TP2012 Master Equipment PolyPro Grooming Tub
Assembly Instructions
9). Attach the Hose (K) to the bottom of the Drain (F)
(underneath the tub base) and screw it to secure.
7). Place the Strainer (I) into the Drain (F) on the floor of the tub.
6). Screw the Locking Ring (G) overtop to secure.
5). Underneath the base of the tub, place the Washer (H) over the
bottom of the Drain (F).
1). Begin by turning the Base (B) upside down. Attach the Legs (A) to the Base (B) of the tub. Line up the
Leg with the base by using the groove. Attach the Leg securely to the body using a Phillips head
screwdriver (not included) and Screws (M) included. Each leg has three screw attachments. Repeat this
step on each of the four legs.
Parts List
(A) Legs (4)
(B) Base (1)
(C) Support Grooming Arms (3)
(D) Subsidiary Grooming Arm (1)
(E) Major Grooming Arm (1)
(F) Drain (1)
(G) Locking Ring (1)
(H) Washer (1)
(I) Strainer (1)
(J) Drain plug (1)
(K) Hose (1)
(L) Door (1)
(M) Screws (12)
(N) Ramp (1)
Tools Requried:
Phillips head screwdriver
AB
C
D
E
F
H
I
J
K
L
M
G
2). Stand the tub up on its feet.
3). Place the Drain (F) into the
hole in the floor of the tub.
4). Screw in the Drain (F) to secure it to the tub.
8). Place the Drain Plug (J) into the Drain (F) on the floor of the tub.
N

15). Slide the Door (L) into the groove on the Base (B) to secure it.
14). Lift the grooming arm structure and fit the base of each of the Support Grooming Arms (C) into the three arm
holes on the top of the tub base.
13). Attach the three Support Grooming Arms (C) to the Major Grooming Arm (E) and Subsidiary Grooming Arm (D).
12). Re-attach the fastener you took off of the
Major Grooming Arm (E) and tighten it to
secure it to the end of the arm. Ensure that the
fasteners with grooming loop holders have the
loop holders pointing downwards for easy
loop attachment.
11). Find the Subsidiary Grooming Arm (D) and slide it onto the
Major Grooming Arm (E). Slide it to the middle of the Major
Grooming Arm (E) and then secure it by tightening the fastener.
10). Place the Support Grooming Arms (C), Subsidiary Grooming Arm (D) and Major Grooming
Arm (E). The Major Grooming Arm (E) has two fasteners – one on either end. Loosen one of the
fasteners and slide it off the Major Grooming Arm (E).
LIMITED WARRANTY
This Master Equipment™ PolyPro Grooming Tub is warranted against defective material or workmanship for one year
from the date of purchase. Any Master Equipment™ product that is determined to be defective in material or workmanship
during the warranty period will be replaced without cost to the purchaser for parts or labor. Please contact
PetEdge Customer Service at 1-800-638-5754 regarding any defective product. PetEdge will not be liable under
this warranty for any defect, failure or malfunction of this product caused by normal wear, abuse, misuse, unauthorized
adjustments or repairs. PetEdge will not be liable for any incidental or consequential damages of any type. Any implied
warranty is limited to the one-year period provided in this express warranty. Some states do not allow limitations on
how long an implied warranty lasts or exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. Warranty is void if product has been modified in any manner,
repaired by anyone other than PetEdge or has been subject to unreasonable use. Warranty is valid in the United States.
________________________________:esahcruPetaD
Manufactured for / Fabricado para / Fabriqué pour
©Tops Pet Products, Beverly, MA 01915
Made in / Hecho en / Fabriqué à China
TP2012 Master Equipment PolyPro Grooming Tub
16). Fully assembled with Ramp (N).
