Masterplug BDCPL30 User manual

●x2 Fixing Screws
●x2 Rawl Plugs
●Double Sided Sticky Pad
●Push Button Battery (3V CR2032)
Accessories
Installation:
4. Pull plastic tab from under battery to power the push button.
Push
Button
Push Button Receiver
CR2032 Battery
Included
Speaker
Volume
Melody
Control Standard UK
3 Pin Plug
1. First, identify a suitable area for the push button to be positioned. Ideally, this should be sheltered
from rain or excess heat. It would be recommended that the button is tted to the door frame
itself, so you are able to screw directly into the woodwork, making the installation simple.
2. Place a small athead screwdriver into the slotted hole and gently twist to remove push button
back.
3. Offer the push button backing up to the wall and drill holes. If tting to masonry, use a 6mm drill
bit, as per the depressions and securing by using the supplied rawl plugs and screws. If tting
directly to the woodwork, use a 2mm drill bit and screw directly into frame or use the provided
sticky pad.
5. Ret the push button to the secured backing by offering up the button of the push button and
gently pushing back together.
6. Identify a suitable position for the door chime within the recommended range and plug in.
The socket is easily accessible. The door chime and push button is only suitable for mounting at
heights <2m.

Radio Equipment Directive (RED)
2014/53/EU
Article 3.1(a) Health
EN62479:2010
EU Directives Conformas to
2011/65/EU and its amendment
2015/863/EU (ROHS)
ROHS 2011/65/EU and its amendment
2015/863/EU
2009/125/EC ERP ERP:
EN 50564:2011
Article 3.2 Radio:
EN 300 220-1 V3.1.1 (2017-02)
EN 300 220-2 V3.1.1 (2017-02)
Article 3.1(b) EMC:
Draft EN 301 489-1 V2.2.0 (2017-03)
EN 301 489-3 V2.1.1 (2019-03)
Article 3.1(a) Safety:
EN62368-1:2014+A11:2017
This product belongs to receiver category 2
: Caution
Warning: Risk of explosion if the battery is replaced by an incorrect type.
Push Button
This product contains a coin/button cell battery and if ingested can cause severe chemical burns. If the battery has been ingested, please
seek medical advise immediately. In just 2 hours a digested battery can lead to death. Keep new and used batteries away from children. If
the battery compartment does not close securely, please stop using the product.
IP44: Protect from ingress of solid object which diameter greater than 1mm and splash water proof.
Direct current (DC Power)
Push Button Battery: 1 x 3V CR2032
Push Button: IP44
Melody Count: 2
Sound Level: 80dB
Technical Data
Chime Battery: 220-240V~
Radiated Power: 8mW
Temperature: Max. 40°c
Range: 30M (open area)
Frequency: 433.92MHz
Unique Code Selection
The door chime and push button will be paired straight of the box, with 1 out of 1 million unique codes to prevent interference with another
door chime. If the door chime does not sound, please refer to the ‘Pairing Additional Push Buttons & Door Chimes’ section.
Chime Selection
Single press the melody button on the left of the door chime to lter through the two different options – ‘Ding-dong’ and ‘Westminster’ chimes.
Volume Selection
Single press the volume selection button to lter through the four different volumes settings - mid (default) > high > mute > low
Pairing Additional Push Buttons & Door Chimes
To pair an additional push button to the door chime, unplug or switch off the socket to power down the door chime. Re-insert or switch on the
chime and press the push button after the rst ‘beep’ and before the second double ‘beep’. (A maximum of 16 push buttons can be paired).
Reset Door Chime
Press and hold the melody button for 10 seconds or until you hear a triple ‘beep’ to reset the door chime.
Door Chime Not Working?
1. Ensure new batteries are being used in both the door chime and push button
2. Check if the battery polarity in the door chime and push button is correct
3. Objects and materials, such as walls, doors, ceilings and furniture, could be blocking the signal. Try moving the chime closer to the push
button. Maximum distance is based on an open area environment. Any walls, doors or ceilings may reduce the operating range. Door chime
is to be used indoors only.
4. Wireless interference can be caused by external wireless devices, such as alarms and adaptors. Try moving away from these devices.
5. Door chime and push button are not paired-please refer to the ‘Pairing Additional Push Buttons’ secion.
6. Ensure the socket is switched on.
IMPORTANT
This product does not consist of any serviceable parts and should not be repaired. The device should not be operated by persons who have
a lack of experience or knowledge in using such products. People who have a reduced physical, sensory or mental capability should be
supervised or given instruction when operating. Childen should be supervised, so that they do not play with the device.

Masterplug Help Line Visit our website at
www.masterplug.com
Suppied by
Masterplug Ltd
Luceco PLC Stafford Park 1 Telford TF3 3BD ENGLAND
(EU) Luceco SEC/Bobinadora 1-5 08302 Mataró SPAIN
EU Declaration of Conformity
Applicant: Luceco PLC
Address: Luceco Distribution Centre, Stafford Park 1, Telford Shropshire, United Kingdom
(EU) Luceco SEC/Bobinadora 1-5 08302 Mataró SPAIN
Description: Wireless door chime
Model: BDCPL30
Type / batch or serial number range 20W27 – 21W27
We declare under our sole responsibility that the products above are in conformity with the essential requirements of the following:
Signed for and on behalf of: David Cleaver
Senior Product Manager
Place of Issue: Stafford Park 1, Telford Shropshire, United Kingdom
Date of Issue: 16/Mar/2020
