HI-SPEED
USB 2.0 TO
SATA/IDE
ADAPTER
WITH POWER SUPPLY
USER
MANUAL
Model 179072
MAN-179072-UM-0208-01

Thank you for purchasing the MANHATTAN
®
Hi-Speed USB 2.0 to
SATA/IDE Adapter with Power Supply, Model 179072.
This convenient device connects SATA, SATA-enhanced, IDE and
enhanced-IDE hard disks and CD/DVD drives to desktop and notebook
computers using a USB port so that transferring, sharing and backing
up les or storing large le archives on external drives is faster and
easier to accomplish.
Installation of the adapter is quick and simple, so you’ll soon be enjoying
the benets of these features:
• Supports data transfer SATA 150 speeds up to 1.5 Gbps and Hi-Speed
USB 2.0 speeds up to 480 Mbps
• Supports 48-bit LBA (Logical Block Addressing) for drives up to 750 GB
• Fits external SATA 150 and IDE hard disks and CD/DVD drives up to
5.25”
• Plug and Play; hot-swappable; Windows, Mac and Linux compatible
• Lifetime Warranty
INSTALLATION
NOTE: Do not store or operate this device in conditions of excessive heat
or humidity. If the initial installation attempt fails, go to My Computer ‡
Control Panel ‡System Properties ‡Device Manager and remove any
items tagged with a question mark (?) or exclamation point (!).
1. Connect the Hi-Speed USB 2.0 to SATA/IDE Adapter to the HDD
IDE port and the computer’s USB port.
2. Windows will detect a new device and automatically install the driver
(no added software is needed).
• To verify the connection, go to My Computer ‡Control Panel ‡
System Properties ‡Device Manager. Open “Hard disk controllers”
to display the newly added hard disk drive.
• If connecting to a brand new hard disk drive, use “Fdisk” to set its
capacity. NOTE: This will destroy any data on the HDD. Back up any
data on the drive rst if it needs to be saved.
Format the HDD using standard procedures. If its icon appears on
2

the desktop but you can’t nd it listed, check/conrm the following:
- The HDD has been properly installed
- The HDD is set in the “Master” position
- The correct driver for this HDD is installed
SPECIFICATIONS
Standards and Certications
• Hi-Speed USB 2.0
• USB 1.1
• Complies with ATA/ATAOI-100 spec v1.0 standards
• SATA 1.0a
• FCC
• CE
General
• 1 Hi-Speed USB 2.0 type A male; 1 SATA 150 L-type male; IDE 40-pin;
IDE 44-pin ports
• Hi-Speed USB 2.0 transfer interfaces
• HDD/CD-ROM/CD-R/RW/DVD/MO/ZIP-compatible mode
• 480 Mbps maximum transfer rate
• Supports SATA, enhanced-SATA, IDE and enhanced-IDE drives
Power Supply
• Input 100 – 250 V AC; 50/60 Hz maximum, 0.5 A
• Output: 5 V / 2 A; 12 V / 2 A
Physical
• 3.8 x 2.5 x 1.25 cm (2.75 x 1.75 x 0.5 in.)
• Cables: USB, 76.2 cm (30 in.); SATA, 10 cm (4 in.); 4-pin housing /
SATA Y-power, 10 cm (4 in.); power, 1.7 m (67 in.)
• Weight: 303 g (10.7 oz.) with power supply
System Requirements
• Windows 2000/XP/Vista, Mac OS 10, Linux
Package Contents
• Hi-Speed USB 2.0 to SATA/ IDE Adapter with Power Supply
• User manual
