Matrix MAGNUM SERIES User manual

MATRIX FITNESS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
Toll Free 866.693.4863 | matrixfitness.com | Fax [phone]
PART # MH0204528B
REV. 1.3
MAGNUM SERIES
MG-PL23 SHOULDER PRESS
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
Lubricate Guide Rods † As Needed
* Upholstery & Grips should be cleaned with a mild soap and water or a non-ammonia based cleaner.
† GuiderodsshouldbelubricatedwithTeonbasedlubricant.Applythelubricanttoacottonclothandthenapply
up and down the guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Max. User Weight 159 kg / 350 lbs
Max. Training Weight 204 kg / 450 lbs
Product Weight 118 kg / 260 lbs
Overall Dimensions (L x W x H)* 162 x 160 x 119 cm / 63.5” x 63” x 46.5”
Starting Resistance 5.4 kg / 12 lbs
Weight Horn Diameter (Storage) 3.8 cm / 1.5”
Weight Horn Diameter (Working Arms) 5 cm / 1.97”
* Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around MATRIX strength
equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs.
WARRANTY
VALID IN NORTH AMERICA ONLY
Frame (not coatings) * 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Anyitemsnotspecied 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
Accessories 6 months
* Frameisdenedastheweldedmetalbaseoftheunitanddoesnotincluderemovableparts.
Productspecicationssubjecttochangewithoutnotice.
EXCLUSIVE REMEDY
The exclusive remedy for any of the above warranties shall be repair or replacement of defective
Parts, or the supply of Labor to cure any defect, per the terms of the Commercial Warranty. All
LaborshallbesuppliedbythelocalMatrixcertiedtechnician.TheProductmustbelocatedwithin
that service provider’s service area. Products located outside service area will not be covered by
the Labor warranty.
EXCLUSIONS AND LIMITATIONS
1. This warranty applies only to the original owner and is not transferable.
2. Under no circumstances will MATRIX FITNESS be liable by virtue of this warranty or otherwise
for damage to any person or property whatsoever for any special, indirect, incidental, secondary
or consequential losses, damages or expenses in connection with exercise products.
3. This warranty is expressly limited to the repair or replacement of a defective Frame or Part.
Repair or replacement will be at the discretion of MATRIX FITNESS, and is the sole remedy of
the warranty.
4. Do not use equipment in any location that is not climate controlled, such as but not limited to
garages, porches, pool rooms, saunas, bathrooms, car ports or outdoors. Failure to comply
may void the warranty.
5. This warranty does not cover normal wear and tear – including but not limited to: cuts in
upholstery, damage caused externally that is not due to a manufacturer defect, improper
assembly or maintenance, or installation of parts or accessories not originally intended or
compatible with the MATRIX FITNESS Product as sold.
6. This warranty does not cover damage or failure due to accident, abuse, corrosion, discoloration
ofpaintorplastic,neglect,theft,vandalism,re,ood,wind,lightning,freezing,orothernatural
disastersofanykind,powerreduction,uctuationorfailurefromwhatevercause,unusual
atmosphericconditions,collision,introductionofforeignobjectsintothecoveredunit,or
modicationsthatareunauthorizedornotrecommendedbyMATRIXFITNESS.
7. Parts reconditioned to As New Condition by MATRIX FITNESS or its vendors may sometimes
besuppliedaswarrantyreplacementpartsandconstitutefulllmentofwarrantyterms.Any
warranty replacement parts shall be warranted for the remainder of the original warranty term.
This warranty shall NOT apply to the following:
1. Failure to provide reasonable and necessary maintenance as outlined in the Owner’s Manual.
2. Software limitations and upgrades.
3. Batteries or other consumable goods.
4. Cosmetic items.
5. Repairs performed on equipment missing a serial number or with a serial number tag that has
been altered or removed.
6. Service calls to correct installation of the equipment or instructing on use of equipment.
7. Pick-up, delivery or freight charges involved with repairs.
8. Any labor charges incurred beyond the applicable labor warranty.
MATRIX FITNESS expressly disclaims all other warranties, express or implied, including but not
limitedtoallwarrantiesoftnessforaparticularpurposeorofmerchantability.Thiswarrantygives
youspeciclegalrights,andyourrightsmayvaryfromstatetostate.
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX products to instruct all individuals, whether they are the end user or
supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX exercise equipment be informed of the following information prior to its use.
Do not use any equipment in any way other than designed or intended by the manufacturer.
ItisimperativethatMATRIXequipmentbeusedproperlytoavoidinjury.
INSTALLATION
1. STABLE AND LEVEL SURFACE: MATRIX exercise equipment must be installed on a stable base and properly
leveled.
2. SECURING EQUIPMENT: Manufacturer recommends that all stationary MATRIX strength equipment be secured to
theoortostabilizeequipmentandeliminaterockingortippingover.Thismustbeperformedbyalicensedcontractor.
• All anchor points must be able to withstand 750 lbs. (3.3 kN) pull-out force.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
your country’s local MATRIX dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information. If
unreadable or missing, contact your MATRIX dealer for a replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping
your liability to a minimum. Equipment needs to be inspected at regular intervals.
4. Ensurethatanyperson(s)makingadjustmentsorperformingmaintenanceorrepairofanykindisqualiedtodoso.
MATRIX dealers will provide service and maintenance training at our corporate facility upon request.
ADDITIONAL NOTES
Thisequipmentshouldonlybeusedinsupervisedareaswhereaccessandcontrolisspecicallyregulatedbytheowner.
It is up to the owner to determine who is allowed access to this training equipment. The owner should consider a user’s:
degree of reliability, age, experience, etc.
This training equipment meets industry standards for stability when used for its intended purpose in accordance with the
instructions provided by the manufacturer.
This equipment is for indoor use only. This training equipment is a Class S product (designed for use in a commercial
environmentsuchasatnessfacility).ThistrainingequipmentisincompliancewithENISO20957-1andEN957-2.
PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. Ifapplicable,adjustseatpads,legpads,footpads,rangeofmotionadjustment,oranyothertypeofadjustment
mechanismstoacomfortablestartposition.Makecertainthattheadjustingmechanismisfullyengagedtoprevent
unintentionalmovementandtoavoidinjury.
4. Sit on bench (if applicable) and get into appropriate position for exercise.
5. Exercise using no more weight than you can safely lift and control.
6. In a controlled manner, perform exercise.
7. Return weight to its fully-supported start position.
WARNING
Plate-loaded / Free Weight
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS
EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID
INJURY!
1. Keep children under the age of 14 away from this
strength training equipment. Teenagers must be
supervised at all times while using this
equipment.
2. This equipment is not intended for use by persons
with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the equipment by a
person responsible for their safety.
3. All warnings and instructions should be read and
proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
4. Inspect the machine before use. DO NOT use
machine if it appears damaged or inoperable.
5. Do not exceed weight capacity of this equipment.
6. ALWAYS use a spotter if using free weights.
7. Balance the weight applied to this equipment
and/or any barbell. Where applicable, use
retention devices to retain weight discs.
8. Injuries to health may result from incorrect or
excessive training. Cease exercise if you feel faint
or dizzy. Obtain a medical exam before beginning
an exercise program.
9. Keep body, clothing, hair, and fitness accessories
free and clear of all moving parts.
10. Adjustable stops, where provided, must be used
at all times.
11. When adjusting any adjustable mechanism (stop
position, seat position, pad location, range of
motion limiter, pulley carriage, or any other type),
make certain that the adjustable mechanism is fully
engaged prior to use to prevent unintended motion.
12. Manufacturer recommends that this equipment be
secured to the floor to stabilize and eliminate
rocking or tipping over. Use a licensed contractor.
13. If equipment is NOT secured to floor: NEVER allow
resistance straps, ropes or other means to be
attached to this equipment, as this may result in
serious injury. NEVER use this equipment for
support during stretching, as this may result in
serious injury.
14. DO NOT REMOVE THIS LABEL. REPLACE IF
DAMAGED OR ILLEGIBLE.
MX15_MAGNUM_OM_MG-PL23 shoulder press_r1_3.indd 1 4/20/15 10:22 AM

MAGNUM SERIES (MG-PL23) SHOULDER PRESS
UNPACKING (MG-PL23) SHOULDER PRESS
Thank you for purchasing a MATRIX Fitness product. Your MAGNUM SERIES (MG-PL23) SHOULDER PRESS is inspected before it is packaged. It is shipped in
multiplepiecestofacilitatethecompactpackagingofthemachine.Priortoassembly,conrmallthecomponentsbymatchingthemwiththeexplodeddiagrams.
Carefully unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
Toavoidinjurytoyourselfandpreventdamagetotheframecomponents,besuretohaveproperassistanceremovingtheframepiecesfromthisbox.Pleasebe
sure to install the equipment on a stable base and properly level the machine. Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage
around MATRIX strength equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs.
TOOLS REQUIRED FOR ASSEMBLY (NOT INCLUDED)
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench Phillips Screwdriver
5MM L-Shaped Allen Wrench 8MM Open-End Wrench
6MM L-Shaped Allen Wrench 17MM Open-End Wrench
8MM L-Shaped Allen Wrench Guide Rod Lubrication
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Step 1 Frame Detail
Item
Z01
Z06
Z07
Z02
Z11
Description
Screw (M10x25L)
Washer;Arc (Ø10)
Washer;SPL (Ø10)
Flat Washer (Ø10)
Screw (M10x80L)
Qty
20
2
20
20
2
2xZ06
20xZ01
20xZ07
2xZ11
20xZ02
Step 2 Frame Detail
Item
D26
Z07
D27
Z04
Description
Screw (M10x20L)
Washer;SPL (Ø10)
Flat Washer
(Ø10.2XØ28.5)
Screw (M8x25L)
Qty
2
2
2
4
2xD26
2xZ07
2xD27
4xZ04
Step 3 Frame Detail
Item
Z03
Description
Screw (M10x35L)
Qty
7
7xZ04
Shoulder
Press
Shoulder
Press
11
22
PL23 Shoulder Press
Rev 1.1
July, 2014
Die lines. Do not print.
Black
Pantone 4715C
Pantone 719C
Pantone 1795C
Pantone 7409C
Pantone 7461C
Blacks
100%
80%
60%
20%
Size:
80 x 180 mm
3.1 x 7.1 in
Pantones
– Process Black C
– Cool Gray 11C
– Cool Gray 8C
– Cool Gray 2C
PLACARD
PL23
TRAINING
AREA
FREE AREA
0.6 M(2 FT)
WIDE PATH
1.6 M
(63”)
2.21 M
(87”)
FOOTPRINT AREA
