Marantz PM8200 User manual

Model PM8200 User Guide
Integrated Amplifier

ENGLISH
WARRANTY
For warranty information, contact your local Marantz distributor.
RETAIN YOUR PURCHASE RECEIPT
Your purchase receipt is your permanent record of a valuable purchase.
It should be kept in a safe place to be referred to as necessary for
insurance purposes or when corresponding with Marantz.
IMPORTANT
When seeking warranty service, it is the responsibility of the consumer
to establish proof and date of purchase. Your purchase receipt or in-
voice is adequate for such proof.
FOR U.K. ONLY
This undertaking is in addition to a consumer's statutory rights and does
not affect those rights in any way.
FRANÇAIS
GARANTIE
Pour des informations sur la garantie, contacter le distributeur local
Marantz.
CONSERVER L'ATTESTATION D'ACHAT
L'attestation d'achat est la preuve permanente d'un achat de valeur. La
conserver en lieu sur pour s'y reporter aux fins d'obtention d'une
couverture d'assurance ou dans le cadre de correspondances avec
Marantz.
IMPORTANT
Pour l'obtention d'un service couvert par la garantie, il incombe au cli-
ent d'établir la preuve de l'achat et d'en corroborer la date. Le reçu ou la
facture constituent des preuves suffisantes.
DEUTSCH
GARANTIE
Bei Garantiefragen wenden Sie sich bitte an Ihren Marantz-Händler.
HEBEN SIE IHRE QUITTING GUT AUF
Die Quittung dient Ihnen als bleibende Unterlage für Ihren wertvollen
Einkauf Das Aufbewahren der Quittung ist wichtig, da die darin
enthaltenen Angaben für Versicherungswecke oder bei Korrespondenz
mit Marantz angeführt werden müssen.
WICHTIG!
Bei Garantiefragen muß der Kunde eine Kaufunterlage mit Kaufdatum
vorlegen. Ihren Quittung oder Rechnung ist als Unterlage ausreichend.
NEDERLANDS
GARANTIE
Voor inlichtingen omtrent garantie dient u zich tot uw plaatselijke Marantz.
UW KWITANTIE, KASSABON E.D. BEWAREN
Uw kwitantie, kassabon e.d. vormen uw bewijs van aankoop van een
waardevol artikel en dienen op een veilige plaats bewaard te worden
voor evt, verwijzing bijv, in verbend met verzekering of bij correspondentie
met Marantz.
BELANGRIJK
Bij een evt, beroep op de garantie is het de verantwoordelijkheid van de
consument een gedateerd bewijs van aankoop te tonen. Uw kassabon
of factuurzijn voldoende bewijs.
ESPAÑOL
GARANTIA
Para obtener información acerca de la garantia póngase en contacto
con su distribuidor Marantz.
GUARDE SU RECIBO DE COMPRA
Su recibo de compra es su prueba permanente de haber adquirido un
aparato de valor, Este recibo deberá guardarlo en un lugar seguro y
utilizarlo como referencia cuando tenga que hacer uso del seguro o se
ponga en contacto con Marantz.
IMPORTANTE
Cuando solicite el servicio otorgado por la garantia el usuario tiene la
responsabilidad de demonstrar cuá¥do efectuó la compra. En este caso,
su recibo de compra será la prueba apropiada.
ITALIANO
GARANZIA
L’apparecchio è coperto da una garanzia di buon funzionamento della
durata di un anno, o del periodo previsto dalla legge, a partire dalla data
di acquisto comprovata da un documento attestante il nominativo del
Rivenditore e la data di vendita. La garanzia sarà prestata con la
sostituzione o la riparazione gratuita delle parti difettose.
Non sono coperti da garanzia difetti derivanti da uso improprio, errata
installazione, manutenzione effettuata da personale non autorizzato o,
comunque, da circostanze che non possano riferirsi a difetti di
funzionamento dell’apparecchio. Sono inoltre esclusi dalla garanzia gli
interventi inerenti l’installazione e l’allacciamento agli impianti di
alimentazione.
Gli apparecchi verranno riparati presso i nostri Centri di Assistenza
Autorizzati. Le spese ed i rischi di trasporto sono a carico del cliente.
La casa costruttrice declina ogni responsabilità per danni diretti o indiretti
provocati dalla inosservanza delle prescrizioni di installazione, uso e
manutenzione dettagliate nel presente manuale o per guasti dovuti ad
uso continuato a fini professionali.
PORTUGUÊS
GARANTIA
Para informações sobre a garantia, contactar o distribuidor Marantz lo-
cal.
GUARDAR O RECIBO DE COMPRA
O recibo é o registo permanente da compra que fez. Deve ser guardado
num local seguro, para ser apresentado em questões relacionadas com
o seguro ou para quando tiver de contactar a Marantz.
IMPORTANTE
Quando procurar assisténcia técnica ao abrigo da garantia, é da
responsabilidade do consumidor estabelecer a prova e data de compra.
O recibe é prova adequada.
SVENSKA
GARANTI
För information om garantin, kontakta Marantz lokalagent.
SPAR KVITTOT
Kvittot är ett inköpsbevis på en värdefull vara. Det skall förvaras säkert
och hänvisas till vid försäkringsfall eller vidkorrespondens mod Marantz.
VIKTIGT
Fö att garantin skall gälla är det kundens sak att framställa bevis och
datum om köpet. Kvitto eller faktura är tillräokligt bevis fö detta.
DANSK
GARANTI
Henvend dem til Deres MARANTZ-forhandler angående inrformation om
garantien.
GEM DERES KVITTERING
Deres købskvittering er Deres varige bevis på et dyrt køb. Den bør
gemmes godt og anvendes som bevis, hvis De vil tegne en forsikring,
eller hvis De kommunikerer med Marantz.
VIGTIGT
Det påhviler forbrugeren at skaffe bevis for købet og købsdatoen, hvis
han eller hun ønsker garantiservice. Deres købskvittering eller faktura er
et fuldgyldigt bevis herpå.

English
To ventilae the unit, do not install the unit in a rack or bookshelf, and note
the followings.
- Do not touch the top of the enclosure during operation.
- Do not block the openings in the enclosure during operation.
- Do not insert objects beneath the unit.
- Do not block the ventilation slots at the top of the unit.
Do not place anything about 1 meter above the top panel.
- Make a space of about 0.2 meter around the unit.
Français
Pour que l’appareil puisse être correctement ventilé, ne pas l’installer dans
un meuble ou une bibliothèque et respecter ce qui suit.
- Ne pas toucher le dessus du coffret.
- Ne pas obstruer les ouïes de ventilation du coftret pendant le
fonctionnement.
- Ne placer aucun objet sous l’appareil
- Ne pas obstruer les ouães de ventilation du panneau supérieur. Ne placer
aucun objet à moins d’un mètre environ du panneau supérieur.
- Veiller à ce qu’aucun objet ne soit à moins de 0,2 mètre des côtés de
l’appareil.
Deutsch
Um eine einwandfreie Belüftung des Geräts zu gewährleisten, darf das
Gerät nicht in einem Gestell pder Bücherregal aufgestellt werden; die
folgenden Punkte sind besonders zu beachten:
- Während des Betriebs das Oberteil des Gehäuses nicht berühren.
- Während des Betriebs die Öffnungen im Gehäuse nicht blockieren.
- Keine Gegenstände in das Gerät einführen.
- Die Belüftungsschlitze an der Oberseite des Geräts dürfen nicht blokkiert
werden. Darauf achten, daß über dem Gerät ein Freiraum von
mindestens 1 meter vorhanden ist.
- Auf allen Geräteseiten muß ein Zwischenraum von ungefähr 0,2 meter
vorhanden sein.
Nederlands
Installeer het toestel niet in een rek of boekenkast waar de ventilatie
mogelijk wordt gehinderd. Let tevens op de volgende punten:
- Raak de bovenkant van het toestel niet aan als het in gebruik is.
- Blokkeer de openingen van het toestel niet als het in gebruik is.
- Plaats geen onderwerpen onder het toestel.
- Blokkeer de ventilatie-openingen aan de bovenkant van het toestel niet.
Zorg dat er tenminste 1 meter vrije ruimte boven het toestel is.
- Zorg dat er 0,2 meter vrije ruimte rond het toestel is.
Español
Para ventilar la unidad no la instale en una estanteria ni estante para
libros, y tenge en cuenta lo siguiente:
- No toque la parte superior de la caja durante el funcionamiento.
- No tape las ranuras en la caja durante el funcionamiento.
- No ponga objetos debajo de la unidad.
- No tape las ranuras de ventilación de la parte superior de la unidad.
No ponga nada a menos de 1 metro por encima del panel superior.
- Deje un espacio de unos 0,2 metro alrededor de la unidad.
Italiano
Perch é l’unità possa essere sempre ben ventilata, non installarla in scaffali
o librerie e tenere presente quanto segue.
- Non toccare la parte superiore del rivestimento durante il funzionamento.
- Non inserire oggetti al di sotto dell’unit¡à.
- Non bloccare le fessure di ventilazione sopra l’unità
Non posare nulla per circa un metro sopra il pannello superiore.
- Lasciare 0,2 metro liberi tutto intomo l’unità.
Português
Para ventilar o aparelho, não instalá-lo dentro duma estante ou algo similar,
e observar as seguintes recomendações:
- Não tocar a parte superior do aparelho durante a operação.
- Não bloquear as aberturas do aparelho durante a operação.
- Não insertar objectos debaixo do apareiho.
- Não bloquear as aberturas de ventilação na parte de cima do aparelho.
Deixar um espaço completamente livre de cerca de 1 metro acima do
painel superior.
- Deixar um espaço de cerca de 0.2 metro ao redor do aparelho.
Svenska
För att ventilera enheten, ställ den inte i ett ställ eller bokhylla och tänk på
följande.
- Vidrör inte ytterhöljets ovansida under pågående drift.
- Blockera inte öppningarna i ytterhöljet under pågående drift.
- Stick inte in föremål under enheten.
- Blockera inte ventialtionshålen ovanpå enheten.
Placera inte någonting närmare än 1 meter ovånför apparaten eller
enheten.
- Se till det finns omkring 0,2 meter fri plats runt omkring enheten.
Dansk
Anbring ikke apparatet i et rack eller en boghylde, da dette kan bloke
luftcirkulationen omkring apparatet, lagttag ligeledes følgende:
- Berør ikke oversiden af kabinettet under anvendelsen.
- Bloker ikke åbningerne i kabinettet under anvendelsen.
- Stik ikke genstande ind under apparatet.
- Bloker ikke ventilationsåbningerne ovenpå apparatet.
Anbring ikke noget nærmere end 1 m over apparatets overside.
- Sørg for, at der er frit område på omkring 0,2 m omkring apparatet.
English
The PM8200 conforms with the EMC directive and low-voltage directive.
Français
Le PM8200 est conforme à la directive EMC et à la directive sur les basses tensions.
Deutsch
Der PM8200 entspricht den Bestimmungen über elektromagnetische Störfreiheit (EMC) und denen über
Niederspannungsgeräte.
Nederlands
De PM8200 voldoet aan de EMC-richtlijn en aan de richtlijn voor laag voltage.
Español
El modelo PM8200 cumple la directiva EMC y a la directiva sobre baja tensión.
Italiano
Il PM8200 è conforme alla direttiva EMC e alla direttiva sul basso voltaggio.
Português
O PM8200 é conforme às Directivas relativas à EMC e à baixa tensão.
Svenska
PM8200 uppfyller direktiven angående elektromagnetisk kompatibilitet och lågspänning.
Dansk
PM8200 overholder EMC-direktivet og lavspændingsdirektivet.
CE MARKING
CONTENTS
Engligh ............................................................................................................................................................................................. page 1
Français ............................................................................................................................................................................................ page 8
Deutsch .......................................................................................................................................................................................... Seite 15
Nederlands .................................................................................................................................................................................. pagina 22
Español ....................................................................................................................................................................................... página 29
Italiano ......................................................................................................................................................................................... pagina 36
Português .................................................................................................................................................................................... página 43
Svenska ......................................................................................................................................................................................... sidan 50
Dansk ............................................................................................................................................................................................. side 57
Specifications ................................................................................................................................................................................. page 64
Figures ........................................................................................................................................................................................... page 65

ENGLISH
1
FOREWORD
This section must be read before any connection is made to
the mains supply.
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
Do not push anything inside the equipment through the
ventilation holes.
Do not handle the mains lead with wet hands.
EQUIPMENT MAINSWORKING SETTING
Your Marantz product has been prepared to comply with the
household power and safety requirements that exist in your area.
This product can be powered by 230 V AC only.
IMPORTANT: (For UK version only)
This apparatus is fitted with an approved moulded 13 Ampere
plug.
To change a fuse in this type of plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362 5A, A.S.T.A. or BSI
approved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of
5A. If a plug without a fuse is used, the fuse at the distribution
board should not be greater than 5A.
NOTE:
The severed plug must be destroyed to avoid a possible shock
hazard should it be inserted into a 13A socket elsewhere.
HOW TO CONNECT A PLUG
The wires in the mains lead are coloured in accordance with
the following code:
BLUE—“NEUTRAL” (“N”)
BROWN—“LIVE” (“L”)
1. The BLUE wire must be connected to the terminal which is
marked with the letter “N” or coloured BLACK.
2. The BROWN wire must be connected to the terminal which
is marked with the letter “L” or coloured RED.
3. Do not connect either wires to the earth terminal in the plug
which is marked by the letter “E” or by the safety earth
symbol or coloured green or green-and-yellow.
Before replacing the plug cover, make certain that the cord
grip is clamped over the sheath of the lead — not simply
over the two wires.
COPYRIGHT
Recording and playback of any material may require consent.
For further information refer to the following:
—Copyright Act 1956
—Dramatic and Musical Performers Act 1958
—Performers Protection Acts 1963 and 1972
—any subsequent statutory enactments and orders
ABOUTTHIS USER GUIDE
Refer to the Figures on the page 65 at the rear of this user
guide. The numbers on the diagrams correspond to those in
the text. All references to the connections and controls that
are printed in BOLD type are as they appear on the unit.
PRECAUTIONS
The following precautions should be taken when operating the
equipment.
GENERAL PRECAUTIONS
When setting the equipment ensure that:
—the ventilation holes are not covered
—air is allowed to circulate freely around the equipment
— it is on a vibration free-surface
—it will not be exposed to interference from an external source
—it will not be exposed to excessive heat, cold, moisture or
dust
—it will not be exposed to direct sunlight
—it will not be exposed to electrostatic discharges
Turn counter-
clockwise to
loosen.
Strip coating from extermity.
Twist conductors.
Speaker cord
Turn clockwise
to tighten.
Insert conduc-
tors.
Never place heavy objects on the equipment.
If a foreign body or water does enter the equipment, contact
your nearest dealer or service centre.
Do not pull out the plug by pulling on the mains lead, hold the
plug.
It is advisable when leaving the house, or during a thunder-
storm, to disconnect the equipment from the mains supply.
CONNECTIONS
CONNECTION OF SPEAKER SYSTEMS
This unit is equipped with a sets of SPEAKERS terminals.
-The speakers in the speaker system should have an impedance
between 4 and 16 ohms. If speakers with an impedance of
less than 4 ohms are connected, the protection circuit may be
activated during play.
-Connect the Right channel speaker to the R terminals, and the
Left channel speaker to the L terminals.
-The output terminals have positive ( : Red) and negative
(: white) polarity, and each speakers also has the same
polarity ( and ). When connecting the speaker, be sure to
connect the terminals with the same polarity ( with ,
with ).
CAUTION:
When connecting two pairs of speaker systems simulta-
neously, the impedance of each speaker system should be
no less than 8 ohm .
Connecting a speaker system with a lower impedance than
8 ohm may activate the protection circuitry and make normal
stereo reproduction impossible.
Connection of speaker cord

ENGLISH FRANCÇAIS
2
L
R
CONTROL
REMOTEPRE OUT
GND
PHONO
R
L
CD
/DVD
AUX TUNERPHONO
L
R
OUT IN
CD-R
OUT
IN
OUT
IN
MD/TAPE
AC IN
RL
SPEAKERS
SPEAKERS IMPEDANCE: 4-8 OHMS
Tuner, etc
Analog turntable CD player Tape deck or MD
DVD player, etc CD-R
To output jacks
(LINE OUTPUT)
To output jacks
(LINE OUTPUT)
To output jacks
(LINE OUTPUT)
To output jacks
(LINE OUTPUT)
To output jacks
(LINE OUTPUT)
To input jacks
(LINE INPUT)
To input jacks
(LINE INPUT)
To AC power outlet
If you use the additional power
amplifier, connect the audio cables
to the INPUT jacks on the power
amplifier.
Connect directly
when the cartridge
is MM (Moving
Magnet) type.
Use the step-up
transformer when
the cartridge is
MC (Moving Coil)
type.
REMOTE CONTROL BUS terminals
(REMOTE CONT. BUS)
By connecting this unit with a MARANTZ
component equipped with the remote control
(D-BUS) jacks, both components can be
remote controlled as a system.
For details of the remote control function, read
the owners manual of the connected
component.
Connect the Right channel
speaker to the R terminals,
and the Left channel speaker
to the L terminals.
LR

ENGLISH
3
NAMES OF CONTROLS AND INDICATORS
(Page 65)
AGND (GROUND) terminal
Connect the grounding wire from the Analog turntable to this
terminal.
BPHONO INPUT jacks
Connect the output jacks of the Analog turntable to these jacks.
CCD PLAYER INPUT jacks
Connect the output jacks of a Compact Disc player to these
jacks.
DTUNER INPUT jacks
Connect the output jacks of a tuner to these jacks.
EAUX/DVD INPUT jacks
Connect the output jacks of DVD player or other AV compo-
nents to these jacks.
FCD-R IN/OUT jack
Connect the line output jacks and line input jacks of CD re-
corder to these jacks.
GMD/TAPE IN/OUT jacks
Connect the play (output) jacks and record (input) jacks of
tape decks or MD to these jacks.
HPRE OUTPUT jacks
Output jack for connection to extension power-amp.
IREMOTE CONTROL BUS jacks
(REMOTE CONT. BUS)
By connecting this unit with a MARANTZ component equipped
with the remote control (D-BUS) jacks, both components can
be remote controlled as a system.
For details of the remote control function, read the owner’s
manual of the connected component.
The bus OUT terminal is used to send signals to another item
of equipment. The bus IN terminal is used to receive signals
from another item of equipment.
JSPEAKERTerminals
Connect your speaker system to these terminals.
KAC IN jack
Connect to AC power outlet.
qINPUT SELECTOR switch
Selects the program source to be produced, from PHONO,
CD, TUNER, AUX/DVD, CD-R and MD/TAPE. The indicator on
the front panel will be illuminated due to your selected source.
Also, you can use the remote control to select the source.
wVOLUME control
Turn the knob to adjust the volume. Turning the knob clock-
wise ( ) to increase the volume. The volume up-down opera-
tions can also be controlled from the provided remote control
unit.
eREC SELECTOR switch
Selects the COPY mode between CD recorder and MD or TAPE
deck, or the signal to be output to the OUT jacks of CD-R and
MD/TAPE.
rSPEAKERS switch
Press to switch the speaker systems ON (pressed-in position)
and OFF (out position).
Set the switch to OFF (out position) when you listen through
headphones only.
tPHONES jack
This jack accepts the standard stereo phone plug of head-
phones.
yIR SENSOR
This unit receives the infrared remote control signal through
this window. Point the transmitter of the remote control unit to-
ward this window to send correct remote control signals.
uPOWER switch
Press the power switch to turn ON/OFF.
When the power is ON, the blue light on the middle of the front
panel and the indicator of the source will be illuminated.
iTone (BASS,TREBLE) controls
Turn the knobs to adjust the tone. Turning a knob controls the
level of the corresponding frequency range. Turning each con-
trol toward “+” boosts the corresponding frequency range and
toward “– ” attenuates it.
TREBLE: Controls the tone of high frequencies.
BASS: Controls the tone of low frequencies.
oSOURCE DIRECT switch
When you turn on this switch, you can listen the original sound
from the input source. The Tone (BASS, TREBLE) controls i
and the BALANCE control !0 cannot be used when this switch
is ON.
!0 BALANCE control
This knob can adjust the output level of the left-right balance.
When this knob is turned fully either clockwise or counter-clock-
wise, the other side of sound cannot be heard from the speaker.
!1 LOUDNESS switch
When this switch is ON, both treble and bass sound will be
emphasised.
!2 MUTE indicator
When you press the mute button on the remote control, this
indicator will be illuminated and the sound is muted.
When you press the MUTE button one more time, or change
the listening volume on the remote control, the MUTE will be
canceled.

ENGLISH FRANCÇAIS
4
OFF ON OFF ON OFF ON
AUX/DVD
CD
REC SELECTOR
OFF
COPY
LOUDNESS
SOURCE DIRECT
SPEAKER
MIN MAX
PHONO
TUNER
CD-R
MD/TAPE
CD-R
-+-+
VOLUME
LR
PHONO CD TUNER AUX/DVD CD-R
MUTE
INPUT SELECTOR
MD/TAPE
MD/TAPE
BASS
PHONES
POWER ON/OFF
BALANCE TREBLE
INTEGRATED AMPLIFIRE PM8200
qw
OFF ON OFF ON OFF ON
AUX/DVD
CD
REC SELECTOR
OFF
COPY
LOUDNESS
SOURCE DIRECT
SPEAKER
MIN MAX
PHONO
TUNER
CD-R
MD/TAPE
CD-R
-+-+
VOLUME
LR
PHONO CD TUNER AUX/DVD CD-R
MUTE
INPUT SELECTOR
MD/TAPE
MD/TAPE
BASS
PHONES
POWER ON/OFF
BALANCE TREBLE
INTEGRATED AMPLIFIRE PM8200
q
e
w
PLAYING PROGRAM SOURCE
Playing an analog disk
1. Set the INPUT SELECTOR switch qto PHONO.
2. Play the analog turntable.
3. Adjust the volume with the VOLUME control w.
Caution for analog disk play
- Reduce the volume to the minimum position before replac-
ing the cartridge or placing the stylus on the disk.
- Do not apply shock to the turntable during play. Otherwise
the stylus may jump and damage the disk surface.
- Avoid placing the turntable near the speakers. This may
cause howling and become out of control the VOLUME con-
trol.
- Do not turn off the turntable while the stylus is on a disk.
Playing a CD player
1. Set the INPUT SELECTOR switch qto CD.
2. Play the CD player.
3. Adjust the volume with the VOLUME control w.
Playing a source connected to AUX/DVD
The source component connected to any of the AUX/DVD in-
put jacks on the rear panel can be played as described below.
1. Set the INPUT SELECTOR switch qto AUX/DVD.
2. Play the component connected to the selected input.
3. Adjust the volume with the VOLUME control w.
Playing FM/AM tuner
1. Set the INPUT SELECTOR switch qto TUNER.
2. Play the tuner.
3. Adjust the volume with the VOLUME control w.
Playing a CD-R
1. Set the INPUT SELECTOR switch qto CD-R.
2. Play the CD recorder.
3. Adjust the volume with the VOLUME control w.
Playing a TAPE
1. Set the INPUT SELECTOR switch qto TAPE.
2. Play a pre-recorded tape on the tape deck.
3. Adjust the volume with the VOLUME control w.
RECORDING OFTAPE DECKS
Recording a CD-R, a MD, or a tape
A program source such as the analog turntable, tuner or CD
player can be recorded onto CD-R, MD, or tape as described
below.
Recording from CD
1. Set the REC SELECTOR switch eto CD.
2. Play a CD on the CD player.
3. Operate the CD recorder, MD, or the tape deck to start
recording.
Recording from the analog turntable
1. Set the REC SELECTOR switch eto PHONO.
2. Play an analog disk on the turntable.
3. Operate the CD recorder, MD, or the tape deck to start
recording.
Recording from a source connected toTUNER or AUX/DVD
1. Set the REC SELECTOR switch eto TUNER or AUX/DVD.
2. Play the source component connected to the selected in-
put.
3. Operate the CD recorder, MD, or the tape deck to start
recording.
Copying a CD-R to a MD or aTAPE
Regardless of the program source selected with the INPUT
SELECTOR switch q, when copying from a CD recorder to a
TAPE deck, set the REC SELECTOR switch eto CD-R →MD/
TAPE.
- You can listen to another program source selected with the
INPUT SELECTOR switch qwhile you are copying.

ENGLISH
5
REMOTE CONTROL OPERATION
(Remote control unit: RC8100PM)
The RC8100PM remote control unit can control MARANTZ au-
dio/video components equipped with an infrared remote sen-
sor as well as other MARANTZ components which are con-
nected with the above components through the remote control
bus. The following illustration shows the button layout of the
RC8100PM.
zGroup of buttons for selecting the connected
components *1
These buttons are used as the amplifier’s input selector.
xGroup of buttons for controlling playback, etc.
These buttons are used to control the CD player, tape deck,
etc.
cGroup of numeric buttons
These buttons are used to enter figures for the tuner, CD player,
etc.
vGroup of buttons for player,tuner, and other equipments
These buttons are used to change the modes or programmed
stations, etc.
bGroup of amplifier control buttons
These buttons are used to control the listening volume.
*1 Pressing one of these buttons change the functions of the
buttons in groups x,cand vaccording to the selected
source component except PHONO and AMP.
Please refer to the following tables entitled, which show
how the button functions change.
-+
PRESET
VOL.
VOL.
TUNE TUNE
AUDIO
MODE/
MUTE
VOL VOL
REPEAT
RAND0M
TEXT
POWER
SOURCE
RC8100PM
REMOTE CONTROLLER
TAPE
PHONO
0
879
546
213
CD-R
MD
SCROLL
DISPLAY AMS/SCAN
CLOSE
OPEN/
TUNER
AUX/DVD CD
x
v
c
x
b
z
Button functions when the CD button is pressed:
Button Function
PLAY
Fast forward
Fast backward
Stop
Pause
OPEN/CLOSE Open/Close
AMS/SCAN Music scan
TEXT Display the CD text
Skip forward to next track
Skip backward to previous track
SCROLL Scroll the text on the display
REPEAT Repeat play
RANDOM Random play
DISPLAY Switch the text/time information on the display
MODE/AUDIO Not used
Button functions when the TUNER button is pressed:
Button Function
Not used
Frequency up
Frequency down
Not used
Not used
OPEN/CLOSE Not used
AMS/SCAN Scan the programmed stations
TEXT Not used
Program type up
Program type down
SCROLL Not used
REPEAT Not used
RANDOM Not used
DISPLAY Switch the text/time information
MODE/AUDIO Change the MONO/STEREO

ENGLISH FRANCÇAIS
6
Button functions when the CD-R button is pressed:
Button Function
PLAY
Fast forward playback
Fast reverse playback
Stop
Pause
OPEN/CLOSE Open/Close
AMS/SCAN Intro-scan play
TEXT Not used
Chapter/Track skip forward
Chapter/Track skip backward
SCROLL Scroll the text on the display
REPEAT Repeat play
RANDOM Random play
DISPLAY Switch the time information on the display
MODE/AUDIO Not used
Button functions when the AUX/DVD button is pressed:
Button Function
PLAY
Fast forward playback
Fast reverse playback
Stop
Pause
OPEN/CLOSE Open/Close
AMS/SCAN Intro-scan play
TEXT Not used
Chapter/Track skip forward
Chapter/Track skip backward
SCROLL Not used
REPEAT Repeat play
RANDOM Random play
DISPLAY Switch the time information on the display
MODE/AUDIO Select the audio mode
Button functions when the MD button is pressed:
Button Function
PLAY
Fast forward
Fast backward
Stop
Pause
OPEN/CLOSE Open/Close
AMS/SCAN Not used
TEXT Change the charactors when TEXT is input
Skip forward to next track
Skip backward to previous track
SCROLL Not used
REPEAT Repeat play
RANDOM Random play
DISPLAY Switch the text/time information on the display
MODE/AUDIO Change the MONO/STEREO for recording
Button functions when the TAPE button is pressed:
Button Function
PLAY
Fast forward
Fast backward
Stop
Pause
OPEN/CLOSE Open/Close
AMS/SCAN Automatic music scan
TEXT Not used
Skip forward to next track
Skip backward to previous track
SCROLL Not used
REPEAT Select Deck A
RANDOM Select Deck B
DISPLAY Switch the time information
MODE/AUDIO
Blank skip

ENGLISH
7
HOWTO USETHE REMOTE CONTROL UNIT
1. Remote control unit
The distance between the signal transmitter of the remote con-
trol unit (RC8100PM) and the IR SENSOR of the integrated
amplifier (PM8200) should be less than about 5 meters. To en-
sure remote control, the remote control unit should be pointed
accurately toward the IR SENSOR and there should be no ob-
stacle between the remote control unit and the IR SENSOR.
Remote controllable range
Stereo integrated amplifier (PM8200)
Remote control unit (RC8100PM)
2. Loading batteries
The service life of the batteries used in the remote control unit
is about 1 year under normal use.
Remove the batteries when the remote control unit is not to be
used for a long period of time. Replace batteries early when-
ever they seem to be weakened.
(1) Remove the back cover.
(2) Insert batteries with correct and polarity.
(3) Slide close the battery cover until it clicks.
Improper use of batteries may cause the risk of fluid leakage
or explosion.
Be specially careful in the following points.
1. Insert the batteries with the correct and polarity as
indicated inside the battery case.
2. Do not use a brand-new battery and used battery together.
3. Dry cell batteries may produce different voltages even
when their shapes are the same. Do not use different types
of batteries together.
4. Some batteries are rechargeable and some are not. Be
sure to read the caution and instructions described on each
battery.
5. Used batteries should be disposed of in compliance with
the treatment method specified for your local area.
UM-3/AA
Approx.5m
TROUBLESHOOTING
In case of trouble with the unit, first check the following before
calling for service. What seems to be a serious malfunction is
often due to a simple operation mistake.
If the trouble still persists after checking, please consult your
dealer or nearest MARANTZ service agent.
The amplifier does not work and the indicator does not light.
1. Check if the power cord is plugged properly into an AC
power outlet.
The indicator lights but the amplifier will not function.
1. Check the settings of the INPUT SELECTOR switch, VOLUME
control and SPEAKERS switches.
2. Check the MUTE function is deacivated. (The MUTE indi-
cator is OFF.)
Sound is produced only from one of the speaker systems.
1. Check the setting of the BALANCE control.
2. Turn power of the set off and change the connections of
the left and right speaker systems. If sound is still not output
from the same speaker system, check its connection cord
or the speaker system itself.
Sound is not produced at all.
1. Check the settings of the INPUT SELECTOR switches.
2. Check the SPEAKERS switches is pressed in.
3. Check that the speaker cords are connected properly.
4. Check that the connection cords with RCA pin plugs are
connected properly.
5. Check the MUTE function is deacivated.
Sound from the analog turntable is not output or very noisy
(hum noise).
1. Check that the connection to the PHONO jacks is made
properly.
2. Connect the grounding wire of the turntable to the GND
terminal on the rear panel of the amplifier set. If it has al
ready been connected, try removing it.
3. Check that the cartridge is attached properly to the tone
arm.
4. Remove the power plug of the turntable from the power
outlet and insert it again by inverting the relationship of the
left and right blades with respect to the power outlet slots.
60
60°

64
TECHNICAL SPECIFICATIONS (DIN)
Rated power output........................................................................ 60 W x 2 (8 Ωload)
(1 kHz, 2ch simultaneous drive) 70 W x 2 (6 Ωload)
80 W x 2 (4 Ωload)
Total harmonic distortion (20Hz to 20 kHz, 2ch drive, 8 Ωload)......................... 0.01 %
Cross-modulation distortion (SMPTE) ................................................................ 0.01 %
Output bandwidth (8 Ωload, 0.04 %)....................................................10 Hz to 50 kHz
Frequency response (CD, SOURCE DIRECT) .................... 5 Hz to 60 kHz, +0 / –1 dB
Damping factor (8 Ωload, 20Hz to 10 kHz) ............................................................. 100
Input sensitivity
PHONO (MM) .............................................................................................................................. 2.3 mV
HIGH LEVEL .............................................................................................................................. 200 mV
Maximum allowable PHONO input (1 kHz)
MM ............................................................................................................................................. 130 mV
RIAA deviation (20 Hz to 20 kHz) ................................................................................................ ±0.2 dB
S/N (IHF A network, input shorted)
PHONO (MM) ................................................................................................................................ 85 dB
HIGH LEVEL ............................................................................................................................... 110 dB
Loudness (-20 dB)
100 Hz ............................................................................................................................................. 8 dB
10 kHz ............................................................................................................................................. 3 dB
Tone control
BASS (100 Hz) ............................................................................................................................. ±8 dB
TREBLE (10 kHz) ......................................................................................................................... ±8 dB
Supply voltage................................................................................................................... 230V AC, 50Hz
Power consumption ......................................................................................................................... 155 W
Dimensions
Width ..........................................................................................................................................440 mm
Height .........................................................................................................................................124 mm
Depth ..........................................................................................................................................340 mm
Weight ...........................................................................................................................................8.0 kg
Accessories
Remote control unit (RC8100PM) ...................................................................................................... x 1
Dimensions
Width ............................................................................................................................................55 mm
Height .........................................................................................................................................197 mm
Depth ............................................................................................................................................21 mm
Weight (without batteries) ................................................................................................................ 90 g
SUM-3 (”AA” size) dry cell battery ...................................................................................................... x 2
Design and specifications are subject to change without notice.

COUNTRY COMPANY ADDRESS
ALGERIE Azur 2000 8, Lotissement Ben Hatadi, Alger, Algerie
ARMENIA NGYIG Ltd. 47 A/75 St. Lalaiants, 375000 Yerevan, Armenia
AUSTRALIA Jamo Australia Pty. Ltd., 24 Lionel Road, Mt. Waverley, VIC 3149, Australia
AUSTRIA Huber & Prohaska GmbH Taborstraße 95 / Ladestraße 1, Gebäude Hangartner, A-1200 Wien, Austria
BAHREIN Ambassador Stores P.O. Box 237,141, Government Avenue, Manama,Bahrein
BANGLADESH Target 1078, Ramjoy Mohanja Lane Asadgonj, Chittagong 4000, Bangladesh
BELGIUM Van der Heyden Audio N.V. Brusselbaan 278, 9320 Erembodegem, Belgium
BULGARIA Ariescommerce GmbH Makedonia Blvd. 16, 1606 Sofia, Bulgaria
CANADA Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario
CHINA Guang Chang Audio International Co., Ltd. No.38 Yushan Road, ShiQiao, Pan Yu, Guang Dong, China
CYPRUS Empire Hifi systems Ltd. P.O. Box 5604, Nicosia, Cyprus
CZECH REPUBLIC Audio International Sokolska 41, 67902 Rajecko, OKR,Blansko, Czech Republic
DENMARK Audio Nord Dali Allé 1, 9610 Noerager, Denmark
DUBAI V.V.& SONS P.O. Box 105, Dubai, U.A.E.
EGYPT Solimco 9, El Attibaa St. Doki, Cairo, Egypt
ESTONIA HiFi Club Estonia Ehte 4, 90503 Haapsalu, Estonia
F.Y.R.O.M. T.P. KODI ul.Cedomir Kantargiev 21a, Skopje, Former Yugoslavian Republic of Macedonija
FINLAND Audio Nord Uudenmaankatu 4-6, Helsinki SF-00120, Finland
FRANCE Marantz France A division of Marantz Europe B.V., P.O. Box 301, 92 156 Suresnes Cedex, France
GERMANY Marantz Deutschland Hakenbusch 3, 49078 Osnabrück, Germany
GREECE Adamco S.A. 188, Hippocratous Street, 11471 Athens, Greece
HEADQUARTERS EUROPE: Marantz Europe B.V. Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands
HONG KONG Marantz Asia Ltd. Unit 1706, Metroplaza II, 223 Hing Fong Road, Kwai Fong, N.T., Kowloon, Hong Kong
HUNGARY Infovox Ltd. Terez Krt.31, 1067 Budapest, Hungary
ICELAND ID Electronics Ltd. Armula 38, 108 Reykjavik, Iceland
INDIA NOVA Audio Private 8,Punam Co-op.Society 29/30 Road#5, Union Park MUMBAI 400052, India
IRAN Home Co. 5th floor no 878 Philips Building Enghelab ave, P.O. 11365/7844 Tehran, Iran
IRELAND Marantz Ireland Clonskeagh, Dublin 14, Ireland
ISRAEL Elmor Ltd. 52 Heh Beiyar Street, Kikar Hamedina, Tel Aviv, Israel
ITALY Marantz Italy Via Casati 23, 20052 Monza (Milano), Italy, Servizio Consumatori 1678-20026, Numero Verde
IVORY COAST Hifivoir B.P. 2428, Abidjan 01, Ivory Coast
JAPAN Marantz Japan Inc. 35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505, Japan
KOREA Mk Enterprises Ltd. 121-210, 2F Shinhan Bldg., 247-17 Seokyo-dong, Mapo-ku, Seoul, Korea
KUWAIT alAlamiah Electronics Intl. P.O. Box 8196, Salmiah 22052, Kuwait
LATVIA Ace Ltd. 61, LacPlesa Str., Riga LV 1011, Latvia
LEBANON AZ Electronics S.A., 1, P.O. Box 11 2833, Beirut, Lebanon
LITHUANIA Accapella Ltd. Ausros, Vartu G/5, Pasazo SKG., 2001 Vilnius, Lithuania
MALAYSIA Wo Kee Hong Electronics Sdn. Bhd. Suite 8.1, Level 8, Menara Genesis, No. 33, Jalan Sultan Ismail, 50250 Kuala Lumpur, Malaysia
MALTA Doneo Co Ltd. 78 The Strand, Sliema SLM07, Malta
MAURITIUS SKR Electronics Ltd. P.O. Box 685, Bell Village, Port Louis, Mauritius
MILITARY MARKET EUROPE PASCO GmbH PO BOX 1280, Sandhausen 69200, Germany
NETHERLANDS Marantz Domestic Sales A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands
NEW ZEALAND Wildash Audio Systems 14 Malvern Road, Mt. Albert, Auckland, New Zealand
NORWAY Audio Nord Sandkerveien 64, Oslo 0483, Norway
OMAN Mustafa & Jawad Trading CO. P.O. Box 1918, Ruwi, Oman
