Marey POWER TAK User manual

02
WARNING
PACK CONTENTS
TECHNICAL SPECIFICATIONS
ELECTRICAL REQUIREMENTS
WIRING DIAGRAM
INSTALLATION OPTIONS
INTERNAL COMPONENTS
SAFETY
SITE REQUIREMENTS
CONNECTING TO SERVICES
HOW TO USE - HOW IT WORKS
TEMPERATURE CONTROL
ENERGY SAVING TIPS
FAULT FINDING (Troubleshooting)
SPECIAL EQUIPMENT AND ADVICE TO USERS
TEMPERATURE INCREASE CHART PER GPM
SPARE PARTS
CUSTOMER SERVICE
OTHER PRODUCTS
05
05
05
05
07
07
08
08
09
09
11
12
12
13
14
14
15
16
17
03
Congratulations!
You've just purchased a new Power Pak Plus tankless water heater and will
soonbegintoenjoythebenefitsof“goingtankless.”
Please take the time to thoroughly read and understand this safety and
installation manual in its entirety before you attempt to install your new
tanklesswaterheater,asitcontainsimportantsafetytipsandinstructions.
Please carefully read all instructions and warnings. Should you have any
questions,pleasevisitwww.marey.comforinstallationvideosandFAQ.
Pleasekeepthismanualforfuturereferenceandtechnicalinformation.
QUICK START GUIDE 04

Ifyourwaterheaterrequiresareset,besuretoTURNOFFTHEBREAKERSpriortoresetting
theunit.
Resetting your unit without turning off the breakers can result in personal injury and damage
toyourwaterheater.
WARNING!Thereiswatercontainedinthecoilsofyourwaterheateratalltimes.Ifyourwater
heater is exposed to freezing temperatures, the water in the coils could freeze, causing a
breakin theheatexchangeroftheunit,orthesupplyandreturnlines.Thiskindofdamagewill
result in water running freely into the space where the water heater is located, which can
causeflooding. DONOTinstallthis water heaterwhereitmaybesubjectedtoa freeze.Ifyour
water heater is in an area where freezing is a possibility, you must turn off the water to the
heater and drain it of any water by disconnecting the water lines. Leave the water lines
disconnecteduntilyouintendtousethewaterheater.
-Heater
-HangingBracketwithScrews
The heater must be connected to its own independent electrical circuit. Install a
fuseboxorswitch(“breaker")forexclusiveuseoftheheater.
PP110 PPXE5ITEM CODE
Voltage
Power
Inlet Pipe Measures
Outlet Pipe Measures
Amps.
Cycle
Water Pressure
Wires
Max. Gallons per Minute
Master Place Cover
Width x Height x Depth
Standard and Approvals
½" NPT
½" NPT
10-40A
50-60Hz
0.55 Bar (8 PSI) - 6.37 Bar (92.365 PSI)
8 AWG
2 GPM 3 GPM
ABS Heating Elements Copper
11.1" x 10.2" x 4.8"
ISO 9001
110V
1.1kW - 4.4kW 220V 2.2kW - 8.8kW
04 05

Thewiregaugenecessarywillvarybasedonamperageanddistancetothebreaker,
but 8 gauge wire is generally sufficient for most installations. If the distance is very
short,sometimessmallergaugewiremaybeused.Ifyouaren'tsurewhichgaugeof
wire should be used, contact an electrician. The supply wire, main switch and
circuit protection (Leakage Circuit Breaker) must be sufficient for the
amperage required. Please check the table above and the flow rate/temperature
rise chart for the appropriate amperage for your situation. Note that the lower the
amperage,thelowerthewatertemperaturerisewillbe.
DO NOT TURN ON THE BREAKER SWITCH UNTIL ALL ELECTRICAL AND
PLUMBING CONNECTIONS ARE MADE AND WATER IS FLOWING THROUGH
THEUNIT.
Connect(1)whitewiretothesinglepole10,20,30or40Ampcircuitbreaker.
Connect (1) white wire to the neutral bar on your breaker box. It does not matter
which white wire connects to neutral and which connects to the breaker. Connect
thegreengroundwiretothegroundbaronyourbreakerbox.
Connectthe(2)whitewirestothedoublepole10,20,30or40Ampcircuitbreaker.
Connectthegreengroundwiretothegroundbaronyourbreakerbox.
This appliance MUST be grounded. Connect the ground wire, as indicated in the
ElectricalCode.
When all connections are satisfactorily prepared, install the heater cover. With the
insulated container off and water flow modifier (optional) fully open, the faucet must
be opened fully to get maximum water flow . It is necessary to ensure that the water
tank is full before turning the power on. This is an essential step to protect the
heatingelement.
Note that the above instructions are simply guidelines that apply to most
installations.
The size of the switch and wire gauge must meet all local, state, provincial and
nationalelectricalcodesinyourarea.Contactanelectricianifyou'renotsure.
Todeterminetheminimumelectricalcircuitpleaseseethenexttable:
For PP110:
For PP220 (PPXE5):
Remember that the above instructions are just guidelines that apply at most
installations.
Remember that you should remove the red and blue covers before installing your
unit.
Swing Check Valve
Main Water Supply Valve
Green Ground Wire.
Connect to ground bar on breaker box.
POWER PAK - PLUS Amperage Control Knob
PP110: Connect (1) white wire to
breaker and (1) white wire to neutral.
PP220: Connect both white wires to
breaker.
ONE POINT OF USE TWO OR MORE POINTS OF USE
Power Selector Minimum Breaker
Position 1 and 2
Position 1, 2 and 3
Position 1, 2, 3 and 4
20 Amperes
30 Amperes
40 Amperes
06 07

08 09
Workingwithelectricityrequiresproperskillsandknowledge–Installationoftheunit
shouldbeperformedbysomeonewhoisfamiliarortrainedinthistrade.WeHIGHLY
recommend that you hire the services of a licensed and qualified
“Electrician/Plumber”familiarwithtanklesswaterheatersinstallation.
IMPROPERINSTALLATIONCANCAUSEINJURYOREVENDEATH.
IMPORTANT: All electrical work and unit fixing to the wall should be completed
beforeconnectingelectricalwiring.
Whenyouturnontheunit,extremelyhotwatercouldcomeout.Takepropersafety
precautionstoavoidbeinghurtorburnedbywater.
DO NOT expose the unit to freezing temperatures. Do not use an input water
temperature over 90 degrees F or 32.2 degrees Celsius. This unit is designed for
indooruseonly.
DONOTrestricttheflowofwaterenteringtheunit.
DONOToperatetheapplianceifwaterceasestoflowduringuse,iftheoutercaseor
coverislooseoriftheunitisnotworkingproperly.
Iftheunitleaksordoesnotheatproperly,disconnecttheunit.
ISOLATE the electrical and water supplies before removing the cover and before
proceedingwithinstallationorservicing.
NEVEROPERATETHISHEATERWITHOUTTHECOVER!
WATERANDPLUMBINGREQUIREMENTS
DO NOT USE PVC, CPVC or plastic supply lines directly to the unit.A16” copper or
stainlesssteelpipe must be connected to theheater and then adapted toa different
materialsuchas(CPVC,PVCorPEXPLASTIC).
Be sure to clean the pipes before connecting the heater to the main line. Clean all
the impurities of the pipe, allowing water to flow for a few minutes, check for leaks.
Anyresidueordirtinthepipesmaycauseinternaldamagetotheunit.
Connect the isolation valve at the entry inlet pipe of the heater and make sure you
installa rubber washer.Donotapplyexcessiveforcetotightenconnectors.Asafety
releasevalvemustbefittedinthesupplypipe.
We recommend installing a sediment filter before the entry of water to the heater.
Hardwater or water withhighlevelsof minerals and alkalicancausedamage to this
unit. When this is the case, we recommend the use of a (non-salt) water softening
system.
Theprovision ofaservice stop valveinthe cold supplypipewill assist intheevent of
anysubsequentservicingormaintenance.
These heaters are of the closed type (closed system with no ventilation pressure)
suitable for fitting to the normal input of cold water with a maximum of 94 PSI (6.5
bar).Theymustbefittedwithapressurevalveadjacenttotheentrance.
PREPARATION
1.IsolateelectricalandwatersuppliesBEFOREproceedingwiththeinstallation.

10 11
ON
OFF
ON
OFF
VERTICAL POSITION
PIPES FACING
DOWN
2. Theunit must be mounted on a flat surface in a vertical position with the incoming
and outgoing water pipes facing down. It is not possible to install the unit
horizontally. Please use the installation sticker guide and screws supplied in the
product'soriginalpackage. Drillthewallfortheindicatedholes.Checkthatthereare
nohiddenwiresorpipes,beforedrillingholesforwallmounting.
3.Securethebrackettothewallwiththescrewssupplied.
4. Hook the unit and screw the fixing holes, placing special attention to the bottom
screw.
CABLEENTRY
5. Thereare two cable entrypoints. Youcan choose one ofthem and theback plate
willhavetobecutout.
6.ThisapplianceMUSTbegrounded.
ON
OFF
ON
OFF
WATER INLET
RIGHT SIDE
WATER OUTLET
LEFT SIDE
OUTLET INLET
PLUMBING
7. Use stainless steel flexible hose or copper tubing of ½" on the inlet and outlet
pipes(rightsidewaterinlet,hotwateroutlet,left).
8. Turn on the mains water supply to the water heater and then plug the unit at the
isolatedelectricaloutlet.
NOTE: Theelectrical supply is not turned on untilall the pipes andthe installation is
complete.
THEWATERHEATERWILLTURNON,WHENYOU:
1.Turnonawaterfaucet.
2.Thepowerindicatorwilllight.
TOSTOPTHEWATERHEATER:
Turnoffthefaucet.
TOUSETHEPOWERSELECTOR:
Thepowerselectorknobhasfivepositions:

The water temperature is altered by increasing or decreasing the flow rate of the
water through the water heater, via the temperature control knob. Increased
amperagesettingswillresultinincreasedwatertemperature.
NOTE: If water pressure is low, the inlet pipe of the water should be ¾ "with outputs
of5/8".
The heater should be installed as close as possible to the point of use to avoid heat
loss.Iflongerdistancesarerequired,hotwaterpipesshouldbeinsulated.
Adjust heater temperature settings (located on the front panel of the heater) to the
desired output temperature. Lowering the power setting will save energy, but hot
watertemperaturewilldecrease.
12 13
Power
Selector Water
Temperature
Off
I (10A)
II (20A)
III (30A)
IIII (40A)
Cold
Temperate
Hot
Hotter
Max. Hot Water
Temperature
Small Drop:
Lower water outflow.
Warmer water.
Big Drop:
Higher water outflow.
Less hot water.
We recommend that you install the unit under the sink in the main bathrooms or
utility areas. This will allow for lower amperage usage and a reduced heat loss from
longpiperuns.
For additional savings, reduce the water flow valve at the inlet of the heater so the
temperatureincreases.
YourMareyPowerPak Plusshouldgive you troublefreeoperation, howevershould
a problem or fault occur, the table below will assist in identifying the most common
faults. Diagnosis and fault finding should be carried out by a qualified individual,
skilledinelectrical/plumbing.
Power not connected
No heating occurs
Insufficient Amperage at Breaker Too much water flow Too little water flow Heating Dial Not High Enough Incorrect Wiring Overheat Sensor Engaging
Water is not warm
enough
Water starts out
hot but then unit
shuts off
Breaker is tripping
Double check for correct
wiring and that all
connections are secure.
Ensure that there is
sufficient water flow to
engage unit (9 PSI)
Increase size of breaker
to 40 Amps if smaller
breaker is in use. Turn
heating dial to full.
Reduce amount of water
flowing through the unit.
Oveheat sensor is
shutting the unit off.
Increase water flow or
decrease heat setting.
Double check for correct
wiring and that all
connections are secure.
Ensure that heating dial
is no higher than breaker
size.

14 15
1 2 3 4PP110
GPM*
0.75
1.0
1.25
1.5
2.0
11º
8º
6º
5º
3º
25º
18º
14º
12º
7º
36º
30º
23º
20º
11º
38º
32º
30º
26º
16º
TEMP. INCREASE PER GPM
*GPM = Gallons per Minute
1 2 3 4
GPM*
1.0
1.5
2.0
2.5
3.0
25º
17º
12º
10º
46º
32º
21º
17º
66º
48º
31º
25º
20º
-
58º
41º
33º
26º
13º6º
TEMP. INCREASE PER GPM
The pressure relief device is designed into the water heater. The device will work
automatically, when excessive build up of pressure occurs. Do not replace the
pressurereliefdevicewithanyotherscrew.
Theunitisbuiltoffireproofmaterial.
There is a safety thermal cut-out device in the water heater. This thermostat will cut
off electricity to prevent scalding, when there is a sudden rise in water temperature,
thisprotectingtheuser.
AllmodelscanbefittedwithLeakageCircuitBreaker.(optional)
Itis important tokeepthe showerhead cleaninorderto maintain theperformanceof
thewaterheater.
*Temperature increases listed are based on use of the water heater under optimal
conditions with an incoming water temperature of 48ºF. Variable factors such as
incorrect or imperfect installation or warmer incoming water temperature may yield
differentresults.
ThefollowingcomprehensivelistofsparepartsisavailableforyourPowerPakPlus.
DO NOT REPLACE WITH PARTS NOT RECOMMENDED BY MAREY, AS THIS
WILLINVALIDATE YOUR WARRANTY AND MAYRENDER THE INSTALLATION
DANGEROUS.
Description:
-Thermostat
-SafestyValve
-HeatingElementContainer
-Microswitch
-WaterValve
*Reference in
page 8

16 17
1-855-MAREY-55
[e-mail]
Delbrey Street, 211
San Juan, Puerto Rico
00912
Tel: [phone]
Toll Free: 1-855-627-3955
1-855-MAREY-55
www.marey.com
At Marey, we pride ourselves on the excellence of our customer service and support
team.
Pleasefeel freetocontact usifyou haveanyquestions about ourproducts,warranty
service, or if you need assistance installing a unit. We also strive for continuous
improvement,sowewelcomeyourcomments,feedbackandsuggestions.
Marey proudly manufactures water heaters and accessories for use in almost
any application. Please visit our website to learn more about other Marey
products.
AQUAMATIC ECO180 SANTON
POWERPAK PORTABLE POWER GAS
