K00400 Dispense Chute Conversion Kit
Bucket Fill to Cup Fill
1. Prior to installation make sure you have the following tools:
2. Disconnect the power from the dispenser by unplugging
the power cord from the electrical outlet.
3. Using a phillips head screwdriver, remove the two screws
located on both sides of the ice chute.
4. With the screws out remove the front panel by
grasping both sides and pulling towards you until it is
clear of the ice chute, then pull the panel up and out.
5. Remove the metal outer bracket clip, then use your
thumbs to spread the bracket and unhinge the ice
chute from the bracket pins.
6. Lift the door lock and rotate the ice chute clockwise
while pulling towards you in a slightly downward
motion to complete removal.
TOOLS REQUIRED
Phillips Head
Screwdriver
Screws
Front Panel
Front Panel
Bracket Clip
Door Lock
Ice Chute

K00400 Dispense Chute Conversion Kit Bucket Fill to Cup Fill 020002544 11/08
Manitowoc Foodservice Group, 2110 S. 26th St., P.O. Box 1720, Manitowoc, WI 54221-1720, Tel: [phone], www.manitowocfsg.com
7. Put the new ice chute into place by lifting the door lock and
door lock assembly. Rotate the chute counter clockwise in
an up and away from you motion, but do not snap the
bracket pins into place. Rest the chute on top of the pins.
Thisissoyoucanangle thelongerchute throughthechute
opening as you put the front panel back on to the
dispenser.
8. Place the bottom edge of the front panel on the lower
brackets of the dispenser so that the front panel can be
put back into position with a “scissor” like motion while
simultaneously angling the ice chute through the front
panel opening.
9. Return the front panel to its "in place" position and slide
thechutethroughtheopening,but do not push the front
panel all the way back as shown below.
10. Working from the front opening you can now align the ice
chute with the bracket pins and snap into place.
11. With the cup dispense ice chute now snapped intothe
bracket pins, replace the bracket clip across the front of
the chute bracket by reaching through the front panel
opening and snap into place.
12. With the bracket clip in place the cup dispense ice chute
is now secured in place. The front panel can now be
pushed all the way into place.
13. Once the front panel is pushed all the way back into it’s
final position, replace the two screws on both sides of
the ice chute.
14. Plug unit back in for operation.
15. Test the operation of the dispenser by pushing the ice
chute to dispense ice.
Door Lock
Ice Chute
Bracket Pins
Front Panel
Ice Chute
Opening
Ice Chute Opening
Bracket Pins
Front
Panel
Bracket
Clip
Front Panel
Ice Chute Opening
