Marantz SR6005/N1SG User manual

Service
Manual
•Some illustrations using in this service manual are slightly different from the actual set.
•Please use this service manual with referring to the operating instructions without fail.
•For purposes of improvement, specifications and design are subject to change without notice.
AV Surround Receiver
SR6005 /N1SG/N1B/U1B/K1B
SR6005
SR6005
S0159-1V02DM/DG1010 Copyright 2010 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
Ver. 2
Please refer to the
MODIFICATION NOTICE.

2
MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for
which it is famous.
Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
091105DM/DG
USA
MARANTZAMERICA,INC
100 CORPORATE DRIVE
MAHWAH, NEW JERSEY 07430
USA
EUROPE / TRADING
D&M EUROPE B. V.
P. O. BOX 8744, BUILDING SILVERPOINT
BEEMDSTRAAT 11, 5653 MA EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2507844
FAX : +31 - 40 - 2507860
KOREA
D&M SALES AND MARKETING KOREA LTD.
2F,YEON BLDG.,
88-5, BANPO-DONG, SEOCHO-GU,
SEOUL KOREA
PHONE : +82 - 2 - 715 - 9041
FAX : +82 - 2 - 715 - 9040
CANADA
D&M Canada Inc.
5-505 APPLE CREEK BLVD.
MARKHAM, ONTARIO L3R 5B1
CANADA
PHONE : 905 - 415 - 9292
FAX : 905 - 475 - 4159
JAPAN
D&M BUILDING, 2-1 NISSHIN-CHO,
KAWASAKI-KU, KAWASAKI-SHI,
KANAGAWA, 210-8569 JAPAN
D&MHoldingsInc.
CHINA
D&M SALES AND MARKETING SHANGHAI LTD.
ROOM.808 SHANGHAI AIRPORT CITY TERMINAL
NO.1600 NANJING (WEST) ROAD, SHANGHAI,
CHINA. 200040
TEL : 021 - 6248 - 5151
FAX : 021 - 6248 - 4434
SHOCK, FIRE HAZARD SERVICE TEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary
AC cord connector pins (with unit NOT connected to AC mains and its Power switch ON), and the face or Front Panel of
product and controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied,
and verified before it is return to the user/customer.
Ref. UL Standard No. 60065.
NOTE ON SAFETY :
Symbol zFire or electrical shock hazard. Only original parts should be used to replaced any part marked with symbol z.
Any other component substitution (other than original type), may increase risk of fire or electrical shock hazard.
安全上の注意：
zがついている部品は、安全上重要な部品です。必ず指定されている部品番号の部品を使用して下さい。

3
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. if the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, in each power ON, OFF and STANDBY
mode, if applicable.
CAUTION Please heed the points listed below during servicing and inspection.
◎Heed the cautions!
Spots requiring particular attention when servicing, such
as the cabinet, parts, chassis,etc., have cautions indicated
on labels. be sure to heed these causions and the
cautions indicated in the handling instructions.
◎Caution concerning electric shock!
(1) An AC voltage is impressed on this set, so touching
internal metal parts when the set is energized could
cause electric shock. Take care to avoid electric
shock, by for example using an isolating transformer
and gloves when servicing while the set is energized,
unplugging the power cord when replacing parts, etc.
(2) Tere are high voltage parts inside. Handle with extra
care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when manufacturing parts
from sheet metal, there may in some rare cases be burrs
on the edges of parts which could cause injury if fingers
are moved across them. Use gloves to protect your hands.
◎Only use designated parts!
The set's parts have specific safety properties (fire
resistance, voltage resistance, etc.). For replacement
parts, be sure to use parts which have the same
poroperties. In particular, for the important safety parts
that are marked z on wiring diagrams and parts lists, be
sure to use the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally!
For safety seasons, some parts use tape, tubes or other
insulating materials, and some parts are mounted away
from the surface of printed circuit boards. Care is also
taken with the positions of the wores omsode amd clamps
are used to keep wires away from heating and high
voltage parts, so be sure to set everything back as it was
originally.
◎Inspect for safety after servicing!
Check that all screws, parts and wires removed or
disconnected for servicing have been put back in their
original positions, inspect that no parts around the area
that has been serviced have been negatively affected,
conduct an inslation check on the external metal
connectors and between the blades of the power plug,
and otherwise check that safety is ensured.
(Insulation check procedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and turn the power switch on.
Using a 500V insulation resistance tester, check that the
inplug and the externally exposed metal parts (antenna
terminal, headphones terminal, input terminal, etc.) is
1MΩor greater. If it is less, the set must be inspected and
repaired.
Many of the electric and structural parts used in the set
have special safety properties. In most cases these
properties are difficult to distinguish by sight, and using
replacement parts with higher ratings (rated power and
withstand voltage) does not necessarily guarantee that
safety performance will be poreserved. Parts with safety
properties are indicated as shown below on the wiring
diagrams and parts lists is this service manual. Be sure to
replace them with parts with the designated part number.
(1) Schematic diagrams ......Indicated by the z mark.
(2) Parts lists ......Indicated by the zmark.
Using parts other than the designated
parts could result in electric shock, fires
or other dangerous situations.
CAUTION Concerning important safety
parts

4
NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Parts marked with this symbol zhave critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
CAUTION:
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check. If the
leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the unit is defective.
WARNING:
DO NOT return the unit to the customer until the problem is located and corrected.
NOTICE:
ALL RESISTANCE VALUES IN OHM. k=1,000 OHM / M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASURED AT NO SIGNAL
INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Parts for which "nsp" is indicated on this table cannot be supplied.
When ordering of part, clearly indicate "1" and "I" (i) to avoid mis-supplying.
Ordering part without stating its part number can not be supplied.
Not including General-purpose Carbon Chip Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)
Parts marked with this symbol zhave critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
Not including General-purpose Carbon Film Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)
Part indicated with the mark "★" is not illustrated in the exploded view.
WARNING:
1.
2.
3.
4.
5.
6.
●Resistors
RD: Carbon
RC: Composition
RS : Metal oxide film
RW: winding
RN: Metal film
RK : Metal mixture
P : Pulse-resistant type
NL : Low noise type
NB : Non-burning type
FR : Fuse-resistor
F : Lead wire forming
2B : 1/8 W
2E : 1/4 W
2H : 1/2 W
3A : 1 W
3D : 2 W
3F : 3 W
3H : 5 W
F:±1%
G:±2%
J:±5%
K:±10%
M:±20%
Ex.: RN
Type
14K
Shape
and per-
formance
2E
Power
182
Resist-
ance
G
Allowable
error
FR
Others
*Resistance 1800ohm=1.8kohm1 8 2Indicates number of zeros after effective number.
2-digit effective number.
1.2ohm1 R 2
2-digit effective number, decimal point indicated by R.
1-digit effective number.
: Units: ohm
●Capacitors
CE : Aluminum foil
electrolytic
CA : Aluminium solid
electrolytic
CS : Tantalum electrolytic
CQ: Film
CK : Ceramic
CC: Ceramic
CP : Oil
CM: Mica
CF : Metallized
CH: Metallized
HS : High stability type
BP : Non-polar type
HR: Ripple-resistant type
DL : For change and discharge
HF : For assuring high requency
U : UL part
C : CSA part
W : UL-CSA part
F : Lead wire forming
0J : 6.3 V
1A : 10 V
1C : 16 V
1E : 25 V
1V : 35 V
1H : 50 V
2A : 100 V
2B : 125 V
2C : 160 V
2D : 200 V
2E : 250 V
2H : 500 V
2J : 630 V
F:±1%
G:±2%
J:±5%
K:±10%
M:±20%
Z:±80%
:-20%
P : +100%
C:±0.25pF
D:±0.5pF
= : Others
Ex.: CE
Type
04W
Shape
and per-
formance
1H
Dielectric
strength
3R2
Capacity
M
Allowable
error
BP
Others
･Units:μF.
2200μF2 2 2Indicates number of zeros after effective number.
2-digit effective number. ･Units:μF.
2.2μF2 R 2
2-digit effective number, decimal point indicated by R
1-digit effective number.
*Capacity (electrolyte only)
･When the dielectric strength is indicated in AC,"AC" is included after the dieelectric strength value.
*Capacity (except electrolyte)
･Units:pF
2200pF=0.0022μF2 2 2
Indicates number of zeros after efective number. (More than 2)
2-digit effective number. ･Units:pF
220pF2 2 1
2-digit effective number.
Indicates number of zeros after effective numver. (0 or 1)
NOTE FOR PARTS LIST

5
TECHNICAL SPECIFICATIONS
nAudio Section
• Power amplifier
Rated output :
Front :
110 W + 110 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
190 W + 190 W (6 Ω, 1 kHz with 10 % T.H.D.)
Center :
110 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
190 W (6 Ω, 1 kHz with 10 % T.H.D.)
Surround :
110 W + 110 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
190 W + 190 W (6 Ω, 1 kHz with 10 % T.H.D.)
Surround Back :
110 W + 110 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
190 W + 190 W (6 Ω, 1 kHz with 10 % T.H.D.)
Output connectors : 6 – 8 Ω (SPEAKER A + B : 8 Ω)
• Analog
Input sensitivity/Input impedance : 175 mV/50 kΩ
Frequency response : 10 Hz – 100 kHz — ±3 dB (Source Direct mode)
S/N : 98 dB (IHF–A weighted, Source Direct mode)
nVideo Section
• Standard video connectors
Input/output level and impedance : 1 Vp-p, 75 Ω
Frequency response : 5 Hz – 10 MHz — +1, –3 dB
• Standard video connectors
Input/output level and impedance :
Y (brightness) signal — 1 Vp-p, 75 Ω
PB/ CBsignal — 0.7 Vp-p, 75 Ω
PR/ CRsignal — 0.7 Vp-p, 75 Ω
Frequency response : 5 Hz – 60 MHz — +0, –3 dB
nTuner section
[FM](Note: μV at 75 Ω, 0 dBf = 1 x 10–15 W)
Receiving Range (for U) :
[FM] 87.5 MHz – 107.9 MHz [AM]520 kHz – 1710 kHz
Receiving Range (for N,K) :
[FM] 87.5 MHz – 108.0 MHz [AM]522 kHz – 1611 kHz
Usable Sensitivity :
[FM]1.2 μV (12.8 dBf) [AM]18 μV
50 dB Quieting Sensitivity (for U) :
[FM]MONO 2.8 μV (20.2 dBf)
50 dB Quieting Sensitivity (for N,K) :
[FM]MONO 2.0 μV (17.3 dBf)
STEREO 42 μV (34.5 dBf)
S/N (IHF-A) :
[FM]MONO 70 dB
STEREO 67 dB
Total harmonic Distortion (at 1 kHz) (for U) :
[FM]MONO 0.7 %
STEREO 1.0 %
Total harmonic Distortion (at 1 kHz) (for N,K) :
[FM]MONO 0.3 %
STEREO 0.7 %
nGeneral
Power supply (for U) : AC 120 V, 60 Hz
Power supply (for K) : AC 220 V, 50 Hz
Power supply (for N) : AC 230 V, 50 Hz
Power consumption :
650 W
0.2 W (Standby)
3 W (CEC standby)
Maximum external dimensions :
440 (W) x 161 (H) x 389 (D) mm
Weight : 11.8 kg
nRemote Control Unit (RC011SR)
Batteries : R03/AAA Type (two batteries)
DIMENSION
348.517.5 22.5
389
30.58630.0
53.5 245
440
146.5
344
214.564.0
14.5
161

6
CAUTION IN SERVICING
Initializing AV SURROUND RECEIVER
AV SURROUND RECEIVER initialization should be performed when the μcom, peripheral parts of μcom, and Digital
P.W.B. are replaced.
1. Turn off the power using ON/STANDBY button.
2. Press ON/STANDBY button while simultaneously pressing SURR.MODE and AUTO buttons.
3. Check that the entire display is flashing with an interval of about 1 second, and release your fingers from the 2
buttons and the microprocessor will be initialized.
Service Jigs
When you repair the printing board, you can use the following JIG (Extension cable kit).
Please order to marantz Official Service Distributor in your region if necessary.
8U-110084S : EXTENSION UNIT KIT : 1 Set
(Refer to "JIG FOR SERVICING".)
Note: •If step 3 does not work, start over from step 1.
•All user settings will be lost and this factory setting will be recovered when this initialization mode.
So make sure to memorize your setting for restoring after the initialization.
ON/STANDBY
SURR.MODE
AUTO

DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
• In the case of the re-assembling, observe "attention of assembling" it.
• If wire bundles are untied or moved to perform adjustment or parts replacement etc., be sure to rearrange them neatly
as they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB FRONT
(Ref. No. of EXPLODED VIEW : 26)
PCB USB
(Ref. No. of EXPLODED VIEW : 59-1)
PCB PCB MIC_H/P
(Ref. No. of EXPLODED VIEW : 59-2)
RADIATOR ASSY
Refer to "DISASSEMBLY
2. RADIATOR ASSY"
and "EXPLODED VIEW"
PCB 7CH_AMP ASSY
(Ref. No. of EXPLODED VIEW : 50)
PCB GUIDE_L
(Ref. No. of EXPLODED VIEW : 60)
PCB H/S GUIDE
(Ref. No. of EXPLODED VIEW : 61)
PCB GUIDE_R
(Ref. No. of EXPLODED VIEW : 62)
PCB REG CNT/PCB REG
Refer to "DISASSEMBLY
3. PCB REG CNT/PCB REG"
and "EXPLODED VIEW"
PCB REG
(Ref. No. of EXPLODED VIEW : 53)
PCB REG_CNT
(Ref. No. of EXPLODED VIEW : 54)
CABINET TOP
HDMI UNIT ASSY
Refer to "DISASSEMBLY
4. HDMI UNIT ASSY"
and "EXPLODED VIEW"
PCB FRONT_CNT
(Ref. No. of EXPLODED VIEW : 55)
PCB SIDE_CNT
(Ref. No. of EXPLODED VIEW : 56)
PCB RS232
(Ref. No. of EXPLODED VIEW : 57)
PCB SIRIUS
(Ref. No. of EXPLODED VIEW : 58)
PCB VIDEO ASSY
(Ref. No. of EXPLODED VIEW : 63)
PCB AUDIO
(Ref. No. of EXPLODED VIEW : 64)
PCB PREOUT
(Ref. No. of EXPLODED VIEW : 65)
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : 66)
PCB SPK/PCB SMPS
Refer to "DISASSEMBLY
5. PCB SPK/PCB SMPS"
and "EXPLODED VIEW"
PCB SPK
(Ref. No. of EXPLODED VIEW : 51)
PCB SMPS
(Ref. No. of EXPLODED VIEW : 52)
7

8
About the photos used for descriptions in the "DISASSEMBLY" section.
• The direction from which the photographs used herein were photographed is indicated at "Direction of photograph: ***"
at the left of the respective photographs.
• Refer to the table below for a description of the direction in which the photos were taken.
• Photographs for which no direction is indicated were taken from above the product.
• The Photographs is SR6005 N1B model.
1. FRONT PANEL ASSY
(1) Remove the screws.
The viewpoint of each photograph
(Photografy direction)
［View from above］
Front side
Direction of photograph: B
Direction of photograph: D
Direction of photograph: C
Direction of photograph: A
CABINET TOP FRONT PANEL ASSY
→
Proceeding :
View from bottom

9
(2) Disconnect the connector wires then remove the screws.
(3) Disconnect the connector wires and FFC cable.
Direction of photograph: D
Direction of photograph: C
STYLEPIN : Loose CP308
FFC cable N4401
cut
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in FRONT PANEL ASSY.

10
2. RADIATOR ASSY
(1) Remove the screws.
(2) Cut the wire clamp bands, then remove the screws.
CABINET TOP FRONT PANEL ASSY
→RADIATOR ASSY →
Proceeding :
View from bottom
Direction of photograph: D
Direction of photograph: C
STYLEPIN : Loose
cut

11
(3) Disconnect the connector wires.
PCB 7CH AMP
PCB 7CH AMP
RADIATOR ASSY
CP401
CP405CP403CP402
N4905
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in RADIATOR ASSY.

12
3. PCB REG CNT/PCB REG
(1) Remove the screws.
(2) Disconnect the connector wires and connector board.
CABINET TOP FRONT PANEL ASSY
→RADIATOR ASSY →
Proceeding :
PCB REG CNT/PCB REG
→
Direction of photograph: B
PCB REG CNT PCB REG
Direction of photograph: C
N2004
CP104 PCB REG CNT
Board to board
CP102
CP13APCB REG

13
4. HDMI UNIT ASSY
(1) Cut the wire clamp bands, then disconnect the connector wire and FFC cable.
(2) Remove the screws, then remove the BACK PANEL.
CABINET TOP HDMI UNIT ASSY
→
Proceeding :
HDMI UNIT ASSY
Direction of
photograph: C
FFC cable
N4905
N4610
N4401
CP401
cut cut
N2004
CP13A
Direction of photograph: A

14
(3) Remove the screws and the SUPPORTER PCB.
Remove the PCB SIRIUS and the PCB RS232 from the PCB SIDE CNT(Board to board).
(4) Disconnect the connector board.
(5) Disconnect the connector board.
Board to board
PCB SIRIUS
PCB RS232
SUPPORTER PCB
BRACKET HDMI
PCB HDMI
Board to board
Board to board
Board to board
Board to board
PCB VIDEO ASSY

15
(6) Remove the screws then disconnect the connector.
(7) Disconnect the connector board.
Direction of photograph: A
Connector
PCB AUDIO
PCB PREOUT
PCB FRONT CNTPCB SIDE CNT
Board to board
Board to board
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in HDMI UNIT ASSY.

16
5. PCB SPK/PCB SMPS
(1) Remove the screws and SUPPORTER P.C.
(2) Disconnect the connector wire, then remove the screws and SUPPORTER P.C.
CABINET TOP HDMI UNIT ASSY
→PCB SPK/PCB SMPS →
Proceeding :
View from bottom
SUPPORTER P.C.
Direction of
photograph: D
CX102
SUPPORTER P.C.

17
(3) Disconnect the connector wire, then remove the screws. Remove the PCB SPK and the PCB SMPS from the main
unit.
(4) Disconnect the connector board.
CP1
CP405CP403CP402
PCB SMPSPCB SPK
Board to board

18
SPECIAL MODE
Special mode setting button
bPress the ON/STANDBY button to turn on while pressing both buttons A and B at the same time.
Mode Button A Button B Contents
μcom/DSP Version display mode STATUS RETURN
Firmware versions such as Main, Sub, DSP are displayed in
the FL manager. Errors are displayed when they occur. (Refer
to 19 page.)
Errors checking mode
(Displaying the protection history) STATUS CURSOR 0Displaying the protection history
(Refer to 21page.)
Initialization mode SURR. MODE AUTO Backup data initialization is carried out.
(Refer to 6 page.)
Panel lock mode AUTO ENTER Operations using main unit panel buttons or master volume are
rejected.
Panel lock mode
(Remove Master volume) AUTO CURSOR 1Operations using main unit panel buttons are rejected.
Cancellation of panel lock mode AUTO RETURN Panel lock mode is cancelled.
bWhen power is turned on, pressing both buttons A and B at the same time for 3 seconds or more.
Mode Button A Button B Contents
Mode for preventing remote control
acceptance CURSOR 0MENU Operations using remote control are rejected. Select with the CURSOR 01button.
DUAL BACKUP MEMORY (Backup) BAND ENTER Backup of DUAL BACKUP MEMORY is performed.
(Refer to 23 page.)
DUAL BACKUP MEMORY (Recovery) BAND MENU Recovery of DUAL BACKUP MEMORY is performed.
(Refer to 23 page.)
DUAL BACKUP MEMORY
(Backup Clear) BAND AUTO Backup of DUAL BACKUP MEMORY is cleared. (Refer to 23 page.)
ON/STANDBY
SURR.MODE MENU
AUTO CURSOR
0 1
STATUS BAND
RETURN

19
1. μcom/DSP Version display mode
1.1. Operation specifications
μcom/DSP version display mode:
When started up, the version information is displayed.
Starting up:
With the "STATUS" and "RETURN" buttons pressed, press the "ON/STANDBY" button to turn the power on.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
1.2. Display Order
Error information(Refer to 1.3. Error display) →qModel destination information →wMain μ-com/ROM version →
eMain 1st Boot Loader →rSub μ-com/Sub FBL →tDSP version →yAudio PLD →uOSD FPGA Config →
iOSD Program →oOSD font data →Q0HD RADIO SDK/HD RADIO BBP (SR6005 U only) →Q1USB Version
qModel destination information :
Upper SR6005 N
Lower S/N. **********
wMain μ-com & ROM version :
Upper Main :**.**
Lower Main ROM :**.**
eMain 1st Boot Loader :
Upper Main FBL :**.**
Lower
rSub μ-com & Sub FBL :
Upper Sub :**.**
Lower Sub FBL :**.**
tDSP ROM :
Upper DSP :**.**
Lower
yAudio PLD :
Upper Audio PLD :**.**
Lower
uOSD FPGA Config :
Upper OSD Config:
Lower ************
iOSD Program :
Upper OSD RPG:
Lower ************
oOSD font data :
Upper OSD DAT:
Lower ************

20
Q0HD RADIO SDK/HD RADIO BBP (SR6005 U only):
Upper *HDSDK: **.**
Lower *HDBBP:C0002.000
Q1USB Version :
Upper USB :**.**
Lower
1.3. Error display
See the following table for each "Error information" display and its contents (status).
Display order is q,w,e,r,t,y.
Condition State State
qSub-com NG No response from Sub-com
SUB ERROR 01
wDIR NG No response from DIR
DIR ERROR 01
eDSP NG
When DSP boot, executing DSP reset makes no change to DSP1 FLAG0
port "H".
DSP ERROR 01
No change to DSP FLAG0 port "H" before issuing DSP command.
DSP ERROR 02
When DSP data read, executing WRITE="L" makes no change to ACK="H".
DSP ERROR 03
When DSP data read, executing REQ="L" makes no change to ACK="L".
DSP ERROR 04
When DSP data write, executing WRITE="H" makes no change to ACK="H".
DSP ERROR 05
When DSP data write, executing REQ="L" makes no change to ACK="L".
DSP ERROR 06
When DSP special code boot, executing DSP reset makes no change to
DSP FLAG0 port "H".
DSP ERROR 11
No change to DSP FLAG0 port "H" before issuing DSP special read
command.
DSP ERROR 12
No change to DSP FLAG0 port "H" before DSP version read.
DSP ERROR 13
rEEPROM NG Error appeared in EEPROM checksum.(*** is a block address number.)
E2PROM ERR***
tUSB NG No response from USB

-com.
USB ERROR 01
yBoth SUB/DSP
/EEPROM OK (No error display, version display only)
