V-tech Star Wars Stormtrooper BB-8 User manual

TM & © 2017 VTech Holdings Limited.
All rights reserved
Printed in China
91-003090-012 UK
USER’S MANUAL
STORMTROOPERTM / BB-8TM
CAMERA WATCH
© & TM Lucasfilm Ltd.

3
INTRODUCTION
The STAR WARSTM Camera Watch from VTech®is the perfect accessory
for intergalactic explorers! Personalise the '3D-eect' clock face with 30
themed designs to choose from, take photos and videos with the built-in
camera, and test your skills with the 3 pre-loaded mini games.
FEATURES (PRODUCT LAYOUT AND BUTTONS)
INTRODUCTION / FEATURES
CAMERA
HOME BUTTON MICRO USB PORT
SHUTTER BUTTON
MASTER POWER SWITCH
1.44" TOUCH
SCREEN
WRISTBAND

4
Master Power Switch
When the switch is down (OFF) the battery will be disconnected and
the watch will not function. Slide the switch up (ON) to enable the
watch.
Note: It is not necessary to switch o the watch in daily use. Once the
master power switch is o, the watch will stop functioning. When the
watch is turned on again, the time and date must be reset.
SHUTTER BUTTON /
Press this button to launch the camera and to take photos.
HOME BUTTON /
Clock mode - When the screen is o, press the HOME BUTTON to wake
up the watch and view the time.
Home Menu - Press the HOME BUTTON again when the watch is in clock
mode to enter the home menu, or if the watch is in another activity,
pressing the HOME BUTTON will take you back to the previous menu.
Turn o the screen - When the clock is displayed, hold the HOME BUTTON
down for approximately one second to turn the display o.
Smart Wake up
The VTech®STAR WARSTM Camera Watch allows you to double tap the
screen to wake up the watch and view the current time. For best results,
we recommend tapping the screen with the tip of your finger and not
your finger nail or other tools.
Micro USB
Connect your VTech®Star WarsTM Camera Watch to your computer
using the included micro USB cable to transfer files and charge the
battery.
INCLUDED IN THIS PACKAGE
• 1 VTech®Star WarsTM Camera Watch (with built-in Li-ion polymer
battery*)
• 1microUSBcable
• 1user’smanual
* Battery is not replaceable.
WARNING: All packing materials such as tape, plastic sheets,
packaging locks, removable tags, cable ties and packaging
screws are not part of this toy, and should be discarded
for your child’s safety.
FEATURES / INCLUDED IN THIS PACKAGE

5
The battery in this product must not be disposed of with household
waste. This battery is recyclable. Please follow your local recycling
regulations.
The toy is only to be connected to Class II equipment bearing the
following symbol .
Note: Please keep the user’s manual as it contains important information.
The label covering the screen of the watch is packing material. Please
remove this label before use.
PRODUCT SPECIFICATION
Display 1.44" colour touch screen
Photo Resolution 640 X 480 (0.3 MP)
Video Resolution 320 X 240 pixel or 160 X 120 pixel
Video Length limit
per file 60 seconds
Focus Range 1.5 feet - ∞
Internal Memory
256 MB built-in memory (shared with program
data, actual memory available for user storage
will be less)
Storage capacity
Photos: approx. 1600
Videos: approx. 11 minutes at 320 x 240 pixels,
approx. 23 minutes at 160 X 120 pixels
(Video length limited to 1 minute per file)
Note: The storage capacity is an approximation,
the actual amount varies depending on the
shooting environment.
File Format Photos: Standard Baseline JPEG
Video: AVI (Motion JPEG)
Connectivity Micro USB 2.0 cable (included) for connection
to computer
Battery Li-ion Polymer battery (battery is not replaceable)
Optimum Operating
and Charging
Temperature
0°C - 40°C (32°F - 104°F)
PRODUCT SPECIFICATION
