Manta 50LUA28L User manual

50LUA28L

1
Contents
IMPORTANT SAFETY INSTRUCTIONS . . . . ................................... . 2
SAFETY INFORMATION . . . . ............................................. . . . 3
GETTING STARTED ... . ................................................... . 5
Front/Back View . . . . ................................................. 5
Button Functions . . . . ................................................. 5
REMOTE CONTROL... . ........................ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Basic Operations . . . . ................................................. 8
Install the Batteries . . . . ............................................... 9
Connecting to External Devices ... . ........................ . . . . . . . . . . . . . . . ..7
Connecting external devices to your LED TV . . . . .........................7
What is Included/TV Placement Setup . . . . ................................... 4
TV Stand Installation/Removal . . . . ..................................... 4
Unit and Accessories . . . . .............................................4
Wall Mounting . . ............................... . . . . . . . . . . . . . . . . . . . . . . 4
SETTINGS .......... . . . . . ................................................10
10Initial Setup . . . . ............................................. . . . . . . . .
11
System Setting ... . .......................................... . . . . . ..
10
Main Menu ................................................................
12Network. . . . . . ............... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS........................................................ . 27
27Specifications ... . ........................ . . . . . . . . . . . . . . . . . ..... . . . ..
27Remote Control ... . ..................................................
27Multimedia Playback Format ... . ............................. . . . . . . . ...
13Time........................ . . . . . . . . . . . . . . . . . . . ..................
14General.................... . . . . . . . . . . . . . . . . . . . ....................
. . . . . ............................................ . . . . .... . . . .
15 Multimedia
16Music .................... . . . . . . . . . . . . . . . . . . . .....................
16Photo .................... . . . . . . . . . . . . . . . . . . . .....................
16Folder .................... . . . . . . . . . . . . . . . . . . . .....................
19Sound .................... . . . . . . . . . . . . . . . . . . . ......................
20Channel .................... . . . . . . . . . . . . . . . . . . . ....................
23Time .................... . . . . . . . . . . . . . . . . . . . .......................
TV Setting . . . . . ............... . . . . . . . . . . . . . . . . . . . ....................... 17
24Setting .................... . . . . . . . . . . . . . . . . . . . .....................
25Reset .................... . . . . . . . . . . . . . . . . . . . ......................

2
Important Safety Instructions
• Read these instructions – All the safety and operating instructions should be read
before this product is operated.
• Keep these instructions – The safety and operating instructions should be retained
for future reference.
• Heed all warnings – All warnings on the appliance and in the operating instructions
should be adhered to.
• Follow all instructions – All operating and use instructions should be followed.
• Do not use this apparatus near water – The appliance should not be used near water
or moisture – for example, in a wet basement or near a swimming pool, and the like.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacture’s
instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding plug. A polarized
plug has two blades with one wider than the other. A grounding plug has two blades
and a third grounding prong. The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart or
rack is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
• Unplug the apparatus during lightning storms or when unused for
long periods of time.
• Refer all servicing to qualified personnel. Servicing is required when the apparatus
has been damaged in any way, such as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
• Please keep the unit in a well-ventilated environment.
• WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture. The apparatus shall not be exposed to dripping or splashing and
that objects filled with liquids, such as vases, shall not be placed on apparatus.
• WARNING: The wall socket plug is used as disconnect device, the disconnect device
shall remain readily operable.
• WARNING: The batteries shall not be exposed to excessive heat such as sunshine,
fire or the like.
• This lightning flash with arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of non-insulated “dangerous voltage” within the
CA UT IO N
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock.
• To reduce the risk of electric shock, do not remove cover (or back) as there are no
user-serviceable parts inside. Refer servicing to qualified personnel.
• The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the appliance.
• This equipment is a Class II or double insulated electrical appliance. It does not
require a grounded connection.

3
Safety Information
To ensure reliable and safe operation of this equipment, please read carefully all the
instructions in this user guide, especially the safety information below.
Electrical safety
•The TV set should only be connected to a main power supply with voltage that
matches the label at the rear of the product.
•To prevent overload, do not share the same power supply socket with too many
other electronic components.
•Do not place any connecting wires where they may be stepped on or tripped
over.
•Do not place heavy items on them, which may damage the leads.
•Hold the main plug, not the wires, when removing from a socket.
•During a thunderstorm or when not using the television for long periods, turn off
the power switch on the back of the television.
•Do not allow water or moisture to enter the TV or power adapter. Do not use in
wet, moist areas, such as bathrooms, steamy kitchens or near swimming pools.
•Pull the plug out immediately, and seek professional help if the main plug or
cable is damaged, liquid has spilt onto the set, if accidentally exposed to water
or moisture, if anything accidentally penetrates the ventilation slots or if the set
does not work normally.
•Do not remove the safety covers. There are no user serviceable parts inside.
Trying to service the unit yourself is dangerous and may invalidate the product’s
warranty.
Only qualified personnel should service this apparatus.
•To avoid battery leakage, remove exhausted batteries from the remote control, or
when not using for a long period.
•Do not break open or throw exhausted batteries in a fire.
Physical safety
•Do not block ventilation slots in the back cover. You may place the TV in a
cabinet, but ensure at least 5 cm (2”) clearance all around.
•Do not tap or shake the TV screen, this may damage the internal circuits. Take
good care of the remote control.
•To clean the TV use a soft dry cloth. Do not use solvents or petroleum based
fluids.
•Do not install near any heat sources such as radiators, heat registers, stoves or
other apparatus (including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong, the wide blade, or the third
prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs.
•Unplug the apparatus during lightning storms or when unused for long periods.
•Refer all servicing to a qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled, or objects have fallen into the apparatus,
has been exposed to rain or moisture, does not operate normally, or has been
dropped.

4
What is Included/TV Placement Setup
TV Stand Installation/Removal
Wall Mounting
The TV is provided with mounting holes for a VESA approved wall mounting bracket
(NOT SUPPLIED). The VESA mounting pattern is 400 x 200mm. Remove the screws
holding the base to the base bracket and lift the base away (do not remove the base
mounting brackets). Mount the VESA bracket using 4 x M6 x 12 isometric threaded
screws (not supplied). Do not use screws longer than 12 mm; damage will occur to
the internal components.
Caution: Your new TV is heavy; please consult with a professional wall mount installer
to perform this installation.
Unit and Accessories
TV Set
Remote Control
with Batteries
Base Stand
6Screws
User’s Manual
Four mounting holes
(size M6 screw)
400mm
200mm
3 Screws
4*23 BMH
3 Screws
4*23 BMH
50LUA28L
HOME

5
Getting Started
Front/Back View
Button Functions
1. POWER LED:llluminates green when the TV is turned on.llluminates red when the
TV is in standby mode.The LED will alternate between red and green when the RVR
timer programming has started in the standby mode.
2. IR(Infrared Receiver):Receives IR signals from the remote control.
Do not put anything near the sensor,as its function may be
affected.
3. Power. press the button in
source. push forward and hold for 1-2 seconds
menu. pull back and hold for 1-2 seconds
In User menu move to left/right or push forward/pull back as appropriate
Vol +/- move to right or left

6
8. PC AUDIO: Connect it to the audio
output terminal of the PC
VGA: PC video input9.
AUDIO IN L/R: Stereo audio input
10.
HDMI 7.
VIDEO IN: Video input11.
RJ4512.
11
Coaxial: Digital audio output4.
2. TF
USB
1.
LINE OUT:Video output
3.
6.
RF: Antenna connection
YPbPr: Connect to the YPbPr video
output terminal of the DVD
5.
RJ45 VIDEO L AUDIO R VGA PC AUDIO HDMI1 HDMI2 RF
COAXIAL
Y PrPb LINE OUT TF USB2
5V 0.5A
USB1
5V 0.5A
10
12

cable receiver/satellite box
VGA
cable
Audio
cable
Connecting to External Devices
Connecting external devices to your LED TV
cable TV
company
VHF/UHF
antenna RF Coaxial
cable
7
HDMI
cable
cable
cable
Comonent
Composite
TF
RJ45 VIDEO L AUDIO R VGA PC AUDIO HDMI1 HDMI2 RF
COAXIAL
Y PrPb LINE OUT TF USB2
5V 0.5A
USB1
5V 0.5A

8
Remote Control
Basic Operations
1. POWER:Turn on the TV/Standby.
2. :Press to open the Home Page.
3. MUTE:Mute or restore the sound.
4. NUMBER KEYS: Change the channel directly.
5. SLEEP: Auto Power Off Timer
6. REPEAT: Repeat mode.
:Return to the previous channel tuned.
7. MENU: Show Menu.
8. EXIT: Exit the Menu.
9. SOURCE: Press to change signal source.
10. INFO: Show information about the current
program.
11. NAVIGATION KEYS (Up, Down, Left,Right
and OK): To move in the menus and confirm
settings.
12. V+ / V-:Increase and decrease volume.
13. CH+/CH-:Next and Previous channel.
14. P. MODE: Output image mode selection.
:Shows the main page in the teletext mode.
15. S. MODE: Setting audio options.
:Shows hidden information, such as the
answers to a teletext quiz.
16. GUIDE: Show the Electronic Program Guide.
:Freezes the page change in teletext mode.
17. P.SIZE: Press to select the different picture size.
:Shows the upper, lower section or the whole page.
18. AUDIO:Switch the audio channel when playing DVD
or multimedia.
19. DTV/RADIO:In DTV mode, press DTV/RADIO button to enter DTV or RADIO mode.
GUIDE
P.SIZE
S.MODE
DTV/RADIO FAV SUBTITLE
P.MODE
AUDIO
OK
SOURCE
INFO
MENU
EXIT
SLEEP
MUTE
POWER
CH
VOL
RETURN
1
4
11
14
15 17
2
3
6
16
5
7
8
9
10
12 13
18
19
20
21
22
23
24
25
26
27
28
29
HOME

9
Install the Batteries
If the remote control fails to operate the TV functions, replace the batteries in the
remote control.
1. Open the battery cover.
2. Insert two size-AAA batteries. (Place the batteries with their terminals
corresponding to the (+) and (-) indications in the battery compartment.)
3. Replace the cover.
REC/ :In DTV mode , press REC button to start recording, press button to
stop recording.
25.
: Fast rewind playback.
29.
: Fast forward playback.28.
: Next file or chapter.27.
: Previous file or chapter.
26.
Press the appropriate colour to direct access functions in TELETEXT
or EPG OSD mode.
20. SUBTITLE:Select subtitle of media video file. (needs the support of disk or flie)
21. FAV: Show the list of favourite channels.
22. TS: In DTV mode, press the button to active the TIMESHIFT function.
: Play/Pause.
23. : Stop playback.
GOTO: Play from the desired location.
24.

10
Settings
Initial Setup
1. Connecting your TV on the poweroutlet;
2. Press the POWER button on the remote to turn on the TV in green for the LED light.
CAUTION:Always disconnect the TV from the power outlet when the TV will
not be used for a long period of time. The POWER button on the front panel is only
used for switching the TV into standby, it does not disconnect the device from the
main voltage. To completely disconnect the main voltage, please remove the power
plug from the socket.
3. Press the key▼/▲/◄ / ►and following the picture as bellow to operate the subject.
NOTE:
The picture is for reference only.
Main Menu
Press ▼/▲/◄/ ►to select the menu.

11
Press OK button to enter to set .
Input the signal, and select the input source.
System Setting
Select the Setting in the Main Menu to enter the System Setting

12
Network
Wireless Network
Select the WIFI ,and press the passwork to connect.
wired network
Insert the Ethernet cable ,and select Auto get IP address to connect the Ethernet.

13
Time
Press the ◄ / ► to select the Time to set.
Auto Attach Get the current time and date automatically.
24 Hours Select the 12 hours or 24 hours.
Time Zone Select the local time zone.
Time Edit Edit the current time and date.
Date Format Set current date format.

14
General
Press the to select the General and set the general setting.
Language Setting Select current display language.
Input Method Select the Input method.
System Upgrade Upgrade to the newest system version.
System Recovery Recovery system to original state.

15
About
Information about the TV.
Multimedia
Press the Input to select Media source.
Select the Video, and OK button to enter.
SMART

16
Music
Press the◄/ ►button to select the Music .
Press the ◄/ ►button to select the Photo.
Folder
Press the◄/ ►button to select the Folder.

17
Input Source
Press INPUT button to enter input source.
Press the ▼/▲ button to select.
TV Setting
Press the MENU button to enter the TV Setting.
1/6
VGA

18
Press the to set the picture.
Picture Mode
Highlight the item and Press ENTER to enter the
sub-menu,that shows the picture mode you can
choose: Dynamic/Standard/Mild/User.
Contrast Adjust the white level of the picture.
Brightness Adjust darkness of black sections in
the picture.
Color Adjust the color intensity of the picture.
Sharpness Object edges are enhanced for picture
detail.
Hue Adjust the hue(Red,Green,Blue) of the
picture.
Noise Reduction (Off/Low/Middle/High)
You can clear up the input signal by set the item.
Color Temperature
Select the color temperature that you feel comfortable.
Cool Gives white colors a blue tint.
Medium Gives white colors a neutral tint.
Warm Gives white colors a red tint.
Aspect Ratio
Select the suitable aspect Ration. (4:3/16:9/Zoom1/Zoom2)
DLC Select ON/OFF.
