User Guide and Parts List
UV LEAK LOCATOR KITS
53312
53100-C
53518-UV
53515

3
2 3
DYE INJECTION INSTRUCTIONS
(1)
(2)
(3)
(4)
(4)
(1)
(2)
(3)
(4A)
Disposable
Cartridge Type
Injector (2 oz)
53223
Mini Disposable
Cartridge Type
Injector (1 oz)
53809
(1)
(2B)
Refillable
Cartridge Type
Injector (2 oz)
53123
PLEASE USE CAUTION!!
• When injecting dye into a pressurized system, ALWAYS
wear safety glasses and gloves!
• Never breathe refrigerant vapor!
• Never use the UV light without wearing the UV glasses!
• Lamp surfaces will get hot very quickly.
DO NOT TOUCH THE LENS!
A. PURGING AIR FROM THE HOSE ASSEMBLY
It is important to eliminate any air in the hose before injecting dye
into the A/C system. (This process is necessary only once for the
setup).
Purging Disposable Cartridge Type Injector
• Hold the cartridge (2) upward while unscrewing the cap. Snap
the hose assembly (3) onto the cartridge, and coupler (4) or
(4A) to the hose assembly.
• While holding the assembly upward, attach the handle (1) to
the bottom of the cartridge by turning it clockwise. Continue
turning while dye enters the hose and pushes the air up. Use
a pen to press the depressor of the coupler (4) to release the
air if necessary. Repeat this process as needed until dye
appears at the coupler’s end.
Purging Refillable Cartridge Type Injector
• Hold the dye injector (upward while unscrewing the cap/hose
assembly (2B). Turn the handle of dye injector (1) counter
clockwise all the way before filling. Fill the injector with dye.
Replace cap/hose (2B), tightening securely and attach coupler
(4) to the hose assembly.
• While holding the assembly upward, start turning the handle
(1) clockwise. Continue turning as dye enters the hose and
pushes the air up. Use a pen to press the depressor of the
coupler (4) to release the air, if necessary. Repeat this
process as needed until dye appears at the coupler’s end.
B. INJECTION
1. Turn the A/C system and engine off!!
2. Connect injector to the low side service port of A/C system.
Hold body of injector. Use (I) starting line on handle end as a
guide. Turn handle clockwise to inject 1 application of dye.
(Approximately 1 to 1 1/4 turn(s) for Concentrated Dye)

2 3
2
Dye Application Chart
AUTOMOTIVE
1 Application per system
(for a system using up to 10 oz. [300 ml] of
lubricant)
HVAC
1 Application per system
(for a system using up to 7 lbs. [3.2 kg] of
refrigerant)
3. Disconnect injector from the system and clean any excess
dye left around the service port.
LEAK DETECTION USING A UV LAMP
A. Turn Engine and A/C system on.
B. Allow dye to circulate throughout system.
C. Connect UV lamp to power. (If using rechargeable UV Light,
make sure the battery is fully charged). SEE CHARGING
INSTRUCTIONS!!
D. WEAR PROTECTIVE GLASSES!!
E. Do not use lamp near flammable materials, liquids or gases.
F. For 53012 and 53312 UV lights only: Never use lamp for more
than 3 minutes at a time. Allow lamp to cool between uses, 3
MINUTES ON, 5 MINUTES OFF. If used continuously, you may
damage glass lens.
G. Turn lamp on. Search for a bright green/yellow glow where the
system is leaking. Clean the area around leak after repair.
