Martin Audio W2 User manual

WW22
Arrayable two-way compact trapezoid system
features
Arrayable compact trapezoid enclosure
High SPL output capability
70º coverage angle
Multi-laminate birch plywood construction
Switchable active/passive operation
Certified MAN quick-connect flying option
applications
Theatre sound systems
Club sound reinforcement
Underslung/infill for concert sound reinforcement
Music playback in nightclubs
On-stage instrument monitor
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: [phone] Facsimile: [phone]
E-mail: [email protected]
All information is Copyright © 2006 Martin Audio Ltd.
The qualities of the Wavefront W2 have established its success as
a powerful stand-alone system. This switchable active/passive
two-way cabinet uses specialist high power drive units to achieve
maximum SPL’s from a very compact enclosure.
It combines smooth, dynamic full frequency performance with
exceptional articulation for a portable stand-alone system.
Designed to meet the industry requirement for a 12" (300mm)
driver plus horn configuration, Martin Audio’s version is more
refined for superior, professional results.
www.martin-audio.com
overall dimensions
technical specifications
TYPE Compact two-way trapezoid, switchable
active/passive
FREQUENCY RESPONSE (5) 60Hz-18kHz ± 3dB
-10dB @ 50Hz
DRIVERS 12" (300mm) / 3" (75mm) voice coil
1" (25mm) exit HF compression driver
RATED POWER (2) LF/(LF + HF): 300W AES, 1200W peak
HF: 60W AES, 240W peak
RECOMMENDED AMPLIFIER 400-550W into 4 ohms
SENSITIVITY (6) LF/(LF + HF): 98dB
HF: 106dB
MAXIMUM SPL (7) 122dB continuous, 128dB peak
NOMINAL IMPEDANCE LF/(LF + HF) 8 ohms
HF: 8 ohms
DISPERSION (-6dB) 70º horizontal, 40º vertical
CROSSOVER 1.5kHz active/passive
FINISH Textured grey paint
PROTECTIVE GRILLE Grey perforated steel
CONNECTORS 2 x Neutrik NL4
FITTINGS 8 x M8
1 x mounting pole socket
2 x MAN blanking plates
2 x rear kelp fittings
DIMENSIONS (W) 365mm x (H) 554mm x (D) 364mm
(W) 14.4ins x (H) 21.8ins x (D) 14.3ins
WEIGHT 24kg (53lbs)
touring and theatre
