Manhattan 177368 User manual

HDMI
SWITCH
USER
MANUAL
Model 177368
MAN-177368-UM-0409-01

2
Thank you for purchasing this MANHATTAN
®
HDMI Switch, Model 177368.
By being able to select among multiple high-denition sources sharing
a single display, you can keep devices connected and ready to use,
eliminating the need to swap cables and thus reducing the risk of high-
performance cable and port damage. Using this manual for reference,
you’ll soon be enjoying the benets of these features:
• Maintains highest single-link resolutions for clear, sharp images up to
2.5 Gbps, 1080p or VGA (1920 x 1200)
• Full-function infrared remote control, including an external receiver
that lets you “hide” the switch and cables from view
• Automatically detects and selects active source and routes to display
• Lifetime Warranty
Package Contents
• HDMI Switch with Remote Control
• External infrared receiver
OPERATION
1. Using HDMI cable no longer than 20 m (approx. 65 ft.), connect the
HDMI input sources (for example, a pair of HDMI DVDs, as shown
above) to the Input port(s) of the switch.
2. Using HDMI cable no longer than 15 m (approx. 50 ft.), connect your
HDMI viewing device to the Output port of the switch.
3. Select an input/signal source by pressing the button on the switch
that corresponds to the input port the desired device is connected to.
NOTE: This switch features an “intelligent” function: If a connected
input source is disconnected or turned off, the switch will automatically
select the connected and powered-on device that follows in the input
port sequence; for example, if the device connected to Input port 1 is
turned off or disconnected, the switch will select the device connected
to Input port 2. (Standby mode is read by the switch as still powered on.)
→
→
HDMI DVD
HDMI TV
HDMI swITcH
HDMI DVD Input Output

4. Insert a battery in the remote control.
5. Connect the included external infrared receiver and place it wherever
it will receive an unobstructed signal from the remote control.
Operation Tips
• Always connect and remove cables gently to prevent damage.
• If using HDMI cable longer than 5 m (approx. 16 ft.), use a power
adapter (not included) and connect the switch to an A/C outlet.
• If the switch’s Power LED doesn’t light, check that the switch is on.
• If there is no video display:
- check that the display unit is turned on;
- conrm that all cables are properly connected.
• If there is no audio:
- check the display device volume;
- turn off, then turn back on the HDMI source(s) and the HDMI Switch.
• If the remote control doesn’t work, make sure the remote signal is
reaching the external receiver, or replace the battery.
• If a DVI device doesn’t work, make sure that it’s HDCP-compliant.
SPECIFICATIONS
3 3
Standards & Certications
• HDMI 1.3b, HDCP 1.0 / 1.1,
DVI 1.0, CE, FCC, UL
Connections
• (1) HDMI female (output)
• (3) HDMI female (intput)
• Power: 5 V DC / 2 A (adapter not
included)
• IR receiver: 3.5 mm stereo plug
Signal Input/Output
• Input video signal: 0.5 – 1.0 V p-p
• Input DDC signal: 5 V p-p (TTL)
• Max. single-link range: 2.5 Gbps,
1920 x 1200 and 1080p
• Frequency: 2.25 Gbps / 250 MHz
• Output video: HDMI 1.3b, HDCP
1.0 / 1.1
• Source-to-switch range: 1080p, up
to 20 m (65 ft.)
• Switch-to-display range: 1080p, up
to 15 m (50 ft.)
Video Resolutions
• VGA: 640 x 480, 800 x 600,
1024 x 768, 1920 x 1200
• DTV/HDTV: 480i/480p/576i/576p/
720p/1080i/1080p
Physical
• Dimensions: 80 x 58 x 18 mm
(3.15 x 2.28 x 0.7 in.)
• Weight: 55 g (1.9 oz.)
