Manhattan Comfort Bradley 229BMC6 User manual

Model # 229BMC6, 229BMC8, 229BMC9, 229BMC94
888-230-2225
[e-mail]
Bradley Corner Desk
748 - Ed. 001, 2020/03 - Manhattan Comfort.
The indicated values consider static weights and evenly distributed over the parts.
11
lb
33
lb
5.5
lb

n.° ID Parts Identification (Description) Quantity
03
01
04
01
04
06
07
08
02
05
03
09
02
Top Panel
Right Side Panel
Support for fixing the feet
Left Side Support for keyboard
Left Side Panel
Wood Feet H740mm
Upper Shelf
Right Side Support for keyboard
Base for keyboard
1
1
3
1
1
3
1
1
1
05
INCLUDED IN THE PACKAGE
2
05
05
06
07
08
09
09
09

2x
A3x 15x
3x 14x 10x
4x 4x 22x
2x 2x 2x
3
INCLUDED IN THE HARDWARE
BC
D E F
GH I
J K L
TOOLS NEEDED
Simple hammer.Falt head and phillips
screwdriver.
Electric drill and electric screwdriver with
drill bit Ø1/2 inch and phillips tips.
Level indicator.
!IMPORTANT! Two people are recommended to assemble and install this product.

06
01
STEP 1
STEP 2
STEP 3
• Fix the Left Side Support (06)
and Right Side Support (07) in
the lower face of the Top Panel
(01) with dowels (E) and
cam lock hardware (G+H).
• At the end the fixation, apply
the adhesive covers (I) on the
drums (H).
• Connect the Left Side Panel (02)
into the Top Panel (01) with
dowels (E) and bolts (F).
• Connect the Upper Shelf (04)
into the Left Side Panel (02)
with dowels (E) and bolt (F).
4
07 Lower face
01
02
04
06 07
• Connect the Right Side Panel (03)
into the Top Panel (01), the Left
Side Panel (02) and the Upper
Shelf (04) with dowels (E) and
bolts (F).
01
02
06 07
03
04

STEP 4
STEP 5
5
• Fixing the Feet (09) in the Supports (05):
apply glue (B) to the upper end of the foot
and fix with bolt (A).
• Apply the protective felt (D) in the lower end
of the feet (09).
Apply glue
09
05
DETAIL 1:
POSICIONING THE FOOT (09) IN SUPPORT (05)
To assemble the table with feet, see steps 4 and 5.
To assemble the drop table fixed to wall corner, see steps 6 and 7.
!
• With the feet (09) already fixed in the
supports (05), position them correctly on
the underside of the table top (as shown
in the DETAIL 2) and fix them with bolts (C).
• Install the Base for keyboard (08), fitting it
so that the metallic slides slide smoothly
(see DETAIL 3, below).
DETAIL 2 - LOWER VIEW
FEET POSITION UNDER THE TABLE TOP
01
Lower face
05
05
05
09
09
09
05
DETAIL 3
INSTALLING THE BASE FOR KEYBOARD (08)
08
01
02
03

STEP 6
6
DETAIL 4
ATENTION!
Before installing the furniture, check the conditions of
the wall for strength to properly support and anchor the
weight of the suspended furniture, including equipments
and objects that may be installed on the shelves.
The Kap Toggle bushings (K) supplied with the product
are for hollow walls or dry wall type. Check the type of
the wall on which the installation will be made and, if
necessary, look for more suitable bushings or devices.
To mark the position and fix the furniture on the wall,
check the level of the parts.
• Place the furniture already assembled according to
steps 1, 2 and 3 on the site and at the desired height
for the installation and mark the position of the two
holes on the wall to fixation, as shown in the drawing
and using the two holes indicated in the side panels
(02) and (03) as reference.
• With electric drill and drill bit Ø1/2 inch, make the
two holes in the wall.
• Apply the bushings (K) into the two holes in the wall.
• Reposition the furniture in the place and apply the
bolts 1/4 x 2.1/4 inches as shown in the drawing, for
fixing the Side Panels (02) and (03) at the bushings
(K) already applied on the wall.
STEP 7
1/2 inch hole
in the wall
Kap Toggle
bushing ( K)
Bolt
1/4 x 2.1/4"
02
01
03
04
• Install the Base for keyboard (08), fitting it so that
the metallic slides slide smoothly.
• At the end the fixation, apply the plastic covers (L)
over the bolts used for fixation on the wall.
• Insert the plastic covers (J) into the holes for pass
wires in the Top Panel (01) and in the Shelf (04).
• Apply the adhesive covers (I) on the remaining
apparent holes and bolts.
08
01
02
03
04
