Maretron NMEA 2000 User manual
DSM250 User’s Manual
Page ii Revision 1.4.18
Revision History
Rev.
Description
1.0
Original document.
1.4.2
Added sections on Alert and Anchor Watch and configuration of more devices.
1.4.8
Added prohibition of red Loctite threadlocking compound and cleaning agents
containing acetone
Added new J2K100 configuration capabilities
Added new ACM100 configuration capabilities
Added information on configuring IPG100
Added information on configuring GPS200
1.4.13
Added warning to not block vent port during installation
Added new DST110 configuration capabilities
1.4.16
Added description of Electrical Distribution control and monitoring
Added Fluid Flow category
Added Switch/Breaker display type
Added Engine->Trip Fuel Used parameter
Added Vessel Data Recorder monitoring
Added Airmar transducer configuration/calibration
Added DCR100 configuration
Added FFM100 configuration
Added FPM100 configuration
Added NBE100 configuration
Added VDR100 configuration
Updated Supported Display Types in Technical Specifications
1.4.16a
Corrected Page Number Issue
Updated Received PGN List
Corrected Description of “DSM250 Running in Favorite Screens Mode” Figure
Added notes that zero re-trigger time on an alert will disable re-triggering
1.4.17
Added Configuration of VDR100 Network Parameters
Removed 127502 from Supported PGN Table
Added Configuration of SMS100
1.4.18
Added Device Configuration for SMS100
Updated Device Configuration for EMS100, IPG100,VDR100
Removed 127502 Binary Switch Control from supported PGN list
Added 130834 and 130835 to supported PGN list
Added SMS Phone Book
Added Alert Configuration for SMS Text Messages
Added Control Mode resetting of Trip Log, Total Fuel Used, Total Volume, Anchor
Watch
Revision 1.4.18 Page iii
Table of Contents
1General..........................................................................................................................................1
1.1 Introduction ........................................................................................................................1
1.2 Firmware Revision .............................................................................................................1
1.3 DSM250 Features..............................................................................................................1
1.4 Quick Install........................................................................................................................1
2Installation......................................................................................................................................2
2.1 Unpacking the Box.............................................................................................................2
2.2 Choosing a Mounting Location...........................................................................................2
2.3 Mounting the DSM250........................................................................................................2
2.3.1 Surface Mounting the DSM250.....................................................................................2
2.3.2 Flush Mounting the DSM250 ........................................................................................3
2.3.3 Gimbal Mounting the DSM250......................................................................................4
2.4 Connecting the DSM250....................................................................................................5
2.4.1 Checking the Connection..............................................................................................5
3Operating the DSM250..................................................................................................................6
3.1 Turning the DSM250 On ....................................................................................................6
3.2 Turning the DSM250 Off ....................................................................................................6
3.3 Keypad Essentials..............................................................................................................7
3.3.1 Navigating in a Menu....................................................................................................7
3.3.2 Choosing a Value from a List........................................................................................8
3.3.3 Entering a Numeric Value.............................................................................................8
3.3.4 Entering a Textual Value...............................................................................................8
4Important Concepts .....................................................................................................................11
4.1 Favorite Screens..............................................................................................................11
4.2 Categories and Data Types..............................................................................................11
4.2.1 AC Bus........................................................................................................................12
4.2.2 AC Generator..............................................................................................................12
4.2.3 AC Utility.....................................................................................................................13
4.2.4 Anchor Watch.............................................................................................................14
4.2.5 DC...............................................................................................................................14
4.2.6 Depth..........................................................................................................................14
4.2.7 Elec. Distribution.........................................................................................................14
4.2.8 Engine.........................................................................................................................14
4.2.9 Environment................................................................................................................16
4.2.10 Fluid Flow ...................................................................................................................16
4.2.11 Fuel Management.......................................................................................................16
4.2.12 GPS............................................................................................................................17
4.2.13 Heading ......................................................................................................................17
4.2.14 Humidity......................................................................................................................18
4.2.15 Indicator......................................................................................................................18
4.2.16 Navigation...................................................................................................................18
4.2.17 Rudder........................................................................................................................18
4.2.18 Pressure/Vacuum .......................................................................................................18
4.2.19 Special Devices ..........................................................................................................19
4.2.20 Speed .........................................................................................................................19
4.2.21 Tank............................................................................................................................19
4.2.22 Temperature...............................................................................................................19
DSM250 User’s Manual
Page iv Revision 1.4.18
4.2.23 Time............................................................................................................................20
4.2.24 Transmission ..............................................................................................................20
4.2.25 VDR............................................................................................................................20
4.2.26 Vessel.........................................................................................................................20
4.2.27 Wind............................................................................................................................21
4.3 Alerts................................................................................................................................22
4.3.1 Alert Types..................................................................................................................22
4.3.2 Alert Terminology........................................................................................................22
4.3.3 Alert Priority................................................................................................................22
4.3.4 Vessel Alert Operating Modes ....................................................................................22
4.3.5 Alert States.................................................................................................................23
4.3.6 Available Alert Classes...............................................................................................24
5Operating Modes.........................................................................................................................25
5.1 Favorite screens modes...................................................................................................25
5.2 Menu Mode......................................................................................................................26
5.2.1 Alert Setup Menu........................................................................................................27
5.2.2 Alert Status.................................................................................................................27
5.2.3 Configuration Menu.....................................................................................................27
5.2.4 Display Settings Menu................................................................................................29
5.2.5 Favorite Screens Mode...............................................................................................36
5.2.6 Favorite Screens Setup Menu ....................................................................................36
5.2.7 Units Menu..................................................................................................................40
5.3 Control Mode....................................................................................................................43
6Device Configuration ...................................................................................................................45
6.1 Airmar Depth/Speed/Temperature Transducers ..............................................................48
6.1.1 Advanced Configuration..............................................................................................48
6.1.2 Device Instance ..........................................................................................................49
6.1.3 Installation Description................................................................................................49
6.1.4 NMEA2000 PGN Enable/Disable................................................................................49
6.1.5 Clear Speed Calibration..............................................................................................49
6.1.6 Speed Calibration .......................................................................................................50
6.1.7 Clear Temperature Offset...........................................................................................50
6.1.8 Temperature Calibration.............................................................................................51
6.1.9 Transducer Depth Offset.............................................................................................51
6.1.10 Trip Log.......................................................................................................................52
6.2 Bennett EP-30 (NMEA1) Trim Tabs Configuration...........................................................53
6.2.1 Trim Tabs Calibration..................................................................................................53
6.3 Maretron ACM100 Configuration......................................................................................55
6.3.1 Advanced Configuration..............................................................................................55
6.3.2 AC Circuit Type...........................................................................................................58
6.3.3 AC Device Type..........................................................................................................58
6.3.4 Device Instance ..........................................................................................................58
6.3.5 Label...........................................................................................................................58
6.3.6 Reset Total Energy Recorded.....................................................................................59
6.4 Maretron ALM100 Configuration......................................................................................60
6.4.1 Advanced Configuration..............................................................................................60
6.4.2 Instance......................................................................................................................61
6.4.3 Label...........................................................................................................................61
Revision 1.4.18 Page v
6.4.4 Test Annunciator.........................................................................................................62
6.5 Maretron DCM100 Configuration .....................................................................................63
6.5.1 Advanced Configuration..............................................................................................63
6.5.2 Current Sensor Zero Offset Calibration.......................................................................65
6.5.3 DC Type......................................................................................................................66
6.5.4 Instance......................................................................................................................68
6.5.5 Label...........................................................................................................................68
6.6 Maretron DCR100 Configuration......................................................................................69
6.6.1 Advanced Configuration..............................................................................................69
6.6.2 Device Label...............................................................................................................71
6.6.3 Instance......................................................................................................................71
6.6.4 Channel #1-#6 Configuration......................................................................................71
6.7 Maretron DSM200 Configuration......................................................................................73
6.7.1 Remote Device Selection............................................................................................74
6.8 Maretron DSM150, DSM250 Configuration......................................................................76
6.8.1 Remote Device Selection............................................................................................76
6.8.2 Copy alarms settings from local display......................................................................77
6.8.3 Copy device selection from local display ....................................................................78
6.8.4 Copy display settings from local display .....................................................................79
6.8.5 Copy favorite settings from local display.....................................................................79
6.8.6 Copy DST100 calibrations from local display..............................................................80
6.8.7 Copy all settings from local display.............................................................................80
6.8.8 Label...........................................................................................................................81
6.8.9 Remote Device Selection............................................................................................82
6.9 Maretron DST100 Configuration ......................................................................................83
6.9.1 Advanced Configuration..............................................................................................83
6.9.2 Clear Speed Calibration..............................................................................................84
6.9.3 Speed Calibration .......................................................................................................84
6.9.4 Transducer Depth Offset.............................................................................................85
6.9.5 Trip Log.......................................................................................................................85
6.10 Maretron DST110 Configuration ......................................................................................87
6.10.1 Advanced Configuration..............................................................................................87
6.10.2 Clear Speed Calibration..............................................................................................88
6.10.3 Speed Calibration .......................................................................................................89
6.10.4 Clear Temperature Offset...........................................................................................89
6.10.5 Temperature Calibration.............................................................................................90
6.10.6 Transducer Depth Offset.............................................................................................90
6.10.7 Trip Log.......................................................................................................................91
6.11 Maretron EMS100 Configuration......................................................................................92
6.11.1 Engine Instance..........................................................................................................92
6.11.2 Boost Pressure Gauge Type.......................................................................................92
6.11.3 Boost Pressure Sender Type......................................................................................93
6.11.4 Boost Pressure Sender Offset....................................................................................93
6.11.5 Drive Trim Gauge Type...............................................................................................93
6.11.6 Drive Trim Sender Type..............................................................................................93
6.11.7 Drive Trim Sender Offset............................................................................................94
6.11.8 Oil Pressure Gauge Type ...........................................................................................94
6.11.9 Oil Pressure Sender Type...........................................................................................94
DSM250 User’s Manual
Page vi Revision 1.4.18
6.11.10Oil Pressure Sender Offset.........................................................................................94
6.11.11Water Temperature Gauge Type................................................................................95
6.11.12Water Temperature Sender Type ...............................................................................95
6.11.13Water Temperature Sender Offset..............................................................................95
6.11.14Preset Engine Hours...................................................................................................95
6.11.15Tachometer Flywheel Teeth .......................................................................................96
6.12 Maretron FFM100 Configuration......................................................................................97
6.12.1 Advanced Configuration..............................................................................................97
6.12.2 Device Label...............................................................................................................99
6.12.3 Operating Mode..........................................................................................................99
6.12.4 Channel #0…..............................................................................................................99
6.12.5 Channel #1…............................................................................................................104
6.13 Maretron FPM100 Configuration....................................................................................108
6.13.1 Advanced Configuration… ........................................................................................108
6.13.2 Channel #0-5............................................................................................................110
6.14 Maretron GPS100 Configuration....................................................................................117
6.14.1 Advanced Configuration............................................................................................118
6.14.2 Cold Start GPS .........................................................................................................122
6.14.3 GPS Mode Setting....................................................................................................122
6.14.4 Device Label.............................................................................................................123
6.14.5 SBAS (WAAS) Enable/Disable .................................................................................123
6.15 Maretron GPS200 Configuration....................................................................................125
6.15.1 Advanced Configuration............................................................................................125
6.15.2 Cold Start GPS .........................................................................................................127
6.15.3 Device Label.............................................................................................................127
6.15.4 SBAS (WAAS,EGNOS,MSAS) Enable/Disable ........................................................127
6.16 Maretron IPG100 Configuration .....................................................................................129
6.16.2 Device Label.............................................................................................................132
6.16.3 N2KServer Password................................................................................................132
6.16.4 Maretron Cloud Services ..........................................................................................132
6.16.5 DHCP........................................................................................................................132
6.16.6 IP Address................................................................................................................133
6.16.7 Subnet Mask.............................................................................................................133
6.16.8 Default Gateway .......................................................................................................133
6.16.9 Default DNS..............................................................................................................133
6.17 Maretron J2K100 Configuration .....................................................................................133
6.17.1 Advanced Configuration............................................................................................134
6.17.2 Device Label.............................................................................................................136
6.17.3 NMEA 2000 Instance –Engine.................................................................................136
6.17.4 Transmission Instance..............................................................................................137
6.17.5 AC/Icemaker Instance...............................................................................................138
6.17.6 J1939 Source Address Configuration .......................................................................138
6.17.7 Refresh J1939 source address list............................................................................139
6.18 Maretron NBE100 Configuration....................................................................................139
6.18.1 Advanced Configuration............................................................................................140
6.19 Maretron RAA100 Configuration....................................................................................140
6.19.1 Advanced Configuration............................................................................................141
6.19.2 Label.........................................................................................................................142
Revision 1.4.18 Page vii
6.19.3 Rudder Angle Calibration..........................................................................................143
6.19.4 Rudder Number ........................................................................................................146
6.19.5 Operating Mode........................................................................................................147
6.19.6 Gauge Resistance, + to Sender................................................................................148
6.19.7 Gauge Resistance, - to Sender.................................................................................148
6.20 Maretron RIM100 Configuration.....................................................................................150
6.20.1 Advanced Configuration............................................................................................150
6.20.2 Device Label.............................................................................................................151
6.20.3 Instance....................................................................................................................152
6.20.4 Channel Configuration..............................................................................................152
6.21 Maretron SIM100 Configuration.....................................................................................153
6.21.1 Advanced Configuration............................................................................................153
6.21.2 Device Label.............................................................................................................154
6.21.3 Instance....................................................................................................................155
6.21.4 Channel Configuration..............................................................................................155
6.22 Maretron SMS100 Configuration....................................................................................156
6.22.1 Advanced Configuration............................................................................................156
6.22.2 Label.........................................................................................................................157
6.22.3 Test… .......................................................................................................................158
6.23 Maretron SSC200 Configuration....................................................................................159
6.23.1 Advanced Configuration............................................................................................159
6.23.2 Installation Offset Calibration....................................................................................162
6.23.3 Inverted Installation Entry .........................................................................................163
6.23.4 Label.........................................................................................................................164
6.23.5 Magnetic Deviation Calibration .................................................................................164
6.23.6 Magnetic Deviation Status........................................................................................165
6.23.7 Rate of Turn Damping Period...................................................................................165
6.23.8 Rate of Turn Zero Offset Calibration.........................................................................166
6.23.9 Variation Source Entry..............................................................................................166
6.24 Maretron TLA100 Configuration.....................................................................................170
6.24.1 Advanced Configuration............................................................................................170
6.24.2 Label.........................................................................................................................171
6.24.3 Tank Capacity...........................................................................................................171
6.24.4 Tank Levels Calibration ............................................................................................172
6.24.5 Tank Number............................................................................................................177
6.24.6 Tank Type.................................................................................................................177
6.24.7 Operating Mode........................................................................................................178
6.24.8 Gauge Resistance, + to Sender................................................................................179
6.24.9 Gauge Resistance, - to Sender.................................................................................179
6.25 Maretron TLM100 Configuration ....................................................................................181
6.25.1 Advanced Configuration............................................................................................181
6.25.2 Label.........................................................................................................................182
6.25.3 Tank Capacity...........................................................................................................182
6.25.4 Tank Levels Calibration ............................................................................................183
6.25.5 Tank Number............................................................................................................187
6.25.6 Tank Type.................................................................................................................187
6.26 Maretron TLM150 Configuration ....................................................................................188
6.27 Maretron TLM200 Configuration ....................................................................................188
DSM250 User’s Manual
Page viii Revision 1.4.18
6.28 Maretron TMP100 Configuration....................................................................................189
6.28.1 Advanced Configuration............................................................................................189
6.28.2 Channel Configuration..............................................................................................190
6.28.3 Device Label.............................................................................................................191
6.29 Maretron USB100 Configuration....................................................................................192
6.29.1 Advanced Configuration............................................................................................192
6.29.2 Remote Device Selection..........................................................................................193
6.30 Maretron VDR100 Configuration....................................................................................194
6.30.1 Advanced Configuration ........................................................................................194
6.30.2 Label.........................................................................................................................195
6.30.3 Password..................................................................................................................195
6.30.4 DHCP........................................................................................................................195
6.30.5 IP Address................................................................................................................195
6.30.6 Subnet Mask.............................................................................................................195
6.30.7 Default Gateway .......................................................................................................196
6.30.8 Default DNS..............................................................................................................196
6.31 Maretron WSO100 Configuration...................................................................................196
6.31.1 Advanced Configuration............................................................................................196
6.31.2 Device Label.............................................................................................................198
6.31.3 Installation Offset Calibration....................................................................................199
6.31.4 Wind Data Damping Period ......................................................................................201
6.31.5 Barometric Pressure.................................................................................................201
6.31.6 Outside Humidity.......................................................................................................202
6.31.7 Outside Temperature................................................................................................202
7Data Display Types....................................................................................................................204
7.1 Anchor Watch Display....................................................................................................204
7.2 Compass Rose Display..................................................................................................205
7.3 Gauge Display................................................................................................................206
7.4 GPS Status Display........................................................................................................207
7.5 Numeric Display.............................................................................................................208
7.6 Rolling Road...................................................................................................................209
7.7 Line Graph .....................................................................................................................210
7.8 Weather Display.............................................................................................................210
7.9 Wind Rose......................................................................................................................212
7.10 Moon Phase Display ......................................................................................................212
7.11 Trim Tab Display............................................................................................................212
7.12 Swing Meter Display ......................................................................................................213
7.13 Tank Gauge Display.......................................................................................................213
7.14 Switch/Breaker Display ..................................................................................................214
8Alerts..........................................................................................................................................218
8.1 Displaying Active Alerts..................................................................................................218
8.1.1 Alert Status Screen...................................................................................................218
8.2 Accepting or Cancelling an Alert....................................................................................219
8.2.1 From a Favorite Screen............................................................................................219
8.2.2 From the Alert Status Screen....................................................................................219
8.3 Adding an Alert...............................................................................................................220
8.3.1 Enable/Disable Control.............................................................................................221
8.3.2 Alert Type .................................................................................................................221
Revision 1.4.18 Page ix
8.3.3 Priority.......................................................................................................................221
8.3.4 Trigger Source..........................................................................................................222
8.3.5 Description................................................................................................................222
8.3.6 Location....................................................................................................................222
8.3.7 Trigger Configuration................................................................................................222
8.3.8 Local Audible............................................................................................................236
8.3.9 Tone..........................................................................................................................236
8.3.10 Remote Annunciators ...............................................................................................237
8.3.11 SMS (Text) Settings… ..............................................................................................237
8.3.12 Operating Mode Moored...........................................................................................238
8.3.13 Operating Mode Underway.......................................................................................239
8.3.14 Operating Mode Anchored........................................................................................239
8.3.15 Scope........................................................................................................................239
8.4 Deleting an Alert.............................................................................................................239
8.5 Editing an Alert...............................................................................................................241
8.6 Setting the Vessel Operating Mode................................................................................242
8.7 SMS (Text) Phone Book.................................................................................................243
8.8 Advanced Configuration.................................................................................................245
8.8.1 Remote Alert Audible................................................................................................246
8.8.2 Flashing Screen........................................................................................................246
8.9 Restore Factory Defaults................................................................................................246
9Maintenance..............................................................................................................................248
10 Troubleshooting.........................................................................................................................249
11 Technical Specifications ............................................................................................................250
12 Technical Support......................................................................................................................255
13 Installation Template..................................................................................................................256
14 Maretron (2 Year) Limited Warranty ..........................................................................................258
DSM250 User’s Manual
Page x Revision 1.4.18
Table of Figures
Figure 1 –Surface Mounting the DSM250............................................................................................3
Figure 2 –Flush Mounting the DSM250 ...............................................................................................4
Figure 3 –Gimbal Mounting the DSM250.............................................................................................5
Figure 4 –NMEA 2000®Connector Face View.....................................................................................5
Figure 5 –DSM250 Power Up Screen..................................................................................................6
Figure 6 –Powerdown Countdown Screen...........................................................................................7
Figure 7 –Keypad and Key Names......................................................................................................7
Figure 8 –Entering a Textual Value......................................................................................................9
Figure 9 –DSM250 Running in Favorite Screens Mode.....................................................................25
Figure 10 –Main Menu.......................................................................................................................26
Figure 11 –Configuration Screen.......................................................................................................27
Figure 12 –Device Selection Screen..................................................................................................28
Figure 13 –DSM250 Display Settings Screen....................................................................................29
Figure 14 –DSM250 Advanced Configuration....................................................................................29
Figure 15 –DSM250 Primary Device Selection..................................................................................30
Figure 16 –DSM250 Advanced Information Screen...........................................................................31
Figure 17 –Bus Status Display...........................................................................................................31
Figure 18 –Backlight Menu ................................................................................................................32
Figure 19 –Color Palette Selection Screen........................................................................................33
Figure 20 –Color Palette Configuration Screen..................................................................................33
Figure 21 –Setting the Demo Mode...................................................................................................34
Figure 22 –Setting the Keyboard Beep Option...................................................................................35
Figure 23 –Editing the DSM250 Label...............................................................................................35
Figure 24 –Setting the Favorite Screens Mode..................................................................................36
Figure 25 –Favorite Screens Setup Screen.......................................................................................36
Figure 26 –Favorite Screen Parameters............................................................................................37
Figure 27 –Setting the Favorite Screen Format.................................................................................38
Figure 28 –Setting the Auto Change Interval.....................................................................................38
Figure 29 –Selecting the Data Category............................................................................................39
Figure 30 –Selecting the Data to be displayed...................................................................................39
Figure 31 –DSM250 Units Menu........................................................................................................41
Figure 32 –Device Configuration Screen ...........................................................................................46
Figure 33 –Airmar Depth/Speed/Temperature Transducer Configuration Screen .............................48
Figure 34 –Airmar Transducer Advanced Configuration Screen........................................................49
Figure 35 –Calibrating the Airmar Speed Transducer Speed ............................................................50
Figure 36 –Airmar Temperature Transducer Water Temperature Calibration Screen .......................51
Figure 37 –Setting the Transducer Depth Offset in an Airmar Depth Transducer..............................52
Figure 38 –Resetting the Airmar Speed Sensor Trip Distance Log....................................................52
Figure 39 –EP-30 Trim Tabs Configuration Screen...........................................................................53
Figure 40 –EP-30 Trim Tabs Calibration Opening Screen.................................................................53
Figure 41 –EP-30 Intermediate Calibration Screen............................................................................54
Figure 42 –EP-30 Calibration Success Message...............................................................................54
Figure 43 –ACM100 Configuration Screen ........................................................................................55
Figure 44 –ACM100 Advanced Configuration Screen .......................................................................55
Figure 45 –ACM100 NMEA 2000®PGN Enable/Disable Screen.......................................................57
Figure 46 –Reset Total Energy Recorded Confirmation Screen........................................................59
Revision 1.4.18 Page xi
Figure 47 –ALM100 Configuration Screen.........................................................................................60
Figure 48 –ALM100 Advanced Configuration Screen........................................................................60
Figure 49 –ALM100 NMEA 2000®PGN Enable/Disable Screen .......................................................61
Figure 50 –DCM100 Configuration Screen........................................................................................63
Figure 51 –DCM100 Advanced Configuration Screen.......................................................................63
Figure 52 –DCM100 NMEA 2000®PGN Enable/Disable Screen.......................................................64
Figure 53 –Current Sensor Zero Offset Calibration Confirmation Screen..........................................65
Figure 54 –Current Sensor Zero Offset Calibration Complete Screen...............................................65
Figure 55 –DCR100 Configuration Screen ........................................................................................69
Figure 56 –DCR100 Advanced Configuration Screen........................................................................69
Figure 57 –DCR100 Current Sensor Zero Offset Calibration Screen.................................................70
Figure 58 –DCR100 Current Sensor Zero Offset Calibration Completion Screen..............................70
Figure 59 –DCR100 NMEA2000 PGN Enable/Disable Screen..........................................................71
Figure 60 –DCR100 Channel Configuration Screen (DCR Mode).....................................................72
Figure 61 –DCR100 Channel Configuration Screen (ALM Mode)......................................................73
Figure 62 –DSM200 Remote Configuration Screen...........................................................................74
Figure 63 –DSM200 Remote Device Selection Screen .....................................................................74
Figure 64 –DSM150/DSM250 Remote Configuration Screen............................................................76
Figure 65 –DSM150/DSM250 Remote Device Selection Screen.......................................................77
Figure 66 –DSM150/DSM250 Copy alarms settings from local display.............................................78
Figure 67 –DSM150/DSM250 Copy device selection from local display............................................78
Figure 68 –DSM150/DSM250 Copy display settings from local display.............................................79
Figure 69 –DSM150/DSM250 Copy favorite settings from local display............................................79
Figure 70 –Favorite Settings Transfer Completion Screen ................................................................80
Figure 71 –DSM150/DSM250 Copy DST100 calibrations from local display.....................................80
Figure 72 –DSM150/DSM250 copy all settings from local display.....................................................81
Figure 73 –DSM150/DSM250 Label Configuration............................................................................81
Figure 74 –DSM150/DSM250 Remote Device Selection...................................................................82
Figure 75 –DST100 Configuration Screen.........................................................................................83
Figure 76 –DST100 Advanced Configuration Screen........................................................................83
Figure 77 –Calibrating the DSM250 for DST100 Speed through Water.............................................84
Figure 78 –Setting the Transducer Depth Offset in a DST100...........................................................85
Figure 79 –Resetting the DST100 Trip Distance Log.........................................................................86
Figure 80 –DST110 Configuration Screen.........................................................................................87
Figure 81 –DST110 Advanced Configuration Screen........................................................................87
Figure 82 - DST110 NMEA 2000®PGN Enable/Disable Screen ........................................................88
Figure 83 –Calibrating the DST110 Speed ........................................................................................89
Figure 84 - DST110 Water Temperature Calibration Screen..............................................................90
Figure 85 –Setting the Transducer Depth Offset in a DST110...........................................................91
Figure 86 –Resetting the DST110 Trip Distance Log.........................................................................91
Figure 87 –EMS100 Configuration Screen ........................................................................................92
Figure 88 –FFM100 Configuration Screen.........................................................................................97
Figure 89 –FFM100 Advanced Configuration ....................................................................................97
Figure 90 –FFM100 NMEA PGN Enable/Disable Screen..................................................................99
Figure 91 –FFM100 Channel #0 First Configuration Screen (Differential Mode) .............................100
Figure 92 –FFM100 Channel #0 Second Configuration Screen (Differential Mode)........................100
Figure 93 –FFM100 Channel #0 First Configuration Screen (Two Independent Sensors Mode).....102
Figure 94 –FFM100 Channel #0 Second Configuration Screen (Two Independent Sensors Mode)102
DSM250 User’s Manual
Page xii Revision 1.4.18
Figure 95 –FFM100 Channel #1 Configuration Screen (Differential Mode) .....................................105
Figure 96 –FFM100 Channel #1 First Configuration Screen (Two Independent Sensors Mode).....106
Figure 97 –FFM100 Channel #1 Second Configuration Screen (Two Independent Sensors Mode)106
Figure 98 –FPM100 Configuration Screen.......................................................................................108
Figure 99 –FPM100 Advanced Configuration Screen......................................................................109
Figure 100 –FPM100 NMEA 2000®PGN Enable/Disable Screen...................................................109
Figure 101 –FPM100 Channel #0 First Configuration Screen (Tank Mode) ....................................110
Figure 102 –FPM100 Channel #0 Second Configuration Screen (Tank Mode)...............................111
Figure 103 –FPM100 Tank Levels Calibration Menu.......................................................................112
Figure 104 –Performing Custom Calibration of the Tank Level Adapter..........................................112
Figure 105 –Tank Levels Calibration Capacity Estimation...............................................................113
Figure 106 –Empty Level Calibration...............................................................................................113
Figure 107 –Intermediate Level Calibration .....................................................................................114
Figure 108 –Full Level Calibration ...................................................................................................114
Figure 109 –Custom Tank Level Calibration Confirmation Screen ..................................................115
Figure 110 –Rectangular Tank Calibration ......................................................................................115
Figure 111 –GPS100 Configuration Screen.....................................................................................117
Figure 112 –GPS100 Advanced Configuration Screen....................................................................118
Figure 113 –Configuring Antenna Altitude on a GPS100.................................................................118
Figure 114 –Configuring Satellite Elevation Mask on a GPS100.....................................................119
Figure 115 –Configuring PDOP Mask on a GPS100 .......................................................................120
Figure 116 –Configuring SNR Mask on a GPS100..........................................................................120
Figure 117 –GPS100 NMEA 2000®PGN Enable/Disable Screen...................................................121
Figure 118 –Restoring Factory Defaults on the GPS100.................................................................122
Figure 119 –Performing a Cold Start of the GPS100.......................................................................122
Figure 120 –Configuring GPS Operating Mode on a GPS100.........................................................123
Figure 121 –Configuring SBAS on a GPS100..................................................................................124
Figure 122 –GPS200 Configuration Screen.....................................................................................125
Figure 123 –GPS200 Advanced Configuration Screen....................................................................125
Figure 124 –GPS200 NMEA 2000®PGN Enable/Disable Screen...................................................126
Figure 125 –Restoring Factory Defaults on the GPS200.................................................................127
Figure 126 –Performing a Cold Start of the GPS200.......................................................................127
Figure 127 –Configuring SBAS on a GPS200..................................................................................128
Figure 128 –IPG100 Configuration Screen......................................................................................129
Figure 129 –IPG100 Advanced Configuration Screen.....................................................................129
Figure 130 –IPG100 N2KServer Information Screen.......................................................................130
Figure 131 –IPG100 Client List Display ...........................................................................................131
Figure 129 –IPG100 Maretron Cloud Services Status Display.........................................................132
Figure 133 –J2K100 Configuration Screen......................................................................................134
Figure 133 –J2K100 Advanced Configuration Screen.....................................................................134
Figure 134 –J2K100 J1939 Diagnostic Messages Configuration.....................................................135
Figure 135 –J2K100 NMEA 2000®PGN Enable/Disable Screen.....................................................136
Figure 136 –J2K100 Engine Instance Configuration........................................................................137
Figure 137 –J2K100 NMEA2000 Transmission Instance Configuration ..........................................137
Figure 138 –J2K100 NMEA2000 AC/Icemaker Instance Configuration..........................................138
Figure 139 –J2K100 J1939 Source Address Configuration .............................................................139
Figure 140 –NBE100 Configuration Screen.....................................................................................139
Figure 141 –NBE100 Advanced Configuration Screen....................................................................140
Revision 1.4.18 Page xiii
Figure 142 –RAA100 Configuration Screen.....................................................................................141
Figure 143 –RAA100 Advanced Configuration Menu ......................................................................141
Figure 144 –RAA100 NMEA 2000®PGN Enable/Disable Screen ...................................................142
Figure 145 –RAA100 Label Configuration .......................................................................................143
Figure 146 –RAA100 Rudder Angle Calibration Options .................................................................143
Figure 147 –RAA100 Custom Rudder Angle Calibration.................................................................144
Figure 148 –RAA100 Starboard Rudder Angle Calibration..............................................................144
Figure 149 –RAA100 Center Rudder Angle Calibration...................................................................145
Figure 150 –RAA100 Port Rudder Angle Calibration.......................................................................145
Figure 151 –RAA100 Custom Rudder Calibration Confirmation Screen..........................................146
Figure 152 –RAA100: Setting the Rudder Number..........................................................................147
Figure 153 –RAA100: Setting the Operating Mode..........................................................................147
Figure 154 –RAA100: Setting the + to Sender Gauge Resistance ..................................................148
Figure 155 –RAA100: Setting the –to Sender Gauge Resistance...................................................149
Figure 156 –RIM100 Configuration Screen......................................................................................150
Figure 157 –RIM100 Advanced Configuration Screen.....................................................................150
Figure 158 –RIM100 NMEA 2000®PGN Enable/Disable Screen....................................................151
Figure 159 –RIM100 Channel Configuration Screen .......................................................................152
Figure 160 –SIM100 Configuration Screen......................................................................................153
Figure 161 –SIM100 Advanced Configuration Screen.....................................................................153
Figure 162 –SIM100 NMEA 2000®PGN Enable/Disable Screen ....................................................154
Figure 163 –SIM100 Channel Configuration Screen........................................................................155
Figure 162 - SMS100 Configuration Screen ....................................................................................156
Figure 163 - SMS100 Advanced Configuration Menu......................................................................156
Figure 164 –SMS100 NMEA 2000®PGN Enable/Disable Screen...................................................157
Figure 165 –SMS100 Test Screen...................................................................................................158
Figure 164 –SSC200 Configuration Screen.....................................................................................159
Figure 165 –SSC200 Advanced Configuration Screen....................................................................159
Figure 166 –SSC200 NMEA 0183 Settings Screen.........................................................................160
Figure 167 –SSC200 NMEA 0183 Sentence/Rate Selection Screen...............................................161
Figure 168 –SSC200 Load Default Periodic Rate Selection............................................................161
Figure 169 –SSC200 NMEA 2000®PGN Enable/Disable Screen ...................................................162
Figure 170 –SSC200 Installation Offset Calibration Screen ............................................................163
Figure 171 –Setting the Installation Orientation...............................................................................163
Figure 172 –SSC200 Magnetic Deviation Calibration Start Screen.................................................164
Figure 173 –SSC200 Magnetic Deviation Calibration Progress Screen ..........................................165
Figure 174 –SSC200 Magnetic Deviation Status Screen.................................................................165
Figure 175 –Programming SSC200 Rate of Turn Damping Period..................................................166
Figure 176 –SSC200 Rate of Turn Zero Offset Calibration Screen .................................................166
Figure 177 –Setting Variation Source to NMEA 0183 or NMEA 2000®(factory default)..................167
Figure 178 –Setting Variation Source to NMEA 0183 Only..............................................................167
Figure 179 –Setting Variation Source to NMEA 2000®Only............................................................168
Figure 180 –Entering Manual Variation............................................................................................168
Figure 181 –TLA100 Configuration Screen......................................................................................170
Figure 182 –TLA100 Advanced Configuration Screen.....................................................................170
Figure 183 –TLA100 NMEA 2000®PGN Enable/Disable Screen....................................................171
Figure 184 –Configuring the Tank Capacity.....................................................................................172
Figure 185 –Tank Capacity Change Confirmation Screen...............................................................172
DSM250 User’s Manual
Page xiv Revision 1.4.18
Figure 186 –Performing Custom Calibration of the Tank Level Adapter..........................................173
Figure 187 –Tank Levels Calibration Capacity Estimation...............................................................174
Figure 188 –Empty Level Calibration...............................................................................................174
Figure 189 –Intermediate Level Calibration .....................................................................................175
Figure 190 –Full Level Calibration ...................................................................................................175
Figure 191 –Custom Tank Level Calibration Confirmation Screen ..................................................176
Figure 192 –American Standard Sender Calibration........................................................................176
Figure 193 –European Standard Sender Calibration.......................................................................177
Figure 194 –Configuring the Tank Number......................................................................................177
Figure 195 –Configuring the Tank Type...........................................................................................178
Figure 196 –Configuring the Operating Mode..................................................................................179
Figure 197 –Configuring the + to Sender Gauge Resistance...........................................................179
Figure 198 –Configuring the - to Sender Gauge Resistance ...........................................................180
Figure 199 –TLM100 Configuration Screen.....................................................................................181
Figure 200 –TLM100 Advanced Configuration Screen....................................................................181
Figure 201 –TLM100 NMEA 2000®PGN Enable/Disable Screen....................................................182
Figure 202 –Configuring the Tank Capacity.....................................................................................183
Figure 203 –Tank Capacity Change Confirmation Screen...............................................................183
Figure 204 –Performing Custom Calibration of the Tank Level Monitor...........................................184
Figure 205 –Tank Levels Calibration Capacity Estimation...............................................................184
Figure 206 –Empty Level Calibration...............................................................................................185
Figure 207 –Intermediate Level Calibration .....................................................................................185
Figure 208 –Full Level Calibration ...................................................................................................186
Figure 209 –Custom Tank Level Calibration Confirmation Screen ..................................................186
Figure 210 –Rectangular Tank Selection.........................................................................................187
Figure 211 –Rectangular Tank Calibration ......................................................................................187
Figure 212 –TMP100 Configuration Screen.....................................................................................189
Figure 213 –TMP100 Advanced Configuration Screen....................................................................189
Figure 214 –TMP100 NMEA 2000®PGN Enable/Disable Screen...................................................190
Figure 215 –TMP100 Channel Configuration Screen ......................................................................191
Figure 216 –USB100 Configuration Screen.....................................................................................192
Figure 217 –USB100 Advanced Configuration Screen....................................................................192
Figure 218 –USB100 Device Selection Screen................................................................................193
Figure 219 –VDR100 Configuration Screen.....................................................................................194
Figure 220 –VDR100 Advanced Configuration Screen....................................................................194
Figure 221 –WSO100 Configuration Screen....................................................................................196
Figure 222 –WSO100 Advanced Configuration Screen...................................................................197
Figure 223 –WSO100 NMEA 2000®PGN Enable/Disable Screen..................................................198
Figure 224 –WSO100 Device Label Menu.......................................................................................199
Figure 225 –WSO100 Installation Offset Screen .............................................................................199
Figure 226 –WSO100 Configuration Aborted Due to Low Wind Speed...........................................200
Figure 227 –Installation Offset Success Confirmation Screen.........................................................200
Figure 228 –Installation Offset Abort Confirmation Screen..............................................................201
Figure 229 –Setting the Wind Data Damping Period .......................................................................201
Figure 230 –Setting the Barometric Pressure..................................................................................202
Figure 231 –Setting the Outside Humidity .......................................................................................202
Figure 232 –Setting the Outside Temperature.................................................................................203
Figure 233 –Anchor Watch Display Example...................................................................................204
Revision 1.4.18 Page xv
Figure 234 –Compass Rose Display (Course Up) Example ............................................................205
Figure 235 –Compass Rose (North Up) Display..............................................................................205
Figure 236 –Gauge Display Example ..............................................................................................206
Figure 237 –Rudder Angle Gauge Display Example........................................................................206
Figure 238 –GPS Status Display Example.......................................................................................207
Figure 239 –Numeric Display Example............................................................................................208
Figure 240 –Configuration of Rolling Road Display .........................................................................209
Figure 241 –Rolling Road Display....................................................................................................210
Figure 242 –Line Graph Display ......................................................................................................210
Figure 243 –Weather Display...........................................................................................................211
Figure 244 –Wind Rose Display.......................................................................................................212
Figure 245 –Moon Phase Display....................................................................................................212
Figure 246 –Trim Tab Display..........................................................................................................213
Figure 247 –Swing Meter Display....................................................................................................213
Figure 248 –Tank Gauge Display ....................................................................................................214
Figure 249 –Configuration of Switch/Breaker Display......................................................................214
Figure 250 –Selection of an Individual Switch/Breaker....................................................................215
Figure 251 –Configuration of an Individual Switch/Breaker .............................................................215
Figure 252 –Favorite Screen Showing Highlighted Switch/Breaker.................................................217
Figure 253 –Alert Display.................................................................................................................218
Figure 254 –Adding a New Alert......................................................................................................220
Figure 255 –Part of the Alert Edit Screen ........................................................................................221
Figure 256 –High Alert Parameters..................................................................................................223
Figure 257 –Trigger Configuration –High Alert................................................................................224
Figure 258 –Low Alert Parameters ..................................................................................................225
Figure 259 –Trigger Configuration –Low Alert ................................................................................226
Figure 260 –Trigger Configuration –Data Unavailable Alert............................................................227
Figure 261 –Trigger Configuration –On Alert..................................................................................228
Figure 262 –Trigger Configuration –Data Unavailable Alert............................................................229
Figure 263 –Trigger Configuration Editor –Tripped Alert ................................................................230
Figure 264 –Outside Alert Parameters.............................................................................................230
Figure 265 –Trigger Configuration –Outside Radius Alert ..............................................................231
Figure 266 –Trigger Configuration –Inside Radius Alert .................................................................232
Figure 267 –Trigger Configuration –GPS Quality Alert ...................................................................233
Figure 268 –Direction Alert Parameters...........................................................................................234
Figure 269 –Trigger Configuration –Direction Alert.........................................................................235
Figure 270 –Alert Editor –Time Alert...............................................................................................236
Figure 271 –Remote Annunciator Enable/Disable...........................................................................237
Figure 274 –SMS (Text) Settings... Screen......................................................................................238
Figure 275 –SMS (Text) Phone Number #x Screen.........................................................................238
Figure 272 –Deleting an Alert ..........................................................................................................240
Figure 273 –Deleting Alert List.........................................................................................................240
Figure 274 –Deleting an Alert: Confirmation....................................................................................241
Figure 275 –Editing an Alert.............................................................................................................241
Figure 276 –Editing an Alert: Alert List.............................................................................................242
Figure 277 –Setting the Vessel Operating Mode .............................................................................243
Figure 282 –Editing the SMS (Text) Phone Book ............................................................................243
Figure 283 –SMS (Text) Phone Book Screen..................................................................................244
DSM250 User’s Manual
Page xvi Revision 1.4.18
Figure 284 –Phone Number Editing.................................................................................................244
Figure 285 –Editing the Name of a Phone Book Entry.....................................................................245
Figure 286 –SMS Phone Book Test Message Popup......................................................................245
Figure 278 –Advanced Configuration...............................................................................................246
Figure 279 –Restore Factory Defaults Confirmation........................................................................247
Figure 280 –Surface Mounting Template.........................................................................................256
Figure 281 –Flush Mounting Template ............................................................................................257
Revision 1.4.18 Page 1
1 General
1.1 Introduction
Congratulations on your purchase of the Maretron DSM250 NMEA 2000®Multi-function Color
Graphic Display. Maretron has designed and built your display to the highest standards for years of
dependable and accurate service.
Maretron‟s DSM250 is a high-resolution color display that allows easy interpretation of NMEA 2000®
instrument and navigation data through custom display configurations, with an easy-to-use five-key
illuminated keypad.
The Maretron DSM250 is designed to operate within the harsh demands of the marine environment.
However, no piece of marine electronic equipment can function properly unless installed, configured,
and maintained in the correct manner. Please read carefully and follow these instructions for
installation, configuration, and usage of the Maretron DSM250 in order to ensure optimal
performance.
1.2 Firmware Revision
This manual corresponds to DSM250 firmware revision 1.4.18.
1.3 DSM250 Features
The Maretron DSM250 has the following features.
NMEA 2000®Interface
Waterproof NMEA 2000®Connector
Sealed Waterproof Enclosure
Powered Directly from NMEA 2000®Port
Surface, Flush, or Gimbal Mounting
Adjustable Multi-colored Backlighting of Screen and Keys Preserves Night Vision
Visual and Audible Alarms
16 User Configurable Favorite Screens (Automatic or Manual Scrolling between Screens)
Capable of Viewing Virtually all NMEA 2000®Information including Batteries, Engines,
Generators, Shore Power, Tanks, Navigation, Weather and More
1.4 Quick Install
Installing the Maretron DSM250 display involves the following four steps. Please refer to the
individual sections for additional details.
Unpack the Box (Section 2.1)
Choose a Mounting Location (Section 2.2)
Mount the DSM250 (Section 2.3)
Connect the DSM250 (Section 2.4)
DSM250 User’s Manual
Page 2 Revision 1.4.18
2 Installation
2.1 Unpacking the Box
When unpacking the box containing the Maretron DSM250, you should find the following items:
1 –DSM250 NMEA 2000®Multi-function Graphic Display
4 –Mounting studs
4 –Mounting washers
4 –Mounting lock washers
4 –Mounting knurled nuts
1 –DSM250 User‟s Manual
1 –Warranty Registration Card
If any of these items are missing or damaged, please contact Maretron.
2.2 Choosing a Mounting Location
The DSM250 is housed in a waterproof enclosure (IEC IP67 rating –protected against the effects of
temporary immersion in water) and can be mounted in either an outdoor location or an indoor
location.
2.3 Mounting the DSM250
The DSM250 has three mounting options, which includes surface mounting, flush mounting, or an
optional gimbal mounting. Maretron suggests a location at which the display can be viewed from a
relatively straight angle, and at which the keys are easily pressed.
2.3.1 Surface Mounting the DSM250
The DSM250 can be directly mounted to any suitable surface as shown in Figure 1. The steps for this
type of mounting are as follows:
1. Attach the Surface Mount Template (see Section 0) to the surface where the DSM250 is to be
located.
a. Make sure the template is level by using one of the horizontal lines as a guide.
b. Scotch tape works well for securing the template.
c. The maximum thickness of the mounting material should not exceed 1¼” using the
provided mounting studs, thicker surfaces can be accommodated but you will need to
purchase longer studs.
2. Drill the four mounting holes all the way through the mounting surface at the locations
indicated on the Surface Mount Template.
a. Use a 3/16” drill bit.
3. Drill or cut a single hole for the electrical connector.
a. Use a 2¼” hole saw.
b. You will probably want this hole to be large enough for your fingers so that you can
connect or disconnect the cable without removing the DSM250.
4. Remove the template from the mounting surface.
5. Insert the 2” studs into the back of the DSM250.
Revision 1.4.18 Page 3
a. Make sure the studs are fully inserted into the back of the DSM250 but don‟t over tighten
the studs.
b. Do not use threadlocking compounds containing methacrylate ester, such as Loctite Red
(271), as they will cause stress cracking of the plastic enclosure.
6. Insert the studs protruding from the back of the DSM250 through the mounting holes and
secure with the provided hardware.
a. Place the flat washer on the stud first followed by the lock washer followed by the knurled
nut.
b. Hand-tighten the knurled nut.
Figure 1 –Surface Mounting the DSM250
2.3.2 Flush Mounting the DSM250
NOTE: When flush mounting the DSM250, ensure that the vent port (a small hole near the
NMEA 2000 cable connector is not covered or blocked. Blocking the vent port will
compromise the integrity of the seals on the unit and will void the unit’s warranty.
The DSM250 can be flush mounted to any suitable surface as shown in Figure 2. The steps for this
type of mounting are as follows:
1. Attach the Flush Mount Template (see Section 0) to the surface where the DSM250 is to be
located.
a. Make sure the template is level by using one of the horizontal lines as a guide.
b. Scotch tape works well for securing the template.
c. The maximum thickness of the mounting material should not exceed 1¼” using the
provided mounting studs, thicker surfaces can be accommodated but you will need to
purchase longer studs.
2. Cut out an opening as indicated on the Flush Mount Template.
a. Sorry, we should have made the flange larger, but be very careful not to go outside the
indicated cutout area. Be on the safe side and cut the hole a little small and rasp or file to
fit.
DSM250 User’s Manual
Page 4 Revision 1.4.18
3. Remove the template from the mounting surface.
4. Insert the 2” studs into the back of the DSM250.
a. Make sure the studs are fully inserted into the back of the DSM250 but don‟t over tighten
the studs.
b. Do not use threadlocking compounds containing methacrylate ester, such as Loctite Red
(271), as they will cause stress cracking of the plastic enclosure.
5. Remove the back of the case from the DSM250.
a. Place your thumbs on top of the studs and your finger along the side of the case and
squeeze the back cover off the DSM250.
6. Insert the back of the DSM250 through the front side of the cutout.
7. Place the back cover on the opposite side of the mounting surface with the mounting holes
aligned with the mounting studs and secure with the supplied hardware.
a. Place the flat washer on the stud first followed by the lock washer followed by the knurled
nut.
b. Hand tighten the knurled nut.
Figure 2 –Flush Mounting the DSM250
2.3.3 Gimbal Mounting the DSM250
The DSM250 can be gimbal mounted to any horizontal surface such a counter or ceiling as shown in
Figure 3. The optional gimbal mounting assembly (part number DSMMNTASSBLY) includes a
bracket and screws for attaching the bracket to the DSM250, a stand, and 2 knobs for fastening the
DSM250/bracket to the stand.
Other manuals for NMEA 2000
1
This manual suits for next models
1
Table of contents
Other Maretron Monitor manuals
Maretron
Maretron DSM800 User manual
Maretron
Maretron DSM250 User manual
Maretron
Maretron DCM100 User manual
Maretron
Maretron DCM100-01 User manual
Maretron
Maretron DSM150 User manual
Maretron
Maretron TSM800C Technical manual
Maretron
Maretron DSM250 User manual
Maretron
Maretron TLM100 User manual
Maretron
Maretron DSM410 User manual
Maretron
Maretron FPM100 User manual
