Manhattan 702904 User manual

MAN-702904-UM-0706-01
HI-SPEED
USB 2.0/FIREWIRE
2.5" EXTERNAL
ENCLOSURE
USER MANUAL
MODEL 702904
702904_man.dlrev4C2.indd 1 8/1/06 4:05:04 PM

PB
Congratulations on purchasing the MANHATTAN® Hi-Speed USB 2.0/FireWire 2.5" External
Enclosure, Model 702904. This device will let you quickly and easily transfer, share and archive data,
and expand storage capacities for desktop and notebook PCs.
Among the main features:
• Supports Hi-Speed USB 2.0 data transfer rates of up to 480 Mbps (up to 400 Mbps for
FireWire IEEE 1394)
• Lightweight, compact design; aluminum case protects drive and facilitates cooling
• Fits standard 2.5” PATA (IDE) drives with easy, quick installation
• Windows and Macintosh compatible, Plug and Play, hot swappable
• Lifetime Warranty
Package contents:
• External Enclosure with CD Driver and Travel Case
• USB A-type male to mini-B male cable, 4 ft. (1.2 m)
• DC single-post power connector to USB A-type male to PS/2 pass-through, 5 ft. (1.5 m) overall
• FireWire 6-pin to 4-pin cable, 5 ft. (1.5 m)
• User Manual
SETTING UP THE EXTERNAL ENCLOSURE
NOTE: Create a copy of your original data prior to connecting to the external enclosure to prevent
the possibility of data loss should a mistake be made during the setup procedure. MANHATTAN
accepts no responsibility for lost data.
702904_man.dlrev4C2.indd 2 8/1/06 4:05:04 PM

USB 2.0 Windows 98SE Installation: Place the installation CD in the CD-ROM and connect the
external enclosure to your computer. Auto Detect will run the Add New Hardware wizard, which
searches for new drivers for the USB 2.0 external enclosure. Click "Next."
Select "Search for the best driver for your device (recommended)"; click "Next."
Select "Specify location"; browse to "CD-ROM E:\USB 2.0-98 Driver"; click "Next." With the prompt
"Windows driver file search for the device Hi-Speed USB-to-IDE Bridge Controller," click "Next" to get
the prompt "Windows has finished installing the software that your new hardware device requires."
Click "Finish." Installation is complete; just restart your computer. NOTE: For Windows Me/2000/XP,
no need to install the additional driver: It’s already installed. Windows XP needs to be updated with SP2.
IEEE 1394 Installation: The IEEE 1394 interface is Plug and Play, so no driver setup is needed.
1. Remove the tray
from the enclosure. 2. Connect the drive with the
interface.
3. Attach the drive
with the
screws.
4. Insert the drive back
into the enclosure,
replace the screws on
either side of the cover
— and the installation
is complete.
702904_man.dlrev4C2.indd 3 8/1/06 4:05:05 PM

www.manhattan-products.com
Are you completely satisfied with this product?
Please contact your MANHATTAN® dealer with comments or questions.
