Marimba One One Vibe Quick start guide

[email protected]
www.marimbaone.com
tel [phone]
fax [phone]
OWNER’S MANUAL

021717 - REV. A PAGE 1 0F 9
Bass
Treble
Harp
Accidental Resonators
Natural Bars
Accidental Bars
Natural Resonators
Center Support
FOR ASSEMBLY,
YOU WILL NEED:
1
KEEP These instructions for future reference
ASSEMBLY INSTRUCTIONS & OWNER'S MANUAL
CAREFULLY UNPACK YOUR CRATE
Compare the seven components as shown on this page.
• A large open space with carpet (or a blanket to cover the oor)
•An assistant to help you assemble the One Vibe™
Pedal
TM
TM

2
3
CENTER SUPPORT
4
5
021717 - REV. A PAGE 2 0F 9
Treble
Bass
Bass
Bass
Treble
UNFOLD LEGS
IDENTIFY BASS END OF CENTER SUPPORT
UNFOLD ARMS
Position yourself with the bass end on
your left and treble end on your right,
with legs facing you.
Align bass end of center support with bass end of harp.
Pull legs toward you.
Insert center support through legs of both headboards.
Unfold arms by
swinging them over
to the opposite side.
POSITION CENTER SUPPORT

6 7 8
12 13
PEDAL
9
Treble
021717 - REV. A PAGE 3 0F 9
ATTACH BASS END TIGHTEN KNOB REPEAT FOR TREBLE END
Slide notch onto bolt.
REMOVE PARTS INSERT PEDAL BOLT
Slide bolt through center hole on center support.
Remove knob, threaded
wheel, metal washer, and
one black plastic washer.
TIGHTEN
KNOB
REPEAT FOR
OTHER ARM
ATTACH ARMS
Rotate arm and slide notch onto bolt. 10 11
Retain

14
16 17
19
15
18
RESONATORS
021717 - REV. A PAGE 4 0F 9
SECURE PEDAL TIGHTEN KNOBS
ATTACH STRAP PLACE HARP IN
UPRIGHT POSITION
INSERT RESONATORS
Place black plastic washer, metal washer, threaded
wheel, and knob onto bolt in the following order:
POSITION TREBLE END
First, position treble end of resonators onto
treble end headboard.
Treble
Bass
Insert resonators into the
treble headboard.
Adjust tension using both wheel
and threaded knob.
Treble

20 21
22
24
021717 - REV. A PAGE 5 0F 9
Treble
LIFT BASS END
CHECK FIT
INSERT RESONATORS
Lift bass end of resonators above top
edge of bass headboard.
MAGNETIC DRIVE SYSTEM
Once the resonators are placed
into the frame, the resonator fans
are ready to rotate.
The new Magnetic Drive System
eliminates the need for hooking up
belts and cables.
Insert resonators into slots
on bass headboard.
23 REPEAT FOR OTHER RESONATORS
Push down on the resonators on the treble
end to make sure they are fully in place.
Bass
Bass
Bass
ADJUST DAMPER BAR HEIGHT
To raise and lower the height of the
damper bar at the bass end of the
One Vibe, turn the adjustment screw.
DAMPER BAR
Bass
DO NOT TOUCH
THE BELT
Lowering the damper bar at the bass end
will result in the bass end of the One Vibe
having more sustain.
Raising the damper bar will result in the
bass end having less sustain.

Treble
25 26 TURN TENSION KNOB
Turn spring tension knob counterclockwise
to lower the damper bar.
27 28
021717 - REV. A PAGE 6 0F 9
PUSH PEDAL DOWN
BEFORE installing keyboards, damper
bar must be lowered completely as
shown in the next 2 steps.
Push and hold pedal down.
KEYBOARDS
Treble
POSITION NATURAL KEYBOARD SECURE TREBLE END
Holding cords, lift keyboard, and place
onto harp.
Slide cord around hooks on treble end.
Treble
Treble

29
30
31
021717 - REV. A PAGE 7 0F 9
POSITION BARS ON RAILS
Move each bar into its correct
position, making sure that the cord
rests in the Jacks between each
bar.
Wrap the bar cord around the
Corner jacks at the treble end.
SECURE BARS TO RAIL
Once all the bars are in place, from the bass
end pull the cord taut (pulling evenly on each
end of the cord at the same time). Hook the
springs together and then loop the cord around
the corner jacks.
bass end close-up
FOLLOW SAME PROCEDURE FOR ACCIDENTAL BARS
The bars go over every resonator that is plugged.
When you look from the top you can see the oor through
the resonators without bars over them.
treble end close-up
corner jacks
rail jacks
tuning arch
treble end close-up

BAR CORD TENSION
32
33
34
021717 - REV. A PAGE 8 0F 9
Over time, as you play your instrument, the cord that suspends the
bars may loosen and need to be adjusted. To increase tension in the
bar cord, use the cleats behind the springs to hold the slack in the cord.
cleat cleat
hooks
spring
(bar cord)
UNHOOK SPRINGS
spring
Slip the loop down around the cleat.
Pull the cord taught.
FORM LOOP IN CORD
SLIP LOOP OVER CLEAT
At cleat, pull cord to make
enough slack to form a loop.

3736
38
Speed
Run
Stop
Speed
On
Off
021717 - REV. A PAGE 9 0F 9
Speed
Run
Stop
On
Off
Speed
Run
Stop
On
Off
Speed
Run
Stop
On
Off
Speed
Run
Stop
On
Off
TO START FANS TURNING
TO CHANGE FAN ROTATION SPEED
TO STOP FANS TURNING
Push green button to ON position
and red button to RUN position.
Move slider switch left or right.
DO NOT move green button to the
OFF position. Doing so will result in
fans stopping at random positions.
Green button REMAINS ON.
Push red button to STOP position.
The One Vibe fans always stop in
the 12 o’clock/vertical position.
GREEN Button:
MOTOR on/off
FAST SLOW
SLIDER Switch:
FAN rotation speed
RED Button:
FAN run/stop
USING THE MOTOR CONTROL BOX

WARRANTY
YOU ARE THE OWNER OF ONE OF THE FINEST VIBRAPHONES IN THE WORLD. THE
FOLLOWING WARRANTY PROTECTS YOUR INVESTMENT. PLEASE READ IT CAREFULLY.
marim ba one ®
Manufacturer of World-Class Marimbas and Vibraphones
marimba one ®WARRANTS ON LY TO THE ORIGINAL PURCHASER
THAT THIS INSTRUMENT IS FREE FROM DEFECTS IN MATERIALS
AND/OR WORKMANSHIP AS FOLLOWS:
1. During a period of twelve (12) months from the date of receiving your instrument, marimba one® will
pay all labor and materials necessary to repair any defective instrument or part thereof. We will repair a
defective instrument or part at the location of our factory. The purchaser must pay all shipping charges
to and from our factory in advance.
2. During a period of twelve (12) months from the date of receiving your instrument, marimba one® will
replace at no charge any bar that fails to perform according to acceptable musical standards. marimba
one® will replace any defective bar upon request by the purchaser. The purchaser must return the
defective bar to the location of our factory upon receipt of the replacement bar. The purchaser must
pay all shipping charges to and from our factory in advance.
3. Natural variation occurring in materials which do not affect the musical performance of the instrument
shall not be considered defects, marimba one® reserves the right to inspect any instrument claimed to
be defective to determine if the cause is a manufacturing defect. Excluded from this warranty are all
defects other than manufacturing defects. Specifically excluded are defects occurring as a result of use
other than normal use, any unauthorized alteration or repair of the instrument, defects occurring in the
course of shipping, and other similar defects not related to the manufacture of the instrument.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE PURCHASER, marimba one® SHALL NOT BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
IS LIMITED IN DURATION AND SCOPE TO THE DURATION AND SCOPE OF THIS
WARRANTY. THIS WARRANTY IS NONTRANSFERABLE AND VALID ONLY TO THE
ORIGINAL PURCHASER.
marimba one ® Incorporated
Telephone: [phone] / Fax: [phone]
FACTORY LOCATION MAILING ADDRESS
901 O Street, Arcata, CA 95521 - U.S.A. Post Office Box 786, Arcata, CA 95518 - U.S.A.
INSTRUMENT SERIAL NO.:
Rev.B
