Martin RUSH CS Series User manual

RUSH® CS Series
CS300 GRAZE & WIDE
CS600 GRAZE & WIDE
CS900 GRAZE & WIDE
CS1200 GRAZE & WIDE
CS PSU Power Supply Unit
User manual

Dimensions
46.0
Graze
CS300
CS600
CS900
CS1200
Wide
46.0
65.0
57.0
1203
903
603
303

CS PSU Power supply unit
302.0
180
58.0
195.0
272.0
288.0
80.0
R2.8
Information subject to change without notice. HARMAN Professional Denmark ApS disclaims liability for
any injury, damage, direct or indirect loss, consequential or economic loss or any other loss occasioned by
the use of, inability to use or reliance on the information contained in this document.
©2015-2018 HARMAN Professional Denmark ApS. All rights reserved. Martin® is a registered trademark
of HARMAN Professional Denmark ApS registered in the United States and/or other countries. Features,
specifications, and appearance are subject to change without notice.
RUSH® CS Series User Manual – Revision C
All dimensions are given in millimeters
For mounting bracket dimensions see page 11

Table of contents
Dimensions...............................................................................................................2
Safety information.....................................................................................................5
Introduction...............................................................................................................8
Before using the product for the first time ...........................................................8
Fixture overview..................................................................................................9
Physical installation ................................................................................................11
Fixture location..................................................................................................11
Mounting the fixture...........................................................................................11
AC power and data connection to PSU ..................................................................13
Power requirements..........................................................................................13
Connecting fixtures.................................................................................................13
Data network requirements ...............................................................................14
Setup ......................................................................................................................15
RDM and Martin® M-PC ...................................................................................15
Step one: scanning for devices on the data link................................................15
Setting DMX mode............................................................................................15
Setting DMX addresses ....................................................................................15
Dimming control ................................................................................................16
Temperature status...........................................................................................16
Overall fixture status .........................................................................................16
RDM..................................................................................................................17
Maintenance ...........................................................................................................18
Cleaning............................................................................................................18
DMX protocol..........................................................................................................19
6 channel mode ................................................................................................19
3 channel mode ................................................................................................19
Specifications .........................................................................................................21

RUSH® CS Series User Manual 5
Safety information
WARNING!
Read the safety precautions in this manual before installing, operating or servicing
this product.
The following symbols are used to identify important safety information on the product and in this manual:
Warning!
Safety hazard.
Risk of severe
injury or
death.
Warning!
Powerful light
emission. Risk
of eye injury.
Warning!
See user
manual for
important
safety
information.
Warning!
Hazardous
voltage. Risk
of lethal or
severe electric
shock.
Warning!
Fire hazard.
Warning!
Hot surfaces.
Warning! Risk Group 2 product according to EN 62471. Do not look directly into the beam.
Do not view the light output with optical instruments or any device that may concentrate
the beam.
This lighting fixture is for professional use only and must be installed by a qualified
technician. It is not for household use. It presents risks of severe injury or death due to fire
hazards, electric shock and falls. It can create a fire hazard or a risk of eye injury if the
safet
y
p
recautions below are not followed.
Install, operate and service RUSH® by Martin® products only as directed in their user
manuals, or you may create a safety hazard or cause damage that is not covered by
product warranties. Follow the safety precautions listed below and observe all warnings in
this manual and printed on the product. Keep this user manual for future use.
For the latest user documentation and other information about this and all Martin®
products, please visit the Martin® website at http://www.martin.com
If you have any questions about how to install, operate or service the fixture safely, please
contact your Martin® distributor (see www.martin.com/distributors for details) or call the
Martin® 24-hour service hotline on [phone], or in the USA on 1-888-tech-180.
Respect all locally applicable laws, codes and regulations when installing, operating or
servicing the fixture.
Protection from electric shock
Ensure that the fixture is electrically connected to ground (earth).
Disconnect the fixture from AC power when not in use.
Never connect or disconnect a live Power + Data Cable. Shut down power to the fixtures
before connecting or disconnecting cables.
Do not open the fixture or remove any cover. Refer any service operation not described in
this manual to an authorized Martin Service partner.
Shut down power to the entire installation at the main power distribution board and lock out
power before carrying out any installation or maintenance work.
Use only a source of AC power that complies with local building and electrical codes and
has both overload and ground-fault (earth-fault) protection.
Isolate the fixture from power immediately if any seal, cover, cable, or other component is
damaged, defective, deformed or showing signs of overheating. Do not reapply power until
repairs have been completed

6RUSH® CS Series User Manual
Before using the fixture, check that all power distribution equipment and cables are in
perfect condition and are of suitable type for the location (including water, pollution,
temperature and UV resistance).
Do not immerse the fixture in water or any other fluid, or install it in a location where
floodin
g
ma
y
occur.
Protection from burns and fire
Do not operate the fixture if the ambient temperature (Ta) exceeds 45° C (113° F).
The surface of the fixture can reach up to 55° C (131° F) if the fixture is operated at the
maximum permitted ambient temperature. Allow the fixture to cool for at least 5 minutes
before handling.
Install the fixture on a non-combustible surface (brick, concrete, plaster etc.) only.
Do not aim the fixture towards combustible materials (fabric, wood, paper etc.) that are
within 10 cm (4 in.) of the fixture.
Keep the fixture well away from flammable materials (volatile liquids etc.).
Ensure that there is free and unobstructed airflow around the fixture.
Allow at least 0.1 m (4 in.) free space around the fixture.
Do not attempt to bypass thermostatic switches or fuses.
Do not modify the fixture in any way not described in this manual or install other than
genuine Martin® parts. Do not stick filters, masks or other materials onto any lens or other
optical component. Use onl
y
accessories approved b
y
Martin® to modif
y
the li
g
ht beam.
Protection from eye injury
The CS Series fixtures fall into Risk Group 2 according to EN62471. To minimize the risk
of eye irritation or injury, disconnect the fixture from power at all times when the fixture is
not in use, and provide well-lit conditions to reduce the pupil diameter of anyone working
on or near the fixture.
The light from the LED emitters is possibly hazardous and may be harmful to the eyes. Do
not stare directly into the product’s light output.
Do not look at the light output with magnifiers, telescopes, binoculars or similar optical
instruments that may concentrate the light output.
Ensure that persons are not looking directly into the fixture when the product lights up
suddenly. This can happen when power is applied, when the product receives a DMX
signal, or when certain control menu items are selected.
WIDE fixtures
The CS Series Wide fixtures fall into the following risk groups according to EN62471 at the
distances indicated below. Position the CS Series Wide fixtures so that prolonged staring
into the light output at less than 336mm (13.3 in.) from the fixture is not expected.
RISK GROUP
2
RISK GROUP
1
336 mm
(13.3 in.)
3.4 m
(11.2 ft.)
RISK GROUP
EXEMPT

RUSH® CS Series User Manual 7
GRAZE fixtures
The CS Series Graze fixtures fall into the following risk groups according to EN62471 at
the distances indicated below. Position the CS Series Graze fixtures so that prolonged
staring into the light output at less than 2.4 m (7.9 ft.) from the fixture is not expected.
RISK GROUP
2
RISK GROUP
1
2.4 m
(7.9 ft.)
23.5 m
(77.1 ft.)
RISK GROUP
EXEMPT
Protection from injury
Fasten the fixture securely to a fixed surface or structure when in use. The fixture is not
portable when installed.
Ensure that all supporting structures, surfaces, fasteners and lifting equipment can bear
the weight of all the devices they are intended to support plus an adequate safety margin,
and that they conform to local building and safety regulations.
Ensure that any accessory such as a glare shield is securely fastened.
Block access below the work area and work from a stable platform whenever installing,
setting, adjusting, or cleaning the fixture.
Do not operate the fixture with missing or damaged covers, shields or any optical
component.
If an operating problem occurs, stop using the fixture immediately and disconnect it from
power. Do not attempt to use a fixture that is obviously damaged.

8RUSH® CS Series User Manual
Introduction
The RUSH® CS Series from Martin® is a line of rugged LED-based lighting fixtures with a remote power
supply unit. Fixtures are available in 300 mm (1 ft.), 600 mm (2 ft.), 900 mm (3 ft.) and 1200 mm (4 ft.)
length models, each with either wide or graze optics. Wide optic models are designed for a range of
indirect lighting applications. Graze models are designed for illumination of walls or other surfaces and
have an asymmetric 18° x 65° beam-angle.
The fixtures are powered by a remote power supply unit (PSU) which is controlled by DMX and configured
using RDM (Remote Device Management). Multiple fixtures can be linked together making for simple
installation of long runs. Each PSU can power up to 10 meters (32 ft.) of LED fixtures.
The RUSH® CS Series system features:
•Long-life, high output Cree LEDs
•Remote 100-240 V, 50/60 Hz auto-ranging AC power supply
•Low voltage 36V supply to fixtures
•Easy wiring with integral combined low voltage power and data cables
Each fixture is supplied with two hinged mounting brackets.
Before using the product for the first time
1. Read ‘Safety information’ on page 5 before installing, operating or servicing the fixture.
2. Unpack and ensure that there is no transportation damage before using the fixture. Do not attempt to
operate a damaged fixture.
3. Before operating, ensure that the voltage and frequency of the power supply match the power
requirements of the fixture.
4. If fixtures are exposed to a sudden temperature change, give them time to warm or cool to the
ambient temperature before applying power. This will help avoid damage due to condensation.
5. Check the support pages on the Martin® website at www.martin.com for the most recent user
documentation and technical information about the fixture. Martin® user manual revisions are
identified by the revision letter at the bottom of the inside cover.

RUSH® CS Series User Manual 9
Fixture overview
2
2
1
34
1
Number Description
1 Mounting bracket
2 Tilt lock screws
3 Power/data input connector (blue)
4 Power/data output connector (black)
RUSH® CSSeriesLED fixture partsIdentification
1
2
3
4
5
Number Description
1 Mains power input (Fuse: T6.3A)
2 DMX input
3 DMX output
4 Mains power indicator light
5 Data/power output to fixtures
RUSH® CSPSU PartsIdentification

10 RUSH® CS Series User Manual
Fixture output Fixture input (blue) Power supply output
Number Description
1 Data ground
2 Data -
3 Data +
4 Not used
5 Not used
6 +36 V power
7 Not used
8 0 V power
RUSH® CSSeriescombined power/dataconnector
The 5-pin XLR connectors for DMX use standard pinout.
Pin Number Description
1 Data ground
2 Data -
3 Data +
4 Not connected
5 Not connected
RUSH® CSSeries5-pin XLR pinout
