Manhattan 702942 User manual

MAN-702942-UM-0706-03
hi-speed
UsB 2.0/Firewire
3.5" external
enclosUre
User ManUal
MODEL 702942

Congratulations on purchasing the MANHATTAN®Hi-Speed USB 2.0/FireWire 3.5" External
Enclosure, Model 702942. This device will let you quickly and easily transfer, share and archive
data, and expand storage capacities for desktop and notebook PCs.
Among the external enclosure’s main features:
• Supports Hi-Speed USB 2.0 data transfer rates of up to 480 Mbps (up to 400 Mbps for
FireWire IEEE 1394)
• Lightweight, compact design; aluminum case protects drive and facilitates cooling
• Fits standard 3.5” PATA (IDE) drives with easy, quick installation
• Windows and Macintosh compatible, Plug and Play, hot swappable
• Lifetime Warranty
Package contents:
• External Enclosure with CD Driver and Stand
• USB A-type male to B-type male cable, 1.2 m (4 ft.)
• FireWire 6-pin to 6-pin cable, 1.5 m (5 ft.)
• AC power adapter with cable, 2.7 m (9 ft.)
• User manual
setting Up the external enclosUre
NOTE: Before making connections to the external enclosure, set the IDE drive to Master mode.
Also, create a copy of your original data to prevent the possibility of data loss should a mistake
be made during the setup procedure. MANHATTAN accepts no responsibility for lost data.

USB 2.0 Windows 98SE Installation: Place the installation CD in the CD-ROM device and connect
the external enclosure to your computer. Auto Detect will run the Add New Hardware wizard, which
searches for new drivers for the USB 2.0 device. Click "Next" to get the prompt "Search for the best
driver for your device (recommended)"; then click "Next" to get the prompt "Specify location." Browse
to "CD-ROM E:\USB 2.0-98 Driver"; click "Next." With the prompt "Windows driver file search for the
device Hi-Speed USB-to-IDE Bridge Controller," click "Next" to get the prompt "Windows has finished
installing the software that your new hardware device requires." Click "Finish." Installation is complete;
just restart your computer. NOTE: For Windows Me/2000/XP/Vista, no need to install the additional
driver: It’s already installed. Windows XP needs to be updated with SP2.
IEEE 1394 Installation: The IEEE 1394 interface is Plug and Play, so no driver setup is needed.
1. Remove the tray
from the enclosure. 2. Connect the 40-pin IDE and power cable to the
drive and attach with the
screws.
3. Insert the tray back
into the enclosure.
4. Attach the back
cover with the 4
screws — and
installation is
complete.

www.manhattan-products.com
Are you completely satisfied with this product?
Please contact your MANHATTAN®dealer with comments or questions.
Copyright © MANHATTAN
All products mentioned are trademarks or registered trademarks of their respective owners.
