Matrix G7-S34 User manual

1
Table of Contents
CHAPTER1: Serial number location.................................................................................... 2
CHAPTER2: Important Safety instructions
2.1 Important Safety Information .................................................................................................... 3
2.2 Check for Damaged Parts......................................................................................................... 3
CHAPTER3: Preventative Maintenance
3.1 Preventative Maintenance Checklist.......................................................................................... 4
3.2 Repetition Counter Info.............................................................................................................. 4
CHAPTER4: Product specification& warranty information
4.1 G7-S34 Seated Row.................................................................................................................. 6
CHAPTER5: Assembly instructions
5.1 G7-S34 Seated Row Assembly Instructions.............................................................................. 7
CHAPTER6: Troubleshooting
6.1 Troubleshooting - Repetition Counter Issues............................................................................ 12
6.2 Troubleshooting - Incremental Weight Pin Issues..................................................................... 14
6.3 Troubleshooting – Arms are uneven......................................................................................... 15
6.4 Troubleshooting - Weight Stack Pin Issues............................................................................... 16
6.5 Troubleshooting – Cable is Failing off a Pulley or CAM ……………………………………………17
6.6 Troubleshooting – Cable Jacket is Failing...………………………………………….………………18
6.7 Troubleshooting – Repetition Counter Magnet Missing or Failing off.….……………………….…19
6.8 Troubleshooting – ROM Plunger or Pull Pins Do Not Move Easily………..………………….……19
6.9 Troubleshooting – Seat Loose or Will Not Spring Up…….………………….……………………....20
6.10 Troubleshooting – Seat Failing…………………………….………………….……………….….…..21
CHAPTER7: Part replacement Instructions
7.1 Testing the Unit ........................................................................................................................... 22
7.2 Aluminum Wing Replacement...................................................................................................... 22
7.3 Top Cover Replacement.............................................................................................................. 23
7.4 Repetition Counter Replacement................................................................................................. 24
G7-S34 Seated Row Service manual

2
7.5 Weight Stack Shroud Replacement............................................................................................. 25
7.6 Repetition Sensor Replacement.................................................................................................. 26
7.7 Incremental Weight Pin Replacement......................................................................................... 27
7.8 Weight Plate Replacement.......................................................................................................... 29
7.9 Weight Stack Pulley Assembly Replacement.............................................................................. 31
7.10 Hand Grip Replacement............................................................................................................ 32
7.11 Seat Pad Adjustment Handle Replacement……………............................................................ 32
7.12 Head Pad Replacement............................................................................................................ 33
7.13 Back Pad Replacement............................................................................................................. 33
7.14 Seat Pad Replacement.............................................................................................................. 34
7.15 Adjustable Tie Rod Replacement……………………………………………….………………….....35
7.15 Small Connecting Rod Replacement …………………………………………..………………….....36
CHAPTER1: Serial number location
The serial number is located at the bottom of the weight stack frame.

3
CHAPTER2: Important Safety instructions
2.1 Important Safety Information
It is the sole responsibility of the purchaser of Matrix Fitness Systems products to instruct all individuals,
whether they are the end user or supervising personnel on proper usage of the equipment.
PROPERUSAGE:
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative
that Matrix Fitness Systems equipment be used properly to avoid injury.
Keep hands and feet clear at all times from moving parts to avoid injury.
WARNING: Serious injury can occur on this equipment. Follow these precautions to avoid injuries.
1) Never allow children on selectorized strength equipment. Teenagers must be supervised at all times while
using this equipment.
2) All warnings and instructions should be read and proper instruction obtained prior to use.
3) Cease exercise if you feel faint or dizzy. Obtain a medical exam before beginning an exercise program.
4) Keep body, hair, clothing, and fitness accessories free and clear of all moving parts.
5) Inspect the machine before use. DO NOT use the machine if it appears damaged or inoperable.
6) Check to see that the selector pin is completely inserted into the weight stack.
7) NEVER use the machine with the weight stack pinned in an elevated position.
8) Never use dumbbells or other means to incrementally increase the weight resistance. Only use the means
provided directly from the manufacturer.
9) This equipment should only be used in supervised areas where access and control are regulated by the
owner.\
2.2 Check for Damaged Parts
1) DONOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts
supplied by Matrix Fitness Systems or your local Matrix Fitness Systems dealer.
2) MAINTAINLABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important
information. If unreadable or missing, contract Matrix Fitness Systems for a replacement.
3) SECUREEQUIPMENT: All equipment must be secured to the floor to stabilize and eliminate rocking or
tipping over. This must be performed by a licensed contractor.
4) MAINTAINALLEQUIPMENT: Preventative maintenance is the key to smoothly operating equipment as
well as keeping your liability to a minimum. Equipment needs to be inspected at regular intervals.
5) Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified
to do so. Matrix Fitness Systems will provide service and maintenance training at our corporate facility upon
request.

4
CHAPTER3: Preventative Maintenance
3.1 Preventative Maintenance Checklist
Preventative maintenance and daily cleaning will prolong the life and look of your Matrix Fitness Systems
equipment.
ACTION FREQUENCY
Clean Upholstery Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As eeded
Clean Grips As eeded
Clean Linear Bearing Guide Rods (Calf Press and Leg Press only) As eeded
Lubricate Linear Bearings (Calf Press and Leg Press only) As eeded or every 1.5 million cycles
Lubricate Guide Rods As eeded
Upholstery and grips should be cleaned with a non-ammonia based cleaner (like Simple Green) or a mild
soap and water. Guide rods should be lubricated with Teflon based lubricant. Apply the lubricant to a cotton
cloth and then apply up and down the guide rod.
Linear bearings should be lubricated with a SKF LGMT 2 grease.
3.2 Rep Counter Information
To see the accumulated reps or hours:
1) Hold a magnet to the outside of the rep counter face plate over the clock for 5 seconds to activate Service
Mode.
2) The rep counter will read r0 in the left window and the first 3 digits of the total reps in the right window
(Figure A), record this information.
3) After 3 seconds, the rep counter will switch to r1 and the next 3 digits of the total reps are shown in the right
window (Figure B). Record this information.
4) If there are further digits in the total reps, the rep counter will switch to r2. Record this information.
5) Combine the r values to determine the total reps. Using Figures A & B below, the unit would have 237,145
total reps.
6) Once the complete number of total reps has been displayed, the rep counter will flash c0 and the first 3

5
digits of the accrued hours of use are shown (Figure C).
7) After 3 seconds, if there are more digits in the accrued hours, the rep counter will switch to c1 (Figure D).
8) Combine the c values to determine the accrued hours. Using Figures C & D below, the unit would have
1,209 accrued hours.
9) Remove the magnet from the rep counter to reset to normal function.
TOTAL RESET
1) To reset all data on the rep counter, three magnets must be simultaneously held to all 3 reed switches (2 in
the stack and one in the faceplate) for 5 seconds. This clears all recorded data and cannot be recovered.
LOW BATTERY
1) When the rep counter battery gets low, the display will read Lo bAt (Figure E). At this point, the battery
needs to be replaced. This WILL NOT erase the Service Mode data.

6
CHAPTER4: PRODUCT SPECIFICATION & WARRANTY INFORMATION
G7-S34 Seated Row
TECHNICAL SPECIFICATIONS
Overall Dimensions (L x W x H 64"L x 48"W x 52H"
Weight 646 lbs.
Shipping Weight 693 lbs.
WARRANTY
Frame (not coatings 10 years
Weight Stacks 5 years
Drive sets: cam, pulley, bearing 5 years
Belt/Cable 2 years
Wear items: foam grips, cover, decal, seat pad 1 years

7
CHAPTER5: ASSEMBLYINSTRUCTIONS
G7-S34 Seated Row Assembly instructions
Unpacking the G7-S34 Seated Row
Thank you for purchasing the Matrix Fitness Systems Seated Row. This machine is an EN957-1 and E9576-2
compliant Class S product. Your Matrix Seated Row is inspected before it is packaged. It is shipped in
multiple pieces to facilitate the compact packaging of the machine. Prior to assembly, confirm all the
components by matching them with the exploded diagrams. The weight stack is shipped in separate
packaging to reduce the weight of this box. Carefully unpack the unit from this box and dispose of the packing
materials in accordance with your local laws.
CAUTION
The weight of the Matrix Fitness Systems Seated Row is 350 lbs (159 kg) not including the weight stack. The
weight stack tower is packaged completely assembled for ease of installation; use extra caution when
removing the unit from its pallet during assembly. The weight stack for this machine is 296 lbs (135 kg). To
avoid injury to yourself and prevent damage to the frame components, be sure to have proper assistance
removing the frame pieces from this box. Be sure to install the equipment on a stable base, properly level the
machine and leave at least two feet of clearance to enter and exit the machine. Maximum user weight for this
machine is 300 lbs

8
G7-S34 Seated Row Assembly instructions- Continued
Step1
Step2

9
Step3
Step4

10
Step5
Step6

11
Step7

12
CHAPTER6: Troubleshooting
6.1 Troubleshooting – repetition counter issues
THE REPETITION IS BLANK OR IS NOT COUNTING MOVEMENTS.
Possible Causes
1) The rep counter battery is dead or disconnected.
2) The rep counter is unplugged from the repetition sensors.
3) The magnet is missing or miss-positioned.
4) The repetition sensors are faulty or miss-positioned.
5) The rep counter is faulty.
Solution
1) Remove the 4 screws holding on the aluminum wing and top cover. Check that the battery for the rep
counter is firmly seated and has a charge. Replace the battery if needed.
2) Check the connection of the wiring coming from the repetition sensors to the rep counter (Figure A).
3) Check that the magnet is present and in a position to be read by the repetition sensors (Figure B). The
magnet should be slightly off the center of the sensors.
4) If the rep counter displays a value, but is not counting repetitions, check the position of the sensors. The
sensors should be positioned depending on the model according to the chart on the following page. If the
rep sensors are positioned correctly and still not reading, replace the repetition sensors (Figure C).
5) If the repetition sensors and battery have been replaced and the issue is still present, replace the rep
counter.

13
6.1 Troubleshooting – repetition counter issues - CONTINUED

14
6.2 Troubleshooting - incremental weight pin issues
INCREMENTAL WEIGHT PIN IS LOOSE OR FEELS SLOPPY
Possible causes
1) The snap ring holding the incremental weight pin in position is damaged or missing.
2) The incremental weight pin is damaged.
Solution
1) Remove the weight stack covers.
a. Remove the 4 screws holding the clear plastic cover over the incremental weight pin and remove the
clear plastic cover.
b. Check the incremental weight pin for damage, replace if needed.
2) Check if the snap ring and washer holding the incremental weight pin to the stack is in place (Fig. A & B).
a. If this snap ring is missing, install a new snap ring.
b. If the snap ring is in place, but not holding the incremental weight pin in place, it may not be properly
installed in the groove in the pin.
c. If the snap ring is in place and properly installed in the groove, but the pin is still loose, replace the
snap ring (the ring may be too stretched out to be affective).

15
6.3 Troubleshooting - arms
ARMS ARE NOT EVEN AT THE STARTING POSITION
Possible Causes
1) The arm tie rods are uneven.
2) The arms are bent or uneven.
3) The frame is bent or uneven.
Solution
1) The tie rods on the Shoulder Press, Chest Press, Lat Pull Down and Seated Row are adjustable.
a. If the arms are uneven, loosen the jam nuts and adjust the tie rods as needed to level the arms.
Tighten the jam nuts to hold the arms in place.
2) Place a level along multiple points on each arm to determine if the arms are bent or if it is the frame.
a. Replace the unit or arms as needed.

16
6.4 Troubleshooting - weight stack pin issues
WEIGHT STACK PIN WILL NOT GO INTO SOME OR ALL WEIGHT PLATES
Possible Causes
1) The weight stack pin is bent.
2) The cable is attached too loosely or too tightly.
3) The weight plates are not seated correctly at the bottom of the guide rods.
4) The top weight plate bushings are damaged.
Solution
1) Check the weight stack pin for straightness. Replace if needed.
2) Check the tightness of the cable. If the cable is too loose or too tight:
a. Remove the 4 screws holding down the aluminum wing and top cover. Detach the rep counter wire and set
aside the aluminum wing and top cover.
b. Loosen the 2 bolts holding the 2 pulleys in place at the top of the weight stack frame (Figure A). NOTE: A
short 8 mm Allen wrench may be needed for some models.
c. Rotate the 2 pulley assemblies to remove the slack from the cable, then re-tighten the 2 pulley bolts.
3) Remove the clips holding the weight stack guide rods to the top of the weight stack frame (Figure B).
a. Lean the guide rods towards the unit frame and shake back and forth so that the weight plates are seated
at the bottom of the guide rods without any gap between plates.
4) Replace the top weight plate bushings.

17
6.5 Troubleshooting - cable is failing off a pulley or cam
THE WEIGHT STACK CABLE IS FALLING OFF A PULLEY OR CAM
Possible Causes
1) The cable is too loose or too tight.
2) The cable is routed incorrectly.
3) A cable retainer needs to be added to the Hip Abductor, Hip Adductor and Leg Press (See Sections 6.6
and 6.7).
Solution
1) Check the tightness of the cable. Make sure that it is tensioned as outlined in Section 3.2.
2) Check the routing of the cable through the weight stack.
a. Make sure that the cable is not routed around a stand off in the weight stack frame (Figure A).
b. Follow the routing of the cable. The cable should be centered on pulleys and cams before being
tensioned.
3) If the unit is a Hip Abductor, Hip Adductor or Leg Press, see Sections 6.6 & 6.7 for instructions on adding a
cable retainer.

18
6.6 Troubleshooting - cable jacket is failing

19
6.7 Troubleshooting – repetition counter magnet missing or failing off
REPETITION MAGNET HAS FALLEN OFF OR IS MISSING
Possible Causes
1) The repetition counter magnet was not secured tightly enough to the repetition counter bracket.
Solution
1) Install a zip tie to securely attach the magnet to the bracket (Figure A).
2) When installing the zip tie, make sure that the head of the zip tie is on the opposite side of the bracket from
the magnet so that the head does not interfere with the movement of the top weight plate (Figure B).
6.8Troubleshooting - ROM plunger or pull pins do not move easily
ROM PLUNGER OR PULL PINS DO NOT MOVE EASILY
Possible Causes
1) The pins are rubbing on the frame creating friction.
Solution
1) Remove the affected pin, add grease (Matrix recommends SuperLube brand grease with PTFE) and then
re-install the pin.

20
6.9 Troubleshooting - seat loose or will not spring up
SEAT IS TOO LOOSE OR NOT SPRINGING UP
Possible Causes
1) The swirl springs are miss- positioned or missing from the connecting rods.
2) The swirl springs are broken in the connecting rods.
Solution
1) Remove the bottom seat connecting bars (Figures A & B) and check that the swirl springs are present
and in working order, on the bottom connection point (there should be at least 2 swirl springs for each set
of 4 connecting rods) (Figure C).
2) Re-install the seat connecting bars being careful to correctly orient the swirl springs so that they contact
the stopper bar and provide spring when the seat pad is adjusted up (Figure D).
