Marshall Electronics VAC-12HS User manual

INTRODUCTION
FEATURES
• Supportedhigh-denition(HD)formats:
  NTSC[email protected],PAL625@50,720p@50,[email protected], 
  720p@60,1080i@50,[email protected],1080i@60,[email protected], 
  1080p@24,1080p@25,[email protected],1080p@30,1080p@50, 
  [email protected],1080p@60
• BitRate:2.97Gbps,2.967Gbps,1.485Gbps,1.4835Gbps,270Mbps
• Auto3G/HD/SD-SDIdetection
• SupportHDMIDeepColor
• TwoSDIcompliantoutputs
• ExternalDIPSwitchConguration
TheVAC-12HSHDMIto3G/HD/SD-SDIConverterprovidesaprofessionalway
toconvertHDMIto3G/HD/SDSDIinrealtime.TheconversionbetweenSDIand
HDMIispurelydigitalandguaranteesnolossofvideoandaudiosignal.Audio
issupported.*TheVAC-12HSalsoprovidestwolowjitterSDIoutputsfordaisy
chainormultiplemonitors.WiththeuseofVAC-12HS,themostpopular
uncompressedvideointerfaceintheconsumerworldisreadilyavailablefor
professionalSDIequipment!
*SDIsupports48KHz.DolbyTrueHDandDTSHDarenotsupportedinSDI.
HDMICable
SDICable SDICable
Front Rear
POWER
SIGNAL
HDMI IN
+ 5V DC
DevicewithSDIinputDevicewithSDIinput
SDI OUT 1 SDI OUT 2 MODE
1910EastMapleAve.ElSegundo,CA90245
Tel:(800)800-6608•(310)333-0606
•Fax:310-333-0688
www.LCDracks.com
[email protected]
Marshall Electronics
36
Marshall Electronics
User Manual
FRONTPANEL
REARPANEL
1.HDMIinput
2.SignalLED:
<green>signalactive
<red>power
3.Interlocked+5Vpowerjack
4.3G/HD/SD-SDIoutput
5.3G/HD/SD-SDIoutput
6.DIPswitch(Pin#1andPin#2)
PANEL DESCRIPTION

SAFETY & NOTICE
PACKAGE CONTENTS
SUPPORTED RESOLUTIONS
DIP SWITCH
Followallinstructionsandwarningsmarkedonthisunit.
Donotattempttoservicethisunityourself,exceptwhereexplainedinthis
manual.
Provideproperventilationandaircirculation.Donotusenearwater.
Keepawayfromobjectsthatmightdamagethedevice.
Assurethattheplacementofthisunitisonastablesurface.
Useonlythepoweradapter,powercordsandconnectioncables
designedforthisunit.
Donotuseliquidoraerosolcleanerstocleanthisunit.Alwaysunplugthe
powertothedevicebeforecleaning.
TABLE OF CONTENTS
INTRODUCTION
FEATURES
PACKAGE CONTENTS
SUPPORTED RESOLUTIONS
DIP SWITCH
SPECIFICATIONS
PANEL DESCRIPTIONS
EDID LEARNING
WARRANTY
3
3
4
4
4
5
6
7
7
EDID LEARNING
SPECIFICATIONS
Marshall warrants the VAC-12HS HDMI to 3G/HD/SD-SDI Converter to be
freefromdefectsinthematerialandworkmanshipfor1yearfromthedateof
purchasefromanauthorizedMarshalldealer.Shouldthisproductfailtobein
goodworkingorderwithin1yearwarrantyperiod,Marshallwill,atitsoption,
repair or replace the unit, provided that the unit has not been subjected to
accident, disaster, abuse or any unauthorized modications including static
dischargeandpowersurges.
Unitthatfailsunderconditionsotherthanthosespeciedabovewillberepaired
atthecurrentpriceofpartsandlaborineffectatthetimeofrepair.Suchrepairs
are warranted for 90 days from the day of reshipment to the BUYER. If the
unitisdeliveredbymail,customersagreetoinsuretheunitorassumetherisk
oflossordamageintransit.Undernocircumstanceswillaunitbeaccepted
withoutareturnauthorizationnumber.
Thewarranty isin lieuof allother warrantiesexpressedor implied,including
withoutlimitations,anyotherimpliedwarrantyortnessormerchantabilityfor
anyparticularpurpose,allofwhichareexpresslydisclaimed.
Proofofsalemayberequiredinordertoclaimwarranty.Cablesarelimitedto
a30daywarrantyandcablemustbefreefromanymarkingsorscratches.
Thecontentofthismanualhasbeencarefullycheckedandisbelievedtobe
accurate.However,Marshallassumesnoresponsibilityforanyinaccuraciesthat
maybecontainedinthismanual.MarshallwillNOTbeliablefordirect,indirect,
incidental, special, or consequential damages resulting from any defect or
omission in this manual, even if advised of the possibility of such damages.
Also, the technical information contained herein regarding the VAC-12SH
featuresandspecicationsissubjecttochangewithoutfurthernotice.
1.PleasemakesurebothPin#1andPin#2ofDIPswitchare“On.”
2.ConnecttheHDMIdisplaycabletotheHDMIportofthesignalsource.
3.Poweronthesignalsource.
4.WhenthegreenLEDturnson,theEDIDlearningprocedureiscompleted.
5.PleaseDONOTchangetheDIPswitch.Otherwisethebuilt-inEDIDLearning
informationwillbelost.
LIMITED WARRANTY
72
54
• VAC-12HSConverter
• 5V/2Apoweradapter
• UserManual
3G-SDI OUTPUT
HD-SDI OUTPUT
SD-SDI OUTPUT
1080p@50/59.94/60Hz SMPTE424M,SMPTE425M
720p@50Hz SMPTE296M-3
720p@60/59.94Hz SMPTE296M-1,-2
1080i@50Hz SMPTE274M-6
1080i@60/59.94Hz SMPTE274M-4,-5
1080p@24/23.98Hz SMPTE274M-10,-11
1080p@25Hz SMPTE274M-9
1080p@30/29.97Hz SMPTE274M-7,-8
NTSC
PALB,D,G,H,I
A2-pinDIPswitchisusedforuserinterface.
Userscanaccessthisswitchfromthebottomoftheunit.
Pin #1 Pin #2 EDID Feature
OFF OFF 3G/HD/SD-SDIwithmulti-channelaudioexceptDTS-HD
&DolbyTrueHD
OFF ON 3G/HD/SD-SDIwithStereoPCMAudio
ON OFF HD/SD-SDIwithStereoPCMAudio
ON ON EDIDLearningMode
TECHNICAL
Mechanical
SDIstandards 3G-SDI&HD-SDI&SD-SDI
Auto3G/HD/SD-SDIdetection Yes
SDIDataRate [2.97Gpbs&2.975/1.001Gbps]
Videosupport
[3G]-1080p50/59.94/60(4:2:2)
[HD]-720p@50/59.94/60Hz,1080i
@50/59.94/60Hz,[email protected]/24/25/29.97/30Hz
[SD]-NTSC@59.94Hz,PAL@50Hz
Inputsignal HDMI
Outputsignal SDI
Outputimpedance 75ohms
Eyepatterncharacteristics Extralowalignmentjitter0.05UIatHD
Cableequalization [3G-SDI]upto90m(300ft) [HD-SDI]upto150m(500ft)
[SD-SDI]upto300m(1000ft)
Audiosupport Yes
Input 1xHDMI
Output 2xBNC[SDI]
BNCconnector 75ohminter-lockedsocket
HDMIconnector TypeA[19-pinfemale]
DIPswitch 2-pin[forEDIDuse]
Housing Metalenclosure
Dimensions[LxWxH] 79x84x27mm[3.1”x3.3”x1.2”]
Weight Model [TX]–250g[8.8oz]
Package 780g[1.7lbs]
Powersupply 5V2ADCwithLockingPowerConnector
Powerconsumption 3Watts[max]
Operationtemperature 0~40°C[32~104°F]
Storagetemperature -20~60°C[-4~140°F]
Relativehumidity 20~90%RH[nocondensation]
