marsden PT-700 User manual

Marsden PT-700 User Manual
Please take time to read these instructions before starting to use the scale.

Page 2 of 14
Contents
Product Specification ..............................................................................................................................3
Safety Instructions...................................................................................................................................3
Cleaning ..................................................................................................................................................3
Maintenance............................................................................................................................................3
Before Using the Scale ...........................................................................................................................3
Explanation of Graphic Symbols .............................................................................................................4
Dimensions..............................................................................................................................................5
Function keys ..........................................................................................................................................6
Operation - Switching on the scale .........................................................................................................7
Operation - Using Hold............................................................................................................................7
Operation - Using Tare ............................................................................................................................7
Operation - Switching between kg and lb................................................................................................7
Operation - Using Zero............................................................................................................................7
Operation - Using Accumulation..............................................................................................................7
Operation NB (PT-700 only): ...................................................................................................................8
Charging the scale...................................................................................................................................8
Using The Printer ....................................................................................................................................9
Replacing the printer’s tally roll................................................................................................................9
Error messages .....................................................................................................................................10

Page 3 of 14
Product Specification
Model Number
MarsdenPT-700
Capacity/Division
2000kg x 500g
Inner Resolution
1 million
Weight of Scale
Approximately 125kg
Dimensions
Length–1470mm Width –545mm Width betweenforks –220mm Fork to ground
78mm
Indicator
HL318L with 6-digit 32cm LED display and seven function keys
Protection Level
IP5X
Battery
6V4Ah
Adaptor
Voltage–100-240VAC Current –0.1A
Operating Temperature
-10˚C - 40˚C
Print Output
Weight, count, net weight, gross weight, tare weight, accumulation
Please note: Marsden’s policy is one of continuous development and therefore we reserve the right to change product
specification without notice.
Safety Instructions
Before using the scale, please read with care the information given in this user manual, which contains important instructions
for proper installation, use and maintenance.
Marsden/the manufacturer shall not be liable for damages arising from failure to heed the following instructions:
•When using electrical components under increased safety requirements, always comply with appropriate regulations.
•Inappropriate installation/use will render the warranty null and void.
•Ensure the voltage marked on the power supply unit matches your mains supply.
•This product is not waterproof. While it can be used outside, we do not recommend using the scale in humid, damp
or wet environments.
•Observe the permissible ambient temperatures for use.
•The device meets the requirements for electromagnetic capability. Do not exceed the maximum values specified in
the applicable standards.
If you have any problems, contact Marsden/your local dealer/your service partner.
Cleaning
•Please do not use corrosive liquids or large amounts of water to clean the scale.
•Always disconnect the scale from the mains power supply before cleaning.
Maintenance
•The scale does not require routine maintenance. However, we recommend checking accuracy regularly. If
inaccuracies occur, please contact your service partner.
•If you’re in the UK, you can book an accuracy check with the Marsden Service team. Email
[e-mail] for more information.
Before Using the Scale
•The scale’s indicator, the I-400-APP, must be connected to the mains for operation.
•Ensure the indicator and scale are connected via the cables provided prior to use.
•Once switched on, the scale is only ready to use once the display shows 0.000.
•This scale is fitted with adjustable levelling feet. Please adjust these accordingly to ensure the scale is level. An unlevel
surface could result in inaccurate readings.

Page 4 of 14
Explanation of Graphic Symbols
Caution, consult
accompanying
documents before use
Separate collection for
waste of electrical and
electronic equipment,
in accordance with
Directive 2002/96/EC
Manufacturer of medical
device
Manufacturing year of
medical device
Carefully read user
manual before
installation and usage,
and follow instructions
for use.
Medical electrical
equipment with Type B
applied part
Device catalogue
number
Authorized
representative in the
European Community
Manufacturer's batch or
lot number
Device is a medical
device
Serial number
Unique Device
Identifier
Device conforms to 93/42/EEC as amended by 2007/47/EC Medical
Device Directive. Four digit number refers to Notified Body.
Device complies with International Organization of Legal Metrology
(Class III) requirements (verified models only)
Device complies with EC directives (verified models only)
M: Conformity label in compliance with Directive 2014/31/EU for non-
automatic weighing instruments
19: Year in which conformity verification was performed and the CE
label was applied. (ex: 19=2019)
0122: Refers to Notified Body for metrology
Device complies with UK Regulation.
M: Non-Automatic Weighing Instruments Regulations 2016.
21: Year in which conformity verification was performed and the CE
label was applied. (ex: 21=2021)
0120: Refers to the Approved Body for metrology

Page 5 of 14
Dimensions

Page 6 of 14
Function keys
Hold
Hold of weight function
Hold of weight reading on the indicator
screen
Total
Accumulation function
Addupmultipleseparate weights
Lb/Kg
Unitsconversionfunction
Switchbetweenweight displayed in kg
and lb
Gross
Tarefunction cancel key
Cancel apreviously entered tare weight
Tare
Tarefunction
Remove unwanted weight from the
reading, such as a pallet
Zero
Scale re-zero function
Return the scale to a zero reading
Print/On/Off
On/Offbutton;printfunction
Powerupor powerdown; print weight or
count data

Page 7 of 14
Operation - Switching on the scale
•Press and hold the PRINT/ON/OFF button for three seconds.
•The display will show ‘0.00’ once the scale is ready to begin weighing.
Operation - Using Hold
•If an unstable weight on the scale causes fluctuations in the weight display, press the HOLD button
and the indicator will ‘lock’ the weight of the item on the screen.
•Press HOLD again to cancel the held weight reading.
Operation - Using Tare
•You can remove the weight of the pallet by using the TARE function. Place the pallet only on the scale,
and press TARE.
•Remove the pallet. The display will show the pallet’s weight as a minus number.
•Add your palletized goods to the scale and the weight of the pallet will be removed.
•Press GROSS and the display will show the full weight on the scale.
•Press TARE again to cancel the tare weight.
Operation - Switching between kg and lb
•To switch the scale from kg to lb, press LB/KG.
•Press again to return to KG readings.
Operation - Using Zero
•If at any time the indicator shows a reading when nothing is on the scale, press ZERO.
•The display will then show a zero reading.
Operation - Using Accumulation
•The accumulation function allows you to add up the weights of several pallets.
•Add your first item to the scale and press TOTAL. Remove the pallet from the scale.
•Add the next item to the scale and press TOTAL again.
•If you would like to see the current total at any time, press and hold TOTAL for at least two
seconds.
•To print the individual weights and a total, press PRINT/ON/OFF.
•To clear accumulation readings press ZERO.
•Press HOLD to return to normal weighing.

Page 8 of 14
Operation NB (PT-700 only):
•Pressing PRINT whilst under target will print weight and state as ‘less’
•Pressing PRINT whilst at target will print weight and state as ‘OK’
•Pressing PRINT whilst over target will print weight and state as ‘over’
Charging the scale
The PT-700 is supplied with a 7v 100ma tip +ve adaptor, which plugs directly into the indicator.
Please allow eight hours for the internal rechargeable battery to reach full charge from flat.

Page 9 of 14
Using The Printer
•Once the PT-700 is bearing the load, press the PRINT key once to produce a physical print out of the weight.
Replacing the printer’s tally roll
Simply pull the lever down on the top right hand side of the printer and the front cover of the printer will release.
Remove the tally carefully and replace with a new one supplied by Marsden, ensuring the end of the tally roll is lined up with
the opening of the printer.
For replacement tally rolls call 01709 364296.

Page 10 of 14
Error messages
Display
Problem
Solution
Unableto reset after start up
Ensure there is nothing on the scalewhen
switchingon
Possible scale overload
Removeweightfromthe scale
Scale is below zero
Press zero to re-zero the scale
Out of balance range
Remove any weight from the scale and try
again
Invalid operation
EEPROM error
Switch the scale on again; if the error
message still shows, contact your
dealer/Marsden
AD initialization error
Switch off the scale and restart.If the
erroroccurs again, contact your
dealer/Marsden

Page 11 of 14

Page 12 of 14

Page 13 of 14

Page 14 of 14
MARSDEN
Unit 1, Genesis Business Park,
Sheffield Road, Rotherham,
S60 1DX
Telephone: + 44 (0) 1709 364296
Version 1.0
