Master Culinary | Air Fryer Oven Model: A-1700
Air Fryer Oven
Model A-1700
12.6 QT
Extra Large Capacity
Owner’s Manual

2 Master Culinary | Model: A-1700
Welcome totheAirFryingRevolution
The Master Culinary Air Fryer Oven is an all-in-one unit
that air-fries, roasts, grills and bakes all your favorite foods
with little or no oil
We All Love Fried Food.
Crispy fried chicken, French fries, coconut shrimp, chicken parmesan, spicy hot wings…
The list goes on and on.
Those tasty delights have become part of our everyday diet.
The problem is that it was impossible to get that great, crispy-fried crunch and flavor without
frying in deep fat or oil.
Our culinary team of chefs and engineers has perfected a cooking system that virtually eliminates
the oil from the cooking process.
Messy, unhealthy oil is replaced with Turbo Cyclonic Air that surrounds your food, cooking it to
crisp and juicy perfection.
Not only cooks your favorite fried foods, but also broils and bakes many other favorites like
“air fried” burgers, calzones, and doughnuts.
It couldn’t be easier, 12 “one touch presets” set the time and temperature for some of your favorites
like crispy shrimp, fries and southern style chicken.
Plus a Dehydrator preset that preserves fresh fruits and other foods for future use.

3Master Culinary | Model: A-1700
TableofContent
Important safeguards
4
Parts & Accessories
6
The Digital Control Panel
7
Cooking Presets
8
Adjusting Time and Temp Manually
9
Mobile Recipe App & Recipe Cookbook
9
Manual Setup Cooking Chart
10
Cooking With The Air Fryer Oven
11
Safety Features
13
Cleaning & Maintenance
13
Caring For The Environment
14
Troubleshooting
15
Frequently Asked Questions
16
Warranty Information
17
Contact Information
17

4 Master Culinary | Model: A-1700
ImportantSafeguards
• NEVER IMMERSE the Main Unit Housing,
which contains electrical components and
heating elements, in water. Do not rinse under
the tap.
• TOAVOIDELECTRICALSHOCK,DO NOTput
liquid of any kind into the Main Unit Housing
containing the electrical components.
• This appliance has a polarized plug (one
blade is wider than the other). To REDUCE
THERISK
OF ELECTRIC SHOCK, this plug is intended to fit
into a polarized outlet only one way. If the plug
does not fit fully into the outlet, reverse the plug. If
it still does not fit, contact a qualified electrician.
DO NOT ATTEMPT to modify the plug in any way.
• MAKE SURE the appliance is plugged into a wall
socket. Always make sure that the plug is
inserted into the wall socket properly.
• Toprevent food contact with the interior upper
screen and heat element, DO NOT
OVERFILL the Rotating Mesh Basket.
• DO NOT COVER the Air Intake Vent or Air
Outlet Vent while the Air Fryer Oven is
operating. Doing so will prevent even cooking
and may damage the Unit or cause it to
overheat.
• While cooking, the internal temperature of the
Unit reaches several hundred degrees
Fahrenheit.
TO AVOID PERSONAL INJURY, never place hands
inside the Unit unless it is thoroughly cooled down.
• This appliance is NOT INTENDED FOR
USE by persons with reduced physical,
sensory, or mental capabilities, or lack of
experience and knowledge, unless they
are UNDER THE SUPERVISION of a
responsible person or have been given
proper instruction in using the appliance.
This appliance is NOT INTENDED FOR USE
by children.
• When cooking, DO NOT PLACE the
appliance against a wall or against other
appliances.
Leave at least 5” free space on the back and
sides and above the appliance. Do not place
anything on top of theappliance.
• DO NOT USE this Unit if the plug, the power
cord, or the appliance itself is damaged in any
way.
• DO NOT PLACE the unit on stovetopsurfaces.
• If the power cord is damaged, YOU MUST HAVE
IT REPLACED by the manufacturer, its service
agent, or a similarly qualified person in order to
avoid hazard.
• Keep the appliance and its power cord OUT OF
THE REACH of children when it is in operation or
in the “cooling down” process.
• KEEP THE POWER CORD AWAYfrom hot
surfaces. DO NOT PLUGin the power cord or
operate the Unit controls with wet hands.
• NEVER CONNECT this appliance to an
external timer switch or separate remote-
control system.
• NEVER USE this appliance with an extension
cord of any kind.
• DONOTOPERATEthe appliance on or
near combustible materials such as
tablecloths and curtains.
• DONOTUSE the Air Fryer Oven for any
purpose other than described in this manual.
• NEVER OPERATEthe applianceunattended.
• When in operation, air is released through
the Air Outlet Vent. KEEP YOUR HANDS
AND FACE at a safe distance from the Air
Outlet Vent. Also avoid the air while removing
the fry pan from the appliance.

5Master Culinary | Model: A-1700
ImportantSafeguards
• Should the Unit emit black smoke, UNPLUG
IMMEDIATELYand wait for smoking to stop before
removing oven contents.
• When time has run out, cooking will stop but the
fan WILL CONTINUE RUNNING for one minute to
cool down the Unit.
• Always operate the appliance on a horizontal
surface that is level, stable, and noncombustible
Overheating Protection
Should the inner temperature control system fail,
the overheating protection system will be activated
and the Unit will not function. Should this happen,
unplug the power cord. Allow time for the Unit
tocoolcompletelybeforerestartingorstoring.
Electromagnetic Fields(EMF)
This appliance complies with all standards
regarding electromagnetic fields (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based
on scientific evidence available today.
• This appliance is intended for normal household
use only. It is not intended for use in commercial
or retail environments.
• If the Air Fryer Oven is usedimproperly
or for professional or semi-professional
purposes or if it is not used according to the
instructions in the user manual, the warranty
becomes invalid and we will not be held liable
for damages.
• Always unplug the appliance after use.
• Let the appliance cool down for approximately
30 minutes before handling, cleaning, or
storing.
• Make sure the ingredients prepared in this Unit
come out cooked to a golden-yellow color
rather than dark or brown. Remove burnt
remnants.
Electric Power
If the electrical circuit is overloaded with other
appliances, your new Unit may not operate
properly. It should be operated on a dedicated
electrical circuit.
INTENDED FOR HOUSEHOLD USE ONLY

6 Master Culinary | Model: A-1700
Parts & Accessories
1. Digital control panel
2. Main body
3. Door
4. Double safety glass window
5. Pull handle
6. Top heating tube
7. Protect cover
8. Top rack level
9. Middle rack level
10. Lower rack level
11. Micro-switch protection
12. Lower heating tube
13. Stirring connector
14. Air inlet & outlet, ceramic filter
15. Power cord and plug
16. Pizza tray 10 inches
17. Air flow wire rack
18. Stirring blade
19. High capacity frying pan
20. Chicken rack (for whole chicken)
21. Silicon heat-resistant gloves

7Master Culinary | Model: A-1700
The Digital Control Panel
22. Selected Temperature Display
23. Selected Time Display
24. Power ON/OFF
25. Menu button
26. Start/Pause button
27. Temperature setup button
28. Timer setup button
29. Timer & Temperature decrease button /
pre-set cooking programs browse left
30. Timer & Temperature increase button /
pre-set cooking programs browse right
31. Preheat function button
32. Stirring blade ON/OFF button
33. 12 pre-set cooking programs
(see more info on next page)
Use buttons 29 & 30 to browse the 12 pre-set cooking programs
Warning!
Never use the Wire rack (17) in air oven without the pizza tray (16) or the Fry Pan (19)
Always place the Pizza tray (16) or the Frying pan (19) under in the level under the Wire rack (17)
during cooking, so they collect the residue of the ingredients and extra oil.

8 Master Culinary | Model: A-1700
12 Presets Cooking programs
The air oven is equipped with 12 auto pre-set programs. With these programs you can easily cook different
types of food by selecting the right program.
1. Press the Power button to turn on the Air Fryer. You will hear a beep and the digital display will switch on.
2. Press the Menu button (25) to enter the 12 pre-set cooking programs.
3. Use buttons 29 & 30 to browse the 12 pre-set cooking programs.
4. When you selected the program, press the Start button (26).
Icon
Food Type
Temp (F)
Time (Min)
Suggested Weight
1
Frozen French
Fries
400
20
Up to 2 LB
Use the frying pan with the Stirring blade
2
Fish/Seafood
355
13
2 items –1 LB each
3
Hamburger
355
13
4 items –0.5 LB each
4
Frozen Pizza
320
9
10 inch Pizza
5
Steak
355
11
2 items –1 LB each
6
Frozen Chicken
Drumsticks
355
13
2 LB (about 6 pieces)
7
Fresh Potatoes
400
25
1 LB
Use the frying pan with the stirring blade
8
Fried Chicken
355
25
3 LB
Use the frying pan with the chicken rack
9
Cakes
355
38
1 LB
10
Cookies
320
18
up to 20 pieces
11
Vegetable
Dehydrator
150
210
(3.5 hours)
1 LB
Use the frying pan with the stirring blade
12
Defrost
145
5
1 LB

9Master Culinary | Model: A-1700
Adjusting Time and Temp Manually
The timer and temperature can be adjusted manually at any point, before or even during cooking.
This can be done after selecting a pre-set program or when you want to use the Master Culinary Air Fryer
Oven using manual setup (see recommended cooking chart in the following page).
Manually adjusting the temperature:
1. Press Temperature control button (27), the temperature display (22) will start blinking.
2. Press the Temperature increase button (30) to raise the temperature.
Or Temperature decrease button (29) to lower the temperature.
3. Press the start button (26) to set the selected temperature and resume cooking.
Manually adjusting the timer:
1. Press Timer control button (28), the temperature display (23) will start blinking.
2. Press the Timer increase button (30) to increase the time.
Or Timer decrease button (29) to decrease the time.
3. Press the start button (26) to set the selected timer and resume cooking.
Our Mobile Recipe App & Recipe Cookbook
Download the free Master Culinary mobile app (for both for iOS and Android) and start cooking like a
chef.
And also make sure to look at the free color recipe book that you received with the air fryer oven.
With Hundreds of delicious recipes and step by step instructions, nutritional and calorie values,
Chef's tips and much more -
Our Mobile Recipe App & Recipe Cookbook Will help you make the most out of your product.

10 Master Culinary | Model: A-1700
Manual Setup Cooking Chart
As you become more familiar with the Master Culinary Air Fryer Oven cooking process
you may adjust these settings to suite your own personal tastes.
This table will help you select the correct temperature and time for best results.
*Add 3 minutes to cooking time when starting with a cold appliance.
Keep in mind that these settings are indications. As ingredients differ in origin, size, shape and brand, we
cannot guarantee the best settings for your ingredients.
Food Item
Min - Max
Time*
Temperature
Comments
Thin Frozen Fries
1 1/4 - 3 cups
15 - 16 min.
400° F (200° C)
Thick Frozen Fries
1 1/4 - 3 cups
20 min.
400° F (200° C)
Homemade Fries
1 1/4 - 3 1/4 cups
10 - 16 min.
400° F (200° C)
Add 1/2 tbsp. oil
Homemade Potato Wedges
1 1/4 - 3 1/4 cups
18 - 22 min.
360° F (182° C)
Add 1/2 tbsp. oil
Homemade Potato Cubes
1 1/4 - 3 cups
12 - 18 min.
360° F (182° C)
Add 1/2 tbsp. oil
Hash Browns
1 cup
15 - 18 min.
360° F (182° C)
Potato Gratin
2 cup
15 - 18 min.
400° F (200° C)
Steak
1/4 - 1.1 lb.
8 - 12 min.
360° F (182° C)
Pork Chops
1/4 - 1.1 lb.
10 - 14 min.
360° F (182° C)
Hamburger
1/4 - 1.1 lb.
7 - 14 min.
360° F (182° C)
Sausage Roll
1/4 - 1.1 lb.
13 - 15 min.
400° F (200° C)
Chicken Drumsticks
1/4 - 1.1 lb.
18 - 22 min.
360° F (182° C)
Chicken Breast
1/4 - 1.1 lb.
10 - 15 min.
360° F (182° C)
Spring Rolls
1/4 - 3/4 lb.
15 - 20 min.
400° F (200° C)
Use oven-ready
Frozen Chicken Nuggets
1/4 - 1.1 lb.
10 - 15 min.
400° F (200° C)
Use oven-ready
Frozen Fish Sticks
1/4 - 1.1 lb.
6 - 10 min.
400° F (200° C)
Use oven-ready
Mozzarella Sticks
1/4 - 1.1 lb.
8 - 10 min.
360° F (182° C)
Use oven-ready
Stuffed Vegetables
1/4 - 1.1 lb.
10 min.
320° F (160° C)
Cake
1 1/4 cups
20 - 25 min.
320° F (160° C)
Use baking tin
Quiche
1 1/2 cups
20 - 22 min.
360° F (182° C)
Use baking tin/oven dish
Muffins
1 1/4 cups
15 - 18 min.
400° F (200° C)
Use baking tin
Sweet Snacks
1 1/2 cups
20 min.
320° F (160° C)
Use baking tin/oven dish
Frozen Onion Rings
1 lb.
15 min.
400° F (200° C)

11 Master Culinary | Model: A-1700
Cooking with the Air Fryer Oven
Before using the Air Fryer Oven for the first time
1. Place the appliance on a stable, level, horizontal and heat resistant surface.
2. Remove all packing materials, labels and stickers.
3. Wash all parts and accessories used in the cooking process with warm soapy water.
4. Wipe the inside and outside of the oven with a clean moist cloth.
NOTES:
- Only the accessories are dishwasher safe. Never wash or submerge the cooking unit in water.
- When using this unit, never fill any cooking vessel with oil or liquid of any kind.
General Cooking instructions
1. Place the ingredients on an Air Flow Rack, or in the Fry Pan.
2. Put the Air Flow Rack or the Fry Pan into the unit and shut the oven door.
3. When food is in place, Press the Power Button once.
4. Select a preset function (page 8) or manually set the Temperature andthen the Time (page 9).
5. Press the "start" button to begin the cooking cycle.
6. If selecting manual own temperature and time, please refer to the Cooking Chart on page 10, for
recommended Time and Temp.
Youmay open the oven door to view the food at any time during the process to check the progress.
Using the frying pan and the stirring blade
1. Place the frying pan (19) and on a stable, horizontal, flat surface.
2. Install the stirring blade (18) into the frying pan(19)
3. Put the food into the frying pan up to the "Max" mark

12 Master Culinary | Model: A-1700
Cooking with the Air Fryer Oven
Using the Chicken rack
The extra-large Master Culinary Air Fryer Oven allows you to cook whole chicken at once.
1. Place the frying pan (19) and on a stable, horizontal, flat surface.
2. Install the stirring blade (18) into the frying pan(19)
3. Put the chicken rack (20) over the stirring blade as shown below
4. Place the chicken on the rack and enter the frying pan into the air fryer oven.
5. Select "Fried Chicken" from the auto pre-set programs (page 8) and press the Start button.
From time to time - Check the chicken cooking phase through the glass window;
You can adjust the cooking time and temperature to have the result you like.
Cooking Tips
• Foods that are smaller in size usually require a slightly shorter cooking time than larger ones.
• “Flipping” or turning smaller sized foods halfway through the cooking process, assures that all the pieces
are evenlyfried.
• Misting a bit of vegetable oil to fresh potatoes is suggested for a crispier result.
When adding a little oil, do so just before cooking.
• Snacks that normally cooked in an oven can also be cooked in the Master Culinary Air Fryer Oven.
• Use pre-made dough to prepare filled snacks quickly and easily.
Pre-made dough also requires a shorter cooking time than homemade dough.
• Place a baking tin or oven dish in the Master Culinary Air Fryer Oven when baking a cake or quiche.
A tin or dish is also suggested when cooking fragile or filled foods.
• Youcan use the Master Culinary Air Fryer Oven to reheat various types of food.
Simply set the temperature to 300° F (150° C) for up to 10minutes.

13 Master Culinary | Model: A-1700
Safety First!
Every unit of Master Culinary Air Fryer Oven undergoes rigorous testing and has multiple
safety mechanisms in place, to give you and your family the peace of mind you need.
Overheating protection
The air oven comes with an overheating protection sensor. The safeguard is activated once the temperature
reaches its threshold. If this happens, the machine will shut down automatically.
To reuse the air fryer oven - take the plug from the socket, and allow the appliance time to cool down for
at least one hour.
Open door protection
If the door is opened when the air oven is working, the appliance will stop heating, the fan and stirring motor
will also stop working, and time will pause.
When the door will be properly closed the appliance will resume working and the timer countdown will
continue.
Automatic Cool down protection
When the selected time is up you will hear a beep, and then the air fryer oven will stop heating;
but the fan will continue running for one more minute to cool down the machine.
The air oven will switch to its standby mode after that one minute.
Cleaning&Maintenance
Clean the Master Culinary Air Fryer Oven and its loose parts thoroughly after each use.
1. Press the on/off button (24) and take the plug out of the socket.
2. Let the appliance cool down.
3. Take all the accessories from the appliance.
4. Remove remaining food parts by wiping them off with absorbent paper towels.
5. Clean the accessories thoroughly with hot water, dish-washing soap and a non-grating sponge.
The accessories can also be cleaned in a dish-washing machine. Dry them off thoroughly after cleaning.
6. Clean the housing and interior cavity with a moist towel, if need be with some dish-washing soap added to
it. Dry it off thoroughly after cleaning.
7. Reassemble the parts.
8. Store the appliance in a dry place.
CAUTION:
Verify that the appliance is not connected to the power supply before you clean it.
Never use corrosive or scouring cleaning agents or sharp objects (such as knives or hard brushes) to
clean the appliance.
Never immerse the heating element unit in water or another liquid and never place it under flowing water.

14 Master Culinary | Model: A-1700
Caring For The Environment
Please help us protect the environment.
Dispose of packaging material, such as plastic and boxes, in the appropriate waste containers.
When this product reaches the end of its life do not dispose of it by putting it in a dustbin;
hand it in at a collection point for the reuse of electrical and electronic equipment.
Please refer to the symbols on the product, the user’s instructions or the packing.
The materials can be re-used as indicated.
Your help in the re-use, recycling or other means of making use of old electrical equipment
will make an important contribution to the protection of the environment.
This marking indicates that this product should not be disposed with other household wastes.
To prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources.
To return your used device, please use the return and collection systems or contact the retailer
where the product was purchased.
They can take this product for environmentally safe recycling.
Safety Warning
• NEVER put anything on top of theappliance.
• NEVER cover the air vents on the top andback of the cooking Unit.
• NEVER fill any cooking vessel with oil or liquid of any kind. This Unit cooks solid food only.
• NEVER immerse the heating element unit in water or another liquid and never place it under flowing
water.
Unit Specifications
Model Number
Supply Power
Rated Power
Function
Temperature
Display
A-1700
AC 120V
60Hz
1700W
Rotation
150° F - 400° F
(65° C - 200° C)
LED Touch
Screen

15 Master Culinary | Model: A-1700
Troubleshooting
Problem
Possible Cause
Solution
The Master Culinary Air
Fryer Oven does not
work
The appliance is not plugged in.
You have not turned the Unit on, by
setting the preparation time &
temperature
Plug power cord into wall socket.
With basket in place, set the Temperature
and Time. Check that door is closed.
Food is not cooked
a. The oven overloaded
b. The temperature is set too low.
a. Use smaller batches for more even frying
b. Raise Temperature and continue cooking
Food is not fried evenly
Somefoodsneedtobe"turned"
during the cooking process.
Remove the stirring blade and install it properly,
check from the window and make sure it is rotating
Black smoke coming from
Unit (with burned smell)
Oil is being used. Accessories have
excess grease residue from previous
cooking.
Wipe down to remove excess oil.
Clean the frypan after each use.
White smoke coming
from Unit
Greasy ingredients or too much oil
being used.
When Cooking greasy ingredients in the air oven
the grease will drain into the Cooking Pan. The
oil produces white smoke and the pan may heat
up more than usual. This does not affect the
appliance or the end result.
French fries are not
fried evenly
a. Wrong type of potato is being used.
b. Potatoes not rinsed properly during
preparation.
a. Use fresh, firm potatoes.
b. Use cut sticks and pat dry to remove excess
starch.
Fries are not crispy
Raw fries have too much water.
a. Dry potato sticks properly before misting oil.
b. Cut sticks smaller.
c. Add a bit more oil.
Error Messages
E1 or E2
System Malfunction
Contact customer support (see page 17)
Stirring Blade does
not rotate
Stirring Blade button is OFF
The Stirring Blade will rotate automatically when
selecting preset programs 1 (Frozen French
Fries) or 8 (Fried Chicken). To activate it in other
programs or for manual setup, press the Stirring
Blade button (32) after pressing the Start button.

16 Master Culinary | Model: A-1700
Frequently Asked Questions
1. Can I prepare foods other than fried dishes
with my Air FryerOven?
Youcan prepare a variety of dishes including
steaks, chops, burgers, and baked goods.
See the Master Culinary Air Fryer Oven Recipe
book.
2. Is the Master Culinary Air Fryer Oven good
formaking or reheating soups andsauces?
Never cook or reheat liquids in the Air Fryer
Oven.
4. Whatdo I do if theUnitshutsdownwhilecooking?
As a safety feature, the Air Fryer Oven
has an Auto Shut-Off device that prevents
damage from overheating. Unplug and allow the
Unit t ocooldown.Plugbackin andrestartwith
the PowerButton.
5. Does the Unit need time to heatup?
If you are cooking from a “cold start”, add 3 minutes
to the cooking time to compensate. Or you can
select the “Preheat Function” and preheat the air
fryer 5 minutes before starting to cook.
6. Is it possible to shut off the Unit at any time?
Press the Power Button once or open the door.
7. CanI check thefoodduring thecooking
process?
Youcan remove the fry pan at any time while
cooking is in progress. During this time, you can
“flip” the contents on the Air Flow Racks
if needed to ensure even cooking. Time
and temperature will resume where you left off.
8. Is the Master Culinary Air Fryer Oven
dishwashersafe?
Only the accessories are dishwasher safe.
The Unit itself containing the heating coil and
electronics should never be submersed in
liquid of any kind or cleaned with anything
more than a hot, moist cloth or nonabrasive
sponge with
a small amount of mild detergent.
9. What happens if the Unit still does not work
after I have tried all the troubleshooting
suggestions?
Never attempt a home repair. Contact customer
support (see page 17), and follow the
procedures set forth by the warranty.
Failure to do so could render your warranty null
and void.

17 Master Culinary | Model: A-1700
Manufacturer’s 180 Day Limited Warranty
The manufacturer warrants that all parts and components are free of defects in materials
and workmanship for 180 days. This warranty is valid only in accordance with the
conditions set forth below:
1. The warranty extends only to the original consumer purchaser and is not
transferable. In addition, proof of purchase must be demonstrated.
2. This limited warranty is the only written or express warranty given by the manufacturer.
Any implied warranty of merchantability or fitness for a particular purpose on this
product is limited to the duration of this warranty. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.
3. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
For Free Extended 365 day warranty
Register your product at
www.masterculinary.net
We take great pride in the design and quality of our
Master Culinary Air FryerOven
It was designed and built using 2018 product technology,
and manufactured to the highest quality standards.
Should you have any problem, we are here to help you.
Please Contact us at www.masterculinary.net
