Marantz PM7005 User manual

.
Integrated Amplifier
PM7005
Owner’s Manual
You can print more than one page of a PDF onto a single sheet of paper.
Contents Connections Playback Settings Tips Appendix
1
Front panel Rear panel
Remote control
unit
Index

Accessories 3
Inserting the batteries 4
Operating range of the remote control unit 4
Features 5
High quality sound 5
High performance 6
Easy operation 6
Part names and functions 7
Front panel 7
Rear panel 10
Remote control unit 12
Connections
Connecting speakers 18
Speaker connection 19
Connecting a playback device 20
Connecting a recording device 21
Connecting to a device with digital audio output connectors 22
Connecting a PC or Mac 23
Connecting devices with remote control connectors 24
Performing operations by RC on this unit without visual contact 24
Remotely connecting Marantz audio devices 24
Connecting the power cord 25
Playback
Turning the power on 27
Turning speaker output on 28
Selecting the input source 28
Adjusting the volume 28
Turning off the sound temporarily (Muting) 28
Adjusting the tone 28
Playing CDs 29
Connecting and playing back from a computer (USB-DAC) 30
Connect and playback from a digital device (Coaxial/Optical) 37
Recording 37
Settings
Setting the Auto Standby mode 38
Turning Auto Standby mode off 38
Turning Auto Standby mode on 38
Tips
Tips 40
Troubleshooting 41
Appendix
D/A converter 47
Explanation of terms 47
Specifications 48
Index 51
Contents Connections Playback Settings Tips Appendix
Contents
2
Front panel Rear panel
Remote control
unit
Index

Thank you for purchasing this Marantz product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
.
.
.
Quick Start Guide CD-ROM (Owner’s Manual) Safety Instructions Warranty (for USA/for CANADA)
.
.
.
Power cord Remote control unit (RC003PMSA) R03/AAA batteries
Contents Connections Playback Settings Tips Appendix
3
Front panel Rear panel
Remote control
unit
Index

Inserting the batteries
1Remove the rear lid in the direction of the arrow and
remove it.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
R03/AAA batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 23 ft/7 m
30°
Contents Connections Playback
Settings Tips Appendix
4
Front panel Rear panel
Remote control
unit
Index

Features
High quality sound
0All-discrete current-feedback amplifier
Marantz proprietary current-feedback circuit, using discrete
components, is adopted in the pre-amplifier and power amplifier. It is a
high-speed amplifier using the latest technology developed for the
higher-grade amplifiers.
0HDAM®SA3 Module
This unit includes the HDAM®SA3 which had been developed for
highend models. The HDAM®SA3 is incorporated into many
components, such as the current feedback power amplifier.
0Short-power-line layout
For strong momentary current supply, a short power-line layout unifies
the power circuit and output stage of the power amplifier section.
This layout allows connecting the large-current lines via the shortest
route while to arranging the left and right channels symmetrically.
0CD direct buffer amplifier
An input buffer amplifier exclusive for CD is mounted near the CD input
jacks. This is a high-speed buffer amplifier made with discrete
components, which avoids interference between right and left channels
and can send the signals to the pre-amplifier with very high fidelity.
0Block condenser of large capacity
The unit is equipped with a newly developed 15000 μF large capacity
condenser that incorporates the concepts of high-end devices into the
power amplifier power circuit.
Contents Connections Playback Settings Tips Appendix
5
Front panel Rear panel
Remote control
unit
Index

High performance
0Equipped with a USB-DAC function to support DSD file playback
This unit is equipped with a USB-DAC function that supports DSD
signals and 192 kHz/24 bit PCM signals. You can enjoy high-quality
audio playback from the D/A converter built in to this unit by inputting
PCM signal or DSD signal music files into this unit from a computer via
USB connection.
0Install the dedicated driver software onto the computer before use.
“Installing the driver software” (v p. 30)
0You can use whichever commercially available or downloadable
player software you like to playback files on your computer.
0Can be used as a D/A convertor
Digital audio signals input from an external device or computer into this
unit can be converted and output as analog signals using this unit’s D/A
converter.
Easy operation
0Remote control compatible with CD players and network audio
players
The remote control provided with this unit can control Marantz CD
players and network audio players in addition to this unit. (v p. 13)
Contents Connections Playback
Settings Tips Appendix
6
Front panel Rear panel
Remote control
unit
Index

Part names and functions
Front panel
.
t Q1 Q3 Q4uy i Q0o Q2w req
A B C D E F G H I J K L M N
Contents Connections Playback Settings Tips Appendix
7
Front panel Rear panel
Remote control
unit
Index

.
t uyweqr
APower operation button (X)
This turns the power on/off. (v p. 27)
BPower indicator
This is lit as follows according to the power status:
0Power on : Off
0Standby : Red
0Power off : Off
0When the protection circuit is activated : Red (blinking)
CInput source select knob (INPUT SELECTOR)
This selects the input source. (v p. 28)
DHeadphones jack (PHONES)
Used to connect headphones.
Turn off speaker output when using headphones. (v p. 28)
NOTE
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
EBASS control knob
This setting adjusts the volume level for the bass. (v p. 28)
FSpeaker output button/indicator (SPEAKERS)
This switches speaker output on/off. (v p. 28)
Indicates the status of the unit’s as follows:
0Speaker output on: Blue
0Speaker output off: Off
GMUTE button / indicator
This switches the mute on/off. (v p. 28)
0Mute on: Red
0Mute off: Off
Contents Connections Playback
Settings Tips Appendix
8
Front panel Rear panel
Remote control
unit
Index

.
Q
1
Q
3
Q
4
i Q
0
o Q
2
HTREBLE control knob
This setting adjusts the volume level for the treble. (v p. 28)
IANALOG MODE button / indicator
This turns the ANALOG MODE on/off. (v p. 29)
0ANALOG MODE on: Blue
0ANALOG MODE off: Off
JSOURCE DIRECT button/indicator
This turns SOURCE DIRECT mode on/off.
(v p. 29)
0SOURCE DIRECT mode on: Blue
0SOURCE DIRECT mode off: Off
KBALANCE control knob
This adjusts the balance of the volume output from the left and right
speakers. (v p. 28)
LInput indicator
(v p. 28)
MRemote control sensor
This receives signals from the remote control unit. (v p. 4)
NVOLUME knob
These adjust the volume level. (v p. 28)
5, 8 and a can be adjusted when 0 is off (SOURCE DIRECT mode is off).
Contents Connections Playback Settings Tips Appendix
9
Front panel Rear panel
Remote control
unit
Index

Rear panel
.
o Q0tr y u
q w e
i
A B C
D E F G H I J
Contents Connections Playback Settings Tips Appendix
10
Front panel Rear panel
Remote control
unit
Index

.
wqe
yurt Q
0
oi
ADIGITAL AUDIO IN connectors
Used to connect devices equipped with digital audio output connectors
and PC. (v p. 22)
BSIGNAL GND terminal
Used to connect a turntable. (v p. 20)
CAC inlet (AC IN)
Used to connect the power cord. (v p. 25)
DTurntable input connectors (PHONO)
Used to connect a turntable. (v p. 20)
ECD input connectors
Used to connect a CD player. (v p. 20)
FNetwork audio player input connectors (NETWORK)
Used to connect a network audio player. (v p. 20)
GTuner input connectors (TUNER)
Used to connect a tuner. (v p. 20)
HRecorder input/output connectors (RECORDER)
Used to connect the input/output connector of a recorder. (v p. 21)
ISpeaker terminals (SPEAKERS)
Used to connect speakers. (v p. 18)
JRemote control input/output connectors (REMOTE CONTROL)
Used to connect to a Marantz audio device that is compatible with the
remote control function. (v p. 24)
Contents Connections Playback Settings Tips Appendix
11
Front panel Rear panel
Remote control
unit
Index

Remote control unit
.
t
y
r
e
w
q
oAmplifier operations
AInput source select buttons
This selects the input source. (v p. 28)
BANALOG MODE button
This turns the ANALOG MODE on/off. (v p. 29)
CSOURCE DIRECT button
This turns SOURCE DIRECT mode on/off. (v p. 29)
DMUTE button (:)
This mutes the output audio. (v p. 28)
EAMP POWER button (X)
This turns the power on/off (standby). (v p. 27)
FVOLUME buttons (df)
These adjust the volume level. (v p. 28)
Contents Connections Playback Settings Tips Appendix
12
Front panel Rear panel
Remote control
unit
Index

.
o
Q0
i
u
w
q
e
r
y
t
Q3
Q1
Q2
oCD player operations
The supplied remote control can be used to control a Marantz CD
player in addition to this unit. To operate a Marantz CD player, press
the REMOTE MODE CD button to switch the remote control to the CD
player operation mode.
0REMOTE MODE CD button lights for approximately two seconds.
APOWER button (X)
BRemote mode select button (REMOTE MODE CD)
CSkip buttons (8, 9)
DStop button (n)
EInput source select button (INPUT)
FInformation button (INFO)
GTIME button
HCursor buttons (uio p)
IProgram button (PROG)
JNumber buttons (0 – 9)
KDIMMER button
LRANDOM button (P)
MSOUND MODE button
Contents Connections Playback
Settings Tips Appendix
13
Front panel Rear panel
Remote control
unit
Index

.
Q5
Q9
W0
W1
Q4
Q6
Q8
Q7
NPause button (3)
OPlay button (1)
PPlayback mode switching button (MODE)
QENTER button
RSETUP button
SCLEAR button
TREPEAT A-B button
UREPEAT button (L)
The amplifier can be operated with the amplifier operation buttons even when the
remote control operation mode is set to CD.
Contents Connections Playback Settings Tips Appendix
14
Front panel Rear panel
Remote control
unit
Index

.
w
e
q
r
y
i
u
t
Q0
Q1
Q2
o
oNetwork audio player operations
The remote control provided with this unit can control a network audio
player in addition to this unit. To operate a Marantz network audio
player, press the REMOTE MODE NET button to switch the remote
control to the network audio player operation mode.
0REMOTE MODE NET button lights for approximately two seconds.
APOWER button (X)
BRemote mode select button (REMOTE MODE NET)
CSkip buttons (8, 9)
DStop button (n)
EInput source select button (INPUT)
FInformation button (INFO)
GTOP MENU button
HCursor buttons (uio p)
IFAVORITES button
JNumber buttons (0 – 9, +10)
KDIMMER button
LRANDOM button (P)
Contents Connections Playback
Settings Tips Appendix
15
Front panel Rear panel
Remote control
unit
Index

.
Q4
Q5
Q3
Q7
Q8
Q6
Q9
W0
MPause button (3)
NPlay button (1)
OPlayback mode switching button (MODE)
PENTER button
QSETUP button
RCLEAR button
SSEARCH button
TREPEAT button (L)
The amplifier can be operated with the amplifier operation buttons even when the
remote control mode is NET.
Contents Connections Playback Settings Tips Appendix
16
Front panel Rear panel
Remote control
unit
Index

oContents
Connecting speakers 18
Connecting a playback device 20
Connecting a recording device 21
Connecting to a device with digital audio output connectors 22
Connecting a PC or Mac 23
Connecting devices with remote control connectors 24
Connecting the power cord 25
NOTE
0Do not plug in the power cord until all connections have been completed.
0Do not bundle power cords together with connection cables. Doing so can result in
humming or noise.
oCables used for connections
Provide necessary cables according to the devices you want to
connect.
Speaker cable
.
Audio cable
.
R
L
R
L
Remote connector cable
.
Optical cable
.
Coaxial digital cable
.
USB cable
.
Contents Connections Playback Settings Tips Appendix
Connections
17
Front panel Rear panel
Remote control
unit
Index

Connecting speakers
NOTE
0Disconnect this unit’s power plug from the power outlet before connecting the
speakers.
0Connect so that the speaker cable core wires do not protrude from the speaker
terminal. The protection circuit may be activated if the core wires touch the rear
panel or if the + and - sides touch each other. (“Protection circuit” (v p. 47))
0Never touch the speaker terminals while the power cord is connected. Doing so
could result in electric shock.
0Use speakers with impedance of 4 - 8 Ω/ohms.
oConnecting the speaker cables
Carefully check the left (L) and right (R) channels and + (red) and -
(white) polarities on the speakers being connected to this unit, and be
sure to connect the channels and polarities correctly.
1Peel off about 3/8 inch (10 mm) of sheathing from the
tip of the speaker cable, then either twist the core wire
tightly or terminate it.
.
2
Turn the speaker terminal counterclockwise to loosen it.
.
3Insert the speaker cable’s core wire to all the way into
the speaker terminal.
.
4Turn the speaker terminal clockwise to tighten it.
.
Spade lug connector
.
When using a banana plug
Tighten the speaker terminal firmly before inserting the banana plug.
.
Contents Connections Playback Settings Tips Appendix
18
Front panel Rear panel
Remote control
unit
Index

Speaker connection
.
wq wq
(R) (L)
Contents Connections Playback
Settings Tips Appendix
19
Front panel Rear panel
Remote control
unit
Index

Connecting a playback device
You can connect turntables, tuners, CD players and network audio players to this unit.
This unit is compatible with turntables equipped with a moving magnet (MM) phono cartridge. When you connect to a turntable with a low output moving
coil (MC) cartridge, use a commercially available MC head amp or a step-up transformer.
If you set this unit’s input source to “PHONO” and you accidentally increase the volume without having a turntable connected, you may hear a hum noise
from the speakers.
NOTE
The earth terminal (SIGNAL GND) of this unit is not for safety grounding purposes. If this
terminal is connected when there is a lot of noise, the noise can be reduced. Note that
depending on the turntable, connecting the ground line may have the reverse effect of
increasing noise. In this case, it is not necessary to connect the ground line.
GND
AUDIO
OUT
L
R
AUDIO
OUT
LR
AUDIO
OUT
LR
AUDIO
OUT
LR
L
L
R
R
L
L
R
R
L
L
R
R
Network audio
player
Tu n e r
Turntable
CD player
Contents Connections Playback
Settings Tips Appendix
20
Front panel Rear panel
Remote control
unit
Index
