Marantz PS2100N1S User manual

TABLE OF CONTENTS
1. TECHNICAL SPECIFICATIONS .............................................................................1
2. SERVICE MODE ....................................................................................................2
3. TUNER ADJUSTMENT...........................................................................................3
4. DLOCK DIAGRAM..................................................................................................5
5. SCHEMATIC DIAGRAM AND PARTS LOCATION .................................................7
6. MICROPROCESSOR AND IC DATA ....................................................................29
7. SODA(Self-Oscillating class D Amplifier) .............................................................36
8. EXPLODED VIEW AND PARTS LIST...................................................................37
9. ELECTRICAL PARTS LIST...................................................................................40
Service
Manual
Please use this service manual with referring to the user guide (D.F.U) without fail.
328J855010 AO
3120 785 22660
First Issue:2001.05
PS2100/N1S, /C1S
AV Receiver
PS2100
PS2100
(PUSH ENTER)
- +
VOLUME
DISPLAY AMP TIMER
SURROUND
PHONES
MULTI JOG
MEMORY BAND TUNER
OPEN/CLOSE
STANDBY
PS2100
STANDBY
OPEN/CLOSE

MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
SHOCK, FIRE HAZARD SERVICE TEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC
cord connector pins ( with unit NOT connected toAC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
Ref. UL Standard No. 1492.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
001120 A.O
USA
MARANTZ AMERICA, INCMARANTZ AMERICA, INC.
440 MEDINAH ROAD
ROSELLE, ILLINOIS 60172
USA
PHONE : 630 - 307 - 3100
FAX : 630 - 307 - 2687
BRAZIL
PHILIPS DA AMAZONIA IND. ELET. ITDA
CENTRO DE INFORMACOES AO
CEP 04698-970
SAO PAULO, SP, BRAZIL
PHONE : 0800 - 123123(Discagem Direta Gratuita)
FAX : [phone]
JAPAN Technical
MARANTZ JAPAN, INC.
35- 1, 7- CHOME, SAGAMIONO
SAGAMIHARA - SHI, KANAGAWA
JAPAN 228-8505
PHONE : [phone]
FAX : [phone]
EUROPE / TRADING
MARANTZ EUROPE B.V.
P.O.BOX 80002, BUILDING SFF2
5600 JB EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2732241
FAX : +31 - 40 - 2735578
TECHNICAL AUDIO GROUP PTY, LTD
558 DARLING STREET,
BALMAIN, NSW 2041,
AUSTRALIA
PHONE : 61 - 2 - 9810 - 5300
FAX : 61 - 2 - 9810 - 5355
CANADA
LENBROOK INDUSTRIES LIMITED
633 GRANITE COURT,
PICKERING, ONTARIO L1W 3K1
CANADA
PHONE : 905 - 831 - 6333
FAX : 905 - 831 - 6936
AUSTRALIA
QualiFi Pty Ltd,
24 LIONEL ROAD,
MT. WAVERLEY VIC 3149
AUSTRALIA
PHONE : +61 - (0)3 - 9543 - 1522
FAX : +61 - (0)3 - 9543 - 3677
NEW ZEALAND
WILDASH AUDIO SYSTEMS NZ
14 MALVERN ROAD MT ALBERT
AUCKLAND NEW ZEALAND
PHONE : +64 - 9 - 8451958
FAX : +64 - 9 - 8463554
THAILAND
MRZ STANDARD CO.,LTD
746 - 754 MAHACHAI ROAD.,
WANGBURAPAPIROM, PHRANAKORN,
BANGKOK, 10200 THAILAND
PHONE : +66 - 2 - 222 9181
FAX : +66 - 2 - 224 6795
TAIWAN
PAI- YUING CO., LTD.
6 TH FL NO, 148 SUNG KIANG ROAD,
TAIPEI, 10429, TAIWAN R.O.C.
PHONE : +886 - 2 - 25221304
FAX : +886 - 2 - 25630415
MALAYSIA
WO KEE HONG ELECTRONICS SDN. BHD.
SUITE 8.1, LEVEL 8, MENARA GENESIS,
NO. 33, JALAN SULTAN ISMAIL,
50250 KUALA LUMPUR, MALAYSIA
PHONE : +60 3 - 2457677
FAX : +60 3 - 2458180
AMERICAS
SUPERSCOPE TECHNOLOGIES, INC.
MARANTZ PROFESSIONAL PRODUCTS
2640 WHITE OAK CIRCLE, SUITE A
AURORA, ILLINOIS 60504 USA
PHONE : 630 - 820 - 4800
FAX : 630 - 820 - 8103
AUSTRALIA
KOREA
MK ENTERPRISES LTD.
ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
3GA, HANGANG-RO, YONGSAN-KU, SEOUL
KOREA
PHONE : +822 - 3232 - 155
FAX : +822 - 3232 - 154
SINGAPORE
WO KEE HONG DISTRIBUTION PTE LTD
130 JOO SENG ROAD
#03-02 OLIVINE BUILDING
SINGAPORE 368357
PHONE : [phone]
FAX : [phone]

1
1. TECHNICAL SPECIFICATIONS
FM TUNER SECTION
Frequency Range........................................................................................................................................... 87.5 - 108.0 MHz
Usable Sensitivity ...................................................................................................................................... IHF 1.8 V / 16.4 dBf
Signal to Noise Ratio........................................................................................................................ Mono / Stereo 75 / 68 dB
Distortion .......................................................................................................................................... Mono / Stereo 0.2 / 0.5 %
Stereo Separation .............................................................................................................................................. 45 dB at 1 kHz
Alternate Channel Selectivity ........................................................................................................................ 60 dB ( 300 kHz)
AM TUNER SECTION
Frequency Range............................................................................................................................................... 531 - 1602 kHz
Signal to Noise Ratio......................................................................................................................................................... 50 dB
Usable Sensitivity ................................................................................................................................................... Loop 400 V
Distortion ........................................................................................................................................... 400 Hz, 30 % Mod. 0.5 %
Selectivity ........................................................................................................................................................... 18 kHz 40 dB
AUDIO SECTION
Rated Output Power (5 channel drive)............................................................................................................ 30 W at 8 ohms load
Stereo mode ................................................................................................................................................................ 50 W + 50 W
Input Sensitivity/Impedance ............................................................................................................................... 300 mV / 47 k ohm
Video Selector
Input, Output Level/Impedance............................................................................................................................ 1.0 Vp-p / 75 ohm
GENERAL
Power Supply ...................................................................................................................................... AC 230 V 50 Hz - N1S
AC 220 V 60 Hz - C1S
Power Consumption ........................................................................................................................................................ 280 W
Dimension (MAX)
Width........................................................................................................................................................................ 420 mm
Height ........................................................................................................................................................................ 76 mm
Depth ....................................................................................................................................................................... 322 mm
Weight........................................................................................................................................................................ 5.5 Kg
ACCESSORIES
Remote Control Unit RC2100SR...............................................................................................................................................1
AAA-size batteries.................................................................................................................................................................... 2
FM Feeder Antenna ..................................................................................................................................................................1
AM Loop Antenna......................................................................................................................................................................1
Bus cable...................................................................................................................................................................................1
AC cord .....................................................................................................................................................................................1
Specifications subject to change without prior notice.

2
2. SERVICE MODE
1.Trucking point memory of present memory / LCD segment luminous / check of speaker output
Connect an AC cable plug to mains while pressing <DISPLAY> and <ENTER>.
: Press <ENTER>, or Automatically to go
: Press <DISPLAY> and <ENTER>
: Turn JOG
: Only first time to go
1sec.
5sec.
5sec.
<DISPLAY>
and
<ENTER>
SERVICE
VER xxxx
PUSH ENTER
LCDTEST
VER xxxx
PUSH ENTER
TR FREQ
VER xxxx
PUSH ENTER
TONE
VER xxxx
PUSH ENTER
EXIT
VER xxxx OFF
All parts of
LCD is
Turned on
Each
Segment
is
displayed
one by one
Version of
MAIN u-com
is displayed.
<ENTER>
AUTO
PRESET
FM 87.50
MHz
<DISPLAY>
and
<ENTER>
<ENTER>
M02 AUTO
M02
FM 90.10
MHz
M10M10
AM 1620
kHz
M01 AUTO
M01
FM 87.50
MHz
M01 AUTO
PRESET1
FM 87.50
MHz
AUTO
TUNER
FM 87.50
MHz
AUX
DVD
LD/VCR
TV
VCR
5sec.
<ENTER>
<ENTER>
CLEAR
VER xxxx
LF NOISE
ALL MUTE
CENTER
ALL MUTE
RF NOISE
ALL MUTE
RS NOISE
ALL MUTE
LS NOISE
<DISPLAY>
and
<ENTER>
<ENTER> 2sec.
1sec.
2sec.
1sec.
2sec.
1sec.
2sec.
ALL MUTE
2sec.
1sec.
Shut down the power.
BAND M01 M02 M03 M04 M05 M06 M07 M08 M09 M10
FM
[MHz] 87.50 90.10 100.10 106.10 108.00 --- --- --- --- ---
AM
[kHz] --- --- --- --- --- 552 612 999 1503 1620
Turn JOG
Turn JOG
Turn JOG
Turn JOG
Turn JOG
Turn JOG
Turn JOG <DISPLAY>
and
<ENTER>
Turn JOG
Turn JOG

3. TUNER ADJUSTMENT
3 4
2.3 FM STEREO Distortion Adjustment
Adjust the L-channel with the RF signal modulated only L-channel first and confirm the R-channel with
RF signal modulated only R-channel.
Step
Input
Signal
Connection Signal
Frequency Source Signal Output Level and Modulation P–No. Reception Frequency Adjust. point Adjustment Value
1Level500V(54dB)
2
Only L-ch 1kHz/
Dev.67.5kHz 90% (C)
40k Hz 53.3% (N)
Pilot 19kHz/
Dec. 6.75kHz 9% (C)
6kHz 8% (N)
IF COIL
in Front
End
Distortion
Level
Minimum
at VCR-OUT
at VCR-OUT
VCR-OUT
VCR-OUT
L-ch.
3
Signal
generator
output to
FM
antenna
terminal
(75ohms)
100.1MHz 100.1MHz
100.1MHz
100.1MHz
Only R-ch
M03
Only
Confirm
Distortion
Level
Similar
as L-ch at
R-ch.
2.4 FM STEREO Separation Adjustment
Step
Input
Signal
Connection Signal
Frequency Source Signal Output Level and Modulation P–No. Reception Frequency Adjust. point Adjustment Value
1Level500V(54dB)
2
Only L-ch 1kHz/
Dev.67.5kHz 90% (C)
40k Hz 53.3% (N)
Pilot 19kHz/
Dec. 6.75kHz 9% (C)
6kHz 8% (N)
Output Level
Minimum
R-ch.
3
Signal
generator
output to
FM
antenna
terminal
(75ohms) Only R-ch
M03 R211
Output Level
Similar
as R-ch at
L-ch.
1. AM auto stop Level Check
Step Input Signal
Connection Signal Frequency
Source Signal
Output Level and
Modulation P–No. Reception
Frequency Adjust. point Adjustment Value
1Level 54 dB/m
(500 V/m) M08 999 kHz RA11 “TUNED”
indicates on
LCD
2
Signal generator
output to
transmission loop
antenna.
(‘Standard
required loop)
999 kHz
Level 60 dB/m
(1000 V/m) AUTO SCAN Only Confirm
Stop scan and
“TUNED”
Indicates on
LCD
2. FM Adjustment
2.1 F
*Auto scan mode activates that push and hold [ ] button on remote controller RC2100SR.
M MONO. Distortion Adjustment.
Step Input Signal
Connection Signal Frequency Source Signal Output Level and Modulation P-No. Reception Frequency Adjust. Point Adjustment Value
1
Signal generator
output to FM
antenna terminal
(75ohms)
100.1MHz
100.1MHz
Level 500 V (54 dB)
Mono 1kHz
Dev. 75kHz 100%(C)
Dev. 40kHz 53%(N)
M03
MONO 100.1MHz
100.1MHz
L201
Distortion
Level
Minimum at
VCR-OUT
2.2 FM Muting Threshold Check
First of all, check illuminates “AUTO” on LCD. If shows “ MONO” on LCD, press [TUNER MODE] button on unit or
remote that to set the AUTO mode. LCD shows “AUTO”. Input the signal and receipt it.
Step Input Signal
Connection Signal Frequency
Source Signal
Output Level and
Modulation P–No. Reception
Frequency Adjust. point Adjustment Value
1
Level 6.3 V(16dB)
Mono 1kHz/
Dev. 75kHz (C)
40kHz (N)
M03 --- “TUNED” indicates on
LCD
2
Signal generator
output to FM
antenna terminal
(75ohms) Level 12 V(22dB) AUTO SCAN Only
Confirm
Stop scan
and “TUNED”
Indicates on
LCD
Remark: AUTO MODE: [MODE] button in tuner mode on remote.
*Set RA11 first TUNED OFF (disappearTUNED) and 2nd set to TUNED ON (appearTUNED).

RC_OUT
RC_IN
MUTE
POWER_ON/OFF
POWER
HEADPHONE
DATA_BUS
POWER_SUPPLY
VIDEO
CONT1-4
–
–
–
-
–
SUB.WOOFER
CENTER
SURR_L/R
FRONT_L/R
BACKUP_SUPPLY
POWER_ON/OFF
QU51 VU50
LCD/DRIVER
QU01
U-COM/KEY_INPUT
QG01
QL51
VIDEO_SELECTOR
MUTE
QG04
QG03
QG02
QS03
QQ01
QS01
Q301 Q501
Q201
A101
TUNER_BLOCK
QW01
HEADPHONE_AMP
P724
P714
P704
FRONT_R
FRONT_L
CENT
SURR.R
SURR.L
L/R
L/R
L/R
L/R
DISPLAY
PROTECTER
PROTECTER
PROTECTER
AUX
SELECTOR
SELECTOR
CS_SURROUND
EL_VOLUME
DIGITAL_AMP_UNIT
CENTER
REAR
FRONT
HEADPHONE
BUS
OUT
IN
PLL
MPX&FM/AM
AMP IF
END
FM FRONT
AM
FM
TUNER
MONITOR
VCR
OUT
IN
LD
DVD
TV
VIDEO
INPUT
AUDIO
VCR
AUX
OUT
IN
LD
TV
CONT
IN
DIRECT
6CH
OUTPRE
SUBWOOFER
CENTER
REAR
FRONT
SUBWOOFER
CENTER
REAR
FRONT
5
4. BLOCK DIAGRAM
6

JG01
YT02060500
7
8
4
5
10
6
9
1
2
3
CS07 220p
50v
A-GND
A-GND
A-GND
RG02
1k
RG03
1k
RG05
1k
RG04
1k
RG06
1k
CG07
10/50v
CG08
10/50v
CG09
10/50v
CG10
10/50v
CG11
10/50v
CG12
10/50v
A-GND
A-GND
A-GND
DP02
1SS301/
DAN202U
QG02
NJM2068M
8
+V
765
1234
-V
CG44
0.1
CG13 68p 50v
CG14
68p 50v
CG43
0.1 CG20
100p
50v
CG19
100p
50v
RG16 2.2k
RG14
10k RG26
1k
RG25
1k
RG15 2.2k
RG13
10k
RG31
100k
RG32
100k
A-GND
A-GND
A-GND
A-GND
RG33
100k
CG16
68p
50v
A-GND
RG34
100k
RG28
1k
CG45
0.1
QG03
NJM2068M
8
+V
765
1234
-V
A-GND
RG27
1k
CG22
100p
50v
RG19
2.2k
CG21
100p
50v
CG46
0.1
RG1710k
RG20 2.2k
A-GND
CG15
68p
50v
CG48
0.1
A-GND
RG36
100k
RG2110k
RG35
100k
RG30
1k
RG24
3.3k
RG22
10k
CG47
0.1
A-GND
CG18
68p
50v
CG17
68p
50v
QG04
NJM2068M
8
+V
765
1234
-V
CG24
100p
50v
RG23
2.2k
A-GND
CG23
100p
50v
RG29
1k
QS03
LC78213
1
R
234
R
567
SW
89101112
VEE
13
CE
14
DI
15
CL
16
VSS
17
S
18
RES
19
VDD
2021
2ch/5ch
22
SW/CENTER
23
CS
24
C
25
REAR
26
CS
27
L
28
FRONT
29
CS
30
L
QQ03
SSM2005
1RFIN
2RFOUT
3LFIN
4LFOUT
5LOUT
6LOUTA
7LIN
8ROUT
9ROUTA
10 RIN
11 VEE
12 AGND
13 GND
14 VCC
15 (L+R)0
16 (L-R)0
17
(L-R)HI
18 (L-R)LO
19 RHBD
20 CHBD
21 HBD0
22 RLBD
23 LLBD
24 LBT0
48
COUT 47
LFOUT 46
RFOUT 45
LSOUT 44
RSOUT 43
NIN 42
NOUT 41
LOAD 40
RST 39
DI 38
VCC 37
AGND 36
GND 35
VEE 34
WR 33
CLK 32
F/RTF
31
LTF 30
HTF 29
FRD 28
(L-R)D 27
(L+R)D 26
ABL0 25
ABT
JS04
YJ07011550
9604S-25C 25242322212019181716151413112111098765432
QG01
M62446FP
1
OUT4
2
OUT3
3
OUT2
4
OUT1
5
AVDD
6
SWIN
7
GNDS
8
SRIN
9
SLIN
10
GNDC
11
CIN
12
GNDR
13
RIN
14
GNDL
15
LIN
16
BYSR
17
BYSL
18
LTRE
19
LBASS3
20
LBASS2
21
LBASS1
42 DVDD
41 CLK
40 DATA
39 LATCH
38 DGND
37 AGND
36 SWOUT
35 SROUT
34 SLOUT
33 COUT
32 ROUT
31 LOUT
30 AVSS
29 CL1
28 CL2
27 CR1
26 CR2
25 RTRE
24 RBASS3
23 RBASS2
22 RBASS1
RS23 220k
RS24 220k
RS25 220k
RS26
220k
RS07
1k
RS08
1k
RS09
1k
RS10
1k
CS08 220p
50v
CS10 220p
50v CS09
220p
50v
CS34 0
RS99
0
RS27 220k
RS28 220k
RS29 220k
RS30 220k
RS31 220k
RS32 220k
RS11
1k
RS12
1k
RS13
1k
RS14
1k
RS15
1k
RS16
1k
RS98
0
CS35 0
CS11 220p
50v
CS12 220p
50v
CS13 220p
50v
CS14 220p
50v
CS15 220p
50v
CS16 220p
50v
RS19 220k
CS04 220p
50v
JS01
YT02060500
1
2
4
5
10
6
3
7
8
9
RS06
1k
RS01
1k
CS06 220p
50v
CS33 0
RS20 220k RS18
220k
RS97
0
RS04
1k
CS01 220p
50v
RS03
1k
CS02 220p
50v
RS22 220k
RS02
1k
RS17 220k
RS05
1k
CS03 220p
50v
RS21 220k CS05 220p
50v
CG01 220p
50v
CG02 220p
50v
CG03 220p
50v
CG04 220p
50v
CG05 220p
50v
CG06 220p
50v
CG49
0
RG65
0
RG01
1k RG07
47k
RG08
47k
RG09
47k
RG10
47k
RG11
47k
RG12
47k
+12V
+12V
-12V
-12V
RG18
10k
+12V RG37
100
RG38
100
CG28 10/50v
CG30 10/50v
CG29 10/50v
CG26 10/50v
CG27 10/50v
CG25 10/50v
AA-GND
D-GND
+6V
RG40
100
RG39 100
RG41
100
CG38 3.3/50v
CG37 3.3/50v
CG36
8200p
25v CG35 0.015
CG34
0.33
CG40
100/10v
A-GND
CG33
0.33
CG31
8200p
25v
CG32
0.015
A-GND
CG39
100/10v
A-GND
-6V
+6V
RG42
22k
RG43 22k RG44 22k RG45 22k
D-GND
RS36 100k
CS29
100/16v
CS31
0.1
A-GND
CS30
100/16v
CS32
0.1 A-GND
-12V CQ45
10/50v
QS01
LC78211
123 456789101112
VEE
13
CE
14
DI
15
CL
16
VSS
17
S
18
RES
19
VDD
2021
SYSTEM
22
AUX
2324
VCROUT
25
VCRIN
2627
LD/VCD
28
TV
29
DVD
30
TUNER
RS33
100k CS23
100/16v
+12V
CS25
0.1
CS24
100/16v
CS26 0.1
A-GND
-12V
QS02
NJM4558M
4
-V
321
5678
+V
+12V
CS27
0.1
A-GND
CS22
150p
50v CS44
22/50v
RS38
47k
CQ64
10/50v
RS37
47k
A-GND
CS21
150p
50v CS43
22/50v
CS19
100p 50v
CS20
100p 50v
RS34
100k
RS35
100k
CS17
10/50v
CS18
10/50v
CS28
0.1
A-GND
A-GND
-12V
CQ63
10/50v
QQ04
NJM2068M
5678
+V
4
-V
321
+12V
-12V
RQ58
2.7k RQ57 1.5k
RQ56
1.5k RQ55 560
CQ43
1/50v
CQ44
0.47
A-GND
QQ01
NJM2068M
5678
+V
4
-V
321
-12V
+12V
CQ52
0.1
A-GND
CQ53
0.1
A-GND
CQ04
4700p
50v
CQ08
4700p
50v
RQ08
4.7k
RQ07
100k
RQ06
47k
RQ05
1.8k
CQ05
0.01 50v
RQ03
1.2k RQ04 4.7k
CQ03
0.1
CQ07
0.1 RQ11
1.8k RQ14 4.7k
RQ12
47k RQ13
100k CQ09
0.01
50v
RQ09
1.2k RQ10 4.7k
CQ54
0.1
RQ30
820
RQ25
5.6k
CQ18
100p
CQ59
0.1
+12V
-12V
RQ26
2.2k RQ28 220k CQ19
0.01
50v
QQ02
NJM2068M
5678
+V
4
-V
321
CQ17
0.1
A-GND
RQ27
560k
A-GND
RQ29
82
RQ24
150k
RQ23
12k
RQ22
220
RQ21
560 CQ15
1000p
50v
CQ14
1000p
50v
RQ19
39k RQ20 1.2k
CQ13
0.1
RQ17
560
RQ18
220
CQ21 0.1
CQ06
10/50v
CQ10
10/50v CQ11
0.1
RQ15
100
A-GND
A-GND
CQ56
0.1
CQ57 0.1
AA-GND
RQ68
10
RQ67
10
+6V
-6V
CQ29
1/50v
CQ28
0.1
CQ30
22/50v
RQ43
4.7M
CQ31
1/50v
RQ44
10k
AA-GND CQ32
1/50v
RQ41
1k
CQ27
10/50v
A-GND
RQ16
100 CQ12
0.1
CQ16
10/50v
CQ20 10/50v
CQ33
1/50v
RQ42
1k
CQ22 0.1 CQ23
1/50v CQ25
1/50v
RQ31
82
RQ32
820 RQ34
120 RQ33 330
RQ35
330
RQ36
120 RQ37
330
RQ38
120
RQ39
330
RQ40
120 CQ24
0.1
CQ26
0.1
A-GND
AA-GND
CQ60
0.1
CQ61
0.1 AA-GND
RQ65
10
RQ66 10
-6V
+6V
CQ51
100p
50v
D-GND
CQ50
100p
50v
CQ48
100p
50v
CQ49
100p
50v
CQ47
100p
50v
RQ62
100
RQ63
100
RQ50
3.3k RQ51
560
CQ41
0.47 CQ42
1/50v
RQ52
33k RQ53 180
AA-GND
RQ61
100
RQ60
100
RQ48
270k RQ49 3.9k
CQ40
0.22
(2125)
CQ39
0.1
RQ47
100k
CQ38
1/50v
CQ37
1/50v
RQ46
3.9k
CQ36
0.22
(2125)
RQ45
270k CQ35
0.1
AA-GND
QW01
NJM4556AM
4567
3218
CW12 0.1
CW10
10/50v
A-GND
-12V
CW09
10/50v
CW11
0.1
+12V
A-GND
RW04
39k
CW04
47p
A-GND
RW06
2.2k CW06
10/50v
RW08
560
CW05
10/50v
RW07
560
RW03
39k
CW03
47p
RW05
2.2k
A-GND
A-GND
CW08
100p
50v
CW07
100p
50v
JW01
YP0601045X
EH-5P
1
2
3
4
5
A-GND
JT02
YP0601045X
EH-5P
1
2
3
4
5
WT01
EARTH CT03
0.1
CT11
1000p
50v 1000p
CT12
50v
JT01
YJ01004710
2
3
4
5
1
6
Q803
NJM7806FA
2
3
1
C817
0.01
50v
C818
470/10v
+6V
Q802
NJM7812FA
2
3
1
C819
10/50v
C820
0.01
50v
+12V C815
2200/25v
C821
0.01
50v
C822
10/50v
Q801
NJM7912FA
3
12
-12V
C816
2200/25v
D804
S2VB
3
2
4
1
C802
0.01
500v J802
YP06003690
VH-6P
6
5
4
3
2
1
-6V
C824
470/10v
Q804
NJM7906FA
3
12
C823
0.01
50v
GND
D801
S5VB
2
3
1
4
C807
6800/50v
C808
6800/50v
C801
0.01
500v
J801
GND
JP01
YJ06008820
12JQ 123456789101112
A-GND
PR-GND
PA-GND
FP01
250V
T3.15A
FP02
250V
T3.15A
Q830
LM2575HVT
5ON/OFF
4
FB
1VIN
2
OUTPUT
3
GND
D830
RB160L-60
C835 470/25v
L830
220UH
DD-GND DD-GND
DD-GND
DD-GND
C830
220/63v
DD-GND
Q805
NJM7812FA
2
3
1
C805
0.01
50v
C804
0.01
50v GND
Q806
NJM7912FA
3
12
C828 0.01 C826
0.01 C827
10/50v
PR-GND
C829
10/50v
PB-GND FP04
250V
T3.15A
PR-GND
JP02
YJ06008820
12JQ 123456789101112
A-GND
FP03
250V
T3.15A
JP03
YJ06008820
12JQ 123456789101112
PC-GND
A-GND
FP05
250V
T3.15A
PR-GND
FP06
250V
T3.15A
QP09
RN2303/
DTA124EU
QP08
RN1303/
DTC124EU
+12V
A-GND
QM01
LB1641
12345678910
QP05
RN2303/
DTA124EU
QP04
RN1303/
DTC124EU
DP01
1SS301/
DAN202U
QP07
RN2303/
DTA124EU
QP06
RN1303/
DTC124EU A-GND
A-GND
RM01
220
DD-GND
CM01
0.01
RM02
2.7k
RM03
4.7 1/4w
CM04
220/16v
DD-GND
DD-GND
CM05
0.1
JM01
YP06006660
UP CONNECTOR
654321
CM03
0.01
CM02
0.01
D-GND
JS05
YP06010460
EH-7P
1234567 D-GND
+12V
D-GND
JG51
YP06010460
EH-7P
7
6
5
4
3
2
1-6V
+6V
V-GND
123456
SD
CEO
DO
CLK
DI
DP03
SFPL-52V
RP01
1k
RP02
47k
CP01
0.47/50v
GND
QP01
RN1303/
DTC124EU A-GND
A-GND
QP02
RN1303/
DTC124EU
QP03
RN1303/
DTC124EU A-GND
CG41
100/10v
D-GND
-12V
CG50
100/16v
A-GND
CG51
100/16v
A-GND
QW03
2SC4213
QW02
2SC4213
C
B
E
QG05
2SC4213
CB
E
QG06
2SC4213
CB
E
QG10
2SC4213
CB
E
QG08
2SC4213
C
B
E
QG07
2SC4213
C
B
E
QG09
2SC4213
QQ05
NJM2068M
5678
+V
4
-V
321
A-GND
RQ70 10k
A-GND
RQ69
47k
A-GND
RQ71
10k
CQ65
47p CQ66
10/50v
RQ72
47k
A-GND
RQ73
47k
RQ74
47k
RQ75
10k
RQ76
10k
QQ06
NJM2068M
5678
+V
4
-V
321
RQ78
10k
CQ68
47p
RQ77
10k
CQ67
47p CQ69
10/50v
RQ79
47k
RQ80
47k
A-GND
CQ70
10/50v
CQ75
100/16v
A-GND
RQ81
47k RQ83
10k
RQ84
10k
RQ82
47k
A-GND
QQ07
NJM2068M
5678
+V
4
-V
321
CQ71
47p
RQ85
10k
CQ72
47p
RQ86
10k
CQ74
10/50v
RQ87
47k
RQ88
47k A-GND
CQ73
10/50v
RG50
4.7k
RG51
4.7k
RG52
4.7k
RG53
4.7k
RG55
4.7k
RG54
CQ76
100/16v
-12V
A-GND
RW10
4.7k
RW09
4.7k
RW11
2.2k
DP04
1SS301/
DAN202U
DP06
1SS301/
DAN202U
RM04
390
DD-GND
RDS_IN
RQ95
10k
CQ87
47p
RQ96
47k
A-GND
RQ94
10k
A-GND
RQ93
47k
CS37
10/50v
CS38
10/50v
CS36
10/50v
CS39
10/50v
CS40
10/50v
CS41
10/50v
DP09
1SS301/
DAN202U
DP07
1SS301/
DAN202U
DP08
1SS301/
DAN202U
+6V
-12V
RG56
680k
RG57
680k
RG58
680k
-12V
-12V
JS03
YT02060460
7
8
4
5
10
6
9
1
2
3
JS02
YT02040940
4
5
1
2
7
3
6
+12V
TUNER_R
TUNER_L
CM06
DD-GND
CQ85
100/16v
A-GND
CQ86
0.1
A-GND
CQ83
100/16v
CQ84
0.1
A-GND
A-GND
CQ34
1/50v
CQ78
0.1
A-GND
CQ77
0.1
A-GND
CQ80
0.1
A-GND
CQ79
0.1
A-GND
CQ82
0.1
A-GND
CQ81
0.1A-GND
C831
0.01
50v
C832
0.01
50v
C833
0.01
50v
A-GND
AA-GNDV-GND
C834
0.01
50v
AA-GNDV-GND
PA-GND PR-GND D-GND DD-GND
A-GND
A-GND
+BC -BC
-BB+BB
+BD
-BA+BA
+BA
+BB
+BC
-BA
-BB
-BC
PC-GND
PB-GND
CW14
CW13
R805
4.7
1/6w
R806
4.7 1/6w
CG53
CG54
CG55
CG56
CG57
CG58
LP03
100UH
LP04
100UH
CP03
100p
A-GND
CP04
100p
A-GND
LP02 100UH
NLC453232
LP01
100UH
NLC453232
CP06
100p CP05
100p
A-GND A-GND
LP05
100UH
NLC453232
LP06
100UH
NLC453232
A-GND
CP02
100p
DM02
DD-GND
A-GND
A-GND
A-GND
DG01
1SS302
A-GND
+12V
CP09
0.1
C836
470/25v
DD-GND
L832
10UH
CDRH5D28
R832
47
C837
1000p
L831 10UH
CDRH5D28
R831
2.2
1/6w
RQ97
100k
A-GND
F803250VT5.0A
F804 250VT5.0A
R833
1k C838
470p DP10
1SS301/
DAN202U
RP03
1k
CP08
220/25v
GND
+BD
+VM
+VM
4.7k
RG59
QQ08
NJM2068M
5678
+V
4
-V
321
RQ91
0
-12V
A-GND
CQ92
0.1
CQ94
10/50v
A-GNDA-GND
RQ92
0
RQ01
10k
RQ99
10k
RQ89
10k
CQ89
47p
A-GND
A-GND
CQ91
0.1 CQ93
10/50v
A-GND
+12V
RQ98
10k
RQ90
10k
CQ90
47p
RQ02
10k
RQ54
R315
R316
T-GND AA-GND
J831
YP0600383X
EH-3P
1
2
3
DD-GND
+BD
RP04
QP10
RN1303/
DTC124EU A-GND
QP11
A-GND
QP12
A-GND
RP05
SD
SW1
SW2
SW3
SW4
CLK
DO
CS_RESET
CLK
DO
CE1 SW4
SW3
SW2
SW1
CLK
DO
CEO
CEO
DO
CLK
TUNER_L SD
CEO
DO
CLK
DI
RDS_IN
CEO
CE1
DI
CS_RESET
CE2
CLK CLK
DO DO
RDS_IN
CE2
TUNER_R
L
LD/VCD R
TV R
L
L
SYSTEMAUX R
L
R
VCR IN
R
L
VCR OUT
FRONT L
R
CENTER
SUB-W
DVD
5.1CH INPUT
CENTER
L
FRONT R
L
PREOUT R
SUB-W
RVR
2CH/5CH_IN
POW-MUTE
CS_RESET
CE2(CS_WRITE/LOAD)
DI(PLL_DO)
OSC_SHIFT/FM_OUT(RDS)
SD
+6VD
CE1
D-GND
CLK
D.OPEN_SW.
CEO
DO
2/5_OUT
+12V
RC_IN
MUTE
RC_OUT
POWER
D.MOTOR_FWD.
D.MOTOR_REV.
SYSTEM_IN/OUT
P.DOWN
D.CLOSE_SW.
+6VD
POWER
P_DOWN
D-GND
RC_IN
RC_OUT
SYSTEM
WV01
TO JV04
(PV04)
021C 008C
CLOSE
OPEN
DOOR MOTOR
016C
LIMIT SW1
LIMIT SW2
016C
(RMO)
DOOR_OPEN/CLOSE
DOOR_MOTOR
R_IN A-GND L_IN RELAY+B RELAY +12V PR-GND -12V +BC PC-GND -BC
CENTER_BLOCK
L_IN PR-GND +12V
FRONT_BLOCK
RELAY RELAY+B -BA -12V A-GND R_IN +BA PA-GND
RELAY+B -12V +12V PR-GND
SURROUND_BLOCK
PB-GND A-GND -BB RELAY R_IN L_IN +BB
MAINAMP
RMA
+12V
-12V
RPS
+6V
+12V
-12V
-6V
HEADPHONE PCB
RHP
RRK
TUNER BLOCK
RRJ
++
+
+
+
+
SW4
SW3
SW2
SW1
+6V
V-GND
-6V
FROM WG01
(PL04)
(VIDEO BLOCK)
(FRONT PCB)
(POWER/REMOTE PCB)
TO JB05
(PB01)
RMO
FRONT_L
FRONT_R
SURROUND_R
CENTER
SURROUND_L
2CH/5CH_IN
++
(LCH)(RCH)
+
+
+
+
+
+
+++
+
+
+
R
L
N_ONLY
RHP
WG327J1040
PT04
TO L001
(TRANSF)
HEADPHONE_IN HIGH
HEADPHONE_OUT LOW
HEADPHONE_R
HEADPHONE_L
WG328J2010
P704
RMP
RMD RMP
RMB
P714
MAINAMP
WG328J2020
RMC
WG328J2030
RMP
P724
MAINAMP
WG328J1012
PV04
+
+
N_ONLY
(WT02)
FRONT_L
SURROUND_L
CENTER
FRONT_R
SURROUND_R
OSC_SHIFT
SURROUND
SURROUND
OSC SHIFT OSC SHIFT OSC SHIFT
+
+
0
0
0
0
0
0
0
0
00.7
0.7
0.7
0.7
0.7
0.7
8.0 8.0
8.0 8.0
0
0
0
0
7.4
5.7v 0.9v 1.5v
0v 0v
12v 12v
0.7v
-5.3v
0
0
11.0
0
0
11.0
011.0
012.0
0
0
12.0
-12.1v
12.1v
-18.4v
-17.3v
0
0
0
37.2v
12.2v
12.0v
-5.9v
0
-11.7v
-12.1v -18.4v
0
12.0v 17.4v
0
11.7v6.1v
-0.1
-0.1
0
0
0
(328J493B)
R
L
7
5. SCHEMATIC DIAGRAM AND PARTS LOCATION
8

A101
AV01202270
43218765
J101
YT03030020
1
3
2
4
L201
M292BEAS-5968Z
4
61
2
3
L301
19/38kHz LPF
6
4
1
2
3
LA01
7RBW-3702
67
11
5
9
8
10
14
43
12
2
1
13
FA01
SFZ450JL3
2
5
1
3
6
4
T-GND
DA06
1SS302
T-GND
CA01 0.01
T-GND
RA01
10k
C218 0.01
C216
100/16v
C202 0.01
T-GND
T-GND T-GND
R201
0
F201
N:SFE10.7MS3-A
T-GND
R202
390
R203 1.5k
T-GND
R204
470
T-GND T-GND
C201 0.01
Q202
2SC2714
R205
330
T-GND
F202
SFE10.7MS3-A
Q203
DTA114EU/
RN2302
+12V
Q501
LC72130
24
XOUT
23
VSS
22
AOUT2
21
AIN2
20
PD2
19
PD1
18
AIN1
17
AOUT1
16
VDD
15
FMIN
14
AMIN
13
I02
12
IFIN
11
I01
10
B04
9
B03
8
B02
7
B01
6
DO
5
CLK
4
DI
3
CE0
2
B05
1
XIN
Q201
LA1837
1
FMIFI
2
AMMIXO
3
FMIFB
4
AMIFI
5
GND
6
AFIFO
7
AFIFO
8
VCC
9
FM
10
AMCF
11
FMS
12
AMS
13
IFBO
14
LPF
15
LPF
16
AMPIO
17
AMPIO
18
AMPIO
19
AMPIO
20
MPXO
21
MPXO
22
MPXI
23
FMO
24
AMO
25
AGC
26
AFC
27
RFI
28
REG
29
OSC
30
FMSD
Q206
N:2SC4116
R219
N:10k
R221
N:100k
C221
N:0.01
R222
N:100k
T-GND
C222
1500p
T-GND
R215
N:68k
C227
C:2200p
C217
N:0.015
C220
2200p
C209
1/50v
C205 1/50v
T-GND
C204
0.047
T-GND
C214
47/16v
LA05
39mH
R206
6.8k
T-GND
C219
10/50v
T-GND
C203
0.047
T-GND
C511 0.01
C503
100/10v
C504 0.01
R507 68k
T-GND
R505 1k
C505
2.2/50v
T-GND
RA02
100k
T-GND T-GND
CA03
9p
R502
2.2k
R504
4.7k
C508
100/16v
R506
1k
C509
0.01u
50v
C502
47p
X501
7.2MHz
C501
47p
T-GND
R511 8.2k
C510 100p
R508
47k
R515
10k
R509
22k
R513
10k
T-GND
T-GND
T-GND
C215
0.047
C206
10/50v
T-GND
C235 0.01
T-GND
+6V
R216
27k
R214
47k
Q204
DTC144EU/
RN1304 T-GND
T-GND
R220 100
Q301
NJM4558M
1234
8765
R305
10k
C317
680p R309
220
C305
4.7/50v
R313
47k
T-GND
R314
47k
R310
220 C306
4.7/50v
R306
10k
C318
680p
R312
10k
R308
47k
T-GND
R311 10k R307 47k
T-GND
-12V
C316
0.01
T-GND
T-GND
C207
100/16v
T-GND
C208
0.047
T-GND
C311
2700p
T-GND
C301
N:0.033
R301
2.7k C303
10/50v
C304
10/50v
L302
19/38kHz LPF
6
4
1
2
3
T-GND
R302
2.7k
C312
2700p
C302
N:0.033
C309
10/50v
C310
10/50v
R218
4.7k
R303
1k
R304
1k
C307
2200p
C308
2200p
T-GND
R213
47
C210 0.01
T-GND
C234 4.7/50v
T-GND
T-GND
C236 0.01
R208 2.7k
T-GND
CA18
4.7/50v
T-GND
C213
0.47/50v
T-GND
C226 0.01
R210
3.3k
C212
1/50v
R207
100 1/4w
R209 4.7k C211
2.2/50v
C233
100/16v
+12V
C315 0.01
RDS_IN
CEO
DI
CLK
DO
SD
TUNER_L
TUNER_R
C320
100/16v
T-GND
D201
1SS301
/DAN202U
C237 0.01
T-GND
T-GND
R510
4.7k
C507 0.01
T-GND
D505
1SS301/
DAN202U
D504
1SS301/
DAN202U
C223 0.01
T-GND
R101
10k
1/2W
U-only
T-GND
TA-GND
T-GND
+12V
LA06
K7-H5
6
4
321
C319
100/16v
T-GND T-GND
+12V
T-GND
TA-GND
R211
N:22k
RA11
10k
T-GND
R212
4.7k
R299
T-GND T-GND
D202
9.1V
T-GND
J301
EARTHT-GND
RA12
T-GND
TUNER_R
TUNER_L
RDS_IN
CEO DO CLK SD DI
CEO
DI
CLK
DO
SD
ST DISTFM FRONT-END
ANT NC GNDGNDVT +B IF OUTOSC OUT
FM75
GND
AM
PLL
AM IF
MONO DIST
AM STOP
SEP
+
+V
+
-V
C:0.047
C:0.047
C:0.027
C:27k
N:
C:
RTU
L1
VCD
L2
FM MUTE
STRQ/MUTE
C:SFF10.7MA8-A
C:
C:
C:
C:
C:10k
TUNER_L
TUNER_R
11.8
(0)
(12.0)
0
(0)
10.6
(0)
1.7
(0)
2.4
(2.0)
0
7.7
(0)
910

JL53
YT02030590
1
7
6
2
3
4
5
CL93
0.1
CL94
100/10v
V-GND
JL52
YT02030590
1
7
6
2
3
4
5
CL54 10/50v
V-GND
V-GND
150
RL54
RL56
82
RL57
82
CL51
10/50v
CL53
10/50v
CL57
47p
150
RL53
RL59
82
CL52
10/50v
RL52
150
CL87
0.1
WG01
YB00111112
7
6
5
4
3
2
1
+6V
CL90
QL51
NJM2296M
16
+V
15 14 13 12
GND
11 10 9
8
-V
7654321
CL56
47p
V-GND
V-GND
RL58
82
V-GND
CL91
RL51
V-GND
CL86
0.1
V-GND
CL89
CL92
0.1
CL95
100/10v
CL88
V-GND
CL55
10/50v
CL59
100/10v
RL55
150
RL61
150
V-GND V-GND
RL60
82
-6V
-6V
V-GND
V-GND
DL52
V-GND
JL51
YT02010560
1
3
2
CL85
0.1
V-GND V-GND
V-GND
V-GND V-GND
+6V
DL51
1SS301
/DAN202U
V-GND
RL62 6.8k
RL63 6.8k
DVD
LD
TV
AUX
VCR
VCR
OUT
MONI
OUT
TO JG51
(MAIN PCB)
EARTH
WG328J1032
PL04
RVC
EARTH
SW4
SW3
SW2
SW1
+6V
V-GND
-6V
EARTH
(PV04)
11 12
PL04
QL51

J901
YT02020890
1
2
4
3S901
SS02021470
SSSS92
FB01 250VT1.6A
1
2JB04
JB05
LB02
TS12812020
4
19
5
D902
1SS301/DAN202U
C
B
E
QB03
2SC2705
LB01
G5PA-1
TV-5
4
1
3
2
QB01
L76MR06
3
51
42
L001
TS17207010
8
6
5
3
7
4
2
11
2
3
4
5
6
JB01
YP06010460
EH-7P
1
2
3
4
5
6
7
Q901
TC7W14FU
8
+V
765
1234
GND
J001
YP04000580
1
2
R902
47
C902
0.1
D901
1SS301/DAN202U
3
1
2
R903
47k
D-GND
R901
47k
D-GND
C901 0.01
D-GND
D-GND
+6VD
D-GND
+6VD
RB03
10k
D-GND
CB03
4.7/50v
D-GND
RB02
1 1/6w
CB02
1000/25v
GND
DB01
SFPL-52V
DB02
SFPL-52V
RB07
22
1/4w
DB03
SFPL-52V
DB04
SFPL-52V
GND
CB05 0.01
CB01 0.01
JB02
YP04000760
VH-B3P
21
DB06
1SS301/DAN202U
RB05 100k
RB04 100k CB04
1/50v
DB05
1SS301/DAN202U
D-GND
1
2
1
2
21
JB03
YP04000760
1
2
QB02
DTC114TS
4.7k RB06
CB06
10/50v
CB07
0.1
D-GND D-GND
D-GND
JB07
EARTH
RB01
2.2M 1/2W
IN
OUT
REMOTE
CONTROL
W001
W002
12.8V
4.8V
5.9V
5.8V
+6V
SYSTEM
RC-OUT
RC-IN
D-GND
P-DOWN
POWER
+6VD
BLU
WHT
BLU
ORG
BLK
ORG
TO JS05
(MAIN PCB)
WG328J1022
PB04
RPB
AC
230V
50/60Hz
AC
INLET
(PV04)
U-ONLY
YA01075020
(JS05 TO JB01)
13 14
PB04
QB03 QB02 Q901 QB01

30 31
50
51
80
81
100 1
50
51
100 125 26
75
76
80
85
95
5
10 15 20
30
35
40
45
55606570
90
1
2
3 4
5
6
7
8
9
10
11
12 13
14
15
16 17
18 19
20
21
22 23
24
1.4
2.3
1.4 1.4
0.4
1.1
2.1 2.1 5.1
3.7
0
2.5 2.5
2.5
0 0
0.7
0
1.5 1.2 2.8
2.6
00
CU01
CU08
XU01
CU14 CU13
CU03
CU04
RU12 CU07CU06
C354
C356
R352
X351
D351 C351
C357
R353
R354
C353
CA68
CA69
CA63
CA64
CA70
CA53
CA54
CA80
JA51
CA73
CA72 CA71
CA65
CA51
CA59CA57
RA74 RA62
RA61XA51
LA51
CA67
CA66
CA79
RA73
RA75
RA51
RA77
RA53
RA69
RA57
RA55
RA71
CA61
CA60
CA58
RA54
RA70
RA58
RA56
RA72
CA62
RU31
RU33
RU35
RU37
CU31
CU32 CU34
CU33 CU35
CU36 CU38
CU37
SU31 SU32
RA99
RA64
CA52
RU36 RU38
RU34
RU32
CA81
CA83 CA85
CA86 CA82
CA87
CA88
RA87
RA88
RA85
RA86
RA82 RA84
RA81
CA84
RA83
CA75
CA76
QA51
RU51
RU56
RU55
RU54RU53RU52
RU57 RU58 RU59 RU60
RU62
RU63 RU64
SU71
JU51 JU52
JU71
JU01
JU02
JU03 JU04
SU51 SU52 SU53 SU54 SU55
SU56 SU57
DU51 DU52 DU53
JU05
XU02
CU15
CU16
RU67
RU18 RU21
RU22
SU91
RU65
CU51
JU06
JU07
JU81
QU81
RU81
QU41
RU41
JU08
JU41
JU91
C358
C355
R357
RU07
CA77
QA59 RA89 RA90
DU54
DU91
QU31
QU32 QU33 QU34
QU14
QU13
QU16QU15
DU06
DU02
QU17
Q352
Q353
QA52
QA57
QA58 QA55 QA56
QA54
QA53
CA78
RA78
RA63
RA65
RA59
RA60
CA56
R356
RU14
RU15
RU10
RU11
RU16
RU66
RU68
Q351
CA55
QU53
RU24
RU25
DU01
RU20
DU04
RU28
RU29
RU30
RU39
RU09
CU81
CU41
DU07
RU23
RU26
RU27
QU04
DU05
QU06
RU74 DU55
RU70
RU72
RU71
RU01
RU02
QU18
RU40
QU19 DU08
RU19
QU20
QU01
RU75 QU51
RU98
DU81
DU41
RU17
RU13
CU05
CU02
RU73
RU42
RU43
C352
CU09
100/6.3V
0.1/50V
8.00MHZ
0.01 100/6.3V
10K
100/6.3V
0.01
15P
CH
15P
CH
560p
15p
CH
100k
4.322MHz
5.1V 0.01
15p
CH470k
10k
330p
1/50V
22/16V
0.47/50V
10/50V
47/16V
10/50V
10/50V
10/50V
1000P
1000P 1000P
0.22
1000P
330P330P
1K 2.2K
2.7K3.6MHZ
450KHZ
47P (CH)
0.01
0.01
180K
100K
47K
10K
47K
6.8K
27K
47K
6.8K
680P
330P
330P
47K
6.8K
27K
47K
6.8K
680P
47K
47K
47K
47K
220P
220P 220P
220P 220P
220P 220P
220P
VOLUME
100K
100K
1000P
15K 15K
15K
15K
0.1
0.1 0.1
0.1 0.1
0.01
10/50V
220K
220K
1M
1M
27K 12K
27K
0.1
12K
10/50V
10/50V
MC13022A
10K
10K
6.8K
3.3K2.2K1.5K
10K 1.5K 2.2K 3.3K
10K
10K 10K
*
**
** *
**
FLUSH WRITER
32.7KHZ
0.1
0.01
4.7K
10K 22
220
10K
0.01
RPM-670CBR
100
IR SENSOR
100
100/6.3V
10/16V
10k
10K
10/50V
NJM7809F 10K 10K
2SC4116
2SC4116 2SC4116 2SC4116
RN2303
RN1303
RN1303RN1303
ISS301
ISS300
DTC114TU
RN2303
RN1303
4558MD
RN1303
RN2303 2SD2144
S/U/V 2SD2144
S/U/V
2SC4116
RN1303
100/10V
4.7K
47K
2.7K
47K
47K
0.01U
50V
470 1/4W
0
0
DUMMY
DUMMY
DUMMY
0
1M
LC72722
1000P
RN1303
10K
10K
ISS300
47
ISS300
10K
10K
10K
47K
10K
100/6.3V
47/6.3V
ISS300
10K
10K
10K
RN1303
ISS300
RN1303
01SS302
10K
100
470
0
0
S80825ANNP-EDN
2.5V RESET
10K
RN1303 ISS300
180
S-80843ALNP
4.3V RESET
MB90583B
OR MB90F583B
16 BIT CPU
10K NJU6450A
LCD DRIVER
JRC
0
ISS300
ISS300
0
DUMMY
0.22F
5.5V
0.22F 5.5V
100K
10K
10K
10/16V
100/6.3V
+9V
VCC_A
VCC_A
VCC_A
LCD_+B
LCD_+B
+6V
LCD+6V
VCC_B
VCC_B
+12V
+9V
VCC_B VCC_B
VCC_B
+12V
VCC_B
+6V
+12V
+12V
VCC_B
+6V
+6V
VCC_B
VCC_B
VCC_B
+12V
+12V
+9V
+9V
+12V
VCC_B VCC_B
VCC_B
VCC_A
VCC_A
VCC_B
MUTE D-REV D-FWD D-CLOSE D-OPEN SYS-SW RDS DATA
SYS SW
P-DOWN
DI
D-FWD
D-CLOSE
D-REV
CLK
DO
SD
D-OPEN
CE
MUTE
POWER
D-FWD
D-REV
DO CLK DI SD P-DOWN
RDS_DO
TUN_CLK
TUN_DI
KEY_0
KEY_1
RDS
JPN
LW
RDS JPN
MODEL
MODEL
D-OPEN
D-CLS
D-FWD
D-REV
HOLD
LCD_DIM
LCD_D7
LCD_D6
LCD_D5
LCD_D4
LCD_D3
LCD_D2
LCD_D1
LCD_D0
LCD_RW
LCD_RST
AUD_MUT
ROT_J_A
ROT_J_B
ROT_V_A
ROT_V_B
MUTE
RDS_KIL
CE1(ELE.VOL)
KEY_0
KEY_1
CE CE1(ELE.VOL) POW_ON
HOLD
POWER
LCD_+B
LCD_D3
LCD_E
LCD_RST
LCD_A0
TMODE
TAUX3
RST
TMODE TAUX3 RST TCK TRXD TTXD TAUX
TRXD
TAUX
VOL_A
VOL_B
JOG_A JOG_B
LCD_D7 LCD_D6 LCD_D5 LCD_D4 LCD_D3 LCD_D2 LCD_D1 LCD_D0 LCD_A0 LCD_E LCD_RW LCD_RST LCD_DIM
LCD_D7 LCD_D6 LCD_D5 LCD_D4 LCD_D2 LCD_D1 LCD_D0
LCD_A0
LCD_E
LCD_RW
LCD_RST
LCD_RD LCD_RW LCD_A0 LCD_D0 LCD_D1 LCD_D2 LCD_D3 LCD_D4 LCD_D5 LCD_D6 LCD_D7
COM_0
COM_1
COM_2
COM_3
COM_4
COM_5
COM_6
COM_7 COM_8 COM_9 COM_10 COM_11 COM_12 COM_13 COM_14 COM_15
SEG_53 SEG_52 SEG_51 SEG_50 SEG_49 SEG_48 SEG_47 SEG_46 SEG_45
SEG_0
SEG_1
SEG_2
SEG_3
SEG_4
SEG_5
SEG_6
SEG_7
SEG_8
SEG_9
SEG_10
SEG_11
SEG_12
SEG_13
SEG_14
SEG_15
SEG_16
SEG_17
SEG_18
SEG_19
SEG_20
SEG_21
SEG_22
SEG_23
SEG_24
SEG_25
SEG_26
SEG_27
SEG_28
SEG_29
SEG_30
SEG_31
SEG_32
SEG_33
SEG_34
SEG_35
SEG_36
SEG_37
SEG_38
SEG_40
SEG_41
SEG_42
SEG_43
SEG_44
SEG_45
SEG_46
SEG_39
SEG_47
SEG_48
SEG_49
SEG_50
SEG_51
SEG_52
SEG_53
COM_0
COM_1
COM_2
COM_3
COM_4
COM_5
COM_6
COM_7
COM_8
COM_9
COM_10
COM_11
COM_13
COM_14
COM_12
SEG_0 SEG_1 SEG_2 SEG_3 SEG_4 SEG_5 SEG_6 SEG_7 SEG_8 SEG_9
SEG_10 SEG_11 SEG_12 SEG_13 SEG_14 SEG_15 SEG_16 SEG_17 SEG_18 SEG_19
SEG_20
SEG_21
SEG_22
SEG_23
SEG_24
SEG_25
SEG_26
SEG_27
SEG_28
SEG_29
SEG_30
SEG_31
SEG_32
SEG_33
SEG_34
SEG_35
SEG_36
SEG_37
SEG_38
SEG_39
SEG_40
SEG_41
SEG_42
SEG_43
SEG_44
RDS_KIL
TTXD TCK
2CH/5CH_OUT
IR-IN
IR-IN
CE3
CE3
OLD/NEW
CS_RESET POW_MUTE
(LCD_BL)
2/5CH_IN
2/5CH_OUT
2/5CH_IN
POW_MUTE
CS_RESET
CE2
CE2 (LCD_BL)
12345678
12345678
WV01
FUNCTION : CD
VOLUME : MINIMUM
FM FREQ. : 87.5MHZ
DOOR : CLOSE
CLOCK : SET
(PV04)
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
32
33
34
35
36
37
38
39
RESET
VSS
D-OPEN
D-FWD
D-REV
MUTE
RDS
LW
JAPAN
P-DOWN SD CLK DO RDS DATA SYS-SW
D-CLOSE
D.CLOSE SW.
P.DOWN
SYSTEM IN/OUT
D.MOTOR REV.
POWER
D.MOTOR FWD.
MUTE
DO
CL
D.OPEN SW.
GND
+6V
SD
1 2 3 4 5 6 7 8
R-CH
L-CH
ST
GND
AMIF
VCC
WA01 (PV04)TO JA01
5.4
:AUDIO L,R
:FM L,R
:AM L,R
TO JV04
RED
1
2
3
1
2
3
1
1
2
2
3
3
+6V
WH31
RDS DECODER
MONO
1.7
123456789
L OUT
R OUT
AM STEREO BLOCK
STEREO:0V
MONO:5V
LCH
RCH
7.2
2.9 2.9 1.3 0.9 0.2 1.8 1.2 1.2 1.2 1.2 1.2 1.2 1.8 0.1
2.9 2.9 2.9 2.9 6.4 5.2
0
0.4 3.6 8.0 2.9 8.0 7.3
F ONLY
(AM SEP.ADJ)
28 27 26 25 24 23 22 21 20 19 18 17 16 15
1413121110
ENTER
JOG-A
JOG-B
VOL-A
VOL-B
JOG/
RED GRN
24
40
41
42
43
44
45
46
47
48
49
5253545556575859606162636465666768697071727374777879
99
98
97
96
95
94
93
92
91
90
89
88
87
86
82
83
84
85
CE0
76 75
25 26 27 28 29
MODEL
AVRL
AVSS
AVRH
AVCC
X0
X1
X0A X1A
HST(HOLD)
CE1(ELE.VOL) RDS KILLER LCD_DIM POW-ON IR-KIL
VCC C
VCC
TIMER
TIM-LED
CE1
DI(PLL-DO)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
DI(PLL-DO)
V1
V2
V3
V4
V5
M/S
VDD
RST
FR
D2 D3
D4
D5
D6
D7
12345678910
12345678910
11
11
COM0
COM1
COM2
COM3
COM5
COM6
COM7
COM8 COM9 COM10
COM11
COM12 COM13 COM14 COM15
SEG60
SEG59 SEG58 SEG57 SEG56
SEG55
SEG54 SEG53 SEG52 SEG51
SEG50
SEG49 SEG48 SEG47 SEG46
SEG45
SEG44
SEG41
SEG40
SEG39
SEG38
SEG37
SEG36
SEG35
SEG34
SEG33
SEG32
SEG31
SEG30
SEG29
SEG28
SEG27
SEG25
SEG24
SEG23
SEG22
SEG26
SEG43
SEG42
SEG21
SEG20
SEG19
SEG18 SEG17 SEG16
SEG15
SEG14 SEG13 SEG12 SEG11
SEG10
SEG9 SEG7 SEG6
SEG5
SEG4 SEG3 SEG2 SEG1
SEG0
SEG8
A0
OSC1 OSC2
E
RW
VSS
D0
D1
VCC_B
VCC_B
LCD+6V
GRN
RED
+12V
PU54 LCD/TACT SW PCB
1234
5678
DOOR
PU74
PU84
LCD DISPLAY
RC IN
RC OUT
44
POWER
123
RU10:PS2100 ONLY
RU11:F ONLY
RU12:N ONLY
NORMAL:H/DIMMER:L
LCD BACK LIGHT LED
TAUX
RC OUT/TRXD
TAUX3
IR-KIL
RC OUT
RESET
12
12
22
23
24
25
CS RESET
POWER-ON
(RLD)
(RLD)
COM4
1
2
3
4
5
6
7
8
9
11
12
13
14
10
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
FM102.75MHz
LCD
DISPLAY
VU51
M12STEREO
TUNER
123
GRN
123
123
(RLD)
FM-IN
N ONLY
TCK TTXD RC IN
MUTE
2/5_OUT
2CH/5CH_IN
(RTA)
(RTR)
(RLD)
WU71
WU81
P154
(RTA)
(RLD)
(RLC)
PU04 U-COM PCB
(RLC)
TUNER MODE TUNER
BAND MEMORY DISPLAY TIMER AMP
FUJITSU
IR-IN
IR-OUT
RC-IN
RC-OUT
REV-IR
CS RESET
9
9
CE0
RU13:OLD PCB ONLY
KEY_0
KEY_1
ONLY N-VERSION
CN
RU10
RU11
RU12
RU13 Y
NN
N
NN
RU14
RU15
RU16
RU17
YY
NY
YY
NCVER VER
MODEL SELECT MAP
POW_MUTE
CE2(CS WRITE/LOAD)
FM-OUT/OSC_SHIFT
WU02
WU08
CE2(CS WRITE/LOAD) POW_MUTE
YY NN
2CH/5CH_IN
2/5CH_OUT
OSC_SHIFT
CE3
OSC_SHIFT (LCD_BL)
PU94
PU44
PU54
15 16

JF02
YT01040642
5
4
2
1
3
RF35
22
(3216)
CF97
LF06
BLM41P600S +BA
CF34
0.1
50v
CF32
1000/50v
PA-GND
DF14
CRG01
PA-GND
CF98
QN06
2SC4116
PA-GND
RN16
10k
RN15
4.7k
QN07
2SC4116
RN18
10k
RN17
47k
PA-GND
PA-GND
DF16
CRG01
CF12 0.68
PA-GND
DF12
30BQ100
QF10
IRF540N
RN04
1k
CN04
5600p
RN06 1.5k
QN02
2SC4117
RN08
3.3
(3216)
CF36
1000/50v
LF08
BLM41P600S
PA-GND
-BA
LF07
BLM41P600S
CF35
1000/50v
PA-GND
QN01
2SC4117
RN07
3.3
(3216)
RN05
1.5k
CN03
5600p
RN03
1k
RN01
0.1
(6331)
RN02
0.1
(6331)
CN02
0.1
50v
CN01
0.1
50v
PA-GND
DF15
CRG01
DF13
CRG01
CF11
0.68
PA-GND
DF11
30BQ100
QF09
IRFI540N
RF23
10
RF21
10
DF09
015AZ10
DF07
015AZ10
RF27
1M
CF05
0.1 50v
RF25
1M
DF03
015AZ10 DF05
015AZ10
CF03
0.1 50v
QF03
2SC4539
QF05
2SA1734
CF25
0.47
16v
CF23
100/25v
PA-GND
+12V-A
RF26
1M
DF06
015AZ10
RF22
10
RF24
10
DF10
015AZ10
RF28
1M
DF08
015AZ10 DF04
015AZ10
CF04
0.1
50v
CF06
0.1
50v
QF04
2SC4539
QF06
2SA1734
CF30
0.47
16v
CF29
0.47
16v
CF28
100/25v
CF27
100/25v
-12V-A
PA-GND DN01 1SS368
RF36
22
(3216)
RN11
10k
QN04
2SC4116
DN03
1SS368
DN04
1SS368
PA-GND
QN03
2SC4116
PA-GND
RF56 100k
RF55 100k
CN05
100/25v
CN06
100/25v
PA-GND
+12V-B
RN12
47k
RN14
1k
CN07
0.01u
50v
CN09
4.7/35v
RN19
10k
RN20
10k
PA-GND
QN08
2SC4116
PA-GND
RN21
10k
CN11
0.1
50v
SH-GND
DN05
1SS368
CN10
0.1
50v
PR-GND
RN23
47k
RN22
10k
-12V-A
QN09
2SA1586
RN24 4.7k
JF01
YP06006480
S12B-XH
121110987654321
QF02
LM311M
8
V+ 7
6
BAL_STR 5
BAL
1GND
2
3
4V-
16v
CF26 0.47
CF24
100/25v
PA-GND
+12V-A
RF16
2.2k
(2125)
RF18 2.2k
(2125)
RF20
1k
DF02
1SS368
RF30
180k
CF22 0.47
16v
PR-GND
CF20
100/25v
+12V-A
RF34
56k
CF10
68p
50v
CF08 1000p
RF32
100k
RF14
120
PR-GND
PR-GND
CF16
100/25v
-12V-A
CF17
0.47
16v
16v
CF18
0.47
CF15
100/25v
QF01
LM311
5
BAL 6
BAL_STR 7
8
V+
4V-
3
2
1GND
RF17
2.2k
(2125)
RF15
2.2k
(2125)
RF19
1k
DF01
1SS368
CF19
100/25v
CF21
0.47
16v
PR-GND
+12V-A
RF29
180k
CF07
1000p
PR-GND
RF31
100k
RF13
120
PR-GND
RF33
56k
CF09
68p
50v
QN11
2SC4213
PR-GND
QN10
2SC4213
RF12
4.7k
PR-GND
PR-GND
RF10
4.7k
RF11
4.7k
CF02
100/25v
CF01
100/25v RF09
4.7k
QF11
NJM2068M
8
V+
765
1234V-
CF13
100/25v
PR-GND
+12V-A
RF05
10k
RF03
10k
A-GND
RF07
3.3k
RF01
2.2k
RF02
2.2k
CF14
100/25v
PR-GND
-12V-A
A-GND
RF08
3.3k
RF06
10k
QK01
2SA1736 RK01
10k
(2125)
RK03
10k
(2125)
QK02
2SC2712
DK02
015AZ10
PR-GND
RK06
10k
(2125)
RK04
10k
(2125)
QK03
2SC4541
QK04
2SA1162
DK04
015AZ10
PR-GND
PA-GND PR-GND
A-GND
CN08
22/35v
PA-GND
QN05
2SA1586
RN13
10k
RF04
10k
RF47
1k
PR-GND
DK03
CRG01
DK01
CRG01
RF48
0
PA-GNDPR-GND
PA-GNDPR-GND
RF49
0
JF03
QF07
IRFI9540G
QF08
IRFI9540G
CF31
1000/50v
LF05
BLM41P600S
PA-GND
CF33
0.1
50v
+BA
LF09
LY20120630
1
2
3
4
8
7
6
5
RN26
10k
RN25
10k
RN27
22k
PA-GND
CN12
0.1u
50v
PR-GND
CF99
PA-GND
PR-GND
PR-GND
+12V-A
+12V-B
-BA
+BA
RF46
10
(2125)
RF45
10
(2125)
RF43
10
(2125)
RF41
10
(2125)
RF42
10
(2125)
RF44
10
(2125)
RF39
10
(2125)
RF40
10
(2125)
RF38
10
(2125)
RF37
10
(2125)
-12V-A
+12V-A
RK05
3.3
(2125) RK02
3.3
(2125)
PR-GND LF02
30UH
1
2
3
5
6
7
8
10
49
LF01
30UH
1
2
3
5
6
7
8
10
49
CF42
0.47 (3216)
CF41
0.47
(3216)
RN28
10k
QN12
2SC4116
PA-GND
RN29
4.7k
+12V-A
CF38
0.22 (3216)
CF37
0.22
(3216)
PA-GND
RF53 680
QF13
2SC4213
PR-GND
CF39 0.01
PR-GND
RF51
10k
RF54
680
QF14
2SC4213
PR-GND
PR-GND
CF40 0.01
RF52
10k
QF15
RN1303
DTC124EU
QF16
RN2303
/DTA124EU
PR-GND
+12V-A
CN13
PA-GND
CF43
330p
330pCF44
CF48
PA-GND
CF50
PA-GND
CF47
PA-GND
CF49
PA-GND
EARTH
SH-GND
RN30
2.2k
PA-GND
DF18
02CZ4.7
DF20
02CZ4.7
DF19
02CZ4.7
DF17
02CZ4.7
P704
SODA_50W_MODULE
R-CH
L-CH
R-CH
L-CH
R_CH
L_CH
R_IN
A-GND
L_IN
RELAY+B
RELAY(ACT_LOW)
FROM_REG.+12V
PR-GND
-12V
+BA
PA-GND
-BA
RPK
KICK_START
RMP
RMA
-
+
+
-
WG328J2013
(FRONT)
+
-
+
-
FRONT
OSC SHIFT
FROM JP01 (PV04)
0.0
0
0.7
-10.6
0
0.0
-10.5 0.0
0
0
0.0
0.7
-11.3 -37.0
-36.7
-36.7
-11.3
-10.3
11.0 37.2
36.8
36.8
11.0
10.3
11.0
11.0
0
4.6
-0.2
-0.2
10.7
-0.2
-10.7
-0.2
-0.2
-0.3
-10.8
-0.2
-0.3
10.4
37.0
35.5
0.02
-37.2
-34.4
10.7
-37.4
-37.2
-37.8
10.7
-37.5
-37.5
0.02v
-34.7
35.1
37.1
-10.5 0
0
0
0
11.0
11.0
11.0
0
0
06.0
0
0.0
0.7
0
0.6
0.0
10.8
10.8
0
00
0
17 18

JR02
YT01040642
5
4
2
1
3
RR35
22
(3216)
CR97
LR06
BLM41P600S +BB
CR34
0.1
50v
CR32
1000/50v
PB-GND
DR14
CRG01
PB-GND
CR98
QN36
2SC4116PB-GND
RN46
10k
RN45
4.7k
QN37
2SC4116
RN48
10k
RN47
47k
PB-GND
PB-GND
DR16
CRG01
CR12 0.68
PB-GND
DR12
30BQ100
QR10
IRF540N
RN34
1k
CN34
5600p
RN36
1.5k
QN32
2SC4117
RN38
3.3
(3216)
CR36
1000/50v
LR08
BLM41P600S
PB-GND
-BB
LR07
BLM41P600S
CR35
1000/50v
PB-GND
QN31
2SC4117 1
23
RN37
3.3
(3216)
RN35 1.5k
CN33
5600p
RN33
1k
RN31
0.1
(6331)
RN32
0.1
(6331)
CN32
0.1
50v
CN31
0.1
50v
PB-GND
DR15
CRG01
DR13
CRG01
CR11
0.68
PB-GND
DR11
30BQ100
QR09
IRFI540N
RR23
10
RR21
10
DR09
015AZ10
DR07
015AZ10
RR27
1M
CR05
0.1 50v
RR25
1M
DR03
015AZ10 DR05
015AZ10
CR03
0.1 50v
QR03
2SC4539
QR05
2SA1734
CR25
0.47
16v
CR23
100/25v
PB-GND
+12V-A
RR26
1M
DR06
015AZ10
RR22
10
RR24
10
DR10
015AZ10
RR28
1M
DR08
015AZ10 DR04
015AZ10
CR04
0.1
50v
CR06
0.1
50v
QR04
2SC4539
QR06
2SA1734
CR30
0.47
16v
CR29
0.47
16v
CR28
100/25v
CR27
100/25v
-12V-A
PB-GND DN31 1SS368
RR36
22
(3216)
RN41
10k
QN34
2SC4116
DN33
1SS368
DN34
1SS368
PB-GND
QN33
2SC4116
PB-GND
RR56 100k RR55
100k
CN35
100/25v
CN36
100/25v
PB-GND
+12V-B
RN42
47k
RN44
1k
CN37
0.01u
50v
CN39
4.7/35v
RN49
10k
RN50
10k
PB-GND
QN38
2SC4116
PB-GND
RN51
10k
CN41
0.1
50v
SH-GND
DN35
1SS368
CN40
0.1
50v
PR-GND
RN53
47k
RN52
10k
-12V-A
QN39
2SA1586
RN54 4.7k
JR01
YP06006480
S12B-XH
121110987654321
QR02
LM311M
8
V+ 7
6
BAL_STR 5
BAL
1GND
2
3
4V-
16v
CR26 0.47
CR24
100/25v
PB-GND
+12V-A
RR16
2.2k
(2125)
RR18 2.2k
(2125)
RR20
1k
DR02
1SS368
RR30
180k
CR22 0.47
16v
PR-GND
CR20
100/25v
+12V-A
RR34
56k
CR10
68p
50v
CR08 1000p
RR32
100k
RR14
120
PR-GND
PR-GND
CR16
100/25v
-12V-A
CR17
0.47
16v
16v
CR18
0.47
CR15
100/25v
QR01
LM311
5
BAL 6
BAL_STR 7
8
V+
4V-
3
2
1GND
RR17
2.2k
(2125)
RR15
2.2k
(2125)
RR19
1k
DR01
1SS368
CR19
100/25v
CR21
0.47
16v
PR-GND
+12V-A
RR29
180k
CR07
1000p
PR-GND
RR31
100k
RR13
120
PR-GND
RR33
56k
CR09
68p
50v
QN41
2SC4213
PR-GND
QN40
2SC4213
RR12
4.7k
PR-GND
PR-GND
RR10
4.7k
RR11
4.7k
CR02
100/25v
CR01
100/25v RR09
4.7k
QR11
NJM2068M
8
V+
765
1234V-
CR13
100/25v
PR-GND
+12V-A
RR05
10k
RR03
10k
A-GND
RR07
3.3k
RR01
2.2k
RR02
2.2k
CR14
100/25v
PR-GND
-12V-A
A-GND
RR08
3.3k
RR06
10k
QK31
2SA1736 RK31
10k
(2125)
RK33
10k
(2125)
QK32
2SC2712
DK32
015AZ10
PR-GND
RK36
10k
(2125)
RK34
10k
(2125)
QK33
2SC4541
QK34
2SA1162
DK34
015AZ10
PR-GND
PB-GND PR-GND
A-GND
CN38
22/35v
PB-GND
QN35
2SA1586
RN43
10k
RR04
10k
RR47
1k
PR-GND
DK33
CRG01
DK31
CRG01
RR48
0
PB-GNDPR-GND
PB-GNDPR-GND
RR49
0
JR03
QR07
IRFI9540G
QR08
IRFI9540G
CR31
1000/50v
LR05
BLM41P600S
PB-GND
CR33
0.1
50v
+BB
LR09
LY20120630
1
2
3
4
8
7
6
5
RN56
10k
RN55
10k
RN57
22k
PB-GND
CN42
0.1u
50v
PR-GND
CR99
PB-GND
PR-GND
PR-GND
+12V-A
+12V-B
-BB
+BB
RR46
10
(2125)
RR45
10
(2125)
RR43
10
(2125)
RR41
10
(2125)
RR42
10
(2125)
RR44
10
(2125)
RR39
10
(2125)
RR40
10
(2125)
RR38
10
(2125)
RR37
10
(2125)
-12V-A
+12V-A
RK35
3.3
(2125) RK32
3.3
(2125)
PR-GND LR02
30UH
1
2
3
5
6
7
8
10
49
LR01
30UH
1
2
3
5
6
7
8
10
49
CR42
0.47 (3216)
CR41
0.47
(3216)
RN58
10k
QN42
2SC4116
PB-GND
RN59
4.7k
+12V-A
CR38
0.22 (3216)
CR37
0.22
(3216)
PB-GND
RR53 680
QR13
2SC4213
PR-GND
CR39 0.01
PR-GND
RR51
10k
RR54
680
QR14
2SC4213
PR-GND
PR-GND
CR40 0.01
RR52
10k
QR15
RN1303
DTC124EU
QR16
RN2303
/DTA124EU
PR-GND
+12V-A
CN43
100p
PB-GND
CR43
330p
CR44 330p
CR48
PB-GND
CR50
PB-GND
PB-GND
CR49
PB-GND
CR47
EARTH
SH-GND
RN60
2.2k
PB-GND
DR18
02CZ4.7
DR20
02CZ4.7
DR19
02CZ4.7
DR17
02CZ4.7
P714
SODA_50W_MODULE
R-CH
L-CH
R-CH
L-CH
R_CH
L_CH
R_IN
A-GND
L_IN
RELAY+B
RELAY(ACT_LOW)
FROM_REG.+12V
PR-GND
-12V
+BB
PB-GND
-BB
RPK
KICK_START
RMP
RMB
-
+
+
-
WG328J2023
(SURROUND)
+
-
+
-
SURROUND
OSC SHIFT
FROM JP02 (PV04)
0.0
0.7
0
0
-10.6
0.0
0.0
-10.5
0
0
0.7
0.0
-11.3 -37.0
-36.7
-36.7
-11.3
-10.3 11.0
11.0 37.2
36.8
36.8
10.3
11.0
11.0
0
0
4.6
-0.2
-0.2
10.7
-0.2
-0.2
-10.7
-10.8
-0.2
-0.3
-0.3
10.4
-0.2
37.0
35.5
0.02
-34.4
-37.2
-37.2
10.7
-37.4
-37.5
10.7
-37.8
-37.5
-34.7
0.02
35.1
37.1
-10.5 0
0
0
0
11.0
11.0
11.0
00
0
6.0
0
2.7 0.0
0.0
0.6
0
10.8
0
0
0
0
10.8
19 20

21 22
JC02
YT01020230
5
4
2
1
3
RC35
22
(3216)
PC-GND
CC97
QN66
2SC4116
PC-GND
RN76
10k
RN75
4.7k
QN67
2SC4116
RN78
10k
RN77
47k
PC-GND
PC-GND
-BC
LC07
BLM41P600S
CC35
1000/50v
PC-GND
QN61
2SC4117
RN67
3.3
(3216)
RN65
1.5k
CN63
5600p
RN63
1k
RN61
0.1
(6331)
CN61
0.1
50v
PC-GND
DC15
CRG01
DC13
CRG01
CC11
0.68
PC-GND
DC11
30BQ100
QC09
IRFI540N
RC23
10
RC21
10
DC09
015AZ10
DC07
015AZ10
RC27
1M
CC05
0.1 50v
RC25
1M
DC03
015AZ10 DC05
015AZ10
CC03
0.1 50v
QC03
2SC4539
QC05
2SA1734
CC25
0.47
16v
CC23
100/25v
PC-GND
+12V-A
CC29
0.47
16v
CC27
100/25v
-12V-A
PC-GND DN61
1SS368
RN71
10k
QN64
2SC4116
DN63
1SS368
DN64
1SS368
PC-GND
QN63
2SC4116
PC-GND
RC55 100k
CN65
100/25v
CN66
100/25v
PC-GND
+12V-B
RN72
47k
RN74
1k
CN67
0.01u
50v
CN69
4.7/35v
RN79
10k
RN80
10k
PC-GND
QN68
2SC4116
PC-GND
RN81
10k
CN71
0.1
50v
SH-GND
DN65
1SS368
CN70
0.1
50v
PR-GND
RN83
47k
RN82
10k
-12V-A
QN69
2SA1586
RN84 4.7k
JC01
YP06006480
S12B-XH
121110987654321
PR-GND
-12V-A
CC17
0.47
16v
CC15
100/25v
QC01
LM311
5
BAL 6
BAL_STR 7
8
V+
4V-
3
2
1GND
RC17
2.2k
(2125)
RC15
2.2k
(2125)
RC19
1k
DC01
1SS368
CC19
100/25v
CC21
0.47
16v
PR-GND
+12V-A
RC29
180k
CC07
1000p
PR-GND
RC31
100k
RC13
120
PR-GND
RC33
56k
CC09
68p
50v
QN71
2SC4213
PR-GND
RC11
4.7k
CC01
100/25v RC09
4.7k
QC11
NJM2068M
8
V+
765
1234V-
CC13
100/25v
PR-GND
+12V-A
RC05
10k
RC03
10k
A-GND
RC07
3.3k
RC01
2.2k
CC14
100/25v
PR-GND
-12V-A
QK61
2SA1736 RK61
10k
(2125)
RK63
10k
(2125)
QK62
2SC2712
DK62
015AZ10
PR-GND
RK66
10k
(2125)
RK64
10k
(2125)
QK63
2SC4541
QK64
2SA1162
DK64
015AZ10
PR-GND
PC-GND PR-GND
A-GND
CN68
22/35v
PC-GND
QN65
2SA1586
RN73
10k
RC47
1k
PR-GND
DK63
CRG01
DK61
CRG01
RC48
0
PC-GNDPR-GND
PC-GNDPR-GND
RC49
0
JC03
QC07
IRFI9540G
CC31
1000/50v
LC05
BLM41P600S
PC-GND
CC33
0.1
50v
+BC
LC09
LY20120630
1
2
3
4
8
7
6
5
RN85
10k
RN87
22k
PC-GND
CN72
0.1u
50v
PR-GND
CC99
PC-GND
PR-GND
PR-GND
+12V-A
+12V-B
-BC
+BC
RC45
10
(2125)
RC43
10
(2125)
RC41
10
(2125)
RC39
10
(2125)
RC38
10
(2125)
RC37
10
(2125)
-12V-A
+12V-A
RK65
3.3
(2125) RK62
3.3
(2125)
LC01
30UH
1
2
3
5
6
7
8
10
49
CC41
0.47
(3216)
RN88
10k
QN72
2SC4116
PC-GND
RN89
4.7k
+12V-A
CC38
0.22 (3216)
CC37
0.22
(3216)
PC-GND
RC53 680
QC13
2SC4213
PR-GND
CC39 0.01
PR-GND
RC51
10k
QC15
RN1303
DTC124EU
QC16
RN2303
/DTA124EU
PR-GND
+12V-A
RC08
0
A-GND
RC02
0
CN73
100p
PC-GND
CC43
330p
CC49
PC-GND
PC-GND
CC47
EARTH
SH-GND
RN90
2.2k
PC-GND
DC19
02CZ4.7
DC17
02CZ4.7
P724
SODA_50W_MODULE
L-CH
L-CH
R_IN
A-GND
L_IN
RELAY+B
RELAY(ACT_LOW)
FROM_REG.+12V
PR-GND
-12V
+BC
PC-GND
-BC
RPK
KICK_START
RMP
RMC
-
+
+
-
WG328J2033
(CENTER)
+
-
CENTER
OSC SHIFT
FROM JP03 (PV04)
0
0
0.7
0
0.0
0.7
-11.3 -37.0
-36.7
-11.3
-10.3
11.0
10.3
11.0 37.2
36.8 11.0
0
11.0
0
4.6
-10.5 0
0
0
0
11.0
11.0
11.0
00
0
6.0 6.0
0.0
0
0
0.0
0.7
0
10.8
0
0
10.8
0
-0.5
-0.2
-10.7
-0.2
-0.5
10.6
35.1 37.1
0.02
-34.7
-37.5 -37.5
10.7
-37.8

PV04
QP01
QP03QP02
QP11 QP12QP10
Q806
QM01 Q830
Q805 Q801 Q802 Q804 Q803
QW03 QW01 QG01 QQ08 QQ04
QQ01
QQ02
QS01 QS02 QQ05 QQ06 QQ07 Q203 Q202Q204 Q501 Q301 Q201QQ03
QW02
QP04 ~ QP09
QG04 QG03 QG02
QG10 QG09QG08QG07 QG06 QG05
23 24

25 26
VCC_B
DOOR
1
3
PU74
WG327J107-0
DOOR
SU71
JU71
4
1
GRN
RED
PU94
WG327J108-0
POWER
GRN
VCC
RED
POW
DU91
SU91
JU91
WG327J106-2
G
G
+B
OUT
1
+
OUT
+B
PU44
DU41
JU41
QU41
CU41
RU41
9
1 12
1
100 9080
70
60
50 40 30
20
10
WG327J102-0
C I
PU54
VU01
35
30
25
15
10
5
69
65
60
55
50
45
40
36
1
TUNER BAND MEMORY AMP TIMER
DISPLAY
TU-MODE
SURROUND
DOOR
LCD_BL
LCD_DIM LCD+B
+12VGND
VCC_B KEY_0 KEY_1
LCD_RST LCD_RW LCD_E LCD_A0 LCD_D0 LCD_D1 LCD_D2 LCD_D3 LCD_D4 LCD_D5 LCD_D6 LCD_D7
RU75
RU98
DU55
DU54
RU66
RU63
RU64 RU65
RU62
RU68 RU74
DU51
DU52
DU53
SU56 SU57
SU51
SU52 SU55SU54SU53
RU61
RU56RU55RU54
QU51
JU52
JU51
RU60 RU59RU58
RU57
RU53RU52 RU51
RU72
RU71
QU53
QU52
CU51
RU67
JT01 JT02
CT02
CT01
CT03
CT11
CT12
L
R
R
L
G
SW
SW
WG327J104-0 PT04
WT01
SW
1
PS2100
WG327J105-2
1
3
G
+6V OUT
G
+
PU84
OUT +6V
DU81
QU81
CU81
JU81
RU81
CA60
RA58
CA62
RA56 RA72
CA58
RA54RA70
CA55 RA51 RA73
RA75
RA74
QA53
CA51
CA73
CA72
RA62
CA71
CA67 RA61
QA51
RA71
RA55
RA57 RA53 RA69
RA99
CA56
RA77
RA78
QA54
RA63
RA64
CA52
QA52
RA83
RA81
RA85
RA86
RA82
RA88
RA59
RA60
QA57QA58
RA89
RA90
QA59
RA84 RA87
CA57 CA61
CA59
QA55QA56
CA77
CA80
CA63CA64
CA68
CA69 CA70
CA66
CA65
XA51
CA78
CA54
CA53
CA88 CA75
CA76
CA87
CA86
CA84
CA82
CA85
CA83
CA81
CA79
LA51
AM+B GND IF MONO
ST RCH
LCH
MT
+
++
+
+
+
+
+
+++
+
WG327J103-0
PR54
+
MUTE
PU54
PT04 PU44 PU74 PU84 PU94 PR54
QU41
QU51
QU81 QA51 QA52
QA59 QA58
QA54
QA53 QA56 QA55
QU53QU52
PU04
QU16 QU15
QU17 QU01 QU19 QU04QU06 QU32QU31 Q351 QU33 QU34 QU14QU13 Q353 Q352

27 28
P704
QF07
QF09 QF08 QF10 QN07
QN08 QN05
QN09 QK03 QK04
QN06
QN12 QK01 QF15 QF16 QF06 QF10
QF08
QF04
QN04
QN03
QK02 QN02 QF02 QF13 QN11 QF03
QF07
QF05QF01QF11QF14QN10
P714
QR07
QR09 QR08 QR10
P724
P704
P714
P724
QC07
QC09 QC08 QC10
QF09 QN01
QN37
QN38 QN35
QN39 QK33 QK34
QN36
QN42 QK31 QR15QR16 QR06 QR10
QR08
QR04
QN34
QN33
QK32 QN32 QR02 QR13 QN41 QR03
QR07
QR05QR01QR11QR14QN40 QR09 QN31
QN67
QN68 QN65
QN69 QK63 QK64
QN66
QN72 QK61 QC15QC16 QC06 QC10
QC08
QC04
QN64
QN63
QK62 QN62 QC02 QC13 QN71 QC03
QC07
QC05QC01QC11QC14QN70 QC09 QN61

29 30
6. MICROPROCESSOR AND IC DATA
Page Address I / O Buffer
Line Decoder
b
0 b 1 b 2 b 3 b 4 b 5 b 6 b 7
Line Counter
Staet Line Register
Displey
Timing
Generator
Common
SEG
0 ~SEG 60
COM 0 ~COM 15
Timing
Generator
Page Address Decoder
RST
D
0 ~D 7
A 0
Instruction
Decoder
Reset
MPU Interface
Bus
Holder Status
Multiplexer
Com. Address
Register
Com. Address
Counter
Culumn Decoder
Display
Data RAM
Display Data Latch
M/S
FR
OSC
2
OSC
2
Segment
Driver
V DD V SS V 1 V 2 V 3 V 4 V 5
Common
Driver
V
DD
, V
1
. V
4
. V
5
V
DD
, V
2
. V
3
. V
5
2560 bit
BF
Register
E (RD)
R/W (RD)
25126
50
SEG 20
SEG 21
SEG 22
SEG 23
SEG 24
SEG 25
SEG 26
SEG 27
SEG 28
SEG 29
SEG 30
SEG 31
SEG 32
SEG 33
SEG 34
SEG 35
SEG 36
SEG 37
SEG 38
SEG 39
SEG 40
SEG 41
SEG 42
SEG 43
SEG 44
V SS
D 0
D 1
D 2
D 3
D 4
D 5
D 6
D 7
V DD
RST
FR
V
5
V 3
V 2
M/S
V
4
V 1
COM 0
COM 1
COM 2
COM 3
COM 4
COM 5
COM 6
R/W (WR) E (RD) OSC
2
OSC
1
A
0
SEG
0
SEG
1
SEG
2
SEG
3
SEG
4
SEG
5
SEG
6
SEG
7
SEG
8
SEG
9
SEG
10
SEG
11
SEG
12
SEG
13
SEG
14
SEG
15
SEG
16
SEG
17
SEG
18
SEG
19
COM
7
COM
8
COM
9
COM
10
COM
11
COM
12
COM
13
COM
14
COM
15
SEG
60
SEG
59
SEG
58
SEG
57
SEG
56
SEG
55
SEG
54
SEG
53
SEG
52
SEG
51
SEG
50
SEG
49
SEG
48
SEG
47
SEG
46
SEG
45
5175
NJU6450A
76
100
BLOCK DIAGRAM
QU51 : NJU6450A
PIN CONFIGURATION
PIN FUNCTION

80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
100
99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81
31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50
P20/A16
P21/A17
P22/A18
P23/A19
P24/A20
P25/A21
P26/A22
P27/A23
P30/ALE
P31/RD
V
SS
P32/WRL
P33/WRH
P34/HRQ
P35/HAK
P36/RDY
P37/CLK
P40/SIN0
P41/SOT0
P42/SCK0
P43/SIN1
P44/SOT1
V
CC
P45/SCK1
P46/ADTG
P47
C
P71
P72
DVRH
X0A
PA2
RST
PA1
PA0
P97/POT
P96/PWC
P95/TOT2/OUT1
P94/TOT1/OUT0
P93/TOT0/IN3
P92/TIN2/IN2
P91/TIN1/IN1
P90/TIN0/IN0
RX
*
TX
*
P65/CKOT
P64/PPG0
P63/PPG1
P62/SCK2
P61/SOT2
P60/SIN2
P87/IRQ7
P86/IRQ6
P85/IRQ5
P84/IRQ4
P83/IRQ3
P82/IRQ2
HST
MD2
X1A
P17/AD15 P16/AD14 P15/AD13 P14/AD12 P13/AD11 P12/AD10 P11/AD09 P10/AD08 P07/AD07 P06/AD06 P05/AD05 P04/AD04 P03/AD03 P02/AD02 P01/AD01 P00/AD00 V
CC
X1 X0 V
SS
DV
SS
P73/DA00 P74/DA01
P50/AN0/SIN3
P51/AN1/SOT3 P52/AN2/SCK3
P53/AN3
V
SS
P54/AN4/SIN4
P55/AN5/SOT4 P56/AN6/SCK4
P57/AN7
P80/IRQ0 P81/IRQ1
MD0 MD1
AV
CC
AVRH
AVRL
AV
SS
* : N.C. pin on the MB90587
124VREF SYR
223MPXIN CE
322Vdda DI
421Vssa CL
520FLOUT DO
619CIN
LC72722M
Top view
RDS-ID
718T1 SYNC
817T2 T7(CORREC/ARI-ID/TA/BEO)
916T3(RDCL) T6(ERROR/57K/TP/BE1)
10 15T4(RDDA) Vssd
11 14T5(RSFT) Vddd
12 13XOUT XIN
REFERENCE
VOLTAGE
ANTIALIASING
FILTER SMOOTHING FILTER
57 kHz
BPF
(SCF)
TEST
+
–
PLL
(57 kHz)
VREF
CLOCK
RECOVERY
(1187.5 Hz)
DATA
DECODER
SYNC
DETECT-2
SYNC
DETECT-1
OSC/DIVIDER
MEMORY CONTROL CLK(4.332 MHz)
+5V +5V
Vdda
Vssa
MPXIN
T2
T3 to T7
T1
CCB
DI
CE
CL RAM
(24 BLOCK DATA) ERROR CORRECTION (SOFT DECISION) SYNC/EC CONTROLLER
DO
XIN XOUT
SYR
SYNC
RDS-ID
Vssd
Vddd
CINFLOUT
VREF
Pin PORT Name of port I/O Description
1P20/A16 P-DOWN I Power Detect LOW:SUB-CLOCK Power Detect=H
2P21/A17 CLK O ANA.SW/PLL/RDS CLOCK Active H
3P22/A18 DO O ANA.SW/PLL/RDS DATA OUT Active H
4P23/A19 CE0 O ANA.SW/PLL.RDS CE Active H
5P24/A20 SYS_SW I System Switch INPUT SYSTEM =L, INT=H
6P25/A21 SD I TUNER SD INPUT Active L
7P26/A22 CE1 O ELE.VOLUME CE Active H
8P27/A23 RDS-KIL O RDS DECODER OSC KILLER Active L
9P30/ALE PLL-DI I DATA INPUT FROM PLL
10 P31/RD RDS-DI I DATA INPUT FROM RDS
11 VSS GND
12 P32/WRL LCD_
_BT_CNCL)
DIM O LCD BACK LIGHT DIMMER DARK:L,NORMAL:H
13 P33/WRH (AM
AM BEAT CANCEL AM BEAT CANCEL NORM : H, ON :L for PS2100
O
14 P34/HRQ CE2 O CSWRITE Active : L for PS2100
15 P35/HAK Timer-LED O Timer-LED,TIMER:ACTIVE Active :H
16 P36/RDY POWER_ON O Power Control Power ON; H
17 P37/CLK IR-KILL O IR Sensor KILLER KILL=L
18 P40/SIN0 TTXD I Flash Writer Conn ection
19 P41/SOT0 RC-OUT
TRXD O REMOTE Control bus Output Flash Writer Conn ection
20 P42/SCK0 TCK I Flush Writer Conn ection
21 P43/SIN1 RC-IN O REMOTE Con trol bus(U-ART)INPUT
22 P44/SOT1 N.C
23 VCC +5STB -- Vcc
24 P45/SCK1 CS RESET O CS RESET Output Active H for PS2100
25 P46/ADTG CS Load O CS Load Output Active L for PS2100
26 P47 N.C.
27 CC
28 P71 N.C
29 P72 N.C
30 DVRH GND I
31 DVSS GND I
32 P73/DA00 N.C. I
33 P74/DA01 2/5 OUT O 2CH/5CH CONTROL Output 5CH:H,2CH:L for PS2100
34 AVCC +5STB -- Vcc
35 AVRH +5STB -- Vcc
36 AVRL GND
37 AVSS GND
38 P50/AN0/SIN3 KEY_IN_0 I KEY_0 Input
39 P51/AN1/SOT3 KEY_IN_1 I KEY_1 Inpu t
40 P52/AN2/SCK3 OLD/NEW I OLD/NEW mode set H:OLD PCB
41 P53/AN3 RDS I RDS mode set H:RDS
42 VSS GND
43 P54/AN4/SIN4 JPN I JAPAN Destination. set H:JAPAN
44 P55/AN5/SOT4 MODEL I SR/PS MODEL set H:PS2100
45 P56/AN6/SCK4 N.C. I
46 P57/AN7 N.C. I
47 P80/IRQ0 ROT_V_A I Rotary Encoder(Volume) Input A Active H
48 P81/IRQ1 ROT_V_B I Rotary Encoder(Volume) Input B Active H
49 MD0 TMODE I CPU mode set Flush Writer connection
50 MD1 MD1 I CPU mode set Fixed High
51 MD2 TAUX3 I/O CPU mode set, Flush Writer connection
52 HST HST I Hardware standby HOLD LOW:STOP
53 P82/IRQ2 D_MOTOR_REV O Door REV.Motor ON Active H
54 P83/IRQ3 D_MOTOR_FWD O Door FWD.Motor ON Active H
55 P84/IRQ4 D_OPEN_SW I Door Open detect Active L
56 P85/IRQ5 D_CLOSE_SW I Door Close detect Active L
57 P86/IRQ6 ROT_J_A I Rotary Encoder(JOG) Input A Active H
58 P87/IRQ7 ROT_J_B I Rotary Encoder(JOG) Input B Acti ve H
59 P60/SIN2 H.P_
_
SW I Mode set by Headp hone Switch L:Normal, H:2ch
60 P61/SOT2 MUTE O Audio Mute output ON:H
61 P62/SCK2 CE3 O RDS Decoder CE output Active H
62 P63/PPG1 N.C. I
63 P64/PPG0 N.C I
64 P65/CKOT N.C. I
65 TX N.C. O
66 RX N.C. I Fixed LOW
67 P90/TIN0/IN0 RC IN IIR/RC5 INPUT
68 P91/TIN1/IN1 N.C. I
69 P92/TIN2/IN2 N.C. I
70 P93/TOT0/IN3 N.C. I
71 P94/TOT1/OUT0 N.C. I
72 P95/TOT2/OUT1 N.C. I
73 P96/PWC N.C. I
74 P97/POT N.C. I
75 PA0 N.C. I
76 PA1 N.C. I
77 RST RST I CPU RESET Low:RESET
78 PA2 N.C. I
79 X1A 32kHz X’tal -- 32kHz X-tal Connect.
80 X0A 32kHz X’tal -- 32kHz X-tal Connect.
81 VSS GND
82 X0 8MHz X’tal -- 8MHz Ceramic Resonator Conn ect
83 X1 8MHz X’tal -- 8MHz Ceramic Resonator Conn ect
84 VCC +5STB -- Vcc
85 P00/AD00 TAUX I/O Flush Writer Connection
86 P01/AD01 --- I CPU mode set Fixed High
87 P02/AD02 RST O LCD Driver RESET Active L
88 P03/AD03 LCD_RW O LCD Driver R/W Active L
89 P04/AD04 LCD_/RD O LCD Driver RD Active L
90 P05/AD05 A0 O LCD Driver mode set Refer NJU6450 data sheet
91 P06/AD06 N.C I
92 P07/AD07 N.C I
93 P10/AD08 D0 I/O LCD Driver data set
94 P11/AD09 D1 I/O LCD Driver data set
95 P12/AD10 D2 I/O LCD Driver data set
96 P13/AD11 D3 I/O LCD Driver data set
97 P14/AD12 D4 I/O LCD Driver data set
98 P15/AD13 D5 I/O LCD Driver data set
99 P16/AD14 D6 I/O LCD Driver data set
100 P17/AD15 D7 I/O LCD Driver data set
BLOCK DIAGRAM
Q351 : LC72722M
QU01 : PIN CONFIGURATION
Q351 : PIN CONFIGURATION
PIN FUNCTION
QU01 : MB90583B
31 32

33 34
Pin # Name Connected to / Function:
1 R Filter In 3-Pole Active Low-Pass Filter Output; used for Center Cancelling Correction
2 R Filter Out 3-Pole Active Low-Pass Filter Input
3 L Filter In 3-Pole Active Low-Pass Filter Output; used for Center Cancelling Correction
4 L Filter Out 3-Pole Active Low-Pass Filter Input
5 L Out Connect to Pin 6
6 L Out A Connect to Pin 5
7 L In Left Stereo Source Line Input; Should be 0 dBd (300 mV rms)
8 R Out Connect to Pin 9
9 R Out A Connect to Pin 8
10 R In Right Stereo Source Line Input; Should be 0 dBd (300 mV rms)
11 V
EE
Negative Supply
12 ACOM Audio GND Audio Ground
13 GND Power Ground
14 V
CC
Positive Supply
15 (L+R) Out RC to Front/Rear Detector Input
16 (L—R) Out RC to Front/Rear Detector Input and Input of Crossover
17 (L—R)High In Output of High-Pass Crossover
18 (L—R)Low In Output of Low-Pass Crossover
19 R High Band Det. RC Network Fed by Right Stereo Source Line Input
20 L High Band Det. RC Network Fed by Left Stereo Source Line Input
21 High Band Det. Out Capacitor to ACOM; Controls Rear High Frequency Output Steering
22 R Low Band Det. Right Input, used for Autobalance and Low Band Steering
23 L Low Band Det. Left Input, used for Autobalance and Low Band Steering
24 Low Band Det. Out Capacitor to ACOM; Controls Left-to-Right Output Steering
25 Autobalance TC RC Network to ACOM
26 Autobalance Lockout RC Network to ACOM
27 Front/Rear (L+R) Det. RC Network Fed by (L+R) Out (Pin 15)
28 Front/Rear (L—R)Det. RC Network Fed by (L-R) Out (Pin 16)
29 Front/Rear Det. Capacitor to ACOM; Controls Front-to-Back Output Steering
30 High Band TC Filter RC Network to ACOM
31 Low Band TC Filter RC Network to ACOM
32 Front/Rear TC Filter RC Network to ACOM
33 Clock In Clock from Serial Bus
34 WRITE Chip Select from Serial Bus
35 V
EE
Negative Supply
36 GND Power Ground
37 ACOM Audio GND Audio Ground
38 V
CC
Positive supply
39 Data In Data from Serial Bus
40 Reset Reset from Serial Bus
41 LOAD Load from Serial Bus
42 Noise Out Connect to RC Filter; White Noise Output
43 Noise In Connect to RC Filter Output; Filtered White Noise
44 RS Out Connect to Right Surround (Rear) Amplifier Input
45 LS Out Connect to Left Surround (Rear) Amplifier Input
46 RF Out Connect to Right Front Amplifier Input
47 LF Out Connect to Left Front Amplifier Input
48 Center Out Connect to Center Amplifier Input
STEERING
CONTROL
GENERATOR
LEFT
RIGHT
INPUTS
RIGHT
SURROUND
LEFT
SURROUND
CENTER
RIGHT
LEFT
RESET
SERIAL BUS
OUTPUTS
L+R FOR
SUBWOOFER
STEERING MATRIX
AND OUTPUT
AMPLIFIERS
ANALOG
SIGNAL
PROCESSING
MODE CONTROL
LOGIC AND NOISE
GENERATOR
TOP VIEW
(Not to Scale)
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
SSM2005
CENTER OUT
R FILTER IN
R FILTER OUT
L FILTER IN
L FILTER OUT
L OUT
L OUT A
L IN
R OUT
R OUT A
R IN
VEE
ACOM AUDIO GND
GND
VCC
(L+R) OUT
(L—R) OUT
(L—R) HIGH IN
(L—R) LOW IN
R HIGH BAND DET.
L HIGH BAND DET.
HIGH BAND DET. OUT
R LOW BAND DET.
L LOW BAND DET.
LOW BAND DET. OUT
LF OUT
RF OUT
LS OUT
RS OUT
NOISE IN
NOISE OUT
LOAD
RESET
DATA IN
VCC
ACOM AUDIO GND
GND
VEE
WRITE
CLOCK IN
FRONT/REAR TC FILTER
LOW BAND TC FILTER
HIGH BAND TC FILTER
FRONT/REAR DET.
FRONT/REAR (L—R) DET.
FRONT/REAR (L+R) DET.
AUTOBALANCE LOCKOUT
AUTOBALANCE TC
DGND
CLK
DATA
LATCH
DVDDOUT4
OUT1
OUT2
OUT3
AVDD
LBASS1
LBASS2
LBASS3
LTRE
BYPASSL
BYPASSR
Lin
Rin
GNDL
GNDR
Cin
GNDC
SLin
SRin
GNDS
SWin
AVSS
AGND
Lout
Rout
Cout
SLout
SRout
RBASS1
RBASS2
RBASS3
RTRE
CL2
CL1
CR2
CR1
SW out
21
20
19
18
17
15
14
13
12
11
10
9
8
7
6
5
4
3
2
142
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
tone tone
volume
volume
volume
volume
volume
volume
MCU
I/F
OUT-
PUT
PORT
16
BLOCK DIAGRAM
QQ03 : SSM2005
QG01 : M62446
PIN CONFIGURATION PIN FUNCTION
FM SD
ADJ
FM
3 rd 5 th
DECODER
ANTI-BIRDIE
Q201 : LA1837
QM01 : LB1641
