Marathon WS-RB-3PC User manual

SWISS MADE. |CANADIAN DESIGNED.
3-PIECE KIT
STRAP, RUBBER WS-RB-3PC
MAN-WSRB-3PC-03

SPECIFICATIONS
Strap
Widths
Fits Wrists
Rubber IAW
Rubber, FKM
18mm 20mm 22mm
160–225mm 165–240mm 175–250mm
6.25–9" 6.5–9.5" 7–10"
STM INTL STANDARD: D1418

KIT INCLUDES
1x Strap, Rubber: Buckle Section
(with Buckle)
Position: 12 O'clock
Length: 70mm
1x Strap, Rubber: Tail Section
Position: 6 O'clock
Length: 120mm
1x Strap, Rubber: Buckle Section
Position: 12 O'clock
Length: 90mm
4x Shoulderless Spring Bars
4x Shouldered Spring Bars

BUCKLE SECTION 70MM (WITH BUCKLE)
TAIL SECTION
SHOULDERLESS SPRING BARS
SHOULDERED SPRING BARS
BUCKLE SECTION 90MM

WRIST SIZE COMPATIBILITY GUIDE
To nd your wrist size reference our SAR & Accessories Sizing Guide which provides
step-by-step instructions. You can download the template at:
www.MarathonWatch.com/Sizing
There are two lengths to your watch strap, the tail-end or “6 o’clock” (length of long
section), and the buckle end or “12 o’clock” (length of short section, excluding buckle).
NOTE: Wrist ttings are suggestions based on Marathon SAR watches, please adjust
accordingly to ensure proper t.

8.5"6.25"
7" 9"
Using a 70mm
12 O'clock Strap
Using a 90mm
12 O'clock Strap
WRIST SIZE (in) 30 4 5 6 7 8 9 10 11 12
18MM KIT SIZE RANGE

8.75"6.5"
7.25" 9.5"
Using a 70mm
12 O'clock Strap
Using a 90mm
12 O'clock Strap
20MM KIT
WRIST SIZE (in) 30 4 5 6 7 8 9 10 11
SIZE RANGE
12

Using a 70mm
12 O'clock Strap
Using a 90mm
12 O'clock Strap
22MM KIT
WRIST SIZE (in) 30 4 5 6 7 8 9 10 11
SIZE RANGE
12
9"7"
7.75" 10"

REMOVING THE BUCKLE
1. Using a spring bar tool, insert the pin-pusher end into the drilled through buckle
hole, compressing the spring bar until it releases from the buckle. Repeat for
the other side.
2. Remove the spring bar completely by pulling it with your ngers. If the spring
bar does not come easily, use the pin pusher end of the spring bar tool to
push it out.
3. Once the spring bar has been removed, the prong will slide out easily.

INSTALLING THE BUCKLE PART 1
1. Insert the spring bar through one side of the strap until it reaches the cut-out.
2. Insert the prong into the cut-out section and hold it in place while you push the
spring bar through the rest of the way.
CAUTION: If the spring bar doesn't go through easily, use the pin pusher end of the
spring bar tool to push it through.

INSTALLING THE BUCKLE
1. Attach one side of the buckle to the spring bar.
2. Use the pin-pusher end of the spring bar tool to compress the other side of the
spring bar. While holding pressure, slide the loose end of the buckle over the
compressed spring bar to secure in place.
NOTE: Give the buckle a gentle pull to make sure it is attached securely.
PART 2

INSTALLING THE STRAP
1. Insert one end of the spring bar into one of the watch's lugs.
2. Using the pin-pusher end of the spring bar tool, compress the other side of the
spring bar while guiding it into the inner part of the lug.
3. Repeat this process for the other part of the strap.
NOTE: While inserting the opposite end of the spring bar, make sure to align it with
the lug hole. If it doesn't snap into the lug hole, gently adjust the strap until you
hear a click.

REMOVING THE STRAP
1. Insert the pin-pusher end of the spring bar tool into a drilled lug, compressing
the spring bar.
2. Slightly angle the strap until it releases from the lug hole.
3. Repeat Step 1 for the opposite drilled lug. While compressing the spring bar,
remove the strap completely by pulling it with your ngers at an angle.
4. Repeat this process for the other part of the strap.
DRILLED LUGS
