OWNERS MANUAL
Versa Single-Station Strength
VS-S33 Lat Pulldown

Table Of Contents
Safety, General Care & Maintenence .................................................3
Getting Started (Product Specifications)..........................................5
Assembly Information ..........................................................................6
Parts List ................................................................................................7
Markings .................................................................................................8
Installation & Assembly: Value Line
Part 1 Weight Stack To User Frame Assembly............................... 10
Part 2 Thigh Pad Assembly................................................................11
Part 3 Arm Assembly......................................................................... 12
Part 4 Cable Assembly....................................................................... 13
Part 5 Counter Weight Assembly ..................................................... 16
Part 6 Pad Assembly.......................................................................... 17
Part 7 Plastics Assembly................................................................... 18
Part 8 Cable Adjustment.................................................................... 21
Installation & Assembly: Optional Kits
Part 9 Premium Kit Assembly.......................................................... 22

3
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of Matrix products to instruct all individuals, whether they are the end user or supervis-
ing personnel on proper usage of the equipment.
It is recommended that all users of Matrix exercise equipment be informed of the following information prior to its use.
PROPER USAGE
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that Matrix equipment
be used properly to avoid injury.
Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by your
country’s local Matrix dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your Matrix dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over. This
must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping your li-
ability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
Matrix dealers will provide service and maintenance training at our corporate facility upon request.

4
IMPORTANT SAFETY INSTRUCTIONS
WARNING: This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW
THESE PRECAUTIONS TO AVOID INJURY!
1. Never allow children on strength training equipment. Teenagers must be supervised at all times while using this
equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use.
3. Use this equipment for its intended purposes only.
4. NEVER allow resistance straps, ropes or other means be attached to this equipment, as this may result in serious
injury.
5. NEVER use this equipment for support during stretching, as this may result in serious injury.
6. Cease exercise if you feel faint or dizzy. Obtain a medical exam before beginning an exercise program.
7. Keep body, hair, clothing and accessories free and clear of all moving parts.
8. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
9. Check to see that the selector pin is completely inserted into the weight stack.
10. NEVER use this machine with the weight stack pinned in an elevated position.
11. NEVER use dumbells or other means to incrementally increase the weight resistance. Only use the means provided
directly from the manufacturer.
12. This equipment should only be used in supervised areas where access and control are regulated by the owner.

5
GETTING STARTED
TECH SPECS
Overall dimensions 61”L X 48”W X 66”H
Weight Light Stack = 642 lbs (292 kg), Heavy Stack = 729 lbs (331
kg)
Shipping weight 407 lbs (185 kg)
WARRANTY (Valid in USA only)
Frame (not coatings) 10 years
Structural parts 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
ACTION FREQUENCY
Clean Upholstery Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips As Needed
Lubricate Guide Rods As Needed
Upholstery & Grips should be cleaned with a non-ammonia based cleaner or a mild soap and water. Guide rods should be
lubricated with Teflon based lubricant. Apply the lubricant to a cotton cloth and then apply up and down the guide rods.
MAINTENANCE CHECKLIST
EXERCISE PLACARD | PRODUCT SPECIFICATIONS | MAINTENANCE CHECKLIST
PRODUCT SPECIFICATIONS
EXERCISE PLACARD

6
ASSEMBLY
UNPACKING | TOOLS REQUIRED
UNPACKING
Thank you for purchasing a Matrix product. This machine is an EN957-1 and EN957-2 compliant Class S product. Your Ma-
trix product is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the
machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams. Carefully unpack
the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the product is 407 lbs. (185 kg) not including the weight stack. The standard weight stack for this machine
is 235 lbs. (107 kg) & the heavy stack is 322 lbs. (147kg) (Labeled 160 lbs./73 kg & 230 lbs./105 kg respectively). To avoid
injury to yourself and prevent damage to the frame components, be sure to have proper assistance removing the frame
pieces from this box. Please be sure to install the equipment on a stable base, properly level the machine and leave at least
two feet of clearance to enter and exit the machine. Maximum user weight for this machine is 300 lbs.
TOOLS REQUIRED FOR ASSEMBLY
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
Phillips & Standard Screwdrivers
8MM Open-End Wrench
13MM Open-End Wrench
17MM Open-End Wrench.
19MM Open-End Wrench
Adjustable Wrench
Blue Locktite 242 must be used on all fasteners that are not assembled with Nylock Nuts

7
MARKINGS
WARNING LABEL LOCATIONS

8
Parts List
ID DESCRIPTION QTY
1 User Frame 1
2 Weight Stack Frame 1
3 M10 X 105L SHC 2
4 Narrow Cupped Flange 1
5 M10 Flat Washer 14
6 M10 Nylock Nut 4
7 Upper Connecting Tube 1
8 M10 X 20L SHC 6
9 M10 X 125L SHC 2
10 Wide Cupped Flange 1
11 Lower Connecting Tube 1
12 Thigh Pad Assembly 1
13 Pullpin Assembly 1
14 M8 X 150L SHC 1
15 Axle 1
16 M8 Flat Washer 6
17 M8 Nylock Nut 1
18 Large Flat Washer (Ø40 mm) 2
19 Belleville Washer 2
20 Right Arm Assembly 1
21 M10 X 25L SHC 2
22 Left Arm Assembly 1
23 M12 X 25L Socket Head Cap Screw 2
24 M12 Flat Washer 2
25 Weight Stack to User Frame Cable 1
26 User frame Cable 1
27 Counter Weight 2
28 M8 X 20L Socket Head Cap Screw 4
29 M10 X 20L Hex Bolt 4
30 Pad 1
31 Front Shroud 1
32 Rear Shroud 1
33 M8 X 25L Socket Head Cap Screw 4
34 M8 Flat Washer (Ø20 mm) 4
35 Top Cap 1
36 Top Cap Covers 2

9
ID DESCRIPTION QTY
OPTIONAL PREMIUM KIT COMPONENTS
1P Wing 1
2P Rep Counter 1
3P Towel Hook 1
4P ASG Pull Grip 2
5P Premium Pullpin 1
Parts List

10
8
11
1
7
10
6
9
5
2
4
3
ASSEMBLY
PART 1: WEIGHT STACK TO FRAME ASSEMBLY
STEP 1 | WEIGHT STACK FRAME INSTRUCTIONS & NOTES
Machine must be assembled on a flat and level floor.
Install the user frame hardware as shown, BUT DO NOT FULLY TIGHTEN.
ID DESCRIPTION QUANTITY
1 User Frame 1
2 Weight Stack Frame 1
3 M10 X 105L SHC 2
4 Narrow Cupped Flange 1
5 M10 Flat Washer 14
6 M10 Nylock Nut 4
7 Upper Connecting Tube 1
8 M10 X 20L SHC 6
9 M10 X 125L SHC 2
10 Wide Cupped Flange 1
11 Lower Connecting Tube 1

11
ASSEMBLY
STEP 1 | THIGH PAD ASSEMBLY INSTRUCTIONS & NOTES
PART 2: THIGH PAD ASSEMBLY
14
13
15
16
17
12
Install the thigh pad and pullpin assemblies as shown.
Tighten item 14 to 39 N-m/29 ft-lbs.
ID DESCRIPTION QUANTITY
12 Thigh Pad Assembly 1
13 Pullpin Assembly 1
14 M8 X 150L SHC 1
15 Axle 1
16 M8 Flat Washer 2
17 M8 Nylock Nut 1

12
ASSEMBLY
STEP 1 | RIGHT AND LEFT ARM ASSEMBLY INSTRUCTIONS & NOTES
PART 3: ARM ASSEMBLY
Install the user frame hardware as shown, but DO NOT FULLY TIGHTEN.
Belleville washer item 19 must be assembled with inner (convex) diameter contacting the bearing.
The outer diameter and concave side of Belleville washer contacts the outer washer item 18.
24
23
20
21
19
18
ID DESCRIPTION QUANTITY
18 40mm Diameter Washer 2
19 Belleville (Spring) Washer 2
20 Right Arm Assembly 1
21 M10 X 25L SHC 2
22 Left Arm Assembly (Not Shown) 1
23 M12 X 25L SHC 2
24 M12 Flat Washer 2

13
PART 4: CABLE ASSEMBLY
STEP 1 | WEIGHT STACK CABLE ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANTITY
25 Weight Stack To User Frame Cable 1
ASSEMBLY
25
25
Cable Keeper must be positioned as shown

14
PART 4: CABLE ASSEMBLY
STEP 2 | USER FRAME CABLE ASSEMBLY INSTRUCTIONS & NOTES
ASSEMBLY
ID DESCRIPTION QUANTITY
26 User Frame Cable 1
Cable tension is adjusted by raising or lowering pulley as shown in View A.
Note: Nuts for adjustable pulley must be on inside towards weight plates.
26
26

15
ASSEMBLY
STEP 3 | CABLE END ASSEMBLY INSTRUCTIONS & NOTES
PART 4: CABLE ASSEMBLY
26
Torque all M10 Frame Hardware on pages 10 through 15 to: 77 N-m/57 ft/lbs.

16
ASSEMBLY
STEP 1 | COUNTER WEIGHT ASSEMBLY INSTRUCTIONS & NOTES
PART 5: COUNTER WEIGHT ASSEMBLY
ID DESCRIPTION QUANTITY
16 M8 Flat Washer 4
27 Counter Weight 2
28 M8 X 20L SHC 4
Install the counter weights as shown.
Tighten to 39 N-m/29 ft-lbs.
27
16
28

17
STEP 1 | PAD ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANTITY
29 M10 X 20L Hex Bolt 4
30 Pad 1
Install the pad as shown.
Tighten to 57 N-m/41 ft-lbs.
ASSEMBLY
PART 6: PAD ASSEMBLY
29
30

18
STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 7: PLASTICS ASSEMBLY
ID DESCRIPTION QUANTITY
31 Front Shroud 1
32 Rear Shroud (Not shown) 1
ASSEMBLY
Install the weight stack shrouds as shown.
31
Position hangers in their lowest position

19
STEP 2 | TOP CAP ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANTITY
33 M8 X 25L SHC 4
34 M8 Flat Washer (20 mm diameter) 4
35 Top Cap 1
34
33
34
33
35
35
ASSEMBLY
PART 7: PLASTICS ASSEMBLY
Install the top cap onto the weight stack as shown.
Torque to 17 N-m/147 in-lbs.
Position top cap so that the instructional placard faces the user.

20
STEP 3 | TOP CAP COVERS INSTRUCTIONS & NOTES
ID DESCRIPTION QUANTITY
36 Top Cap Cover 2
36
36
ASSEMBLY
PART 7: PLASTICS ASSEMBLY
Install the top cap covers.
