Manhattan 176118 User manual

MAN-176118-UM-1206-02
HI-SPEED USB 2.0
DVB-T TV STICK
USER MANUAL
MODEL 176118

2
Thank you for purchasing the MANHATTAN® Hi-Speed USB 2.0 DVB-T TV Stick, Model 176118.
This Digital Video Broadcasting – Terrestrial tuner transforms your computer into a digital multimedia
center: Digital Personal Video Recording captures and directly saves television programs to your
computer hard drive for replay or transfer to a CD and other portable media devices; Electronic
Program Guide allows you to browse program summaries, conduct channel and program searches,
schedule reminders and more; Time-shifting lets you replay favorite scenes, skip annoying ads and
apply pause/rewind/fast forward control to live video and recorded programs.
• Receive free-to-air DVB-T broadcasts on notebook and desktop computers (SDTV, HDTV and EPG
supported)
• Enjoy clear, crisp reception almost anywhere — no external power required
• Easily schedule and directly save programs to a hard drive for replay or transfer to a CD
• Digital video recording, automatic station searching, customizable favorites and time shifting
• Plug and Play and USB installation; Windows compatible
• Lifetime Warranty
Package Contents:
• Hi-Speed USB 2.0 DVB-T Stick
• DVB-T antenna
• USB extension cable
• Remote control (CR 2025 battery included)
• User manual and software/driver CD

3
System Requirements:
• For SDTV: PIII 600 MHz or above, 128 MB RAM and VGA chipset with 16 MB RAM
• For HDTV: P4 2.0 GHz or above, 256 MB RAM and VGA chipset with 32 MB RAM
• Windows 2000/XP/Media Player 9.0 or above
• DirectX 9.0 or above
Important Notes:
• All channels are subject to coverage, and may be changed periodically.
• Reception can depend on the type and condition of your antenna. It is recommended that
you confirm coverage in your area and determine if an antenna upgrade is necessary.
• As terrestrial digital wireless broadcast signals can be affected by topography, weather and
various objects (resulting in poor signal quality), installing an outdoor antenna for indoor use
of the DTV receiver is recommended.
• When using pre-recording, real-time recording or time-shifting functions, be sure enough hard
disk space exists to save recorded data.
• Improper setup or operation can cause system instability or crashing. Before removing hard
disk devices, close related applications.

4
INSTALLATION
1. With the PC on, insert the installation CD in the CD drive and, using an available USB port,
connect the Hi-Speed USB 2.0 DVB-T Stick to the PC with the USB extension cable.
2. When the prompt "USB Device" appears, select "Cancel."
3. Run "Driver Install" or "Driver/setup.exe." The computer will automatically display an
installation page.
4. Select "Continue anyway" for Windows XP; select "Yes" for Windows 2000.
5. Click "Finish" to proceed to the next device installation. Three new device icons will appear
in Device Manager once the driver has been properly installed.
6. When finished, click on the "Control Panel" icon and select "System," then "System properties,"
then "Device Manager." The three new driver installations will be listed: "HID-compliant
device" and "USB Human Interface Device" (both listed under "Human Interface Devices," as
highlighted in Figure 1 on the next page); and "DVB-T TV Stick" under "Sound, video and
game controllers."
7. Run "TotalMedia/setup.exe" to install the application software.
8. When finished, click on the "TotalMedia" icon on the desktop to enter the application
software.

5
HID-compliant device
USB Human Interface Device
DVB-T TV Stick T328
Figure 1

6
Remote Control Buttons and Key Identification:
Mute: On/Off volume mute.
TV/AV: Switch between S-Video, Composite and
TV.
Full Screen/Restore: Switch from full screen to the
default screen.
TotalMedia: Open/close the TotalMedia software.
0–9: Channel number keys.
ESC: Return.
Time-shifting: Time-shifting function.
Up/Down/Left/Right OK
Vol 5 /Vol6: Volume adjustment up or down.
Ch.+/Ch.– : Channel selection up or down.
Record: Record/stop recording the current program.
Stop: Stop pre-recorded viewing and return to live
TV.
Snapshot: Take a picture of what is on screen.
1
2
3
5
7
9
10
4
8
6

7
TROUBLESHOOTING
If Auto Scan isn’t able to lock on to any program channels and it has already been established
that there is DVB-T broadcasting in the area:
• Check for a too-weak signal by moving the antenna and trying the Auto Scan function
again. (Placing the antenna near a window is best.)
• Check that the antenna connection is tight.
• Check that the correct country has been selected on the TotalMedia Scan Function page.
• Connect to an outdoor antenna (if not already done) and try the Auto Scan function again.
SPECIFICATIONS
Standards
• Hi-Speed USB 2.0 compliant
• Meets PAL/SECAM/NTSC video standards
Tuner
• Input terminal: 75 Ohm IEC (DIN)
• Receiving frequency (TV): 48.2 – 863.25 MHz
• Supports multiple and single channels per carrier
• Supports COFDM and FEC, plus DVB-T
• 2K – 8K FFT size
• Puncture codes: 1/2, 2/3, 3/4, 4/5, 5/6 and 6/7
• Bandwidth: 6/7/8 MHz (auto selected)
Demultiplexer
• 32 PIDs maximum number of Section Filtering
• Software engine
• PES and TS stream capture
A/V Formats
• Video format: MPEG-2 Main Profile and Main Level
• Audio format: MPEG-2 Audio Layer I and II
Connections
• TV or DVB-T: F-type female; USB: A-Type male
Physical
• Dimensions, overall: 8.5 x 2.8 x 1.3 cm (3.3 x 1.1 x 0.5 in.);
62.4 g (2.2 oz.)
• DVB-T antenna, 1.2 m (4 ft.)
• USB extension cable, 76 cm (30 in.)

www.manhattan-products.com
Are you completely satisfied with this product?
Please contact your MANHATTAN® dealer with comments or questions.
Copyright © MANHATTAN
All products mentioned are trademarks or registered trademarks of their respective owners.
