Massagesessel Welt MSW300 User manual
深圳市福瑞斯健康科技有限公司
1 2 3 4 5 6
654321
A
B
C
D D
C
B
A
产品名称
物料编码
零件名称
视 角
重 量
比 例
尺寸范围 A B C
公差( ) 序号 更改事项 日期
设计/
时间
实验室
时间
审核/
时间
核准/
时间
单位
版本
mm
C
A/0
受控 试制 开模 打样
零件图号
产品型号
产品材质
说明书
2.01.12.MAM30000-03
2022-337
钟建辉 12-03
M300
按摩椅
√
尺寸：210*285mm 材质：128G铜版纸
MODEL NO.:MSW300
User Manual
MASSAGE CHAIR
Reference parameters
Model no.: MSW300
Product name: Massage Chair
Rated Voltage: 100V-240V~ 50/60Hz
Rated Power: 120W
Rated Time: 15 minutes
Stroke: 1300mm
Bluetooth name: MSW300 Bluetooth password: 9999
Lying angle: 130°-155°
Safety settings: prevent overheating, overcurrent, overvoltage
Net weight/Gross weight: 62KG/72KG
Packing size: 1540X760X870mm
CONTENTS
01
03
04
05
06
07
1. Notice
2. Chair components
3. Remote controller buttons
4. Functional description
5. Operation instructions
6. Reference parameters
If you are in treatment of disease or have any cases below ,please do not
use it or follow the doctors advice.
Please do not use it in the highly humid environment, such as bathroom.
Please do not place it under the strong sunlight, high pressure,greasy dirt and highly
corrosive, as well as places with flammable and explosive dust,petrol,gas,steam,etc.
09.
08.
07.
06.
05.
04.
03.
02.
01.
15.
14.
13.
12.
11.
10.
09.
08.
07.
06.
05.
04.
03.
02.
03.
02.
01.
08.
07.
06.
05.
04.
03.
02.
01.
11.
10.
09.
08.
07.
06.
05.
04.
03.
02.
01.01.
Usage environment
Fault handling
Routine maintenance
Safety PrecautionsSafety warning
Customers with osteoporosis,spine fractures,severe wound.
Customers vulnerable to electrical disturbance with pacemaker, implantable cardiac
defibrillator and other medical devices.
Please do not use it when your body is wet.
Pregnant or menstruating woman.
Customers with breeding disorder,sepsis,fever, paresthesia.
Customers with diseases like malignant tumor, heart disease,hypertension,acute
diseases.
The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction；children being supervised not to
play with the appliance.
Children under 14 years old must be supervised by adult to ensure their safety .In
order to avoid accident,please keep children off the massage chair while you are
using it.
It has a heating surface,so the customers who are not sensitive to heat must be
careful in use.
The noise during operation is caused by massage part, It is the normal phenomenon.
If he remover cannot be controlled, please check some of the line heads if they are
connected probably, if not, please connect each line heads firmly and make sure it's
plugged in the socket firmly.
Stop working while in use, please check if it finished the 15 minutes scheduled
working time, it is a standby mode, if yes, please press " Power" torestart the
function or the product is over-heated. It imitate its self-protected system and waiting
for it to cool down in 30 minutes and restart it.
Unauthorized repairman is not recommended to transform disassemble or repair the
product .If any abnormal circumstance occurs please contact our dealer oromptly
When you are not using it ,please shut down power switch and unplug.
Please check the socket that it fixes firmly before plug.
Please clean the item with dry cloth,never use any chemical solvent, abrasive
material or metallic brush to clean.
Please do not use it in open-air or humid place, do not expose it to the strong sun or
rain directly.
In order to extent the product serve life and guarantee the normal operation, please
do not press or push hard against the massage parts.
The product can not be dragged or scrolled on uneven ground, and have to be lifted
it and then move.
It' s better not to use the product continuously for a long time per day, but to use it
intermittently.
Please check the input voltage have to match the specifications of the product before
use.
Never pull out the plug or touch the power cord, plug and socket with a wet hand.
Keep the item dry ,and do not allow water into , and avoid the item damage or electric
shock danger.
Please plug in or out the power plug in the socket with the correct way , and do not
excessively lent ,pull twist, knot the power cord rudely.
It's only suitable for using the plug we provide. It cannot be used in other power supply
mode, If any damage occurs, it has to be exchanged or repaired by our dealer or our
maintenance center.
Please clean the plug pin with dry cloth but not the wet cloth, avoid get an electric
shock.
When the power was cut off suddenly, please stop using it and leave away the product,
and unplug the plug.
If any abnormal circumstance occurs, please stop using it right away and unplug, and
then contact our dealer's maintenance department or relevant professional repairman.
It's not a medical equipment,it is not for any curing purpose, or other commercial
purposes. If you feel uncomfortable while in use , please stop using it right away.
Children must be supervised to ensure that they will not spoil the product.
If there is any damage at power at power cord, it must be exchanged by manufacturer or
its maintenance department or relevant professional repairman.
Children should not stand in front of and behind the machine , as these parts can be
movable up and down, avoid accidents.
After use and before cleaning , please unplug the power cord.
Please use the product follow this hand manual instructions.
Please only use the parts and assembly that is long to the product,such as the plug
cord, and do not allow unauthorized replacement of product parts.
Please put the machine indoor, and it is not suitable for outdoor use.
Please read the manual carefully before usage.
This machine is only for person relax massage and cannot be used for other
purposes.
The suggestion using time is 15 minutes/time.
Pleas do not use the machine when the outer casing or PU cover of it has any
broken.
The vent is on the back of the machine. During running, this vent cannot be covered
with any cover.
Please do not put any other objects into the machine, that is not belong to the
product.
Please do not sleep inside of machine while massage.
Never use this machine when you are drunk or body feel unwell.
Please do not use when you in hungry or after have completed the eating in 1 hour.
When the machine is in operation, please do not deliberately force the neck or back
massage head to stop working with your body or other items.
Ensure the space behind the chair
1. When laying down the back of the chair, in order
to avoid touching the wall or other objects, Please
keep the distance between the massage chair and
the wall about 5cm.
2. Confirm that there are no people, pets,
obstacles, etc. behind the machine.
Power plug
Power on method
1. Insert the power plug into the wall socket.
※Before inserting the power plug, make sure that
the power switch of the product is in the off
position.
Use place
1. Please avoid placing the massage chair in a
humid place such as the bathroom.
2. Please avoid placing the massage chair in a
place exposed to long-term sunlight or near a high
temperature stove.
3. In order to prevent damage to the ground and
reduce noise during operation, a carpet can be laid
under the massage chair.
New appearance design
It adopts an ergonomic structural design, and the overall appearance is generous.
Beautiful leg frame safety patent design
The lifting of the beautiful leg frame is not restricted by the movement of the telescopic motor and can be
turned at any time.
The whole body air pressure massage feels three-dimensional
The massage feels stronger and deeper, providing you with a super enjoyment, covering a wider range from
the legs, buttocks, waist, to hands and head.
Zero space design
The unique structural design makes the home layout more space-saving.
Various massage techniques
The massage chair has a variety of techniques such as massage,kneading, beating, air pressure, etc., and can
combine these basic techniques for massage.
Gravity-free design
According to the principle of weightless massage, the back, buttocks and legs are tilted synchronously, and the
weight of the body is absorbed by the buttocks to relax the legs and back properly, and the body pressure is
properly released, giving you a massage feeling of entering a "weightless" state.
Preparation before use
Features
Please turn on the power before use
After use, please cut off the power
Power InputON/OFF
Power Plug
Power Cord Power Switch
Move the scroll wheel
Chair components
Pillow
Storage Box
Armrest
Backrest Pad
Electric Assembly
Armrest
Airbags
Hip Airbags
Cushion
Legrest
Control
Panel
Speaker
Shoulder Airbags
New appearance design
It adopts an ergonomic structural design, and the overall appearance is generous.
Beautiful leg frame safety patent design
The lifting of the beautiful leg frame is not restricted by the movement of the telescopic motor and can be
turned at any time.
The whole body air pressure massage feels three-dimensional
The massage feels stronger and deeper, providing you with a super enjoyment, covering a wider range from
the legs, buttocks, waist, to hands and head.
Zero space design
The unique structural design makes the home layout more space-saving.
Various massage techniques
The massage chair has a variety of techniques such as massage,kneading, beating, air pressure, etc., and can
combine these basic techniques for massage.
Gravity-free design
According to the principle of weightless massage, the back, buttocks and legs are tilted synchronously, and the
weight of the body is absorbed by the buttocks to relax the legs and back properly, and the body pressure is
properly released, giving you a massage feeling of entering a "weightless" state.
Remote controller buttons
Remote controller buttons
Features
In the power-on state,by pressing the manual button,there are five manual modes switchable
with different icon shown on the screen accordingly.
Under the first press: Kneading function
Under the second press: Knocking function
Under the third press: Kneading & Knocking function
Under the fourth press: Finger simulation function
Under the fifth press: Kneading & Knocking function synchronously.
Manual Button:
Full back mode:The mechanical massage head will move on the full back area.
Upper back mode:The mechanical massage head will focuse on moving on the upper back
area.
Lower back mode:The mechanical massage head will focuse on moving the lower back area.
Note: Under lower back mode,press again the location button,Target function will turn off
and operation circle is repeated like this.
Target Button:
In the power-on state, press the automatic button to switch between the three automatic
massage modes
Under mode 1,the whole body massage mode will turn on and “Whole” icon will be shown on
the screen;
Under mode 2,the cradle massage mode will turn on and "Cradle" icon will be shown on screen;
Under mode 3,the sleeping massage mode will turn on and "Sleep" icon will be shown on screen.
Note: 1.Each automatic programme is default at working 15 mins.After that,the massage head
will return to initial status while the massage chair doesnot.
Auto Button:
1. In the standby state, press the power button, the remote controller emits three beeps, the power
button indicator light is always on, the lying angle of the massage chair is automatically adjusted to
the zero gravity state, and the automatic massage mode is turned on by default ( one).
2. In the power-on state, press the power button, the indicator light flashes quickly, the massage
action stops, the massage chair manipulator and the lying angle are automatically reset to the
initial state, the power indicator light changes to red breathing and flashes, and the massage
chair enters the standby state.
Note: When the power indicator is flashing quickly, the remote controller cannot perform other
operations.
On/Off Button ( ):
In the massage state, press the emergency stop button, the indicator light turns red, the
massage chair enters the pause mode, and all massage functions are suspended; press the
emergency stop button again, the indicator light goes out, and the massage chair resumes
massage work.
Pause Button ( ) :
AUTO
M
a
n
u
e
l
l
S
t
ä
r
k
e
L
u
�
Heating
Knead Knock Air
CradleWhole
Sleep
B
e
r
e
i
c
h
Legrest
Electric Assembly
Backrest
Reset position
Moving method
As shown in the figure, unplug the power cord from
the plug, put it on the massage chair and store it,
and lift the front section of the massage chair to
move it.
Restore the massage chair
Restore the backrest and leg rest to their original
positions
Press the backrest up key button to raise the
backrest and the legrest will automatically lower.
Do not store in damp or direct sunlight
Clean the machine first, and then place it in a dry
and dust-free place.
Do not use the massage chair in an environment
with too much dust, oil, humidity or smoke.
Do not expose the massage chair to high
temperature, humidity, sun exposure and
corrosive gas/liquid environment for a long time.
Please keep it under the following conditions:
Temperature: 0℃-40℃
Humidity: (no condensation) 30%RH-85%RH.
1. After using the machine, if there are stains on the machine, please wipe it with a damp cloth
soaked in neutral detergent, then wipe with a damp cloth dampened with clean water, and then wipe
with a dry cloth.
2. Extend the life of the machine (please let the machine rest for 15 minutes after 60 minutes of use)
3. After each use, reset the backrest and leg rest of the massage chair.
4. The beautiful leg rest should be handled gently, do not press, sit, or step on it.
1. Please soak the soft cloth in the diluted neutral
detergent, and then wring the cloth firmly.
2 Wipe the dust on the machine with a wrung cloth, and
finally wipe it with a clean dry cloth.
Method: According to the material of the surface fabric, the maintenance method is different.
Please confirm the material of the fabric before performing maintenance. Please wipe it with a
soft dry cloth every day (do not let chemicals such as petroleum spirit, alcohol or thinner drop on
the massage chair) otherwise it will cause the chair's shape to be deformed and the leather
cover to deteriorate. After dampening a soft cloth with warm water and a suitable detergent,
wring it dry, wipe it with a tap, and then gently wipe it with a dry cloth, and let it dry naturally. (Do
not use rapid drying method for drying).
Steps: Please follow the above method to wipe the following parts
1. Pillow 2. Back cushion 3. Backrest holster 4. Seat cushion holster 5. Beauty leg holder holster
When performing maintenance and cleaning, first turn off the power switch and pull out the
power plug from the socket.
Notice after use
Remote controller buttons Maintenance and storage
In the power-on state,press the HEAT button,then heating treatment function is on.Indicator red
color will be shown ON/FF accroding to HEAT function opening or closing
Heat Button ( ) :
Place of custody
Storage method
Daily maintenance
Machine (handrail part, rear cover part)
Massage chair maintenance methods and steps
warning
In the power-on state, press the air pressure key, the massage chair enters the manual massage
mode, and the air pressure function can be turned on or off, and the corresponding icon will be
shown on screen.
Air Button
Lift up ( ) / Lie down ( ) :
In case of power on,you could manually adjust the angle of massage chair by Lift up / Lie down
button.
You could manually adjust massage position by back UP or Down button.
Back Up ( ) / Down button ( ):
Strength Button:
Under manual mode,by pressing the Strength button,you could enjoy great joy from different
strength under Kneading,Knocking or mixed Kneading & Knocking.
Table of contents
