Marshall Electronics M-CT710 User manual

Marshall
Marshall
Owner’s Manual
M-CT710
Camera-Top Monitor

Marshall M-CT710 Camera-Top Monitor Owner’s Manual M-CT710 Camera-Top Monitor Owner’s Manual
2| |3
Marshall
To ensure the best use of this product, please read this manual carefully
beforehand.
CAUTION
1. Please use the adapter attached in the accessory or another qualied
adapter.
2. Please do NOT expose this product to direct sunlight, heat, or humid
conditions.
3. Please keep away from strong light while using this product to ensure
the image effect and long-term use.
4. Please avoid heavy impact or drop onto the ground.
5. Please do NOT use chemical solutions to clean this product. Please
wipe with a clean, soft cloth to maintain the brightness of the surface.
6. Please do not take apart or repair the unit by yourself to avoid damage
the product.
Dear users:
Thank you for purchasing Marshall’s M-CT710 HD LCD Monitor. This 7”
Pro HD LCD Monitor is designed to be used as an external video display,
allowing you to step back from the camera while still being able to frame
and capture the action without having to look through the camera’s built-in
viewnder. It employs advanced integrated circuits, high quality TFT LCD
modules, and low power consumption.
This monitor is designed to be small, easily operated, and portable, with
HDMI, Composite Video, Audio Input and HDMI Output. This monitor can
be powered by DSLR, Camcorder and AA batteries
Product Advanced Features:
• Zoom mode
• HDMI input and output. Video Input and Audio input
• Viewnder marked ranges:0%, 85%, 90%, 93%, 96%
• Cross the screen center mark
• 16:9 or 4:3 Aspect Ratio Setting
• Earphone stereo output.
• Speaker
• Brightness, Contrast, Hue, Saturation and Color Temperature Adjustment
• Field - Normal, Red, Green, Blue, Gray
• Supports , camcoder or AA batteries
• Removable Sunhood
• 2 Years warranty with registration (see registration form)
1. Product description........................................................ 4
Panel Instruction............................................................ 4
Back view ...................................................................... 5
Sunhood installation and removal ................................. 5
2. Power input.................................................................... 6
3. Operating instructions.................................................... 6
4. Parameters.................................................................... 9
5. Accessories ................................................................. 10
6. Trouble shooting.......................................................... 10
7. Menu List..................................................................... 11
8. Battery Compatibility.................................................... 11
CONTENTS

Marshall M-CT710 Camera-Top Monitor Owner’s Manual M-CT710 Camera-Top Monitor Owner’s Manual
4| |5
Marshall
Back view
11. HDMI input jack
12. HDMI output jack
13. Battery mount (see pg. )
14. Power source input jack
15. Video In
16. Audio In
17. Speaker
Battery installation
Suggestion: Remove the battery for long periods of inactivity.
Sunhood installation and Removal
Attach the self adhesive side of the Velcro® to the side of the monitor.
Panel Instruction
1. 3.5mm headphone jack
2. Volume down or to adjust the value setting function
3. Volume up or to adjust the value setting function
4. MENU: To activate OSD menu
5. Menu navigation key up
6. Menu navigation key down
7. HDMI/Video selector key
8. Zoom - mode
9. Indicator light
10. Power on/off
Product Description
82 5431 6 7 9 10
12 11
13
15
14
16
17

Marshall M-CT710 Camera-Top Monitor Owner’s Manual M-CT710 Camera-Top Monitor Owner’s Manual
6| |7
Marshall
Function
System
Sound
To adjust the volume left and right arrows buttons on the front of the
monitor. Default value is 0.
2. Power input
The monitor can be powered by the enclosed DSLR, Camcorder equivalent
12V power abater or AA batteries or equivalent battery or by a 12V power
adapter. Please note the input polarity is Positive with respect to --○-+,
otherwise will damage the monitor!
3. Operating instruction
3.1 Menu operating instructions
Before setting the menu functions, please make sure the device is
connected correctly. Power switch is to ON position. The monitor
enters into working state. Please dial to OFF position when closing the
unit.
After selecting the optionals, press “►”or “◄” on the unit to conrm, then
using “▲” or “▼” to select or adjust the value of Analog Data. After conrm
the needed adjust parameters, using “►” or “◄” to adjust. If you need to
exit OSD menu, repress “MENU” button.
Brightness
To adjust brightness 0-100. Default value is 50.
Contrast
To adjust contrast 0-100. Default value is 50.
Color
Saturation
To adjust Saturation 0-100. Default value is 50.
Hue
To adjust Hue 0-100. Default value is 50.
Sharpness
To adjust the Sharpness.
Color temperature
To adjust the color temperature.
Pre set 9300, 6500, or User
User-R 0-255 Default value is 128.
User-G 0-255 Default value is 128.
User-B 0-255 Default value is 128.

Marshall M-CT710 Camera-Top Monitor Owner’s Manual M-CT710 Camera-Top Monitor Owner’s Manual
8| |9
Marshall
4. Parameters
Display panel size TFT LCD 5.0inch 1152000 Pixels
Panel type TFT LCD
Resolution 800*480
Max resolution 1920×1440
Horizontal frequency range 30-60kHz
Field frequency range 60Hz ~ 75Hz
Distance 0.045(W) x 0.135 (H)
Display ratio 16:9
Brightness 350 cd/m2
Contrast 500:1
Response time 10ms
Viewing angle 70°/70°(L/R) 50°/70°(U/D)
Backlight LED
Input signal HDMI, VIDEO, AUDIO
Signal output HDMI(optional)
Supported format 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video color system PAL-4.43; NTSC-3.58
Input power voltage range DC6-24V
Power consumption <7w
Standby current <50mA
Unit size(LWH)
With sunhood
146mm(L) *100mm(H) *46mm(W)
146mm(L) *100mm(H) *60.5mm(W)
Weight (no battery)
With sunhood
260g
340g
Working temperature -20~55°C
Storage temperature -30~65°C
5. Accessories
5.1. Standard
Mini HDMI to HDMI cable
HDMI to HDMI cable
Hot shoe mount
battery
Battery Charger
User manual
5.2. Optional
BNC to RCA adapter
DC 12V power adapter
BNC cable
Sunhood
6. Troubleshooting
6.1. Only black and white or monochrome picture. Please check saturation,
brightness & contrast adjustment.
6.2. No picture after turning on the power. Check signal cable connecting,
make sure use the standard adapter is connected the monitor. If power is
supplied by battery, please check if the battery is fully charged.
6.3. The image color distortion or abnormal, e.g. lack some color. Please
check signal cable whether connected correctly or not. If the cable is
damaged or loosened, it will cause poor transfer, causing this malfunction.
Check “color” function menu “color temperature” adjustment, whether
adjustment misconduct under the “user” state.
If you are still experiencing problems, contact Marshall Electronics
technical support at: [phone] or [phone]

Marshall M-CT710 Camera-Top Monitor Owner’s Manual M-CT710 Camera-Top Monitor Owner’s Manual
10| |11
Marshall
Menu Option Chart
Input Mode HDMI Video
Color Brightness X X
Contrast X X
Hue X X
Saturation X X
Color Temperature X NO
OSD Language X X
H Position X X
V Position X X
OSD Timeout X X
Zoom X NO
Transparent X X
Function Reset X X
Display Ratio X X
Screen Marker X X
Center Marker X X
X NO
Sound Volume X X
Battery Compatibility
This camera-top monitor is compatible with a variety of different and
camcorder batteries, depending upon which option is purchased:
Compatible Batteries Compatible Camcorder Batteries
Canon BP511
Canon E6
Nikon EL3
Nikon NEL15
Compatible AA Batteries
AA batteries Alkaline or
rechargeable
Canon BP-970G
JVC BN-V438U
Panasonic CGA-D54
Panasonic VW-VBG6
Sony NP-QM91
Sony NP-F970

Marshall M-CT710 Camera-Top Monitor Owner’s Manual
12|
Marshall Electronics
1910 E. Maple Avenue
El Segundo, CA 90245 USA
Phone: [phone] • 800-800-6608 • Fax: [phone]
marshall-usa.com
Manual contents subject to change without notice.
