AK1A User Manual
17.12.2018 KFM
The AK1A (vehicle key) is a component of a driving authorisation system of a car which further
comprises of the body controller module BCMevo.
The components exchange encrypted data for car access, to start the engine and to locate the key. The
AK1A contains three buttons for car access. By pressing the dedicated button the AK1A sends over RF
authorization data to the control unit to open the doors. The 2nd button releases data to lock the doors. A
third button is dedicated to open the trunk deck. An additional “PANIC” button is implemented optional
for the US market. If the PANIC button is pushed twice or held down for two seconds, the car alarm will
start and can be stopped by pressing this button again.
Moreover car access is also released after touching the door handles. The key is waken by the magnetic
field of the LF antennas, driven by the BCMevo. The AK1A sends over RF encrypted data in return for
authentication.
In case the battery is low car access is possible by means of an integrated mechanic emergency key.
The AK1A is then to be placed into a dedicated slot inside the centre console to be powered wireless by
means of a magnetic field.
Open Button
- To unlock the vehicles doors when the button is pressed
short.
- In case the button is pressed long, the windows will open
additionally.
Close Button
- Locks the vehicles doors when the button is pressed short.
- When the button is pressed, long the windows will close
additionally.
Trunk Button
- To unlock and open the vehicles trunk lid, push the button
twice.
Open
Close
Trunk

Radio equipment authorization to FCC in USA for AK1A
NOTICE:
The enclosed hardware device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference that may cause
undesired operation.
Changes or modifications made to this equipment not expressly approved by (manufacturer name)
may void the FCC authorization to operate this equipment.
Radio equipment authorization to RSS-210 in Canada for AK1A
NOTICE:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) L’appareil ne doit pas produire de brouillage;
(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
