L brackets. Center the L bracket, and then drill the hole. Secure the bracket using the #8 truss head
screws & U-clips, as shown on figure 1.
5 The bottom L brackets pick up factory mounting points, as shown on figure 2.
6
Center the billet grille onto the
opening, line up the L brackets
with the grille and then tighten
fasteners.
× √
√
×
Figure1 Figure2
Page 1of 1
The instruction here is for your reference only. You may need to bend the grille a little bit to
adjust to fit. We strongly recommend the professional installer for best result.
Please use masking tape and tape the OEM grille shell along the edge to protect your vehicle during
installation.
We are not responsible for any damage caused by the installation. Thank you for choosing our product!

Grille Installation Instruction
Part# GR18HEC11A 2004-2006 Chrysler Pacifica Main Upper
Page 2of 2
Rev. 120801
Step Description illustration
7
Secure the billet grille to the L
brackets through 4 mounting tabs
(welded on the billet grille) using
the bolts and k-nuts. As shown on
figure 4.
8 Installation completed!!!
Mountingtab
Lbracket
Bolt&
K
‐Nut
Page 1of 1
